SERVICE MANUAL

DATA

NSX-BL13

COMPACT DISC / STEREO

CASSETTE RECEIVER

SIMPLE

S/M Code No. 09-005-428-8T4

 Replace this Service manual with Revision Publishing when it is issued.

BASIC TAPE MECHANISM : ZZ M-2 YPR1NM

BASIC CD MECHANISM : AZG-1 YZA3RNDM

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-1-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

O ACCESSORY 87-006-225-010 1D ANT,LOOP ANT NC2 LHSC2M CX-SNBL13

O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM LHSC2M CX-SNBL13

O ACCESSORY 8Z-NF9-701-210 1H RC UNIT,ZAS02 LHSC2M CX-SNBL13

! O APPEARANCE 87-CE3-023-010 0E BADGE,AIWA 30N SILV LHSC2M CX-SNBL13

O APPEARANCE 8A-NFA-030-010 -- CABI,REAR LH W/O SPEC LHSC2M CX-SNBL13

O APPEARANCE 8A-NFA-062-010 1D PANEL,TOP V-2 LHSC2M CX-SNBL13

! O APPEARANCE 8A-NFA-063-010 1C PANEL,LEFT V-2 LHSC2M CX-SNBL13

O APPEARANCE 8A-NFA-065-010 1C PANEL,RIGHT V-2 LHSC2M CX-SNBL13

O APPEARANCE 8A-NFZ-001-010 2A CABI,FR U LHSC2M CX-SNBL13

O APPEARANCE 8A-NFZ-002-010 1B PANEL,TRAY H LHSC2M CX-SNBL13

O APPEARANCE 8A-NFZ-003-110 1C BOX,CASS 1 LHSC2M CX-SNBL13

O APPEARANCE 8A-NFZ-004-110 1C BOX,CASS 2 LHSC2M CX-SNBL13

O CD 84-ZG1-245-210 0E CAP,OPTICAL LHSC2M CX-SNBL13

X CD M8-AZG-18K-030 -- AZG-1 YZA3RNDM LHSC2M CX-SNBL13

! X ELECTRICAL 87-069-033-010 0E CABLE,TIE LHSC2M CX-SNBL13

! O ELECTRICAL 87-085-185-010 0E BUSHING,AC CORD(E) CM-22B LHSC2M CX-SNBL13

O ELECTRICAL 88-906-251-110 1A FF-CABLE,6P 1.25 LHSC2M CX-SNBL13

O ELECTRICAL 88-913-221-110 1A FF-CABLE, 13P 1.25 220MM LHSC2M CX-SNBL13

! O ELECTRICAL PT 0001 8A-NFA-609-010 2M PT,ANF-A LH LHSC2M CX-SNBL13

! O ELECTRICAL W 0001 87-A80-157-010 1B AC CORD ASSY,E BLK CC LHSC2M CX-SNBL13

! O FRCB MECHA * 8A-NFA-208-010 0E GUIDE,FL 100-25 ANFA LHSC2M CX-SNBL13

! O FUNC/E.VR CN 0601 87-099-719-010 1B CONN,30P H BLK TYK-B(X) LHSC2M CX-SNBL13

! O FUNC/E.VR CN 0602 87-099-194-010 0E CONN,6P V BLK 6216 LHSC2M CX-SNBL13

S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7BSA LHSC2M CX-SNBL13

S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7BSA LHSC2M CX-SNBL13

S FUNC/E.VR IC 0601 87-A21-443-040 1C C-IC,M62495AFP LHSC2M CX-SNBL13

O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 PBSN LHSC2M CX-SNBL13

S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 LHSC2M CX-SNBL13

S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 LHSC2M CX-SNBL13

S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

O FUNC/E.VR R 0653 87-A11-144-080 0E CAP,TC U 0.1-50 K B LHSC2M CX-SNBL13

O FUNC/E.VR R 0654 87-A11-144-080 0E CAP,TC U 0.1-50 K B LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0605 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0606 87-010-179-080 0E C-CAP,S 1200P-50 K B GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0609 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0610 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0611 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0612 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0613 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0614 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0615 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0616 87-010-385-080 0E CAP,E 220-25 M SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0617 87-010-385-080 0E CAP,E 220-25 M SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0618 87-010-405-080 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0630 87-016-669-080 0E C-CAP,S 0.1-25 K B LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0669 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0670 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

