Operation Manual

110HP-130HP ULTRATRACTOR

IMPORTANT!

You must ensure all operators of this machine read and understand these instructions and any additional instructions provided prior to

operation

Product Identification marks record form

Trade name:

Model Type:

Identification number of Tractor:

Identification number of Chassis:

Engine type:

Identification number of Engine:

Time of acquisition:

Place of purchase and contact:

User name:

Manufacturer’s Name:

Manufacturer’s Address:

Manufacturer’s Phone:

Note: 1. Please users fill out the above form carefully at time of purchasing.

2. The number in the table shall be completely written (including letters).

1104 /1204/1254/1304 Wheeled Tractors

Operation Specification

* * *

Number: BF-SM-E-01.1

Instruction to Users

Valued Customer:

Thank you for your belief in our company, and purchasing wheeled tractors of our company.

For the sake of correct, reasonable and effective operation of tractors, please pay attention to the

following information.

1、Before operating the tractor, please read this specification carefully whether you have

experience of driving or not before, because it will help you operate tractor more reasonably and

effectively.

2、For the sake of more economic benefit to you and longer service life of tractor, before

operation, please read carefully this operation specification and operation instruction of matching

engine and agricultural implements, and manipulate and maintain tractor closely as required in

operation specification for the purpose of full use of performance of tractor.

3、Please don’t modify tractors randomly for fear of effect on tractor performance and

unexpected accident, or even the consequence that it is hard to performance guarantee service.

4、Due to great difference in agriculture and soil condition, there are diversified purposes,

parameters, matching agricultural implements and operation efficiency recommended in this

operation specification accordingly. Please users make a choice according to practical conditions.

5、The tractor can be only manipulated, maintained and repaired by persons familiar with

characteristics of tractor, and relevant safe operation knowledge.

6、Drivers must have the license of agricultural vehicles and tractors issued by local traffic

department.

7、Local safety rules and road traffic regulations shall be observed at any time for fear of

unexpected accident.

8、Tractor shall be used in accordance with requirements of this operation specification;

Otherwise, it will probably lead to degradation or failure of tractor.

9、This operation specification is not a quality warranty. Therefore users must not put forward

any requirements on the basis of data, illustration or instruction in the operation specification.

10、The contents said in this operation specification shall be subject to the published product

structure. The contents are subject to change without further notice. Please users pay attention to

it.

11、The products in operation specification accord with the up-to-date standard before the

date of manufacturing.

General Description

The operation specification introduces in detail the safe operation rules, operation precautions,

main technical specification, and methods of wearing, operation, technical maintenance,

adjustment, and trouble clearing etc. of series 80 of wheeled tractors for reference of tractor

drivers and .service man.

In this operation specification, safety sign indicate important safety information. When

seeing this sign, please pay attention to it to avoid possible injury. Read carefully the following

information of the sign and inform other operators of it.

Warning: denote that if not avoided, there will possibly be potential danger, such as

casualties or serious personal injury.

Attention: denote that if not avoided, there will be potential danger such as low and

medium degree personal injury.

Warning: denote that if not avoided, there will possibly be machinery breakdown or

damage to environment.

Note: specifying supplementary information.

This operation specification is an important part of products. It will be supplied to users along

with tractors. Pleas users keep it properly.

In case of incomprehension of part in the operation specification, you can dial service hotline

for consultation.

Intended Use

This series of wheeled tractors are multipurpose agricultural wheeled tractors. This type of

tractors is characterized by compact structure, convenience manipulation, flexible steering, great

tractive force, wide application, and maintenance and repair convenience etc. if fitted with

appropriate agricultural implements, the tractors will be able to conduct plowing, harrowing,

sowing and harvesting operations etc. fitted with a trailer, they can be used for agricultural

transportation; trailer and tractor mass ratio (specific value between gross mass of trailer and

unladen mass of tractor) shall not be more than 3. By power output shaft, they can be coupled with

straw returning machine to conduct straw returning operation. They can be also used as motive

power of water pump and threshing machine. Please fit agricultural implements correctly as

required in this operation specification for the sake of maximum economic benefit. Users shall

closely comply with prescribed service, maintenance and repair conditions of manufactory, as well

as basic requirements for intended use. The use for other operation will deviate from intended use

of tractors.

