INSTRUCTION MANUAL

BRIEFCASE TURNTABLE

WITH BUILT IN SPEAKERS

MODEL: A60024

We declare that this product conforms to the following product legislation in accordance with

the following directive(s):

2014/30/EU Electromagnetic Compatibility Directive.

2014/35/EU Low Voltage Directive.

2011/65/EU Restriction of Hazardous Substances Directive.

2014/53/EU Radio Equipment Directive.

RKW Quality Assurance.

TECHNICAL DATA

This product is guaranteed for 12 months

from the date of the original purchase.

If any defect arises due to faulty materials

or workmanship, the faulty product must be

returned to the place of purchase.

Refund or replacement is at the discretion

of the retailer.

The following conditions apply:

The product must be returned to the retailer

with the proof of purchase.

The product must be installed and used in

accordance with the instructions contained

in this instruction guide.

This item is for domestic purposes only.

This guarantee does not cover wear and

tear, damage, misuse or consumable parts

RKW has limited responsibility for incidental

or consequential loss or damage.

Valid in the UK and Eire only.

MODEL NO: A60024

POWER SUPPLY

PRODUCT: DC 5V 1A

ADAPTOR:

INPUT: 100-240V ~50/60HZ 0.3A

OUTPUT: DC 5V 1.0A

DECLARATION OF CONFORMITY

GUARANTEE

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

SAFETY INFORMATION

Important safety instructions – read

carefully before use.

It is important that this instruction

manual should be retained with

the Portable Record Player for

future reference. These warnings

have been provided in the interest

of safety. You MUST read them

carefully before installation or use.

WARNING

• Check that the voltage of the

main circuit corresponds with

the rating of the appliance

before operating.

• Please ensure that the appliance

is used on a stable, level, and

heat resistant surface.

• Do not immerse cords, plugs

or any part of the appliance in

water or any other liquid.

• Do not leave the appliance

unattended while it is operating.

• Close supervision is necessary

when any appliance is used by

or near children or pets.

• This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

• Children shall not play with the

appliance.

• Cleaning and user maintenance

shall not be made by children

without supervision.

• Switch off at the wall socket

then remove the plug from the

socket when not in use or before

cleaning.

• If the supply cord or

appliance is damaged, stop

using the appliance immediately

and seek advice from the

manufacturer or its service

agent or a similarly qualified

person.

• Do not let the cord hang over the

edge of a table or counter or let

it come into contact with any hot

surfaces.

• The use of accessory

attachments is not

recommended by the appliance

manufacturer, apart from those

supplied with this product.

• Do not pull the plug out by the

cord as this may damage the

plug and/or the cable.

• Do not use this product for

anything other than its intended

use.

• This appliance is for household

use only.

• Do not carry the appliance by

the power cord.

• Do not use the appliance

outdoors.

• Do not use in direct sunlight

• Do not use in wet or damp

conditions

• Do not sit the product on or

near sources of electromagnetic

pollution, vibration or where the

ventilation is poor as this may

cause damage to the product

or could interfere with other

products.

• Do not place containers filled

with water or any other liquid

on the top of the product as this

may damage the product.

• When handling electrical items

ensure that your hands are dry.

• Never disconnect the plug by

pulling the power cable as this

may damage the plug and/or

socket.

• If water has entered the body of

the product please switch off at

the wall socket and then consult

a qualified electrician for an

inspection and /or repair.

• Should the product malfunction

due to electrostatic discharge,

switch off at the wall socket and

allow 30 minutes for the charge

to dissipate before reconnecting

the power supply.

• Ensure that there are no

metallic objects placed in the

internal space of the product as

this may damage the product

and cause a risk of electric

shock to the user.

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

DISPOSAL

DISPOSAL INSTRUCTIONS FOR AKAI

ITEMS IN ACCORDANCE WITH THE WEEE

DIRECTIVE.

APPLIANCES BEARING THE SYMBOL

SHOWN MAY NOT BE DISPOSED OF IN

DOMESTIC RUBBISH.

YOU ARE REQUIRED TO DISPOSE OF THE

OLD ELECTRICAL AND ELECTRONIC

APPLIANCES LIKE THIS SEPARATELY,

PLEASE VISIT :

WWW.RECYCLE-MORE.CO.UK OR

WWW.RECYCLENOW.CO.UK

FOR ACCESS TO INFORMATION ABOUT THE

RECYCLING OF ITEMS.

THE WEEE DIRECTIVE, INTRODUCED

IN AUGUST 2006 STATES THAT ALL

ELECTRICAL ITEMS MUST BE RECYCLED

RATHER THAN TAKEN TO LANDFILL.

PLEASE ARRANGE TO TAKE THIS

APPLIANCE TO YOUR LOCAL REFUSE

CENTRE.

PACKAGE CONTENTS

PART IDENTIFICATION

1. DUST COVER

2. LOCK CATCH

3. CENTRE PIECE - USE THIS WHEN

PLAYING 45RPM RECORDS WITH CUT

OUT CENTRES

4. TONE ARM LIFT

5. AUTO STOP CONTROL

6. AUX IN

7. ON/OFF DIAL

8. HEADPHONE JACK

9. SPEED SELECTION -

3 SPEEDS CHOICES: 33, 45, 78 RPM

10. SPEAKER

11. CARTRIDGE

12. HANDLE

13. TURNTABLE

FEATURES AND CONTROLS

1. INSTRUCTION MANUAL

2. PORTABLE RECORD PLAYER

3. ADAPTOR

4. SPARE STYLUS

5. AUX CABLE

78910111213

1 3 4

USING YOUR APPLIANCE

BEFORE FIRST USE

Remove the stylus protector.

