AIPTEK MobileCinema i20 Plus Manuel utilisateur

User’s Manual

Care and Safety Information

1. Keep the device and packaging materials out of the reach of infants and

children.

2. Avoid subjecting the power adapter and other contacts to dripping or splashing

water and dry your hands before you use it. Do not place objects filled with

liquids such as vases, etc. on or near the device.

3. Make sure that the used power outlet is always readily available and never

hidden. In case of emergency, use the power adapter to separate the device

from the power network.

4. Keep your device away from all flames such as candles and do not set them up

in the vicinity of the device.

5. Keep the unit at least 10 cm away from other objects. Make sure the ventilation

is not covered by newspapers, tablecloths, curtains, etc.

6. For your own safety, do not use the projector during thunderstorms or lightning.

7. Relative Humidity is 5~35°C, 80% (Max.), non-condensing.

8. The battery is integrated with the device. Do not dissemble and modify. The battery

should be replaced by qualified service staff only.

9. Ensure that the ambient room temperature is within -10~55°C

10.During the operation, this product may heat lightly, which is normal.

11.Wait before using if the device has been moved from a cold location into a

warm one. Any condensation that has formed may in certain circumstances

destroy the device. As soon as the device has reached room temperature it can

be used without risk.

12.Handle the product with care. Avoid contact with sharp objects. Keep device

away from metallic objects.

13.Place the projector on a flat surface. Any collision or falling to the ground is

likely to damage the product.

14.Do not drop or disassemble the product otherwise the warranty voids. Opening

or removing covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

15.Use only the accessories supplied by the

manufacturer.

16.Both product and user’s manual are subject to

further improvement or supplement without further

notice.

17.Avoid facing directly into the projector’s lens.

User’s Manual

Sicherheitshinweise:

1. Das Gerät und das Verpackungsmaterial außerhalb der Reichweite von

Kindern halten.

2. Das Netzteil nicht in Kontakt mit tropfendem oder fließendem Wasser kommen

lassen und Hände vor der Benutzung abtrocknen. Keine mit Flüssigkeiten

gefüllte Gegenstände, wie z.B. Vasen usw. auf oder in die Nähe des Gerätes

stellen.

3. Stellen Sie sicher, dass die verwendete Steckdose immer verfügbar und

niemals blockiert ist. Verwenden Sie im Notfall das Netzteil, um das Gerät vom

Stromnetz zu trennen.

4. Das Gerät von Flammen, wie z.B. Kerzen fernhalten und diese nicht in der

Nähe des Gerätes aufstellen.

5. Das Gerät mindestens 10 cm von anderen Gegenständen entfernt halten.

Stellen Sie sicher, dass die Lüftungsschlitze nicht durch Zeitungen,

Tischdecken, Vorhänge usw. blockiert werden.

6. Den Projektor zu Ihrer eigenen Sicherheit nicht während eines Gewitters oder

Blitzschlages verwenden.

7. Relative Luftfeuchtigkeit liegt bei 5 bis 35°C, 80% (max.), nicht kondensierend.

8. Der Akku ist im Gerät integriert. Nicht auseinander nehmen oder ändern. Der

Akku sollte nur von einer Fachkraft ausgetauscht werden.

9. Stellen Sie sicher, dass die Raumtemperatur innerhalb von -10 ist ~ 55°C liegt.

10.Dieses Produkt kann während des Betriebes etwas warm werden, was normal ist.

11.Warten Sie mit der Verwendung des Geräts etwas, wenn das es von einem

kalten an einen warmen Ort gebracht wurde. Kondenswasser kann das Gerät

unter bestimmten Umständen zerstören. Sobald das Gerät Raumtemperatur

erreicht hat, kann es ohne Risiko verwendet werden.

12.Produkt mit Vorsicht handhaben. Kontakt mit scharfen Gegenständen

vermeiden. Von Gegenständen aus Metall fernhalten.

13.Den Projektor auf eine flache Unterlage stellen. Stöße oder ein Herunterfallen auf den

Boden führt wahrscheinlich zu Schäden des Produktes.

