Aktakom ATE-9538 Manuel utilisateur

SD card real time datalogger, RS232/USB

ENVIRONMENT METER

Model : ATE-9538

Your purchase of this

SOUND LEVEL METER

w i t h S D C A R D

DATALOGGER marks a

step forward for you

into the field of

precision measurement.

Although this METER is

a complex and delicate

instrument, its durable

structure will allow

many years of use if

proper operating

techniques are

developed. Please read

the following

instructions carefully

and always keep this

manual within easy

reach.

OPERATION MANUAL

www.tmatlantic.com

TABLE OF CONTENTS

1. FEATURES..................................................................1

2. SPECIFICATIONS........................................................

3. FRONT PANEL DESCRIPTION.......................................6

4. MEASURING PROCEDURE............................................7

4-1 Function selection .......................................................7

4-2 Anemometer/Temp. measurement................................8

4-3 Humidity/Temp. measurement......................................9

4-4 Li

ht measurement......................................................9

4-5 Type K/J Temperature measurement............................

4-6 Sound level measurement ( optional probe ).................

4-7 Data Hold....................................................................11

4-8 Data Record ( Max./ Min. readin

)...............................

4-9 LCD Backli

ht ON/OFF..................................................12

5. DATALOGGER.............................................................13

5-1 Preparation before execute datalo

er function.............

5-2 Auto Datalo

er ( Set samplin

time 1 second ).......≧14

5-3 Manual Datalo

er ( Set samplin

time = 0 second )....15

5-4 Check time information................................................

5-5 Check samplin

time information..................................

5-6 SD Card Data structure................................................

6. Saving data from the SD card to the computer..............17

7. ADVANCED SETTING...................................................18

7-1 Set clock time

( Year/Month/Date, Hour/Minute/ Second )..............19

7-2 Decimal point of SD card setting.............................20

7-3 Auto power OFF management ...............................20

7-4 Set beep Sound ON/OFF........................................

7-5 Select the thermometer type to Type K or Type J....

7-6 Select the temperature unit to or .................℃℉ 22

7-7 Set sampling time .................................................22

7-8 SD memory card format.........................................22

8. POWER SUPPLY from DC ADAPTER..............................23

9. BATTERY REPLACEMENT.............................................23

10. SYSTEM RESET.........................................................24

11. RS232 PC serial interface...........................................24

12. Optional Type K Temp. probe....................................

13. PATENT....................................................................27

1. FEATURES

* Environment instrument, multi-function, all in one.

ype K/J thermometer, Humidity/Temp. meter,

Anemometer, Light meter, Sound level meter ( optional

adapter ).

* Humidity measurement show both %RH and Temp. .

* Anemometer can default the display unit to m/S, FPM,

Km/h, mph, knot.

* Light meter can default the display unit to LUX or Ft-cd.

* Thermocouple Thermometer can default to accept

type K or type J Temp. probe.

emp. display unit default to or .℃℉

* Meter can default auto power off or manual power off.

* Real time SD memory card Datalogger, it Built-in Clock

and Calendar, real time data recorder , sampling time set

from 1 second to 3600 seconds.

* Manual datalogger is available ( set the sampling

time to 0 ), during execute the manual datalogger

function, it can set the different position ( location ) No.

( position 1 to position 99 ).

* Innovation and easy operation, computer is not need

to setup extra software, after execute datalogger, just

take away the SD card from the meter and plug in the

SD card into the computer, it can down load the all the

measured value with the time information (

year/month/date/ hour/minute/second ) to the Excel

directly, then user can make the further data or graphic

analysis by themselves.

* SD card capacity : 1 GB to 16 GB.

* LCD with green light backlight, easy reading.

* Can default auto power off or manual power off.

* Data hold, record max. and min. reading.

* Power by UM3/AA ( 1.5 V ) x 6 batteries or DC 9V adapter.

* RS232/USB PC COMPUTER interface.

* Available for the HVAC applications.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display LCD size : 52 mm x 38 mm

LCD with green backlight ( ON/OFF ).

Measurement *Type K/J thermometer

Unit *Humidity/Temp. meter

*Anemometer with Temp.

*Lightmeter

*Sound level meter ( optional adapter )

Datalogger Auto 1 second to 3600 seconds

Sampling Time

@ For anemometer measurement,

Setting range

the sampling time setting value

should be 2 seconds.≧

@ Sampling time can set to 1 second,

but memory data may loss.

Manual Push the data logger button

once will save data one time.

@ Set the sampling time to

0 second.

@ Manual mode, can also select the

1 to 99 position ( Location ) no.

Memory Card SD memory card. 1 GB to 16 GB.