Ensure the tone arm is free to move.

Ensure the product is placed a level surface

in a dry environment free of dust and with

good ventilation. Make sure the turntable

can not be knocked or bumped, and that the

power cable will NOT cause a trip hazard.

MAINS CONNECTION

Plug the Portable Record Player into a

mains supply.

AUX-IN

1. Use an AUX cable (included) and plug

one end of the cable into the line in jack.

2. Plug the other end into the line-out

jack or headphone jack of your external

audio device. This enables you to listen

to music from your phone or tablet

through the speakers on the record

player.

You can now control the volume using your

record player.

All other functions are controlled using your

external audio device as usual.

NOTE: If you have connected the aux cable

into a headphone jack you may need to

adjust the volume control on both the record

player and your audio device.

AMPLIFIER CONNECTION (IF REQUIRED)

Whilst you can listen to your new turntable

using the built in speakers you may wish to

connect it to your existing Hi Fi system.

Connect the audio plugs to the Line input on

your mixer or amplifier using an RCA cable

(not supplied)

• Red plug into R/H channel input.

• White plug into L/H channel input.

PLAYING A RECORD

1. Place the record of your choice on the

turntable. If required, do not forget to

place the centre piece on the record

spindle.

2. Choose the desired playing speed using

the speed selection switch between 33,

45 and 78 RPM.

3. Turn on the ON/OFF dial (this dial also

controls the volume).

4. Release the tone arm lock.

5. Raise the arm with your hand lightly

6. Place the stylus vertically over the first

track of the record, the turntable will

start turning automatically.

7. Put down the stylus slowly on to the

record to play.

8. When a record comes to the end, the

turntable will stop automatically if the

auto-stop switch is in the ON position.

9. If the switch is in the off position then it

will keep revolving until the tone arm is

returned to the tone arm rest.

10. Lift up the tone arm and put it on the

rest when finished.

11. Replace the protective cap on the stylus

and close the tone arm lock.

12. Turn off power at mains.

TROUBLESHOOTING

Problem Possible cause Solution

The unit does not

respond (no power).

1. The unit is disconnected

from the AC outlet.

2. The AC outlet has no

power.

Connect to the AC outlet.

Try the unit on another outlet

No sound. 1. Volume not adjusted.

2. Wrong source selected.

3. Device not turned ON.

4. Volume set too low.

Adjust the volume level.

Select the correct source.

Turn ON the device.

Rotate the volume control to turn the

sound level up.

Sound is distorted. Volume level is set too high. Decrease the volume.

Unit becomes warm

after extended play at

high volume.

This is normal. Turn the unit off for some time or

lower the volume.

CLEANING AND CARE

CLEANING & MAINTENANCE

1. Always disconnect the equipment

from the power supply before

cleaning.

2. Clean the equipment with a soft,

damp, lint free cloth.

3. Do not use abrasives or harsh

cleaners.

REPLACING THE STYLUS

Replace your stylus periodically

(approximately every 250 hours).

1. Push the arm lock to release the tone

arm.

2. Take off cap of the cartridge to expose

the stylus.

3. Gently separate the cartridge from the

socket.

4. Take off the audio line from the

cartridge.

5. Replace the stylus with a new one and

reverse the above operations

NOTE: Please exercise extreme care whilst

performing this operation to avoid the tone

arm and audio wires from being damaged.

Dust the stylus from time to time using a

very soft brush dipped in alcohol (brushing

from back to front of the cartridge)

When transporting your record player do

not forget to:

• Replace the protective cap on the

stylus.

• Put the rest clip into the pick-up arm.

NOTES

Table des matières

Autres manuels Akai Intervenants

Akai

Akai A58095 Manuel utilisateur

Akai

Akai Acube Manuel utilisateur

Akai

Akai CEU6800-BT Manuel utilisateur

Akai

Akai CS6 SHINE Manuel utilisateur

Akai

Akai ACS-656 Manuel utilisateur

Akai

Akai A58216 Manuel utilisateur

Akai

Akai CEU7300-BT Manuel utilisateur

Akai

Akai A58003 Manuel utilisateur

Akai

Akai A58076 Manuel utilisateur

Akai

Akai Vibes A50000 Manuel utilisateur

Akai

Akai ASB8I Manuel utilisateur

Akai

Akai TB340-47 Manuel utilisateur

Akai

Akai ABTS-80 Manuel utilisateur

Akai

Akai DJ-222 Manuel utilisateur

Akai

Akai EIE Pro Manuel utilisateur

Akai

Akai GL703-BT Manuel utilisateur

Akai

Akai SYDNEY ABT-52 Manuel utilisateur

Akai

Akai CEU6800-BT Manuel utilisateur

Akai

Akai sonisk A58086 Manuel utilisateur

Akai

Akai A58072 Manuel utilisateur

Akai

Akai SDB-2680 Manuel utilisateur

Akai

Akai HT014A-5086F Manuel utilisateur

Akai

Akai A3 REFLEXO Manuel utilisateur

Akai

Akai ACS-506 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
