ALFATRON ALF -10X-Cam
ALFATRON ALF -10X -CAM
2
ALFATRON ALF -10X-Cam
HD Color Video Camera
User Manual
Attention
1．Usage
To prevent this product or products connected to it from being damaged, please use it within its
prescribed scope of use.
1) Keep the device away from liquids and humid environments.
2) To prevent electrical shock, do not open the main enclosure; only qualified technicians may
install or maintain the device.
3) Do not use the device beyond the scope of its temperature, humidity or power supply
specification.
4) When cleaning the camera lens, wipe it with a soft dry cloth. In the case of stubborn dirt,
clean the lens gently with a mild detergent. Do not use strong or corrosive detergent, as it
may scratch the lens and thus affect the image.
2．Electrical safety
Installation and use of this product shall be in strict accordance with safety standards for
ALFATRON ALF -10X -CAM
3
electricity.
3．Handle with care
Avoid heavy pressure, strong vibrations or immersion during transportation, storage and
installation.
4．Power supply
This product uses a 12V DC power supply.
5．Install with caution
1)Do not forcefully rotate the camera, this could cause a mechanical malfunction.
2)This product should be placed on a stable desktop or other horizontal surfaces. Do not install
the product on uneven surfaces, this may display a skewed image.
3)When installing the camera, use the four double faced adhesive pads at the bottom for fixing.
4)This products casing is constructed from organic materials. Do not expose it to any liquid, gas
or solids which may corrode the exterior.
5)During installation, ensure that there are no obstacles within rotation range of the camera.
6)Do not power on before all the applicable cables are connected.
6．Do not dismantle the product without permission
This product contains no parts which can be maintained by the user. Any damage arising from
dismantling the product by user without permission will not be included in warranty.
7．Magnetic field interference
Magnetic fields under a specific frequency may affect this product image as this is Class A
product.
ALFATRON ALF -10X -CAM
4
Content
1. FAST INSTALLATION..............................................................................................................................6
1.1 CAMERA INTERFACE EXPLANATION..........................................................................................6
1.2 POWER-ON INITIAL CONFIGURATION........................................................................................6
1.3 VIDEO OUTPUT..............................................................................................................................6
2. PRODUCT OVERVIEW...........................................................................................................................10
2.1 PRODUCT INTRODUCTION..........................................................................................................10
2.1.1 PRODUCT MODEL..............................................................................................................10
2.1.2 DIMENSION..........................................................................................................................11
2.1.3 ACCESSORY.........................................................................................................................11
2.2 MAIN FEATURES............................................................................................................................12
2.3 TECHNICAL SPECIFICATION........................................................................................................13
2.4 INTERFACE INSTRUCTION...........................................................................................................16
2.4.1 EXTERNAL INTERFACE.......................................................................................................16
2.4.2 RS-232 INTERFACE..............................................................................................................17
3. APPLICATION INSTRUCTION.................................................................................................................19
3.1 VIDEO OUTPUT...............................................................................................................................19
3.1.1 POWER-ON INITIAL CONFIGURATION...............................................................................19
3.1.2 VIDEO OUTPUT.....................................................................................................................19
3.2 REMOTE CONTROLLER.................................................................................................................20
3.2.1 KEYS INTRODUCTION..........................................................................................................20
3.2.2 APPLICATIONS......................................................................................................................21
3.3 MENU SETTING...............................................................................................................................24
3.3.1 MAIN MENU...........................................................................................................................24
3.3.2 SYSTEM SETTING................................................................................................................24
3.3.3 CAMERA SETTING................................................................................................................25
3.3.4 P/T/Z.......................................................................................................................................29
3.3.5 VIDEO FORMAT.....................................................................................................................29
3.3.6 VERSION...............................................................................................................................30
3.3.7 RESTORE DEFAULT.............................................................................................................30
4. NETWORK CONNECTION......................................................................................................................32
ALFATRON ALF -10X -CAM
5
4.1 CONNECTING MODE....................................................................................................................32
4.2 IE LOG IN.......................................................................................................................................35
4.2.1 WEB CLIENT.....................................................................................................................35
4.2.2 PREVIEW..........................................................................................................................35
4.2.3 PLAYBACK........................................................................................................................36
4.2.4 CONFIGURATION.............................................................................................................36
4.2.5 VIDEO CONFIGURATION................................................................................................ 37
4.2.6 NETWORK CONFIGURATION..........................................................................................40
4.2.7 SYSTEM CONFIGURATION.............................................................................................41
4.2.8 LOGOUT............................................................................................................................42
4.2.9 WIRELESS NETWORK.....................................................................................................43
5. SERIAL COMMUNICATION CONTROL...............................................................................................43
5.1 VISCA PROTOCOL LIST..............................................................................................................43
5.1.1 CAMERA RETURN COMMAND........................................................................................43
5.1.2 CAMERA CONTROL COMMAND.....................................................................................44
5.1.3 INQUIRY COMMAND........................................................................................................47
5.2 PELCO-D PROTOCOL COMMAND LIST....................................................................................50
5.3 PELCO-P PROTOCOL COMMAND LIST....................................................................................51
6. CAMERA MAINTENANCE AND TROUBLESHOOTING.................................................................... 52
6.1 CAMERA MAINTENANCE......................................................................................................... .52
6.2 TROUBLESHOOTING............................................................................................................... .52
7. LIMITED WARRANTY…………………………………………………………………………………….… .54
ALFATRON ALF -10X -CAM
6
1. Quick Installation
1.1 Camera Interface Explanation
Photo 1.1 Interface of U3+HDMI Model
Interface of U3+HDMI Model：
1、Camera Lens 4、Locating Hole 7、HDMI Interface
2、Remote Controller Receiver
Light
5、RS232 Control Interface (input)
8、USB3.0 Interface
3、Tripod Screw Hole 6、LAN Interface 9 、DC12V Input Power Supply
Socket
1.2 Power on initial configuration
1) Power on: Connect DC12V power supply adapter with power supply socket.
2) Initial configuration: Power indicator lights up and remote-control receiver light blinks, camera head moves
from bottom left to bottom right, and then goes to the ‘Home’ position (center), while the camera self-tests
aperture. When remote control receiver light stops blinking, the self-checking is completed.
Note:
1. The default address of the remote controller is the 1# address.
2. If you set preset 0, when Power on self-test is completed, the camera automatically moves to the preset 0
position.
1.3 Video Output
1)Video Output from LAN
a. Network Cable Connection Port: No.6 in Figure1.1
ALFATRON ALF -10X -CAM
7
b. Webpage Login: Open your browser and enter 192.168.5.163 in the address bar (factory default);
press Enter to enter the login page; click on the “player is not installed, please download and install!"
and follow the installation steps for installation. Then enter the user name admin and password admin
(factory default); press Enter to enter the preview page; users can carry out PTZ control, video
recording, playback, configuration and other operations.
2) HDMI Video Output
a. HDMI Video Cable Connection: No.7 in Figure1.1
b. Connect the camera and the monitor via HDMI video cable; video output is available after camera self-
tests.
3)USB3.0 video output
a. USB3.0 video cable connection: No.8 in figure1.1
b. Connect the camera and the monitor via USB3.0 video cable, open video display software, select image
device, and then the video output will be available.
4) USB3.0 compatible with USB2.0 output
a. USB3.0 video cable connection: No.8 in Figure1. 1
b. Connect the camera and the monitor via USB3.0 video cable, open video display software, select image
device, and then the video output will be available.
Note: USB2.0 output and USB3.0 output is the same interface.
ALFATRON ALF -10X -CAM
8
1.4 Bracket mount
Note: Bracket can only be wall mounted or mounted upside down on a concrete wall but it cannot be installed
on plasterboard.
1) Wall mount step
ALFATRON ALF -10X -CAM
9
2. Upside down mount step
ALFATRON ALF -10X -CAM
10
2. Product overview
2.1 Product Introduction
2.1.1 Product Model
There are two main series according to different video formats, lens optical zooms, output interfaces and remote-control modes.
Model NO.X—XXX—XXX—XX
IR ---IR Remote Controller
WR---Wireless Remote Controller
U3+HDMI---USB 3.0 and HDMI Interface
10---10x Optical Zoom Lens
S---1080P60 Downward Compatibility
M---1080P30Downward Compatibility
Please refer to corresponding features in this manual.