The tractors can be only operated, maintained and repaired by persons familiar with their

characteristics, as well as relevant safe operation knowledge.

Users must comply with the rules against unexpected accident, other safety regulations and

road traffic regulations at any time.

Manufactory shall assume no responsibility for degradation of reliability, machinery

breakdown or personal injury caused from random modification, or use for the operation going

against intended use of tractors.

Contents

1. Safety Notes– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 1

1.1 Safety regulations and notes for use – – – – – – – – – – – – – – – – – – – – – – – – – – 1

1.2 Safety Warning Signs– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 7

2. Operation Instruction– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 12

2.1 Product description– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 12

2.2 Operating mechanism and instrument of tractor– – – – – – – – – – – – – – – – – – – – – 12

2.3 Start of engine – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 13

2.4 Start of tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 15

2.5 Steering of tractor– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 16

2.6 Gear shift of tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 16

2.7 Operation of Differential Lock – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 17

2.8 Using of Front Drive Axle – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 18

2.9 Braking of the Tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – –– – – –– – – 19

2.10 Stopping of Tractor Stop and Flameout of Engine– – – – – – – – – – – – – – – – – – – 19

2.11 Adjusting of Tread– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –– – – – 20

2.12 Using, Dismounting and Mounting of Tyre– – – – – – – – – – – – – – – – – – – – – – – 21

2.13 Using of Balance Weight – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 23

2.14 Adjustment of the Driver’s Seat– – – – – – – – – – – – – – – – – – – – – – – – – – – – – 23

2.15 Covering panels of the Tractor– – – – – – – – – – – – – – – – – – – – – – – – – – – – – 24

2.16 Using of the working device of the tractor– – – – – – – – – – – – – – – – – – – – – – –

2.17 Running-in of tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 30

2.18 Frequent faults and solutions of tractor – – – – – – – – – – – – – – – – – – – – – – – – 34

3. Accessories, Spare parts and Quick-Wearing Parts – – – – – – – – – – – – – – – 41

3.1 Accessories – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 41

3.2 Spare parts – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 42

3.3 Quick-Wearing Parts – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 43

Contents

Content

4. Maintenance Instructions – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 44

4.1 Technical maintenance rules – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 44

4.2 Technical maintenance operation – – – – – – – – – – – – – – – – – – – – – – – – – – – – 47

4.3 Adjustment of tractor chassis – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 53

4.4 Adjustment of hydraulic suspension system– – – – – – – – – – – – – – –– – – – – – – – 56

4.5 Attention for the operation of full hydraulic steering system– – – – – – – – – – – – – – – 57

5. Storage– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 59

5.1 Reasons for damage of tractor during storage period– – – – – – – – – – – – – – – – – – 59

5.2 Sealing and storing the tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 59

5.3 Service during the period of sealing and storing tractor– – – – – – – – – – – – – – – – – 60

5.4 Unsealing tractor – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 60

6. Delivery, Acceptance and Transportation – – – – – – – – – – – – – – – – – – – – – 62

6.1 Delivery and acceptance – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 62

6.2 Transportation – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 62

7. Technical Specification – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 63

7.1 Producing Standard – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 63

7.2 Product Sign location– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 63

7.3 Product Specification– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 64

8. Disassembly & Disposal – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 76

9. Warranty Items – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –

9.1 Basis of Warranty– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 77

9.2 Situations beyond warranty– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 77

10. Appendix – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –– – – 78

10.1 Oil and Solution for tractors – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 78

10.2 Tightening torque table of main bolts and nuts – – – – – – – – – – – – – – – – – – – – – 79

10.3 Implements and accessories for wheel tractor – – – – – – – – – – – – – – – – – – – – – 80

Contents

Safety Notes

-1-

1. Safety Notes

1.1 Safety regulations and notes for use

Please carefully read the following information before operation

1. Must be fully read and understand the operator’s manuals and safety warning signs;

2. Must be remembered the correct operation and working method.

Qualified operator

1. When operating the machine, the operator must have enough judgment;

2. Those who feel unwell or suffer from sleep insufficiency, those who are intoxicated,

pregnant woman, those who are color-blind and those who are below 18 years old shall not

operate the machine;

3. The driver shall obtain a driving license after receiving the special training, and shall

receive the examination and check on time.