Advanced * Set clock time ( Year/Month/Date,

setting Hour/Minute/ Second )

* Decimal point of SD card setting

* Auto power OFF management

* Set beep Sound ON/OFF

* Set thermometer type to Type K or Type J

* Set temperature unit to or℃℉

* Set sampling time

* SD memory card Format

Temperature Automatic temp. compensation for the

Compensation Anemometer function and the type K/J

thermometer.

Data Hold Freeze the display reading.

Memory Recall Maximum & Minimum value.

Sampling Time Approx. 1 second.

of Display

Data Output RS 232/USB PC computer interface.

* Connect the optional RS232 cable

UPCB-02 will get the RS232 plug.

* Connect the optional USB cable

USB-01 will get the USB plug.

Operating 0 to 50 .℃

Temperature

Operating Less than 85% R.H.

Humidity

Power Supply

Alkaline or heavy duty DC 1.5 V battery

( UM3, AA ) x 6 PCs, or equivalent.

DC 9V adapter input. ( AC/DC power

adapter is optional ).

Power Current Normal operation ( w/o SD card save

data and LCD Backlight is OFF) :

Approx. DC 15 mA.

When SD card save the data and LCD

Backlight is OFF) :

Approx. DC 36 mA.

Weight 515 g/ 1.13 LB.

Dimension Meter 135 x 60 x 33 mm.

Probe 105 x 46 x 29 mm.

Accessories * Instruction manual.......................

1 PC

Included * Multi-function Probe

( Anemometer/Light/Humidity ).....1 PC

* Hard carrying case ( CA-06 ).........1 PC

Optional * SD Card ( 1 G )

Accessories * SD Card ( 2 G )

* Type K thermocouple probe.

TP-01, TP-02A. TP-03, TP-04

* Sound adapter, SL-417

* AC to DC 9V adapter.

* USB cable, USB-01.

* RS232 cable, UPCB-02.

* Data Acquisition software,SW-U801-WIN.

2-2 Electrical Specifications (23±5 )℃

Anemometer

A. Air velocity

Measure- Range Resolution Accuracy

ment tion

m/S 0.4 - 25.0 m/s 0.1 m/s ± (2% + 0.2 m/s)

km/h 1.4 - 90.0 km/h 0.1 km/h ± (2% + 0.8 km/h)

mph 0.9 - 55.9 mile/h 0.1 mile/h ± (2% + 0.4 mile/h)

knot 0.8 - 48.6 knots 0.1 knots ± (2% + 0.4 knots)

FPM 80 - 4930 ft/min 1 ft/min ± (2%+40 ft/min.)

Note:

m/S - meters per second km/h - kilometers per hour

FPM - feet/per minute knot - nautical miles per hour

mph - miles per hour (international knot)

B. Temperature

Measuring Range

0 to 50 /32 to 122℃℃℉ ℉

Resolution

0.1 /0.1℃℉

Accuracy

± 0.8 /1.5℃℉

Humidity/Temp. meter

A. Humidity

Measuring Range 0 % to 95 % R.H.

Resolution 0.1 % R.H.

Accuracy 70% RH :≧± (3% reading + 1% RH).

< 70% RH : ± 3% RH.

B. Temperature

Measuring Range 0 to 50 /32 to 122℃℃℉ ℉

Resolution 0.1 /0.1℃℉

Accuracy ± 0.8 /1.5℃℉

Light meter

Measuring Range LUX 0 to 20,000 LUX.

Ft-cd 0 to 1,860 Ft-cd

Resolution LUX 1 LUX

Ft-cd 0.1 Ft-cd

Accuracy ± ( 5% rdg ± 8 dgt )

Note:

Ft-cd : Feet candle

Type K/J Thermometer

Sensor Reso- Range Accuracy

Type lution

Type K 0.1 ℃-50.0 to 1300.0 ℃± ( 0.4 % + 0.8 )℃

-50.1 to -100.0 ℃± ( 0.4 % + 1 )℃

0.1 ℉-58.0 to 2372.0 ℉± ( 0.4 % + 1.5 )℉

-58.1 to -148.0 ℉± ( 0.4 % + 1.8 )℉

Type J 0.1 ℃-50.0 to 1200.0 ℃± ( 0.4 % + 0.8 )℃

-50.1 to -100.0 ℃± ( 0.4 % + 1 )℃

0.1 ℉-58.0 to 2192.0 ℉± ( 0.4 % + 1.5 )℉

-58.1 to -148.0 ℉± ( 0.4 % + 1.8 )℉

Accuracy value is specified for the meter only.

Temp. probe ( Type K, TP-01 TP-02A, TP-03. TP-04 ) is

the optional accessories, refer page 26.

