Alpha RE201 Series Manuel utilisateur
WALL MOUNT RE 1201, RE202, RE203 p
I 222nstruction guide for RE 01, RE 02, RE 03 series wall mount remotes
1. PRODUCT APPEARANCE
3. CODE LEARNING (Note: Please do not perform code learning in group control mode.)
2. TECHNICAL DATA
Choose one channel, short press the learning button
on the back, now code learning is successful. Choose
another channel to learn code in the same way.
learning button
learning button
The figure on upper left corner of the screen
shows the current channel. Short press K1/K3
to choose any channel from 1 to 8.
Short press STOP button of Channel A once, then Short press learning button
(on the back) once within 10 seconds, code learning for channel A is successful.
This method is suitable for Channel B code learning.
RE201 single channel RE20 channel3-4C 4
RE20 channel3-16C 16 RE20 channel timer3-1T single RE20 channel timer3-4T 4 RE20 channel timer2 2
RE20 channel3-8C 8 back
•C ≤1urrency: 2mA
• Code: Rolling Code
• Frequency: 433.92MHz
• Powe V Model: CR2032r: 3
• Working Temperature: -10 to +60 LCD )℃℃( remote
• Working Temperature: -20 to +60℃℃(Non CD )- L remote
01. single-channel
Short press the learning button on the back, the code learning is successful.
02. LCD multi-channel (take 8 channel as an example)remote
03. Two channel : channel A & channel B control 2 receivers respectively without interference.remote
1. wall mount
2. panel
ALPHA SUPPORT PHONE (02) 4355 4775
WALL MOUNT RE 2201, RE202, RE203 p
I 222nstruction guide for RE 01, RE 02, RE 03 series wall mount remotes
4. SINGLE CONTROL
5. GROUP CONTROL (LCD)
6. DELETE GROUP CONTROL
7. LCD FOUR CHANNEL TIMER REMOTE
Select a channel by pressing K1/K3 as the current channel, then you can control this channel by pressing a UP/STOP/DOWN button.
01.Time ettingS
03. iming FunctionClose T
In the initial page, press K2 to enter timing setting page, there is a timing clock on the upper left corner.
You can respectively set 8 opening time points and 8 closing time points, in total 16 points.
Press K2 to cycle among 16 time points. Press K3 to choose the output channels which you want (single channel or 4 channels)
02.Timin ettingg S (se ifferent time points to make the motor close or open)t d
18
~
Short press K1/K3 to choose channels
into your group, for example channel
8 as the picture shows.
Short press K1/K3 to choose channels
out 6your group, for example channel
as the picture shows.
Once the hour setting is finished, press
K1 again to adjust minute, the minute
figure will shine. Press UP/DOWN button
to adjust the figure.
Press K2 again to select one point
among 16 timing points.
Press K2 again to select one point
that needs to be closed.
Press STOP button to exit the setting.
Short press K2 to confirm, same method
for other channels.
Short press K2 to confirm, same method
for other channels.
Once the minute setting is finished, press
K1 again to adjust weekday, the weekday
figure will shine. Press UP/DOWN button
to adjust the weekday.
Press K3 to choose your wanted channel
(single channel or 4 channels).
Press K3 until above display appears,
which means the point has closed.
Press K3 again to retrieve this point.
Press UP/STOP/DOWN buttons
to exit the setting.
Press UP/STOP/DOWN buttons
to exit the setting.
After setting, press STOP button to
exit and go back to the initial page.
Press K1 to set time (in the same
way of Time Setting above).
After setting, press STOP button to
exit and go back to the initial page.
Long press K2 for 2 to enter Group Control,s
the current channel on the upper left corner
of the screen will shine.
Long press K2 for 2 to enter Group Controls
the current channel on the upper leftstate,
corner of the screen will shine.
Press K1 button to enter hour setting
page, now the hour figure will shine.
Press UP/DOWN button to adjust
the hour figure.
Press K2 to enter timing setting page.
Press K2 to enter timing setting page.
After one time point is set, press K2 again
to select other time points to set time.
M
Short press K2 button to choose group contro r ingle controll o s S
Note: inwhether or mode, the current channel is always selected.
MS
ALPHA SUPPORT PHONE (02) 4355 4775
WALL MOUNT RE 3201, RE202, RE203 p
I 222nstruction guide for RE 01, RE 02, RE 03 series wall mount remotes
8. LCD TIMER (1 CHANNEL)REMOTE
01. Time Setting
0. Timin3 Close Functiong
0.4 Stop Watch Function
In the initial page, press K2 to enter timing setting page, there is a timing clock on the upper left corner. You can respectively set 8 opening time points
and 8 closing time points, in total 16 points. Press K2 to cycle among 16 time points.
02. Timin ettingg S
18
~
Note:
1. The must enter timing setting page if you want to set timing points. There should be aremote
timing clock on the upper left corner, otherwise, the setting is invalid. If there is no clock on
the screen, please hold STOP button and press K2 within 10 seconds, there will be a clock on
the upper left corner.
2. It is better not to press the ’s buttons too long so as to prolong the battery’s life. Theremote
button press should be about 0.5s with 1s interval.
3. The will stop working if the battery is in low power. Please replace the battery.remote
Once the hour setting is finished, press
K1 again to adjust minute, the minute
figure will shine. Press UP/DOWN
button to adjust minute figure.
Press K2 again to select one point
among 16 timing points.
Press K2 again to select one point
that needs to be closed.
If you want to exit from Stopwatch page,
press K3 again to go back to the initial page.
Once the minute setting is finished, press
K1 again to adjust weekday, the weekday
figure will shine. Press UP/DOWN button
to adjust weekday.
Press K3 to enter time setting page,
then press K1 to set the time points
in the same way as above time setting.
Press K3 once to delete the point.
Press K3 again to retrieve this point.
After setting, press STOP button
to exit and go back to the
initial page.
Once one time point is set, press K2
again to select other time points to
set time. When setting finished,
press STOP to exit.
After setting, press STOP button to
exit and go back to the initial page.
Press K1 button to enter hour setting
page, now the hour figure will shine.
Press UP/DOWN button to adjust
hour figure.
Press K2 to enter timing setting page.
Press K2 to enter timing setting page.
In the initial page, press K3 to enter
Stopwatch page.
ALPHA SUPPORT PHONE (02) 4355 4775
Alpha Tubular Motors Pty Ltd
Unit 108, 12 Pioneer Avenue
Tuggerah NSW 2259 Australia
sales@alphamotors.com.au
alphamotors.com.auwww.
+61 2 4355 4775T