O FUNC/E.VR.LOCAL C 0677 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL C 0678 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL FB 0602 88-100-000-010 0E PLATING-JW, 0.58 SN95 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0503 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0504 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0601 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0603 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0604 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0606 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0607 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0612 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0613 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0614 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0615 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL JR 0617 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0590 88-118-472-080 0E C-RES,S 4.7K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0599 88-118-472-080 0E C-RES,S 4.7K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0601 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0602 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0603 88-118-562-080 0E C-RES,S 5.6K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0604 88-118-562-080 0E C-RES,S 5.6K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0605 88-118-123-080 0E C-RES,S 12K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0606 88-118-123-080 0E C-RES,S 12K-1/10W J LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-2-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

X FUNC/E.VR.LOCAL R 0607 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0608 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0609 88-118-562-080 0E C-RES,S 5.6K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0610 88-118-562-080 0E C-RES,S 5.6K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0611 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0612 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0613 88-121-472-080 0E RES,4.7K-1/8W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0614 88-121-472-080 0E RES,4.7K-1/8W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0615 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0616 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0619 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0620 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0621 88-128-564-080 0E C-RES, 560K-1/8W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0622 88-128-564-080 0E C-RES, 560K-1/8W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0625 88-118-472-080 0E C-RES,S 4.7K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0626 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0627 88-118-123-080 0E C-RES,S 12K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0631 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0632 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0634 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0635 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0637 88-118-272-080 0E C-RES,S 2.7K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0638 88-118-272-080 0E C-RES,S 2.7K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0639 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0640 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0649 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0650 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0651 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0661 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X FUNC/E.VR.LOCAL R 0662 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

