AmazonBasics B01LZAV8KH Manuel utilisateur

3-Shelf Shelving Unit on Wheels - Chrome

Unité De Rayonnage à 3 Étagères Montée Sur Des Roues - Chromée

Regal auf Rollen mit 3 Regalböden - Verchromt

Scaffale a 3 Ripiani Su Ruote - Cromato

Módulo De 3 Estantes Con Ruedas - Cromo

3段キャスター付きシェルフユニット、クローム

3层滚轮置物架 - 铬合金

B01LZAV8KH

English Français Deutsch Italiano Español 日本語中文

English ........................................... 3

Français ....................................... 15

Deutsch........................................ 27

Italiano ......................................... 39

Español ........................................ 51

日本語 ........................................... 63

中文 .............................................. 75

English Français Deutsch Italiano Español 日本語中文

3-Shelf Shelving Unit on

Wheels - Chrome

Contents:

Make sure that the package contains the following parts:

Part Qty.

TOP

Note: Discard the protective covers

. These are used to separate the shelves for

shipping purposes.

Welcome Guide •English

English Français Deutsch Italiano Español 日本語中文

Assembly

Step 1:

Setting Up the Product

TOP

H H

•Remove the protective covers

from the shelves

and dispose of them.

•Screw one wheel

into the bottom of each lower pole

and fasten it

using the wrench

. Position them as shown in the illustration.

•Attach one half of the plastic sleeve

to each lower pole. Then attach the other

half of the plastic sleeve to each lower pole, so both halves are connected with

each other. The arrow above the TOP marks on the plastic sleeves should point

upwards. Four plastic sleeves are necessary to support one shelf.

•If preferred,leveling feet can be used instead of wheel for a static shelving unit.

Remove all items from shelving units and disassemble shelving unit before switching

between wheel and leveling feet.

English Français Deutsch Italiano Español 日本語中文

Assembly

Step 2:

Setting Up the Product

Brakes engaged

Brakes not engaged

•Put the ﬁrst shelf

onto the poles

and lower it down until it rests on the

plastic sleeves

. Note:Poles connected to wheel with brakes should be

placed at the back, poles connected to wheel without brakes should be

placed at the front of the assembly (as shown above).

•Attach another set of plastic sleeves to each lower pole for the second shelf

from the bottom.

English Français Deutsch Italiano Español 日本語中文

Assembly

Step 3:

Setting Up the Product

•Put the next shelf

onto the poles

and lower it down until it rests on the

plastic sleeves

English Français Deutsch Italiano Español 日本語中文

Assembly

Step 4:

Setting Up the Product

•Screw the upper poles

onto the lower poles

in a clockwise direction.

English Français Deutsch Italiano Español 日本語中文

Assembly

Step 5:

Setting Up the Product

•Attach one set of plastic sleeves Eto the upper poles

Put the last shelf Aonto the poles

and lower it down until it rests on the

plastic sleeves E.

•

Cleaning and Maintenance

•Wipe with a dry cloth as needed to remove dust and dirt.

•Avoid contact with corrosive substances like acids, alkaline or similar

substances.

Safety and Compliance

•Warning: Do not let children climb on or play with the unit.

•Handle with care.

•For ease and efﬁciency, the product should be assembled by two adults.

•Regularly check if all screw connections are tight and if all shelves are attached

in a stable way.

•To avoid scratching the ﬂoor, assemble the shelving unit on a soft surface such

as a carpet.

•Warning: Make sure not to drill into water or electricity lines when securing the

shelving unit on the wall.

Use a wire tracer and/or a water pipe ﬁnder if necessary.

•Load the unit evenly and place the heaviest items on the lower shelves.

Maximum Load US Standard Metric

Shelving unit with wheel Static 220 lbs 100 kg

In motion 150 lbs 68 kg

One single shelf with wheel 73 lbs 33 kg

Shelving unit with leveling feet Static 750 lbs 340 kg

Static 250 lbs 113.6 kgOne single shelf with leveling feet

English Français Deutsch Italiano Español 日本語中文

Warranty Information

To obtain a copy of the warranty for this product:

Visit amazon.com/AmazonBasics/Warranty

— or —

Contact Customer Service at

1-866-216-1072
