Allflex LPR Manuel utilisateur

Firmware v1.11 and higher

Allflex LPR Reader

User Guide

©Copyright SCR by Allflex Europe SAS 2020

This manual is copyrighted. All rights are reserved, and no part of this publication

may be reproduced or transmitted in any form or by any means without prior

written consent.

Disclaimer

The information in this manual was accurate and reliable at the time of its release.

However, we reserve the right to change the specifications of the product

described in this manual without notice at any time.

Registered Trademarks

All other proprietary names mentioned in this manual are the trademarks of their

respective owners.

Revision 2.0

September 2020

Allflex LPR User Guide

1Overview..................................................................................................................1

2Operating the Reader ...............................................................................................1

2.1 Getting Started ............................................................................................................. 1

2.2 Switch On/Off Instructions........................................................................................... 1

2.3 Reading a Transponder................................................................................................. 1

3Using Bluetooth Interface .........................................................................................2

3.1 Connection to iPhone/iPad Devices ............................................................................. 3

3.2 Connection to Android Devices.................................................................................... 3

3.3 Connection in Master Mode ........................................................................................ 3

4Using USB Interface ..................................................................................................4

5Battery Management................................................................................................4

5.1 Battery Level Indicator ................................................................................................. 4

5.2 Recharging the Battery................................................................................................. 4

5.3 Battery Handling Instructions....................................................................................... 5

6PC Software..............................................................................................................5

Appendix A: Specifications ...............................................................................................7

Appendix B: Legal Information .........................................................................................8

Reader physical integrity .......................................................................................................... 8

Canada – Industry Canada (IC) ................................................................................................. 8

USA - Federal Communications Commission (FCC) ................................................................. 8

Apple - Legal Notice.................................................................................................................. 8

Trademarks ............................................................................................................................... 9

Regulatory Compliance........................................................................................................... 10

ISO 11784 & ISO 11785 ........................................................................................................... 10

Declaration of Conformity...................................................................................................... 10

Allflex LPR User Guide

1Overview

2Operating the Reader

2.1 Getting Started

Before using the reader, it is necessary to first fully charge the battery pack as described in

battery management section.

2.2 Switch On/Off Instructions

•Press and release the “SCAN” button once to turn the reader on. At start-up, the Red light

switches on and beeps once.

2.3 Reading a Transponder

•To search for tags, press and release the SCAN button. When searching for tags, the red

light will flash. The reader will continue searching tags for 3 seconds until a tag is found or

the time is elapsed.

Once activated, the reader will stay on for 2 minutes by default and then

shut down automatically emitting two beeps.

Allflex LPR User Guide

•The best reading orientation is as shown:

When a tag is detected, the green led will flash once to indicate the good read and the tag

number will be transmitted over Bluetooth®and USB link.

3Using Bluetooth Interface

•The LPR has a built-in Bluetooth®to communicate with computers, smartphones and

iPhone®/ iPad®.

•The blue light indicates the current Bluetooth state:

Status

Meaning

•Bluetooth off

•Blinks once every 2 seconds

•Not connected (slave mode )

•Blinks 5 times every 5 seconds

•Not connected (Master mode)

•Tries to establish a connection

•Bluetooth Connected

•The reader emits a single beep when the Bluetooth connects and 3 beeps when it

disconnects.

•The default passkey of the built-in Bluetooth®is 1234.

•To pair your smartphone to your LPR reader, go into Bluetooth settings of your

smartphone and turn on Bluetooth if currently disabled.

•When the reader is connected in slave mode, the reader stays on for 1

hour.

•When the reader is configured in Master mode, you can force it to

Slave mode by keeping pressed the button for 15 seconds at start-up.

During these 15 seconds, the reader will progressively warn that the

return to slave mode is ongoing (blinking blue led, audible warning).

Allflex LPR User Guide

3.1 Connection to iPhone/iPad Devices

3.2 Connection to Android Devices

Make sure your reader is on and tap on LPR

Type 1234

Paired

3.3 Connection in Master Mode

Use the PC software to configure your reader in master mode (refer to PC software section

for more information).

1Once paired to the iPhone, your reader will automatically switch into master mode to be able the reconnect to

the iPhone automatically the next time.

