AIPTEK SD 2Mega Manuel utilisateur
Contents
Contents
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
Specifications
Notice
Bundled Accessories
Your Camera
Battery Installation
Using a SD Card
Strap and Tripod Use
Using your Camera
LCD Display
Focus
Taking Pictures
Still pictures
Taking AVI Movies
Erase
For Best Results
17
19
20
Software Installation
Hardware Installation
Troubleshooting
AIPTEK Service
Launching PenCam SD Manager
Mode Selecting
DSC Mode
LIVE Mode
18
21
22
23
28
32
35
Bundled Software
PenCam SD Manager Installation
TWAIN Manager 31
Specifications
1
Specifications
System Requirements
Microsoft Windows 98SE / 2000 / ME / XP
Pentium II 266MHz ( or equivalent )
32MB RAM (64MB recommended)
Video Card with 4 MB of RAM
4 X speed CD-ROM
An available
Direct X 8.0 or above
RAM
USB port
Specifications
Sensor Type 1.3M CMOS
Memory 64 Mbits Built-in SDRAM
Effective pixels 1.3M (1280 x 960 pixels)
External SD Card Slot / Support SD Card up to
128 MB/ compatible with MMC
- Digital Camera :
SXGA (1280 x 960 pixels): 10 3 pictures
VGA (640 x 480 pixels): 40 10 pictures
Main Functions
+
+
- Digital Camcorder :
High resolution (640 x 480 pixels) / 6-8fps
Normal resolution (320 x 240 pixels) /8-10fps
- PC Camera :
High resolution (640 x 480 pixels) / 20fps
Normal resolution (320 x 240 pixels) / 20fps
Focus Macro 12"(30cm) / Normal
39"(100cm) to infinity
Auto Exposure Auto White-Balance
Self Timer 10 - second Self Timer
Power Saving Auto power off if idle over 60
seconds
Battery: AAA x 2 ( Alkaline) .
USB port
Dimension : 3.9" x 1.7" x 1.4"
Weight: 51.2 g
This package doesn't include SD Card/MMC.
1. Do not drop, puncture or disassemble the camera.
2. Remove batteries during long periods between use.
3. Avoid using batteries of different brands at the same
time.
4. Avoid using leaking or distorted batteries.
5. Avoid all contact with water and dry hands before
using.
6. Do not expose the camera to high temperature or
leave it in direct sunlight.
7. Avoid pressing hard on the camera body.
Notice
2Notice
Bundled Accessories
CD driver
2 x AAA Alkaline batteries Strap
User guide
3
Bundled Accessories
Camera
USB cable
Tripod
Your Camera
(1) Shutter
(2) View finder
(3) Lens
(4) Focus
(5) LCD display
(6) Mode button
(7) Strap-holder
(8) Battery cover
(9) SD Card slot
(10) USB port
(11) Tripod port
Camera Parts
4Your Camera
(1) (2) (3)
(4)
(5)
(6)
(8)
(7) (9)
(10)
(1)
SD
(11)
Battery Installation
Battery Installation
Your camera runs on two AAA alkaline batteries.
High performance batteries are for this camera.
When not using your camera for extended
periods, we suggest you remove the batteries.
on the LCD display indicates low battery.
Transfer data from SDRAM to your PC
immediately to avoid data loss. All SDRAM
data will be lost when the camera loses power
from battery exhaustion or removal.
Full Low
Battery Indicators
Battery Installation 5
Make sure that you've downloaded data to PC
before removing the battery cover.
Using a SD Card/ MMC
External Memory/ SD Card
/ MMC Card
(Secure Digital
Memory Card) (MultiMediaCard)
In addition to 64Mbits SDRAM, your camera can store
data on SD Cards /MMC. Data will be automatically
stored on the SD card/ MMC until it is full, with additional
data stored on SDRAM. Insert your card as shown.
Using a SD Card/MMC
6
Format SD Card / MMC
" Err" message appears on LCD display as you confront
the following two conditions:
(1) The camera can't read FAT 32 or NTFS format. If your card
is already designated as FAT 32 or NTFS format by your
card reader, please format your card by the camera.
(2) When the memory card is full of data from other devices:
Please transfer data to your card reader or format your card.
This package doesn't include SD card or MMC.
( AVI Movies ) functions only when SD
Card/ MMC is inserted.
SD Card Slot
1. Press and hold the mode button for five seconds until the
LCD shows the " " icon.
2. Then press the shutter button to format SD Card/ MMC.
FOR
Format Steps If your have any problems with your memory
card, please refer to the user guide of your SD
Card/MMC.
NOTE: Formatting SD card or MMC will erase
all of your images
SD CARD
To store data on the built-in memory, please
take out SD Card or MMC.
Strap and Tripod Use
Strap
Tripod
Attach the carrying strap for convenience and
safety.
Use a tripod to minimize camera movement and
ensure optimal image quality, especially while
shooting longer movies, self-portraits or video
conferencing.
Strap and Tripod Use 7
Tight
Loose
Using your Camera
Turning on your camera
Press the Mode button for 2 seconds to turn
on your camera.
Manual shut-off: press the mode button and
shutter button simultaneously for 2 seconds.
Auto shut-off: your camera will automatically
shut off after 60 seconds of inactivity.
Using your Camera
8
