15. EQUALIZER (DSP)
Press DSP to select between (Classic, Rock, POP, Flat) equalizer modes.
16. LCD DISPLAY
The Liquid Crystal Display will display the current state of the unit.
17. OPEN FRONT PANEL BUTTON
Press button and the front panel will be open.
CD/MP3/WMA CONTROL LOCATION OF PARTS
TRACK/SEARCH BUTTON (11)
FORWARD AND REVERSE TRACK SEARCH (or changing songs)
Press the SKIP button ( or ) during play to go to the desired track(song).
....REVERSE ....FORWARD
Press and hold the SKIP button ( or ) during play to scan the disc at high speed. When the desired music section of the disc
is found, release the button. Normal play will resume.
18. CD SLOT
19. CD EJECT BUTTON
Press the button to remove the CD.
20. PAUSE BUTTON
During “PLAY”, press (20) ‘PAU’ button to “PAUSE”. Press it again to resume play.
21. REPEAT BUTTON
When this button is pressed, ‘RPT ON’ indication is displayed and play of the selected track will be continually repeated until the
Track repeat mode is cancelled by pressing ‘RPT’ button again.
22. INTRO BUTTON (Preview all Tracks)
When this button is pressed, ‘INT ON’ indication is displayed and the rst several seconds of each track of the disc are played.
Press again to stop intro and listen to track.
23. RANDOM BUTTON
When this button is pressed, ‘RDM ON’ indication is displayed and each track of the disc are played in random instead of normal
progression. To cancel RANDOM mode, press ‘RDM’ button (23) again.
24, 25. FOLDER DOWN/UP (In case of MP3/WMA les)
M5: Folder down / M6: Folder up
HOW TO SELECT MP3/WMA FILES
1. Searching by Track:
• Press “A/PS”, then search track is activated.
• Turn “VOL” knob to left or right, select rst digit desired.
• Press “VOL” knob, then the rst digit is xed and second digit will ash.
• Turn “VOL” knob to left or right, select 2’nd 3’rd respectively.
• Press “BD/ENT”, the song selected will start.
2. Searching by Character:
• Press “A/PS” twice, then character search mode is activated.
• Turn “VOL” knob to left or right, you can select the desired letter.
• Press “VOL” knob, repeat steps above for 2’nd 3’rd character.
• The songs with the same character that you selected is displayed.
• Turn “VOL” knob to left or right, you can select the desired song.
• Press “BD/ENT”, then the song selected will start.
3. Searching by File Name:
• Press “A/PS” 3 times, then folder search is activated.
• Turn “VOL” knob to left or right, you can select the desired folder.
• Press “BD/ENT”, then the folder is xed and the rst le will be played.
26. RESET
Reset button (26) is placed on the housing.
The reset button is to be activated for the following reason:
• Initial installation of the unit when all wiring is completed.
• All the function button do not operate.
• Error symbol on the display.
Connecting it to Portable MP3 Player
27. USB Port
Using USB cable to connect Your Portable MP3 Player.
28. MULTI-MEDIA CARD (MMC) / SD CARD SLOT
Support MP3/WMA ID3 format music only.
* IMPORTANT INFORMATION:
BECAUSE OF THE GREAT VARIETY OF PRODUCTS WITH USB, SD AND MMC CARD PORTS AND THEIR SOMETIMES QUITE
MANUFACTURER-SPECIFIC FUNCTIONS WE CAN NEITHER GUARANTEE THAT ALL DEVICES WILL BE RECOGNIZED NOR
THAT ALL OPERATING OPTIONS THAT ARE POSSIBLE IN THEORY WILL ACTUALLY WORK
29. FRONT AUX IN
Convenient easy to use front “AUX IN” input jack, allows easy connection of Portable Media and digital MP3 Players.