Make sure your reader is on and tap on LPR

Type 1234

Paired1

Allflex LPR User Guide

4Using USB Interface

The USB port allows the device to transmit and receive data via a USB connection to your

personal computer

1. Before plugging your reader to your computer, first install the LPR PC Software available

on your local Allflex website. This will pre-install the LPR USB driver on your computer

necessary to connect your reader through USB.

2. Remove the protective cap covering the USB port and connect the reader to your

computer using the USB cable. Your computer will automatically find and install the drivers

for the reader.

3. Run LPR PC Software to configure your reader, configure a Bluetooth connection or

download its memory.

5Battery Management

5.1 Battery Level Indicator

The reader has an orange light indicating the battery level or the charge status when a USB

charger powered the device.

Status

Meaning

•Battery OK

•Battery level getting low

•Battery depleted

•Charge necessary

5.2 Recharging the Battery

To charge the battery, simply plug the USB cable into the USB connector and connect it to the

wall mount Power Pax KSAS0050500100D5U AC/DC adapter2provided with the reader. It will

take approximately 5 hours to fully charge the battery pack.

2Install first the plug onto the adapter before use.

•Once the USB cable is connected, the reader is automatically powered on and it

will remain activated until the cable is disconnected.

•The USB connection recharges your battery pack (refer to the Battery

Management section).

•Replace the protective cap on USB port to protect your reader against foreign

contamination and water.

Allflex LPR User Guide

Status

Meaning

•Battery fully charged3

•Slow charge

•Fast charge (#5 hours)

•Charge fault (Temperature exceed limits)

5.3 Battery Handling Instructions

Please read and follow the handling instructions for the battery before use. Improper use of

the battery may cause heat, fire, rupture, and damage or capacity deterioration of the battery.

6PC Software

The LPR PC Software is available on your local Allflex website. Once downloaded, execute the

setup package to install the PC software on your computer.

3After 15 minutes, the RED light blinks every 4 seconds.

•

The batteries can be charged with a computer, but the charge time will

significantly increase.

•The reader cannot read tags with depleted batteries. The other functions

are fully active.

•Use the adapter and the USB cable provided with the reader to charge the

batteries.

Caution

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Warning

Use rechargeable batteries with the same capacity.

Do not use this reader near water when connected to the AC/DC adapter.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.

Do not charge the battery pack from AC main sources during electrical storms or when unused for long periods of time.

The battery must be charged indoor only between 0°C and 35°C.

For best battery performance, charge unit at least every three months, if reader is unused

Allflex LPR User Guide

With the software, you can:

•Download reader memory (when feature enabled)

•Set-up an advanced Bluetooth connection (master mode with remote devices discovery)

•Change the reader configuration (enable memory, change reader name…)

Refer to LPR PC Software user manual for more information (available on your local Allflex

website.

Allflex LPR User Guide

Appendix A: Specifications

All specifications are subject to change without notice.

General

Operating frequency

134.2 kHz

Norms

ISO 11784 / 11785

Special feature:

Temperature scanning with TS and BT implants between 33°C and 43°C

(between 91.4°F and 109.4°F)

Reading distances

Up to 22cm depending on tag type and orientation

User interface

4 lights (red, green, orange and blue)

1 button, 1 buzzer, 1 vibrator

USB interface

CDC class (Serial emulation)

Bluetooth®interface

v3.0 Class 2(up to 15m), Serial Port Profile (SPP)

iPhone/iPad compatible (iAP interface)

Memory

3000 IDs

Battery

7.2VDC – 700mAh NiMH rechargeable

Battery charge duration

Up to 5h00 in fast charge (external power supply)

Up to 9h00 in slow charge (computer)

Radiated power on frequency band range

Maximal radiated power in band from 119 kHz to 135 kHz: 21.36 dBµA/m @ 10m

Maximal radiated power in band from 2400 MHz to 2483.5 MHz: 1.62mW

Mechanical and physicals

Dimensions

234 x 52 x 32 mm (9.21 x 2.05 x 1.26 in)

Weight

300 g (10.6 oz)

Operating Temperature

-20° to +45°C (-4° to +113°F)

Storage Temperature

-20° to +65°C (-4° to +149°F)

Battery charging

temperature

+5°C to +35°C (+41 to +95°F)

Humidity

10% - 90%