Above specification tests under the environment RF Field

Strength less than 3 V/M & frequency less than 30 MHz only.

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1 Disp

3-2 Power Button

(

ESC, Bac

t Button

)

3-3 Ho

Button

(

Function Button, Next Button

)

3-4 REC Button

(

Enter Button, Unit Button

)

3-5 SET Button

(

Button, Time c

Button

)

▼

3-6 Lo

er Button

(

Button, Samp

time c

Button

)

▲

3-7 Pro

e input soc

3-8 Type K

J t

ermometer soc

3-9 SD car

soc

3-10 RS-232 Output Termina

3-11 Reset Button

3-12 DC 9V Power A

apter Input Soc

3-13 Battery Compartment

Cover

3-14 Battery Cover Screws

3-15 Stan

3-16 Tripo

Fix Nut

3-17 Pro

(

Anemometer, Humi

ity

Temp., Li

)

3-18 Anemometer vane

3-19 Humi

ity

Temp. sensor

3-20 Li

t sensor

3-21 Pro

e p

(

Anemometer, Humi

ity

Temp., Li

)

4. MEASURING PROCEDURE

4-1 Function selection

1)Turn on the meter by pressing the " Power Button "

( 3-2, Fig. 1 ) momentarily.

*Pressing the " Power Button " ( 3-2, Fig. 1 )

continuously and > 2 seconds again will turn off the

meter.

2)The meter can select 4 kind function as :

a.Air velocity/Temp.

b. Humidity/Temp. measurement

c.Type K/J Thermometer

d. Light meter

Pressing the " Function Button " ( 3-3, Fig. 1 )

continuously ( not release the button ), the Display

will show the following text in sequence :

An Air velocity/Temp. measurement

rH Humidity/Temp. measurement

tP Type K/J Thermometer measurement

LIgHt Light meter

Until the Display show the desired mode ( Function ),

just release the " Function Button " ( 3-3, Fig. 1 ), the

meter will execute this function with default.

4-2 Air velocity/Temp. measurement

1)Function select to " Air velocity/Temp. " measurement.

2)Plug the " Probe Plug " ( 3-21, Fig. 1 ) into the " Probe

Input Socket " ( 3-7, Fig. 1 ).

Power on the meter by pressing the " Power Button "

( 3-2, Fig. 1 ) once,

3)Hold the Probe by hand and let the " Anemometer

vane " ( 3-18, Fig. 1 ) face against the measuring air

flow source, then the Display ( 3-1, Fig. 1 ) will show

air velocity directly. At the same time, the lower Display

will show the air temperature value.

Change the Air velocity unit

Air velocity unit are :

m/S, FPM ( Ft/min ), Km/h, Knots, mph ( Mile/h )

If intend to change the Air velocity unit, press the

Unit Button " ( 3-4 ) continuously, the unit will

change from m/S to Km/h, mph, Knot, FPM in

sequence, until the desired unit is present on the

Display release the " Unit Button ", the select unit will

save into the memory with default.

Change the temperature unit ( , )℃℉

The meter Temp. display unit is defaulted to " ".℃

If intend to let the meter's temperature unit default

to " " , then please refer chapter 7-6 ( page 22 ).℉

Table des matières

Autres manuels Aktakom Instrument de mesure

Aktakom

Aktakom ATT-8509 Manuel utilisateur

Aktakom

Aktakom AM?-3320 Manuel utilisateur

Aktakom

Aktakom ACM-2352 Manuel utilisateur

Aktakom

Aktakom ACM-2031 Manuel utilisateur

Aktakom

Aktakom ACM-2047 Manuel utilisateur

Aktakom

Aktakom ATE-3012 Manuel utilisateur

Aktakom

Aktakom ATE-9051 Manuel utilisateur

Aktakom

Aktakom ATE-1033 Manuel utilisateur

Aktakom

Aktakom ACM-2348 Manuel utilisateur

Aktakom

Aktakom ATK-2001 Manuel utilisateur

Aktakom

Aktakom ATK-2040 Manuel utilisateur

Aktakom

Aktakom ATK-2021B Manuel utilisateur

Aktakom

Aktakom ATE-9030 Manuel utilisateur

Aktakom

Aktakom ATE-6008 Manuel utilisateur

Aktakom

Aktakom ATE-9051 Manuel utilisateur

Aktakom

Aktakom AKC-1292 Manuel utilisateur

Aktakom

Aktakom ATK-2011 Manuel utilisateur

Aktakom

Aktakom ACM-2311 Manuel utilisateur

Aktakom

Aktakom ATA-2504 Manuel utilisateur

Aktakom

Aktakom ATK-2209 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
