Quick Start Guide
2
www.sar-tick.com
This product meets applicable national
SAR limits of 2.0W/kg.
The specic maximum SAR values can
be found in the Radio Waves section
of this user guide.
When carrying the product or using
it while worn on your body, either
use an approved accessory such as
a holster or otherwise maintain a
distance of 5 mm from the body to
ensure compliance with RF exposure
requirements. Note that the product
may be transmitting even if you are
not surng internet.
Safety and use
We recommend that you read this chapter carefully before
using this device.The manufacturer disclaims any liability for
damage, which may result as a consequence of improper
use of this device or of use contrary to the instructions
contained herein.
Do not switch on your device when its use is
prohibited or when using the device may cause
interference or danger.
Follow rules or regulations in hospitals and
health care facilities. Switch off your device near
medical apparatus.
3
Switch off your device in an aircraft.The device
may cause interference to aircraft control
signals.
Switch off your device near high-precision
electronic devices. The device may affect the
performance of these devices.
Do not attempt to disassemble your device or
its accessories. Only qualied personnel are
allowed to service or repair the device.
Do not place your device or its accessories in
containers with a strong electromagnetic eld.
Do not place magnetic storage media near your
device. Radiation from the device may erase the
information stored on them.
Do not subject your device to high temperatures
or use it in a place with ammable gas such as
a petrol station.
Keep your device and its accessories away from
children. Do not allow children to use your
device without guidance.
Only use approved batteries and chargers to
avoid the risk of explosion.
Observe the laws or regulations on device use.
Respect others’ privacy and legal rights when
using your device.
It is recommended that the equipment only be used in an
environment where the temperature is between -10°C and
50°C and humidity is between 10% to 90%.
4
CHARGERS
Mains powered chargers will operate within the
temperature range of: 0°C to 40°C.
The chargers designed for your device meet with the
standard for safety of information technology equipment
and ofce equipment use.
They are also compliant to the ecodesign directive
2009/125/EC. Due to different applicable electrical
specications, a charger you purchased in one jurisdiction
may not work in another jurisdiction.They should be used
for this purpose only.
1. Overview
Y858 is a portable wireless router, providing a simple way to
share 4G with any Wi-Fi embedded device.
1.1 Package contents
Y858 USB cable
Quick start guide Charger
5
1.2 Application
PC
PAD Smart phone
1.3 Device overview
①②
③
④
① ②
Number Description
①Power on/off Key
②WPS Key
6
Number Description
③LED light
④Micro USB Interface
Use the device’s 2 buttons as follows:
Button Description
① Power
On/Off
Long press to turn on/off the device
Short press to put the LED in either active
or sleep mode.
② WPS
Long press to turn on WPS
Short press to put the LED in either active
or sleep mode
1.4 Turning on the device
Step 1: Open back cover from Bottom of right corner,
then take out battery and put SIM card as remark.
Step 2: Long Press the Power On/Off button.
7
1.5 LED Display
The LED display is interpreted as follows:
Network Indicator(Red or Blue LED)
Wi-Fi indicator (Blue LED)
SMS indicator (Blue LED)
Battery indicator (Red or Blue LED)
LED description:
Category Icon Display
Network
Indicator
Light Blue LED when connect to internet
or ash when no internet service;
Light Red LED when no Network/no
service/no SIM card
Wi-Fi
indicator Light Blue LED when Wi-Fi active
SMS
indicator
Light Blue LED when new message coming
or ash when SMS full
Battery
indicator
Light Red LED for low power alarm; Light
Blue LED during charging
1.6 Driver Installation
1. Power on router and connect router to client end (PC/
Tablet etc.), autorun driver will pop out automatically,
click “Install”. If no antorun, please go to Computer >
8
removable storage device to nd Web Connection
driver as blew.
2. Double click “Web Connceiton”, go to “autorun” exe.
le and click it to install.
3. Installation process as below.
4. Desktop Icon will be generated after Installation nish.
1.7 Connecting in Wi-Fi mode
SSID: locate the SSID information on the sticker on Back
Cover.
Step 1: Use the Wi-Fi manager on the Wi-Fi embedded
device to select network name (SSID).
• From a Windows PC: Right-click Wireless network
connection on the task bar, and select: View Available
Networks.
Choose SSID from the list of available networks.
• From a Mac computer: Select System Preferences ->
Network -> Airport. Click “Advanced” to choose SSID
from the list of available networks.
9
• From an iOS device: Settings ->Wi-Fi. Choose SSID from
the available networks.
• From an android device: Settings -> Wireless controls ->
Wi-Fi settings.Choose SSID from the available networks.
Step 2: Enter the Wi-Fi key when prompted for a security
key.
2. Quick Setup
Open your browser,and input the address http://192.168.1.1
to access the login page.
Default login password: admin
Login and click “Setting” to congure the basic settings.
Admin Password:
• Login Password: Set the password for login.
Wi-Fi Settings:
• SSID: Set the network name of this device.
• Security: Congure the security mode for Wi-Fi
connection.
3. Charging the device
You have two ways to charge your device.
Wall Charger charging:
Connect USB cable with Charger head and device, then
charging begin.
When the device is powered off, charging will take a
maximum of 3 hours.
10
USB Charger charging
You can also charge the device by connecting it to a PC
with the USB cable.
When the device is powered off, charging will take a
maximum of 4 hours.
Note: In order to protect the battery, when low power
LED indicator ash, please charge the device.
4. Certication
WEEE Approval
This device is in compliance with the essential requirements
and other relevant provisions of the Waste Electrical and
Electronic Equipment Directive 2012/19/EU (WEEE
Directive).
This symbol on device means that these
products must be taken to collection points at
the end of their life:
- Municipal waste disposal centres with specic
bins for these items of equipment.
- Collection bins at points of sale.
They will then be recycled, preventing substances being
disposed of in the environment, so that their components
can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these
collection points.