O KNOB 8A-NFA-018-010 0E REFLECTOR,ECO LHSC2M CX-SNBL13

O KNOB 8A-NFZ-008-010 0E KEY,POWER LHSC2M CX-SNBL13

O KNOB 8A-NFZ-009-010 1B KEY,FUN LHSC2M CX-SNBL13

O KNOB 8A-NFZ-010-010 1A KEY,OPE LHSC2M CX-SNBL13

O KNOB 8A-NFZ-011-010 0E KNOB,RTRY VOL LHSC2M CX-SNBL13

O KNOB 8A-NFZ-012-010 0E RING,VOL LHSC2M CX-SNBL13

O KNOB 8A-NFZ-013-110 1B KEY,CD LHSC2M CX-SNBL13

O KNOB 8A-NFZ-016-110 0E KEY,CASS 1 LHSC2M CX-SNBL13

O KNOB 8A-NFZ-017-110 0E KEY,CASS 2P LHSC2M CX-SNBL13

X LBL,POP 8A-NFZ-972-110 0E LBL,POP LHL LHSC2M CX-SNBL13

X LBL,POP 8A-NFZ-980-010 0E LBL,POP JLHR LHSC2M CX-SNBL13

X LOCAL PACKING 87-B40-098-010 0E BAG,PV 0.025-650-750 PL LHSC2M CX-SNBL13

X LOCAL PACKING 8A-NFZ-873-010 -- CUSHION,FRONT BR LHSC2M CX-SNBL13

X LOCAL PACKING 8A-NFZ-874-010 -- CUSHION,REAR BR LHSC2M CX-SNBL13

X LOCAL PACKING 8A-NFZ-875-010 -- CTN,PRINTED BR LHSC2M CX-SNBL13

X LOCAL PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 LHSC2M CX-SNBL13

X LOCAL PLATE 8A-NFZ-061-010 -- LBL,SPEC LSC2M BL13 LHSC2M CX-SNBL13

X LOCAL PRINTED DU 87-B40-086-010 0E BAG,PV 0.04-230-400 PL LHSC2M CX-SNBL13

O LOCAL PRINTED DU 8A-NFZ-920-010 -- IB,LH(P)CCE -BL14J LHSC2M CX-SNBL13

O LOCAL SCREW 87-067-581-010 0E BVT2+3-15 W/0 SL0T LHSC2M CX-SNBL13

O LOCAL SCREW 87-067-641-010 0E UTT2+3-8 W/O SLOT BLK LHSC2M CX-SNBL13

O LOCAL SCREW 87-067-688-010 0E BVTT+3-6 LHSC2M CX-SNBL13

O LOCAL SCREW 87-067-703-010 0E BVT2+3-10 W/0 SL0T LHSC2M CX-SNBL13

O LOCAL SCREW 87-721-096-410 0E QT2+3-10 W/O SLOT LHSC2M CX-SNBL13

O LOCAL SCREW 87-721-097-410 0E QT2+3-12 W/O SLOT LHSC2M CX-SNBL13

O LOCAL SCREW 87-723-096-410 0E QT2+3-10 W/O SLOT BLK LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0771 87-010-263-080 0E CAP,E 100-10 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0772 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) C 0781 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0782 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0783 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0784 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0785 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0786 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0788 87-010-149-080 0E C-CAP,S 5P-50 C CH GRM LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0789 87-A12-052-080 -- C-CAP,S 0.033-25 J B LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0790 87-A12-052-080 -- C-CAP,S 0.033-25 J B LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0791 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0792 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0793 87-010-404-080 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-3-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

O LOCAL TUNER(IF) C 0795 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0796 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0797 87-010-405-080 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0798 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0799 87-010-407-080 0E CAP,E 33-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0800 87-012-369-080 0E C-CAP,S 0.047-50 Z F LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0801 87-010-403-080 0E CAP,E 3.3-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0802 87-012-369-080 0E C-CAP,S 0.047-50 Z F LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0803 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0804 87-010-263-080 0E CAP,E 100-10 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0807 87-010-400-080 0E CAP,E 0.47-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0808 87-010-401-080 0E CAP,E 1-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0809 87-010-401-080 0E CAP,E 1-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0810 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0814 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0815 87-010-403-080 0E CAP,E 3.3-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0816 87-010-403-080 0E CAP,E 3.3-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0821 87-010-405-080 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

X LOCAL TUNER(IF) C 0822 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0823 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0824 87-010-404-080 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(IF) C 0825 87-010-596-080 0E C-CAP,S 0.047-16 K R C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) D 0801 88-100-000-010 0E PLATING-JW, 0.58 SN95 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0780 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0781 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0785 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0786 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0792 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0795 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0797 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) JR 0801 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(IF) R 0790 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0791 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0793 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0795 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0801 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0802 88-118-223-080 0E C-RES,S 22K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0803 88-128-183-080 0E C-RES, 18K-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0804 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0805 88-118-332-080 0E C-RES,S 3.3K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0806 88-118-682-080 0E C-RES,S 6.8K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0809 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0810 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0811 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0812 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0813 88-118-224-080 0E C-RES,S 220K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0814 88-118-105-080 0E C-RES,S 1M-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0815 88-121-682-080 0E RES,6.8K-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0818 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0821 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0823 88-118-333-080 0E C-RES,S 33K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0824 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0825 88-118-473-080 0E C-RES,S 47K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(IF) R 0826 88-118-223-080 0E C-RES,S 22K-1/10W J LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0971 87-010-381-080 0E CAP,E 330-16 M SME LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0972 87-010-404-080 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0973 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0974 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0979 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0981 87-010-260-080 0E CAP,E 47-25 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0982 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0983 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0984 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0987 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0991 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0992 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0993 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0995 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0997 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) C 0998 87-010-260-080 0E CAP,E 47-25 M 11L SME LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-4-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

X LOCAL TUNER(PLL) JR 0971 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0972 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0973 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0974 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0976 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0977 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) JR 0988 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0975 88-118-562-080 0E C-RES,S 5.6K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0976 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0977 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0978 88-118-681-080 0E C-RES,S 680-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0980 88-118-684-080 0E C-RES,S 680K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0981 88-121-471-080 0E RES,470-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0982 88-118-822-080 0E C-RES,S 8.2K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0983 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0984 88-121-181-080 0E RES,180-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0985 88-121-471-080 0E RES,470-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0986 88-118-222-080 0E C-RES,S 2.2K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0987 88-121-472-080 0E RES,4.7K-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0988 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0989 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0990 88-118-563-080 0E C-RES,S 56K-1/10W J LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) R 0991 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0992 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) R 0993 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0994 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

O LOCAL TUNER(PLL) R 0995 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0996 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0997 88-118-154-080 0E C-RES,S 150K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0998 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(PLL) R 0999 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RDS) JR 0871 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0842 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0843 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0844 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0845 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0846 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0847 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0848 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0849 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0850 87-010-260-080 0E CAP,E 47-25 M 11L SME LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0851 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0852 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0853 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0858 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0859 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0860 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

