ALL168250 QIG

www.allnet.de

ALL168250

500 Mbps PLC Ethernet Bridge

QUICK INSTALLATION GUIDE

ALL168250 QIG

www.allnet.de

PREFACE

This document describes installation of the 500Mbps PLC Ethernet Bridge Network products.

Please read this document before installing the product.

TO THE INSTALLER

This publication contains the following sections:

Important safety instructions

The first thing you need to know before you begin to install

Product installation guide

Specification

ALL168250 QIG

www.allnet.de

IMPORTANT SAFETY INSTRUCTIONS

This product is intended for connection to the AC power line. For installation instructions, refer to the

Installation section. For removing the device, refer to the Unplug section. The following precautions should be

taken when using this product.

Please read all instructions before installing and operating this product.

Please keep all instructions for later reference.

Please follow all warnings and instructions marked on the product.

Unplug the AC coupler from the wall outlet before cleaning. Use a damp cloth for cleaning.

DO NOT use liquid cleaners or aerosol cleaners.

DO NOT operate this product near water.

The opening of enclosure near AC plug to face up or frontal, the connector face bottom or rear.

This product should never be placed near or over a radiator, or heat register.

This product relies on the building’s electrical installation for short-circuit (over current) protection.

Ensure that a fuse or circuit breaker no larger than 120 VAC 20A or 240 VAC 16A is used on the

phase conductors (all current-carrying conductors).

DO NOT allow anything to rest on the product interconnect cords.

DO NOT locate this product where people may walk on the cords.

Because the 200Mbps PLC Ethernet Bridge product sends data over the powerline, it is recommended

that you plug directly into a power outlet. Do not plug the device into a UPS or power strip with surge

protection. The 200Mbps PLC Ethernet Bridge product has its own power filter for protection against surges.

The product can be operated at an ambient temperature of 40℃.

For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily

accessible.

Only a qualified technician should service this product. Opening or removing covers may result in

exposure to dangerous voltage points or other risks.

Unplug the AC coupler from the wall outlet and refer the product to qualified service personnel for the

following conditions:

When the interconnect cords are damaged or frayed.

If liquid has been spilled into the product.

If the product has been exposed to rain or water.

If the product does not operate normally when the operating instructions are followed.

If the product exhibits a distinct change in performance.

ALL168250 QIG

www.allnet.de

THE FIRST THING YOU NEED TO KNOW BEFORE YOU BEGIN TO INSTALL…

1. Before installing, make sure your PC meets these requirements for hardware installation:

Microsoft Windows® 98SE, ME, 2000, XP, Vista, Windows 7, Mac OS or linux OS

Pentium® III or better, clock rate faster than 2.0GHz recommended

At least one free Ethernet port for ALL168250 500Mbps PLC-Ethernet Bridge

2. Your PC must not be configured for another network. This means that:

No network clients except for Microsoft Network*, Client for Netware* Networks, or Microsoft

Family Logon* are installed

No network services except file and printer sharing for Microsoft Networks or Personal Web

Server* are installed

No network protocols except Microsoft’s TCP/IP, IPX/SPX, NetBEUI, or Net BIOS support for

IPX/SPX are installed

3. Network installation requires two steps:

1. Install the 500Mbps PLC Ethernet Bridge

2. For each PC to be added to the network, repeat the process

4. Check that you have the following parts for each PC on the network:

Product installation guide for ALL168250 500Mbps PLC-Ethernet Bridge:

1. ALL168250 500Mbps PLC Ethernet Bridge

2. Ethernet Cable (CAT 5)

5. Familiarize yourself with the Powerline device connections:

There is only one Ethernet port. This is used for the connection with PC, xDSL/Router, Cable Modem, or

Wireless AP.

6. Limitation of the PLC device:

To meet the safety regulation, the longest distance between powerline carrier devices will be limited at

200 meter and for in-house use only. More than 200 meter will cause the signal reduction or data loss.

ALL168250 QIG

www.allnet.de

Product installation guide

Important:

Do not plug the device into a power strip or surge protector because these devices may

consist of filter and impair signal. Also avoid plugging the device right next to noisy

sources such as cell phone charger, Halogen light, Energy saving bulb, noisy desktop

computer, vacuum cleaner, etc. Both cases result in poor transmission speed.

To install for the PC local Powerline network

1. Use the supplied Category 5 Ethernet cable to connect Ethernet Bridge and your PC’s Ethernet port.

2. Plug the Ethernet Bridge to outlet.

3. The PWR LED indicator will light on after plugging.

4. You can repeat steps 1 and 2 for connecting the others.

5. The PL-ACT LED indicator starts blinking when the data communication proceeds on Powerline.

6. The ETH-ACT LED indicator starts blinking when the data communication proceeds on Ethernet.

To share a xDSL or cable modem with Internet access service

1. Connect one Ethernet Bridge to the broadband router

Plug the Ethernet Bridge into an AC outlet.