14.Das Produkt nicht fallen lassen oder auseinander nehmen, da sonst die

Gewährleistung erlischt. Das Öffnen oder Entfernen von Abdeckungen kann sie

gefährlichen Spannungen und anderen Risiken aussetzen. Alle

Wartungsarbeiten von Fachpersonal durchführen lassen.

15.Nur vom Hersteller empfohlenes Zubehör

verwenden.

16.Sowohl das Produkt als auch das

Benutzerhandbuch unterliegen fortlaufenden

Verbesserungen oder Ergänzungen ohne

vorherige Mitteilung.

17.Nicht direkt in das Objektiv des Projektors sehen.

User’s Manual

Entretien et précaustion d’emploi (FR)

1. Attention - Evitez de vous placer en face de la lentille du

vidéo projecteur.

2. Evitez tout contact avec de l’eau, et gardez vos mains

sèches lors de l’utilisation.

3. Assurez-vous que la température de la pièce est comprise entre -10 et 55°C

4. Le taux d’humidité relative doit être de 80% au maximum entre 5 et 35°C, sans

condensation.

5. Ne pas faire tomber, frapper ou démonter cet appareil ; sinon la garantie sera

annulée.

Informazioni sulla cura e sulla sicurezza (IT)

1. Attenzione - Non guardare l’obiettivo in modo diretto.

2. Evitare il contatto con liquidi e utilizzare con mani asciutte.

3. Assicurarsi che la temperatura ambiente della stanza sia

compresa tra -10 e 55°C

4. L’umidità relativa deve essere compresa tra 5 e 35°C, all’80% (max.), senza

condensazione.

5. Non far cadere, non colpire e non smontare il dispositivo; in caso contrario la

garanzia verrà annullata.

Información de seguridad (ES)

1. Advertencia - Evite ponerse directamente en frente de las

lentes del proyector.

2. Avite cualquier contacto con el agua. Mantenga sus manos

secas durante su uso.

3. Asegúrese de que la temperatura ambiente de la sala sea de -10~55°C

4. Humedad relativa de 5~35°C, 80% (Máx.), no-condensada.

5. No caiga, golpee o desmonte el dispositivo, ya que de lo contrario se

invalidaría la garantía.

Δϣϼδϟ΍ ΕΎϣϮϠόϣΔϳΎϋήϟ΍ϭ(AR)

1.ήϳάΤΗ-νήόϟ΍ ίΎϬΟ ΔγΪόϟ ήηΎΒϣ ϞϜθΑ νήόΘϟ΍ ΐϨΠΗ.

2.ϟ΍ϭ ˬ˯ΎϤϟΎΑ ίΎϬΠϟ΍ ϝΎμΗ΍ ΐϨΠΗϡ΍ΪΨΘγϻ΍ ˯ΎϨΛ΃ ϦϴΘϓΎΟ ϚϳΪϳ ϰϠϋ υΎϔΤ.

3.ϦϴΑ Ύϣ ΔτϴΤϤϟ΍ Δϓήϐϟ΍ Γέ΍ήΣ ΔΟέΩ ϥ΃ Ϧϣ Ϊϛ΄Θϟ΍10ϰϟ·55ΔϳϮΌϣ ΔΟέΩ.

4.Ϧϣ ΔϴΒδϨϟ΍ ΔΑϮσήϟ΍ ϥϮϜΗ ϥ΃5ϰϟ·35ϝΩΎόϳ ΎϤΑ ˬΔΟέΩ80) %ϰμϗ΃ ΪΤΑ(ήϴϏ ˬ

ΔϔΜϜϣ.

5.ϥΎϤπϟ΍ ϖΣ ϞτΑ ϻ·ϭ ˭ίΎϬΠϟ΍ ϚϔΑ ϡϮϘΗ ϭ΃ ΐϘΜΗ ϭ΃ ςϘδΗ ϻ.

III

User’s Manual

FCC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation

is subjected to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with limits for a Class B

digital device, pursuant to Part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interference in residential

installations. This equipment generates, uses, and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause interference to radio or television

equipment reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Move the equipment away from the receiver.

- Plug the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/television technician for additional

suggestions.

You are cautioned that any change or modifications to the equipment not expressly

approved by the party responsible for compliance could void your authority to

operate such equipment.

(EN)

If the time arises to throw away your

product, please recycle all the

components possible.

Batteries and rechargeable batteries are

not to be disposed in your domestic

waste! Please recycle them at your local

recycling point.

Together we can help to protect the

environment.

User’s Manual

(DE)

Wenn die Lebensdauer des Produkts zu Ende

kommt, lassen Sie bitte möglichst alle

Komponenten recyceln. Bitte recyceln Sie

dieses Produkt ordnungsgemäß, wenn es

nicht mehr verwendet werden kann. Es kann

nicht als Haushaltsmüll behandelt werden. Es

muss separat über die verfügbaren

Rücknahme- und Sammelsysteme entsorgt

werden.

(FR)

Si il est temps de jeter votre produit, veuillez recycler tous les composants possibles. Si ce

produit est arrivé en fin de vie, veuillez s’il vous plait le recycler correctement. Il ne peut pas

être traité comme les ordures ménagères. Il doit être être apporté à un point de collecte

approprié pour le recyclage.

(IT)

Al momento di buttare via il prodotto, riciclare il maggior numero di componenti. Se questo

prodotto giunge alla fine del suo ciclo di vita, lo ricicli correttamente. Non può essere trattato

come rifiuto urbano. Deve essere smaltito separatamente attraverso l'appropriato sistema di

reso e di raccolta.

(ES)

Si ha llegado la hora de deshacerse del producto, recicle todos los componentes que pueda.

Si ha finalizado la vida útil de este producto, recíclelo adecuadamente. Debe deshacerse

del mismo de forma separada a través de los sistemas de recogida disponibles.

(AR)

΍Ϋ·ϥΎΣΖϗϭκϠΨΘϟ΍ϦϣˬΞΘϨϤϟ΍˯ΎΟήϟ΍ΓΩΎϋ·ήϳϭΪΗΔϓΎϛ˯΍ΰΟϷ΍ΔϨϜϤϤϟ΍.

ϻϢΘϳκϠΨΘϟ΍ϦϣΕΎϳέΎτΒϟ΍ΕΎϳέΎτΒϟ΍ϭΔϠΑΎϘϟ΍ΓΩΎϋϹϦΤθϟ΍

ϦϤοΕΎϔϠΨϤϟ΍ΔϴϟΰϨϤϟ΍!˯ΎΟήϟ΍ΓΩΎϋ·ΎϫήϳϭΪΗϯΪϟΰϛήϣΓΩΎϋ·

ήϳϭΪΘϟ΍ϲϠΤϤϟ΍ϚϳΪϟ.

Ύ˱όϣΎϨϨϜϤϳΓΪϋΎδϤϟ΍ϲϓΔϳΎϤΣΔΌϴΒϟ΍.

(NL)

Als het einde van de levensduur van het product is bereikt, moet u alle mogelijke

componenten recyclen. Batterijen en oplaadbare batterijen mogen niet bij het huishoudelijke

afval worden gegooid. Lever ze af bij uw lokale dienst voor recycling. Samen kunnen we

helpen bij de bescherming van het milieu.

(BPT)

Se você decidir descartar o produto, faça-o de modo que seja possível a reciclagem de

todos os componentes. As baterias e pilhas recarregáveis não devem ser descartadas em

seu lixo doméstico! Favor reciclá-las em seu ponto de reciclagem local. Juntos, podemos

ajudar a proteger o meio ambiente.

User’s Manual

Product Overview

LED Indicato

Focus Wheel

Power/Mode

Switch

Speake

USB Charging

Port

Projector Lens iPhone

Connector

Projection Mode

(Push rightward for 2

seconds to turn ON or

turn OFF the projection)

iPhone Charging Mode

User’s Manual

Charging the product

Connect one end of the bundled

USB cable to the USB port of the

product and the other end to PC /

Notebook or iPhone USB power

adapter for charging.

* The Product can be fully

charged around 2 hrs from

empty.

Charging for iPhone

1. Connect the iPhone to the

product.

2. Slide the Mode switch to the

left to start charging for iPhone.

LED Mode Indicators

LED Status Indication

3 white LEDs stay on Power capacity is between 80% to 100%

2 white LEDs stay on Power capacity is between 45% to 80%

1 white LED stays on Power capacity is between 10% to 45%

1 white LED blinks Power capacity is below 10%

LED Marquee Product is being charged

LED blinks

(From 3 to 1 LEDs depends

on product‘s power capacity

status)

Charging for iPhone

User’s Manual

Turning on/off the projector

Push the power / mode switch

rightward for 2 seconds to turn ON

or turn OFF the projector.

Adjusting the Focus

Adjust the focus by using the

focus wheel to get a sharper and

clear picture.

Projecting photos and videos via iPhone native app

1. Select the “Photos” manually icon on iPhone main menu.

2. Choose the photo or video you want to project.

* Photos can only be projected as a slideshow.

* The speaker only support for video playing not for audio playing.

User’s Manual

Projecting with dedicated free app “ShowU”

1. Download and install ShowU app from iPhone App

Store.

2. Connect the product to iPhone.

3. Launch the app from your iPhone. The app will

automatically be projected on a big screen.

4. “ShowU” app enables the product of the following

applications:

(1) Images

Project the images from iPhone Photos with zoom

in and rotation.

(2) Web Browser

Project web pages from iPhone.

(3) Live Projection

Real-time projection from iPhone built-in Camera.

Other Recommended Apps List

ShowU

Presentation Viewer Pointer

Webout Ducati Challenge Free

User’s Manual

Product specifications

Item Description

Optical Technology LCoS

Light Source RGB LED

Resolution 960 x 540 Pixels (Q1080p)

Luminous Flux 12 effective lumens

(7 Peak lumens)

Projection Image Size 13 cm ~127 cm (5” ~ 50” Diagonal)

Internal Speaker Mono

Operating System iOS4, iOS5

Projection Source iPhone 3GS, iPhone 4, iPhone 4S

Power Input / Output 5V / 1A

Battery Type Embedded 950 mAh, Li-polymer battery

Battery Life Projection mode: 100 min

iPhone charging mode: 30% iPhone

battery capacity

Power Consumption Projection mode: 3W

iPhone charging mode: 5W

Operation Temperature 5 °C ~ 35 °C

Dimension (L x W x H) 60 x 47 x 17.5 mm

Weight 80 g

Package Content Pico Projector, Pouch, User‘s Manual,

USB cable

* All specifications are subject to change without notice.

Table des matières

Langues :

Autres manuels AIPTEK Projecteur

AIPTEK

AIPTEK PocketCinema V60 Manuel utilisateur

AIPTEK

AIPTEK POCKETCINEMA V50 Manuel utilisateur

AIPTEK

AIPTEK MobileCinema i55 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema T20 Manuel utilisateur

AIPTEK

AIPTEK POCKETCINEMA V50 Manuel utilisateur

AIPTEK

AIPTEK AN100 Manuel utilisateur

AIPTEK

AIPTEK MobileCinema A50P Manuel utilisateur

AIPTEK

AIPTEK MobileCinema i400 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V10 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V20 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V10 Guide de l'administrateur

AIPTEK

AIPTEK MobileCinema i50S Manuel utilisateur

AIPTEK

AIPTEK MobileCinema i400 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V20 Manuel utilisateur

AIPTEK

AIPTEK D20 Mobile Cinema Manuel utilisateur

AIPTEK

AIPTEK Pico Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V60 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V100 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema T15 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema V10 Guide de démarrage rapide

AIPTEK

AIPTEK PocketCinema V10 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema N100 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema Z20 Manuel utilisateur

AIPTEK

AIPTEK PocketCinema T10 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