X LOCAL TUNER(RF) C 0940 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0959 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0960 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0961 87-010-152-080 0E C-CAP,S 8P-50 D CH GRM LHSC2M CX-SNBL13

O LOCAL TUNER(RF) C 0963 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 LHSC2M CX-SNBL13

X LOCAL TUNER(RF) D 0944 88-100-000-010 0E PLATING-JW, 0.58 SN95 LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0834 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0835 88-128-561-080 0E C-RES, 560-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0836 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0873 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0943 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0946 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0951 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0952 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0954 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) JR 0955 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0832 88-118-391-080 0E C-RES,S 390-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0836 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0839 88-118-151-080 0E C-RES,S 150-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0840 88-118-221-080 0E C-RES,S 220-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0850 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0851 88-118-470-080 0E C-RES,S 47-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0852 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-5-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

X LOCAL TUNER(RF) R 0853 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0854 88-118-331-080 0E C-RES,S 330-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0855 88-118-183-080 0E C-RES,S 18K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0856 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0857 88-118-181-080 0E C-RES,S 180-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0858 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0860 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0945 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0962 88-121-221-080 0E RES,220-1/8W J LHSC2M CX-SNBL13

X LOCAL TUNER(RF) R 0963 88-118-330-080 0E C-RES,S 33-1/10W J LHSC2M CX-SNBL13

X MECHANICAL 8A-NFA-202-110 1E CHAS,MAIN S6640 0.8 LHSC2M CX-SNBL13

! O MICON CN 0101 87-099-720-010 1B CONN,30P BLK TYK-B(P) LHSC2M CX-SNBL13

O MICON CN 0701 87-A60-673-010 0E CONN,9P H 2MM JMT LHSC2M CX-SNBL13

! O MICON CN 0801 87-099-015-010 0E CONN,13P V BLK 6216 LHSC2M CX-SNBL13

S MICON D 0102 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S MICON D 0103 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S MICON D 0104 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S MICON D 0105 87-A40-752-080 0E ZENER,UZ6.2BSC LHSC2M CX-SNBL13

S MICON D 0304 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S MICON D 0305 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

O MICON FL 0201 8A-NFA-604-010 2A FL,10-BT-224GNK LHSC2M CX-SNBL13

S MICON IC 0101 8A-NFA-615-010 1H C-IC,M38B57MCH-E236FP LHSC2M CX-SNBL13

S MICON IC 0102 87-A21-629-010 1B IC,SPS-442-1-N LHSC2M CX-SNBL13

O MICON L 0101 87-A50-434-010 0E COIL,CLK 4.19M(TOKO) LHSC2M CX-SNBL13

O MICON LED0101 87-A40-317-080 0E LED,SLR-342VCT31 RED LHSC2M CX-SNBL13

S MICON Q 0101 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S MICON Q 0102 87-A30-090-080 0E FET,2SK2541 LHSC2M CX-SNBL13

S MICON Q 0103 87-A30-484-080 0E C-TR,KRA102S LHSC2M CX-SNBL13

S MICON Q 0104 87-026-610-080 0E TR,KTC3198GR LHSC2M CX-SNBL13

S MICON Q 0105 87-A30-468-080 0E C-TR,KRC102S-RTK LHSC2M CX-SNBL13

S MICON Q 0701 87-A30-234-080 0E TR,CSC4115BC LHSC2M CX-SNBL13

O MICON S 0101 87-A91-555-010 1A SW,RTRY EC12E24504 LHSC2M CX-SNBL13

O MICON S 0301 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0302 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0303 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0304 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0305 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0306 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0307 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0308 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0309 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0321 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0322 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0323 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0324 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0325 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0326 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0327 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0328 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0329 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0330 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON S 0331 87-A90-164-080 0E SW,TACT SKQNAB(N) LHSC2M CX-SNBL13

O MICON SFR0701 87-024-431-080 0E SFR,3.3K H RH063MC LHSC2M CX-SNBL13

X MICON LOCAL * 8A-NFA-620-210 1C PWB,FRONT 2M LHSC2M CX-SNBL13

O MICON LOCAL C 0101 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0102 87-012-369-080 0E C-CAP,S 0.047-50 Z F LHSC2M CX-SNBL13

