AirLive WT-2000 ARM Manuel utilisateur

AirLive WT-2000ARM ADSL2/2+ Router 1

WT-2000 ARM

Wireless ADSL 2/2+ Modem Router

User’s Guide

AirLive WT-2000ARM ADSL2/2+ Router 2

The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an

information retrieval system, translated into any language, or transmitted in any form or by any means,

mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written

permission.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against radio interference in a

residential environment. AirLive WT-2000 ARM can generate, use and radiate radio frequency energy and, if

not installed and used in accordance with the instructions in this manual, may cause harmful interference to

radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If AirLive WT-2000

ARM does cause harmful interference to radio or television reception, which is found by turning the equipment

ON and OFF, the user is encouraged to try to reduce the interference by one or more of the following measures:

yAdjust or relocate the receiving antenna

yIncrease the separation between the equipment or device

yConsult a dealer or an experienced technician for assistance

CE Declaration of Conformity

This is to certify that this device complies the essential protection requirements of the European Council

Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22).

Compliance with the applicable regulations is dependent upon the use of shielded cables. It is the responsibility

of the user to procure the appropriate cables.

AirLive WT-2000ARM ADSL2/2+ Router 3

Contents

1. INTRODUCTION ...................................................1

1.1. FEATURES....................................................................2

1.2. MINIMUM REQUIREMENTS .............................................3

1.3. PACKAGE CONTENT......................................................3

1.4. HARDWARE PLACEMENT ...............................................4

1.4.1. Rear Panel ....................................................................... 4

1.4.2. Front LEDs ....................................................................... 5

2. HARDWARE INSTALLATION ..............................6

3. SETUP WIZARD....................................................7

4. IP ADDRESS SETTING ......................................13

5. WEB MANAGEMENT CONFIGURATION..........21

5.1. QUICK START .............................................................24

5.2. INTERFACE SETUP ......................................................29

5.2.1. Internet ........................................................................... 29

5.2.2. LAN ................................................................................ 34

5.2.3. Wireless.......................................................................... 37

5.3. ADVANCED SETUP ......................................................41

5.3.1. Firewall........................................................................... 41

5.3.2. Routing........................................................................... 42

5.3.3. NAT ................................................................................ 46

5.3.3.1. NAT........................................................................................ 46

5.3.3.2. DMZ ....................................................................................... 47

5.3.3.3. Virtual Server ......................................................................... 48

5.3.4. ADSL .............................................................................. 50

5.4. ACCESS MANAGEMENT ...............................................51

5.4.1. ACL ................................................................................ 51

5.4.2. IP Filter ........................................................................... 52

5.4.3. SNMP ............................................................................. 55

5.4.4. UPnP.............................................................................. 56

5.4.5. DDNS ............................................................................. 57

AirLive WT-2000ARM ADSL2/2+ Router 4

5.5. MAINTENANCE ............................................................59

5.5.1. Administrator .................................................................. 59

5.5.2. Time Zone ...................................................................... 60

5.5.3. Firmware ........................................................................ 61

5.5.4. System Restart............................................................... 62

5.5.5. Diagnostics..................................................................... 63

5.6. STATUS......................................................................64

5.6.1. Device Info ..................................................................... 64

5.6.2. System Log .................................................................... 65

5.6.3. Statistics ......................................................................... 66

6. TROUBLESHOOTING ........................................67

7. GLOSSARY.........................................................71

1. Introduction

Congratulations on purchasing this 802.11g Wireless LAN ADSL2+ Router. This

router is a cost-effective ADSL2+ router, with the combination of an ADSL2+

modem, router, Ethernet network switch and wireless access point, you can surf

the Internet through your ADSL2/2+ broadband connection without investing

other devices.

This router can support downstream transmission rates of up to 24Mbps and

upstream transmission rates of up to 1Mbps. It supports PPPoA (RFC 2364 -

PPP over ATM Adaptation Layer 5), RFC 1483/2684 encapsulation over ATM

(bridged or routed) and PPP over Ethernet (RFC 2516) to establish a connection

with ISP. The product also supports VC-based and LLC-based multiplexing.

With the web management interface, users can easily configure the various

functions of the router including DHCP server, NAT, virtual server, DMZ, access

control, IP filter, Firewall, PPTP/IPSec/L2TP pass-through, DDNS, UPnP,

Wireless and etc.

This router is a high performance and high-speed device that provides a full rate

of ADSL2+ standard with the superb reliability and a complete solution for home

and office application.

1.1. Features

ADSL2/2+ Compliance

•Support downstream rates of up to 24Mbps and upstream rates of up to

1Mbps.

•Compliant to ITU-T G.992.1 (G.dmt), G.992.2 (G.lite), G.992.3 (ADSL2),

G.992.4 (splitterless ADSL2), G.992.5 (ADSL2+) for Annex A, B. (Annex A

and B are supported in different H/W platform)

•Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1);

G.994.1 and G.996.1 (for ISDN only); G.991.1;G.lite (G992.2)).

•Multiple Protocols over AAL5 (RFC 1483/2684).

•PPP over AAL5 (RFC 2364).

•PPP over Ethernet (RFC 2516).

Support 802.11g Wireless Access Point

•Complies with IEEE 802.11g/b standard.

•High data rate – up to 54Mbps network speed.

•Supports 64-bit/128-bit WEP, WPA-PSK and WPA2-PSK wireless security

functions.

•Supports MAC address filtering.

Router

•NAT (Network Address Translation) IP Sharing

•Virtual Server

•DMZ

•VPN Pass Through (IPSec/PPTP/L2TP)

•SPI Anti-DOS Firewall

•DHCP Server and Client

Access Management

•ACL (Access Control)

•IP Filter

•UPnP (Universal Plug and Play)

•SNMP

•Dynamic DNS

1.2. Minimum Requirements

The following devices are necessary to configure and use the ADSL2+ Router:

•A PC with Pre-installed Ethernet Adapter (Required) and a Web-Browser

(Internet Explorer 4.0 or higher)

•RJ-45 Ethernet crossover cable (Included in the package)

•RJ-11 (ADSL Ready) phone Line

1.3. Package Content

•One ADSL2+ Router (Annex A or B)

•One Dipole Antenna

•One Power Adapter (12VDC, 1A)

•One RJ-45 Ethernet Cable (100 cm)

•One RJ-11 Telephone Line (180 cm)

•One Quick Installation Guide

•One CD with full User Manual

1.4. Hardware Placement

1.4.1. Rear Panel

1) Antenna Connector

The antenna connector of the router is reverse SMA connector. It allows you

to connecting an external antenna with reverse SMA connector to the router

easily.

2) Reset

The Reset button can be used to reset the router or restore to factory defaults.

zIf problems occur with your router, press the router’s reset button with a

pencil tip (for less than 5 seconds) and the router will re-boot itself,

keeping your original configurations.

zIf problems persist or you experience extreme problems or you forgot

your password, press the reset button for longer than 5 seconds and the

router will reset itself to the factory default settings (warning: your

original configurations will be replaced with the factory default settings)

3) Power Jack

Please plug the power adapter attached with the ADSL Router to the power

jack. The power adapter is 12VDC, 1A.

4) Local Area Network (LAN)

The router’s 4 LAN ports are where you connect your LAN’s PCs, printer

servers, hubs and switches etc.

5) ADSL

Connect the supplied RJ-11 telephone line to this port and your

ADSL/telephone network.

1.4.2. Front LEDs

On the router’s front panel there are LED lights that inform you of the router’s

current status. Below is an explanation of each LED and its description.

LED Light Status Description

On The router is readyPWR (Green)

Off Wireless LAN is disabled

Blinking Wireless traffic is transmitting or receiving

WLAN (Yellow)

On Connected to an ADSL DSLAN

successfully

ADSL (Green)

Blinking No connection

On The LAN cable is connected to the router

Off No network connection.

LAN LNK/ACT (Port 1-4)

Blinking Network traffic transferring or receiving

through the LAN port

2. Hardware Installation

Step 1. Connect the ADSL Line

Connect the router to your ADSL cable through the supplied RJ-11 telephone line.

Step 2. Connect the router to your LAN network

Connect the router to your PC, hub or switch by attached the Ethernet cable to

the LAN port of the router.

Step 3. Connect the Power Adapter to the Router

Connect the power adapter to the power jack on the rear panel of router.

Step4: Check the ADSL LED on the Router

The ADSL LED will be ON if the router is connected to the ADSL cable and

receives the ADSL signals successfully. If the LED is blinking, please contact

with your ISP (Internet Service Provider) to check the problem.

Note: You must use the power adapter shipped along with the router, do

NOT use any other power adapter from other sources.
