Datasheet | Switches

AT-FS716L

Unmanaged Fast Ethernet Switches

AT-FS716L-xx

16-port 10/100TX unmanaged switch

with internal power supply

High Performance

Providing powerful 10/100 switching solutions

for desktop and small network environments,

the Allied Telesis AT-FS700 series of unmanaged

switches features full auto-negotiating 10/100

ports.These ports enable the switches to

detect the speed and duplex modes of attached

devices, enabling them to automatically configure

for the best possible performance.

Flexibility

Available as 5-, 8-, 16-, or 24-port models, the

ATFS700 Series meets a multitude of power

requirements with both internal and external

power-supply options. Also, wall-, desk-, and

rack-mounting options giveusers ultimate

flexibility in selecting the model that meets

their physical deployment requirements.

Simplified Installation

Fully auto-configuring AT-FS700 Series switches

require minimal set-up by the user. Auto-sensing

ports enable seamless and simple connectivity

between existing 10Mbps Ethernet and

100Mbps Fast Ethernet UTP devices—and

all units canbe installed in minutes. Every

AT-FS700 Seriesmodels is equipped with

MDI/MDIX ports for simple connection to

other hubs and switches. Finally, easy to read front

panel LEDs show ongoing switch status and

simplify troubleshooting.

Quality & Reliability

Allied Telesis is a worldwide leader in unmanaged

Ethernet switches. Shipping more than 250,000

unmanaged switches each year, Allied Telesis

offers proven reliability and industry recognized

quality.

Key Features

•16 10/100TX ports

•Wirespeed technology

•Non-blocking architecture

•Auto-negotiation ports

•Auto MDI/MDIX ports

•Transparent to VLAN packets

•Half- & full-duplex flowcontrol

•Sturdy metal case

•Rack mountable

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000160 Rev. B

AT-FS716L |Unmanaged Fast Ethernet Switches

Performance

14,800pps for 10Mbps Ethernet

148,000pps for 100Mbps Fast Ethernet

MAC Addresses Up to 4K

Packet Buffer 512K

Half/Full-Duplex

Auto Negotiation

Auto MDI/MDI-X on all ports

Interface Connections

10/100TX RJ-45

Power Characteristics

Frequency 50 to 60Hz

100-240vAC, .4A

Environmental Specifications

Operating Temp 0ºC to 40ºC (32ºF to 104ºF)

Non-operating Temp -25ºC to 70ºC (-13ºF to 158ºF)

Operating Humidity 5% to 80% non-condensing

Storage Humidity 5% to 95% non-condensing

Technical Specifications

Physical Characteristics

Dimensions 3.6cm x 25.0cm x 11.6cm

(1.4” x 9.8” x 4.6”)

Weight 0.9kgs (1.98bs)

Rack-mount

19” rack-mount, hardware included

Standards & Compliance

IEEE 802.3 10T Ethernet

IEEE 802.3u 100TX Fast Ethernet

IEEE 802.3x Flow Control

Electrical/Mechanical Approvals

UL 1950

CSA 22.2 No. 950

FCC/EN55022 Class B

VCCI Class B

EN60950 (TUV)

EN55024

Ordering Information

AT-FS716L-xx

16-port 10/100TX unmanaged switch with

internal power supply

Where xx = 10 for U.S. power cord

=20 for no power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord
