ALDI FERREX FABH 20-I Manuel utilisateur
20 V LI-ION CORDLESS
ROTARY HAMMER DRILL
FABH 20-I
User Manual
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual
Original instructions
Scope of delivery............................................................................3
Components .........................................................................................6
Connecting elements supplied.........................................................6
General information ......................................................................7
Reading and storing the user manual ............................................. 7
Proper use............................................................................................. 7
Residual risks........................................................................................8
Explanation of symbols ......................................................................8
Safety............................................................................................. 9
Explanation of notes ...........................................................................9
General power tool safety instructions............................................9
Cordless tool use and care................................................................ 12
Safety instructions for demolition breakers ................................. 13
Safety notes for drills......................................................................... 13
Operation...................................................................................... 14
Checking the product and package contents .............................. 14
Using the SDS-Plus masonry drill.................................................... 14
Using the wood or metal drill .......................................................... 15
Using the screwdriver bits................................................................ 16
Using the rechargeable battery.......................................................17
Using the product .............................................................................. 19
Setting the mode and direction of rotation .................................. 19
Removing a blockage .......................................................................20
Tips and tricks on how to work properly .......................................20
Cleaning and maintenance ......................................................... 21
Cleaning the product ........................................................................ 21
Inspecting the product.....................................................................22
Transport......................................................................................22
Storage .........................................................................................22
Troubleshooting ..........................................................................23
Technical data ..............................................................................23
Battery and charger information....................................................24
Noise/vibration information.......................................................24
Disposal ........................................................................................27
Disposing of the packaging .............................................................27
Disposing of the product ..................................................................27
Declaration of conformity............................................................28
Table of contents
3
Scope of delivery
Dok./Rev.-Nr. 198258_20200623
A
6
8
7
2
3
4
1
5
Scope of delivery
4
Scope of delivery
B
6
2
5
Scope of delivery
C
8
6
Scope of delivery
Components
1SDS-Plus shank holder
2Locking mechanism of the SDS-Plus shank holder
3Switch (right-hand/left-hand rotation)
4On/Off switch
5Rechargeable battery holder
7LED work light
8Changeover switch (Drilling/Hammer drilling)
Connecting elements supplied
6Quick-action drill chuck
General information
7
General information
Reading and storing the user manual
This user manual accompanies this 20 V Li-Ion Cordless Rotary Hammer Drill
FABH 20-I (referred to below only as the ‘product’). It contains important
information on safety, usage and care.
Before using the product, read the user manual carefully. Pay particular
attention to the safety notes and warnings. Failure to comply with the instructions in
this user manual may result in severe injury or damage to the product.
Comply with valid local or national provisions concerning the use of this product. Keep
this user manual in a safe place for future reference. Make sure to include this user
manual when passing the product on to third parties.
Proper use
The product is only intended for private use – such as hobby or do-it-yourself work –
when undertaking the following:
• for hammer drilling into materials such as concrete, brick and stone,
• for drilling into materials such as wood and metal,
• for screwing in and screwing out screws.
Any other applications are expressly prohibited and are deemed improper use.
This product does not come with a rechargeable battery or charger. These must be
bought separately: The product can be operated with the 20 V rechargeable battery
or with the 20/40V rechargeable battery available from Activ Energy®. Use only the
rechargeable batteries specified in the chapter ‘Technical data’ for the product. Do not
operate the product with rechargeable batteries from other manufacturers.
Neither the manufacturer nor the retailer can accept any responsibility for injury, loss
or damage caused by misuse of this product of any kind. Examples of misuse are giv-
en in the following non-exhaustive list:
• using the product for other purposes other than those intended;
• failure to observe the safety notes and warnings as well as the assembly, operat-
ing, maintenance and cleaning instructions contained in this user manual;
• failure to comply with any regulations relating to accident prevention, occupa-
tional health or safety, which specifically and/or generally apply to the use of the
product;
• use of accessories and spare parts not intended for the product;
• changes to the product;
• product repairs performed by parties other than the manufacturer or a qualified
professional;
General information
8
• use of the product for commercial, artisan or industrial purposes;
• operation or maintenance of the product by persons not familiar with how to
handle the product and/or who are not aware of the related risks.
Residual risks
Despite proper use, inconspicuous residual risks cannot be completely ruled out.
The following risks may arise due to the design of the product:
• lung injury if a suitable dust mask is not worn;
• hearing loss if suitable ear protection is not worn;
• injury to health attributed to hand and arm vibrations if the product is used over
a prolonged time or if the product is not guided and maintained properly;
• risk of injury if long hair, loose-fitting clothing or jewellery get caught by rotating
device parts.
Explanation of symbols
The following symbols are used in this user manual, on the product or on the
packaging.
This symbol provides you with useful supplementary information on
assembly or operation.
Declaration of conformity (see chapter “Declaration of conformity”):
Products marked with this symbol meet all applicable Community regu-
lations for the European Economic Area.
Read the user manual.
Wear protective goggles.
Wear a dust mask.
Wear ear protection.
Wear suitable secure footwear.
Safety
9
Wear suitable protective gloves.
Information on number of strokes
Safety
Explanation of notes
The following symbols and signal words are used in this user manual.
WARNING!
Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Designates a dangerous situation that may result
in minor or moderate injury if not avoided.
NOTICE!
Warns against potential damages to property.
General power tool safety instructions
WARNING Read all the safety notes, instructions, illustrations and technical
details supplied with this power tool. Failure to follow the safety notices and in-
structions may result in an electric shock, fire and/or severe injury.
Save all warnings and instructions for future reference.
The term “power tool” used in the safety instructions refers to mains-operated
power tools (corded) and battery-powered power tools (cordless).
Work area safety
a) Keep your work area clean and well lit.
Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust.
Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool.
If you are distracted, you could lose control of the power tool.
Safety
10
Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators.
There is an increased
risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water enter-
ing a power tool will increase the risk of electric shock.
d) Do not use the cord for improper purposes such as for carrying
the power tool, for hanging it up or for pulling or unplugging
it from the socket. Keep cord away from heat, oil, sharp edges
and moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use only extension cords
that are suitable for outdoor use.
Use of a cord suitable for outdoor
use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply.
Use of an RCD
reduces the risk of electric shock.
Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in
serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-po-
sition before connecting to power source and/or battery pack,
picking up or carrying the tool.
Carrying power tools with your
finger on the switch or connecting the power tool to a power supply
while the switch is set to “on” may lead to accidents.