O MICON LOCAL C 0103 87-010-374-040 0E CAP,E 47-10 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0104 87-A10-797-040 0E CAP,E 47-35 M 5L SRM LHSC2M CX-SNBL13

O MICON LOCAL C 0105 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0107 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0108 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0109 87-012-369-080 0E C-CAP,S 0.047-50 Z F LHSC2M CX-SNBL13

O MICON LOCAL C 0110 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0111 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0113 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0114 87-010-154-080 0E C-CAP,S 10P-50 D CH GRM LHSC2M CX-SNBL13

O MICON LOCAL C 0115 87-010-175-080 0E C-CAP,S 560P-50 J SL LHSC2M CX-SNBL13

O MICON LOCAL C 0116 87-010-400-040 0E CAP,E 0.47-50 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0117 87-016-460-080 0E C-CAP,S 0.22-16 K B LHSC2M CX-SNBL13

O MICON LOCAL C 0118 87-A10-189-040 0E CAP,E 220-10 M 5L LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-6-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

O MICON LOCAL C 0119 87-A10-189-040 0E CAP,E 220-10 M 5L LHSC2M CX-SNBL13

O MICON LOCAL C 0120 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM LHSC2M CX-SNBL13

O MICON LOCAL C 0123 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0124 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0125 87-010-405-040 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0126 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O MICON LOCAL C 0129 87-010-374-040 0E CAP,E 47-10 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0210 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM LHSC2M CX-SNBL13

O MICON LOCAL C 0212 87-010-404-040 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0213 87-010-404-040 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O MICON LOCAL C 0701 87-010-384-040 0E CAP,E 100-25 M 11L SME LHSC2M CX-SNBL13

X MICON LOCAL JR 0101 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0104 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0105 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0106 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0107 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0108 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0109 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0110 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0111 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0112 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL JR 0201 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0202 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0301 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0302 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0303 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0305 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL JR 0701 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL R 0104 88-128-102-080 0E C-RES, 1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0105 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0106 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0107 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0108 88-118-393-080 0E C-RES,S 39K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0109 88-128-101-080 0E C-RES, 100-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0110 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL R 0111 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0112 88-121-101-080 0E RES,100-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0113 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0114 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0115 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0116 88-100-000-010 0E PLATING-JW, 0.58 SN95 LHSC2M CX-SNBL13

X MICON LOCAL R 0117 88-121-109-080 0E RES,1-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0118 88-121-100-080 0E RES,10-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0119 88-118-473-080 0E C-RES,S 47K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0121 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0122 88-118-471-080 0E C-RES,S 470-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0123 88-118-563-080 0E C-RES,S 56K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0125 88-118-100-080 0E C-RES,S 10-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0126 88-128-223-080 0E C-RES, 22K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0127 88-118-823-080 0E C-RES,S 82K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0128 88-121-103-080 0E RES,10K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0130 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0131 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0132 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0133 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0134 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0135 88-118-224-080 0E C-RES,S 220K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0136 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0137 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0138 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0139 88-118-224-080 0E C-RES,S 220K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0140 88-118-472-080 0E C-RES,S 4.7K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0141 88-118-124-080 0E C-RES,S 120K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0142 88-118-333-080 0E C-RES,S 33K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0143 88-118-153-080 0E C-RES,S 15K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0144 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0145 88-118-184-080 0E C-RES,S 180K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0146 88-118-153-080 0E C-RES,S 15K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0147 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0148 88-118-182-080 0E C-RES,S 1.8K-1/10W J LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-7-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON LOCAL R 0149 88-128-100-080 0E C-RES, 10-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0150 88-118-471-080 0E C-RES,S 470-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0151 88-118-479-080 0E C-RES,S 4.7-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0152 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0154 88-118-683-080 0E C-RES,S 68K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0157 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X MICON LOCAL R 0158 88-118-333-080 0E C-RES,S 33K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0202 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0203 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0204 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0205 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0206 88-128-472-080 0E C-RES, 4.7K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0207 88-128-472-080 0E C-RES, 4.7K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0208 88-128-681-080 0E C-RES, 680-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0209 88-128-681-080 0E C-RES, 680-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0301 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0302 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0303 88-118-821-080 0E C-RES,S 820-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0304 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0305 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0306 88-121-122-080 0E RES,1.2K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0307 88-121-182-080 0E RES,1.8K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0308 88-118-182-080 0E C-RES,S 1.8K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0309 88-121-272-080 0E RES,2.7K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0321 88-121-103-080 0E RES,10K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0322 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0323 88-118-821-080 0E C-RES,S 820-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0324 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0325 88-121-122-080 0E RES,1.2K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0326 88-121-122-080 0E RES,1.2K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0327 88-118-182-080 0E C-RES,S 1.8K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0328 88-121-182-080 0E RES,1.8K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0329 88-121-272-080 0E RES,2.7K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0330 88-121-332-080 0E RES,3.3K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0331 88-118-472-080 0E C-RES,S 4.7K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0341 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0342 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0343 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0344 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0610 88-118-104-080 0E C-RES,S 100K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0611 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X MICON LOCAL R 0701 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0702 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0703 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0704 88-118-682-080 0E C-RES,S 6.8K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0705 88-118-821-080 0E C-RES,S 820-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0706 88-118-822-080 0E C-RES,S 8.2K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0707 88-118-393-080 0E C-RES,S 39K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0708 88-118-331-080 0E C-RES,S 330-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0709 88-118-123-080 0E C-RES,S 12K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0801 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0802 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0803 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0804 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0805 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0806 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0807 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0808 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0809 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X MICON LOCAL R 0810 88-121-101-080 0E RES,100-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0811 88-121-101-080 0E RES,100-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0812 88-121-101-080 0E RES,100-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0813 88-121-102-080 0E RES,1K-1/8W J LHSC2M CX-SNBL13