Plug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of

the cable into an available Ethernet port of the Router.

2. Connect the other Ethernet Bridge(s) to the PC(s) to share the Internet access

Plug the Bridge into an AC outlet.

Plug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end

of the cable into Ethernet port on the PC.

As wireless AP (Access Point) Extender

1. Connect one Ethernet Bridge to the broadband router

Plug the Bridge into an AC outlet.

Plug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of

the cable into an available Ethernet port of the broadband router.

2. Connect the other Ethernet Bridge to the wireless AP

Plug the Bridge into an AC outlet.

Plug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end

of the cable into the Ethernet port on the wireless AP.

ALL168250 QIG

www.allnet.de

Specification

Items

Description

PHY Rate

500Mbps (IEEE 1901 and HomePlug® AV compliant)

Effect Data Rate

TCP: Up to 97 Mbps effective throughput

UDP: Up to 97 Mbps effective throughput

Frequency Band

2~68 MHz (With Mask)

Access Methods

priority-based CSMA/CA channel access schemes maximize efficiency and

throughput

Qos

–Integrated Quality of Service (QoS) Enhancements

–Hardware Packet Classifiers for ToS, CoS and IP Port Number

–Supports IGMP managed multicast sessions

Modulation

OFDM (QAM 8/16/64/256/1024/4096, QPSK, BPSK, ROBO)

Standards

IEEE 802.3, IEEE 802.3U, HomePlug AV Protocol Compliance with

HomePlug 1.0 coexistence capability

Microsoft Windows® 2000, XP, Vista ,Windows 7 (for utility-program only)

Nodes

Up to 8 total devices

IGMP

IGMP Supports IGMP managed multicast sessions

Encryption

128-bit AES Link Encryption with key management

Port

One 10/100 Mpbs Ethernet port

Distance

AC Wire : 200 meters

LEDs

PWR (Red) PLC(Green/Orange/Red throughput indicator) ETH (Green)

Push Button

NID/RST Button

Environment

Temperature

Operating : 0~40 ℃

Storage : -20~60 ℃

Relative Humidity

Operating : 10~85% Non-Condensing

Storage : 5~90% Non-Condensing

Power Source

100 ~ 240 VAC 50/60Hz

Power

Consumption

4W Max (Normal mode) Below 0,5W (Standby mode)

Certification

ALL168250 QIG

www.allnet.de

LEDs

PWR

(Red)

On: Power on

Blinking: Standby mode (*1)

Off: Power off

PLC

(Green/Orange/Red)

On: Powerline Link detected and no traffic

Blinking: Powerline traffic detected

Green: The Powerline connection quality is good

Orange: The Powerline connection quality is fair

Red: The Powerline connection quality is bad

Off: No Powerline Link detected

ETH

(Green)

On: Ethernet Link detected

Blinking: Ethernet traffic detected

Off: No Ethernet Link detected

*1 : The “PWR“ LED indicator will blink in standby mode. It will automatically get into standby mode, if the

Ethernet-link is lost for 60 seconds. If you unplug the Ethernet cable, it will get into standby mode after 60

seconds. Under standby mode, PLC and ETH LEDs will both be off.

ALL168250 QIG

www.allnet.de

No part of this document may be reproduced, republished, or retransmitted in any form or by any means

whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying,

recording, information recording, or through retrieval systems without the express written permission of the

owner. Product specifications contained in this document are subject to change without notice. All other

company or product names mentioned are used for identification purposes only and may be trademarks of

their respective owners.

Manufacturer:

ALLNET GmbH

ALLNET Deutschland GmbH

Maistrasse 2

82110 Germering

Tel. +49 89 894 222 22

Fax +49 89 894 222 33

E-Mail: [email protected]

ALL168250 QIG

www.allnet.de

CE-Declaration of Conformity Germering, February 10, 2012

For the following equipment:

500 Mbps PLC Ethernet Bridge

ALL168250

The safety advice in the documentation accompanying the products shall be obeyed.

The conformity to the above directive is indicated by the CE sign on the device.

The ALLNET ALL168250 conforms to the Council Directives of 2004/108/EC EMC.

This equipment meets the following conformance standards:

This equipment is intended to be operated in all countries.

This declaration is made by

ALLNET Computersysteme GmbH

Maistraße 2

82110 Germering

Germany

Germering, 10.02.2012

_______________________________

Wolfgang Marcus Bauer

CEO

EN55022:2006+ A1:2007 CISPR/I/XX/CDV Opt B

EN 61000-3-3:2008 EN 50412-2-2:2005

IEC 61000-4-2:2008 IEC 61000-4-3:2006+A1:2007

IEC 61000-4-4:2004 IEC 61000-4-5:2005

IEC 61000-4-6:2008 IEC 61000-4-8:1993+A1:2000
