Akko Sakura Jelly Manuel utilisateur
Acrylic Mechanical Keyboard
User Manual
Sakura Jelly
Menu
Technical Specifications
HotKeys
System Commands
Backlight Settings
Akko Macro V1.0 Macro Setup Instruction 1
Akko Macro V1.0 Macro Setup Instruction 2
Akko Macro V1.0 Macro Setup Instruction 3
Akko Macro V1.0 Calling Macros
Akko Warranty and Service Statement
1
2
3
4
5
6
7
8
9
Technical Specifications
1
Dimensions
Model
Weight
Keycap
Interface
Multimedia Keys
N-Key Rollover
Custom Keys
Type
Country of Origin
Sakura Jelly
364 x 135 x 30mm
Approximately 0.83KG
China
Mechanical Keyboard
PBT Material
Type-C To USB
YES
YES
YES (use Akko Marco V1.0)
Hold down FN and press right Ctrl Revert Ctrl into Menu (APP) key
Fn
HotKeys
2
F1 F2 F3 F4 F5 F6 F7 F8
C M < >
Ctrl
Cal
Menu
Fn
F1
Fn+ =
F2
F3
F4
C
M
<
>
F5
F6
F7
F8
Fn+ =Fn+ =Previous Song
Next Song
Calculator
Mute
Decrease Volume
Increase Volume
E-mail
Windows Search
Browser Homepage
File Explorer Media
Pause/Playback
System Commands
3
Win Win
Fn
Win
Press Fn and left Win key
Lock Windows Key
Hold down left Win and right Win key for 5s
Restore Factory Settings
Lighting Effect 1
Lighting Effect 2
Lighting Effect 3
Lighting Effect 4
Lighting Effect 5
Lighting Effect 6
“↑”
“↓”
“←”
“→”
“-”
“+”
Ins
Home
PgUp
PgDn
Del
End
F9
F10
F11
F12
ScrLK
Backlight Settings
Fn+ Fn+=Fn+ = =
The adjustments on
the left is for generic
lighting effects. Some
lighting effects cannot
be tweaked.
For example,effects
with constant light can
only adjust brightness
as they don’t have
animation speed and
direction.
Fn
F9 F10 F11 F12 ScrLK
Ins Home PgUp
PgDnEndDel
+
↑
↑
↑
↑
Bright
Dim
Slower Animation
Faster Animation
4
Acrylic Case Light
Animation Faster
Acrylic Case Light
Animation Slower
Acrylic Case Light
Dimmer
Acrylic Case Light
Brighter
Turn Off Backlight
Change the Animation Direction
for Some Lighting Effects
Change the Color for Some
Lighting Effects
5
Akko Macro V1.0
Macro Setup Instruction 1
1. Akko Macro V1.0 is hardware-based and works without software-driven.
2. The following keys cannot be programmed: "Esc", "Fn", "Left Win".
3. Press and hold Fn + Win for 3 seconds to switch to the Macro mode. When the keyboard is re-connected or the
system is restarted, the Macro mode will be exited. You need to switch to the Macro mode again to use
programmed keys.
4. Akko Macro V1.0 does not support simultaneous trigger, that is, pressing "AB" at the same time will trigger the
two keys in the order of A followed by B.
5. Akko Macro V1.0 does not support customized interval time, that is, the trigger interval between key A and key
B cannot be defined and will follow the system's default trigger time.
Akko Macro V1.0
Macro Setup Instruction 2
Enter Macro Mode Start Macro Editor Macro Recording Fn + Custom Key
Exit Macro EditorExit Macro Mode
Fn + Custom Key
Record the next Key
Back to Default Mode Fn+Esc
Long Press Fn +Le� Win Fn+Esc (End Recording)(Press Keys to Store)
Clear Macro：
ot ”yek eht + NF“ sserp nac uoy ,rotide orcaM eht gniretne retfa ,denfied neeb sah yek a fI
clear its definition.
orcaM wen eht trats ot niaga”yek eht + NF“ sserp ,yek taht ezimotsuc-er ot tnaw uoy fI
recording after clearing its old definition.
6
7
Akko Macro V1.0
Macro Setup Instruction 3
Step 1: Press Fn + right Win for 3 seconds to enter the Macro mode.
Step 2: Press Fn + ESC to launch Macro editor.
.drocer ot ”A“ yek esoohc ew snaem sihT .A + nF sserP :3 petS
.”A“ fo noitinfied tnemecalper sa redro ni R ,A ,E ,G ,O ,K ,K ,A sserP :4 petS
.”A“ yek fo gnidrocer orcaM eht dne ot niaga A + nF sserP :5 petS
.”RAEGOKKA“ yalpsid lliw dapeton ni ”A“ gnisserp ,tniop siht tA
.gnidrocer orcaM eht trats ot B + nF sserp ,”B“ yek rof orcaM a etaerc ot tnaw uoy fI
Step 6: Press Fn + Esc to exit Macro editor.
Under the Macro mode, you can configure the keys and Macros you set.
Step 7: Press and hold Fn + Left Win for 3 seconds to exit the Macro mode and return to the default key definition.
”RAEGOKKA“ sa ”A“ enfieD :elpmaxE gnidroceR orcaM
8
Akko Macro V1.0 Calling Macros
Method A:
Enter the Macro mode by long pressing Fn+left Win. Then all keys will turn to pre-configured definitions with
locked Win key. Press Fn+Win to unlock Win key if necessary. In the Macro mode, you can use keys with
customized definitions.
Note, everytime you reboot or re-plugged the cable of the keyboard, the Macro mode will be turned off by
default and all keys will return to default definitions until you re-enter the Macro mode.
Method B:
Under the default key definition, you can also quickly call the customized content of specific keys through
“Fn+right Alt+the key that has been defined through Macro”. Note that you must first press Fn and then press
Alt to call the Macro.