X MICON LOCAL R 0821 88-118-474-080 0E C-RES,S 470K-1/10W J LHSC2M CX-SNBL13

O OTHERS 82-NF7-218-010 0E SPR-T,CASS LHSC2M CX-SNBL13

! X OTHERS 86-NFZ-205-010 0E CUSH, 12.5-15.5-2 (NP) LHSC2M CX-SNBL13

! O OTHERS 86-NFZ-231-010 1A DMPR,70 LHSC2M CX-SNBL13

X OTHERS 87-064-080-010 0E BINDER,WIRE LHSC2M CX-SNBL13

X OTHERS 87-NF4-226-010 0E SH,PT 25-15-1 W/ADH LHSC2M CX-SNBL13

O OTHERS 8A-NF8-205-010 0E HLDR,IC LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-8-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

! O OTHERS 8A-NF9-211-010 0E HLDR,PWB PT HI LHSC2M CX-SNBL13

X OTHERS 8A-NFA-206-010 1H HT-SINK,S LH(35W) LHSC2M CX-SNBL13

O OTHERS 8A-NFA-212-010 1B PLATE,PL LH LHSC2M CX-SNBL13

O OTHERS 8A-NFA-214-010 0E HLDR,PWB M ANFA LHSC2M CX-SNBL13

X OTHERS 8A-NFA-218-010 0E CUSH-R, 20-10-7.2 W/ADH LHSC2M CX-SNBL13

X OTHERS 8A-NFZ-201-010 0E PLATE,EARTH MECHA LHSC2M CX-SNBL13

O OTHERS 8Z-NB8-240-010 0E COVER, PL LHSC2M CX-SNBL13

S P-AMP(LF) D 0101 87-A40-269-080 0E C-DIODE,MC2836 LHSC2M CX-SNBL13

S P-AMP(LF) D 0116 87-A40-270-080 0E C-DIODE,MC2838 LHSC2M CX-SNBL13

S P-AMP(LF) IC 0101 87-A21-397-010 2A IC,STK490-070 LHSC2M CX-SNBL13

O P-AMP(LF) J 0101 87-A60-602-010 1A JACK,DIA6.3 BLK ST W/SW TC LHSC2M CX-SNBL13

! O P-AMP(LF) J 0203 87-A60-238-010 1A TERMINAL,SP 4P (MSC) LHSC2M CX-SNBL13

O P-AMP(LF) L 0101 87-A50-610-010 0E COIL,1UH K(MDEC) LHSC2M CX-SNBL13

O P-AMP(LF) L 0102 87-A50-610-010 0E COIL,1UH K(MDEC) LHSC2M CX-SNBL13

S P-AMP(LF) Q 0123 87-A30-107-070 0E C-TR,CMBT5401 LHSC2M CX-SNBL13

S P-AMP(LF) Q 0124 87-A30-107-070 0E C-TR,CMBT5401 LHSC2M CX-SNBL13

S P-AMP(LF) Q 0126 87-A30-107-070 0E C-TR,CMBT5401 LHSC2M CX-SNBL13

S P-AMP(LF) Q 0130 87-A30-106-040 0E C-TR,CMBT5551 LHSC2M CX-SNBL13

O P-AMP(LF) R 0131 87-A00-258-080 0E RES,M/F 0.22-1W J LHSC2M CX-SNBL13

O P-AMP(LF) R 0132 87-A00-258-080 0E RES,M/F 0.22-1W J LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0101 87-010-183-080 0E C-CAP,S 2700P-50 K B GRM LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0102 87-010-183-080 0E C-CAP,S 2700P-50 K B GRM LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0103 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0104 87-010-545-080 0E CAP,E 0.22-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0105 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0106 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0107 87-010-404-080 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0108 87-010-404-080 0E CAP,E 4.7-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0111 87-010-391-080 0E CAP,E 10-35 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0112 87-010-391-080 0E CAP,E 10-35 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0113 87-010-405-080 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0114 87-010-405-080 0E CAP,E 10-50 M 11L SME LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0119 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0120 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0125 87-012-368-080 0E C-CAP,S 0.1-50 Z F LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0126 87-012-368-080 0E C-CAP,S 0.1-50 Z F LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0127 87-012-368-080 0E C-CAP,S 0.1-50 Z F LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0128 87-012-368-080 0E C-CAP,S 0.1-50 Z F LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0129 87-A11-572-080 0E C-CAP,S 0.015-50 K B LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0130 87-A11-572-080 0E C-CAP,S 0.015-50 K B LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0131 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0132 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0133 87-010-186-080 0E C-CAP,S 4700P-50 K B C2012 LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL C 0140 87-010-182-080 0E C-CAP,S 2200P-50 K B C2012 LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL JR 0101 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL JR 0102 88-129-000-080 0E C-JUMPER,3216 LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL JR 0103 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL JR 0105 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL JR 0109 88-118-000-080 0E C-JUMPER,S LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0103 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0104 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0105 88-118-223-080 0E C-RES,S 22K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0106 88-118-223-080 0E C-RES,S 22K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0107 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0108 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0109 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0110 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0111 88-118-821-080 0E C-RES,S 820-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0112 88-118-821-080 0E C-RES,S 820-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0113 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0114 88-118-273-080 0E C-RES,S 27K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0123 88-128-332-080 0E C-RES, 3.3K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0124 88-128-332-080 0E C-RES, 3.3K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0125 88-128-332-080 0E C-RES, 3.3K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0126 88-128-332-080 0E C-RES, 3.3K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0133 88-118-332-080 0E C-RES,S 3.3K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0134 88-118-332-080 0E C-RES,S 3.3K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0135 88-118-222-080 0E C-RES,S 2.2K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0136 88-118-222-080 0E C-RES,S 2.2K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0137 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

PARTS LIST

-9-

! =! SAFTY PARTS

C=Components marked

All components used on this model at the production line are shown in this service manual.

However,pleasenotethatnotallcomponentswillbeavailableassparepartsforafter-salesservice.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

K NO. =Only use japanese.

CUNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX

X P-AMP(LF) LOCAL R 0138 88-118-101-080 0E C-RES,S 100-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0139 88-118-822-080 0E C-RES,S 8.2K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0140 88-118-822-080 0E C-RES,S 8.2K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0142 88-118-102-080 0E C-RES,S 1K-1/10W J LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL R 0143 87-A00-440-050 0E RES,220-1/2W J RP LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL R 0144 87-A00-440-050 0E RES,220-1/2W J RP LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL R 0145 87-A00-440-050 0E RES,220-1/2W J RP LHSC2M CX-SNBL13

O P-AMP(LF) LOCAL R 0146 87-A00-440-050 0E RES,220-1/2W J RP LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0147 88-130-100-080 0E RES,10-1/4W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0148 88-130-100-080 0E RES,10-1/4W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0149 88-128-100-080 0E C-RES, 10-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0150 88-128-100-080 0E C-RES, 10-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0159 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0160 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0165 88-128-222-080 0E C-RES, 2.2K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0166 88-128-222-080 0E C-RES, 2.2K-1/8W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0167 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0168 88-118-473-080 0E C-RES,S 47K-1/10W J LHSC2M CX-SNBL13

X P-AMP(LF) LOCAL R 0178 88-118-103-080 0E C-RES,S 10K-1/10W J LHSC2M CX-SNBL13

! O P-SUPPLY/PWB/FAN CNA0001 8A-NF8-653-010 1B CONN ASSY,9P TID-A(480) LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0013 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0014 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0015 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0016 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0017 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0018 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0019 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0020 87-A40-455-080 0E DIODE,RL203 GW LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0026 87-A40-553-080 0E DIODE,1N4003 LES LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0027 87-A40-553-080 0E DIODE,1N4003 LES LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0029 87-A40-774-080 0E ZENER,UZ24BSD LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0030 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0031 87-A40-764-080 0E ZENER,UZ10BSC LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0033 87-A40-553-080 0E DIODE,1N4003 LES LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0035 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0036 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0060 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0061 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0062 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0063 87-A40-270-080 0E C-DIODE,MC2838 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0064 87-A40-269-080 0E C-DIODE,MC2836 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0065 87-020-465-080 0E DIODE,1SS133 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0066 87-A40-768-080 0E ZENER,UZ16BSA LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0068 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0071 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0072 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0076 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN D 0077 87-A40-313-080 0E C-DIODE,MC2840 LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0002 87-026-609-080 0E TR,KTA1266GR LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0003 89-213-702-010 1A TR,2SB1370E LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0005 87-026-610-080 0E TR,KTC3198GR LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0006 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0008 87-A30-075-080 0E C-TR,2SA1235F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0009 87-026-609-080 0E TR,KTA1266GR LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0010 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0060 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0061 87-A30-075-080 0E C-TR,2SA1235F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0062 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0063 87-A30-075-080 0E C-TR,2SA1235F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0064 87-A30-076-080 0E C-TR,2SC3052F LHSC2M CX-SNBL13

S P-SUPPLY/PWB/FAN Q 0065 87-A30-075-080 0E C-TR,2SA1235F LHSC2M CX-SNBL13

! O P-SUPPLY/PWB/FAN WH 0001 87-A90-510-010 0E HLDR,WIRE 2.5-9P LHSC2M CX-SNBL13

X P-SUPPLY/PWB/FAN,LOC * 8A-NF9-630-410 1F PWB,COMB MAIN LHSC2M CX-SNBL13

X P-SUPPLY/PWB/FAN,LOC * 8A-NF9-631-410 -- PWB,MAIN LHSC2M CX-SNBL13

O P-SUPPLY/PWB/FAN,LOC C 0003 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O P-SUPPLY/PWB/FAN,LOC C 0004 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O P-SUPPLY/PWB/FAN,LOC C 0005 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O P-SUPPLY/PWB/FAN,LOC C 0006 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

O P-SUPPLY/PWB/FAN,LOC C 0009 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 LHSC2M CX-SNBL13

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Autres manuels Aiwa Autre

Aiwa

Aiwa Z-L20 Manuel utilisateur

Manuels Autre populaires d'autres marques

GO Industries

GO Industries 38017 Manuel utilisateur

Cissell

Cissell 30LBCMAN2 Manuel utilisateur

RIDGID

RIDGID K-60SP Manuel utilisateur

Gage Bilt

Gage Bilt GB751SH-5 Manuel utilisateur

OVE

OVE SIERRA 60 Manuel utilisateur

ReelCraft

ReelCraft 7800 OLB21 Manuel utilisateur

Body Armor 4x4

Body Armor 4x4 ECO-SERIES Manuel utilisateur

ROBLIN

ROBLIN DROP Guide de l'utilisateur

EMG

EMG EMG-ACB BARREL Manuel de service

MiniSolar

MiniSolar MT-150 Manuel utilisateur

Parkside

Parkside PSZ 250 B2 Manuel utilisateur

ABB

ABB REM 610 Manuel du produit

Parkside

Parkside 55992 Manuel du propriétaire

Skyjacker

Skyjacker F250 Manuel utilisateur

IBM

IBM IBM SYSTEM Z Guide d'installation

Grech Motors

Grech Motors G28 Manuel utilisateur

NOVAK

NOVAK BATTERY CARE SHEET Mode d’emploi

Telemotive

Telemotive blue PiraT Mini Guide de l'utilisateur