4. Before getting familiar with the operation, the operators who operate the machine for the

first time shall make the machine run at a low speed.

Clothing appropriate for driver

When operation, the driver shall wear suitable and close-fitting work clothes, and shall not

baggy coat and shirt, or wear a tie.

Oil use

1. The fuel is inflammable, so smoking and fire shall be prohibited when use.

2. Before oil is filled into the fuel tank, the engine shall be stopped;

3. No smoking when oiling and inspection & repair of fuel system;

4. When the fuel or machine oil overflows, please clean it out with a clean rag;

5. The quality of fuel and lubricating oil shall strictly comply with the requirements of the

“appendix”.

Placement of waste oil

1. The replaced machine oil is waste oil, and it shall not be discarded randomly;

2. The replaced storage battery acid will cause environmental pollution, and it shall not be

dumped randomly.

Safety Notes

-2-

When the pipeline has leakage phenomenon

Do not directly contact the high pressure oil leaking out from the oil pipe with hands; thick

paper or wood board can be used to detect the possible positions suffering from leakage.

Emergency response

1. When there is brake failure, stabilize the steering wheel, and immediately stop the machine

after reaching a safe place, and stop the engine;

2. When the steering wheel has a failure, brake immediately and then stop the engine;

3. When the machine catches fire, immediately stop the engine. If there is fire extinguisher,

spray downwards by making the fire extinguisher aim at the flame root; if there is no fire

extinguisher, can put out the fire with sand.

4. After a safety accident occurs, the emergency call of local emergency center, hospital or

fire department shall be made immediately according to the actual conditions.

Warning:

1. For your life safety and property safety and for your relatives’ happiness, please

operate safely.

2. Before the tractor is started, observe if there is any barrier on the road, and if there is

person between the tractor and agricultural implement/ trailer; and whistling sound shall be

made for warning, so as to prevent accident and risk caused by sudden start of the tractor;

3. Do not start and operate the tractor by leaving the driver's seat. When the tractor is

started, it shall be ensured that the gear shift levers are at the neutral position; the power

take off operating handle and the front drive operating handle are at the separation status;

and the lifter operating handle is at the neutral position, so as to prevent accident and risk

caused by sudden start of the tractor;

4. The engine shall not be started by bridging of short circuit terminal, otherwise when

the gear box is put into gear, the tractor will move automatically, which may cause accident

and risk;

5. The motion of pedals shall not be hindered, and all the pedals must be able to return

to the normal position without being hindered. The things that may hinder the pedal stroke

shall not be placed under the floor and pedal, and the articles that may roll or slide when

the pedal is treaded shall not be placed. Additional foot carpet or other cushions shall not

be placed around the pedals, so as to prevent the risks caused by the pedal action. The

lever shall be at the neutral position; the power take off operating handle and the front drive

operating handle are at the separation status; lifter;

Safety Notes

-3-

6. Nobody shall get on/off the tractor when the tractor is moving; and nobody shall be

under the tractor when the engine is running; Inspection and repair shall be performed to

prevent accident and risk;

7. After tractor is stopped, before getting off the tractor, the driver must draw out the

key; make the gear shift levers turned to the neutral position; and lock the brake handle for

parking, so as to prevent accident and risk caused by sudden start of the tractor that may

lead to auto action (out of control);

8. When transport, the left and right brake pedals must be interlocked, and the speed

shall be reasonably controlled; when passing through culverts and bridges, notice whether

the stipulated height is exceeded; when making a turn, sufficient deceleration shall be

made in advance, so as to prevent accident (turnover, crash);

9. When uphill or downhill driving, the minimum gear stage shall be used, and the

throttle control shall be reasonably applied. It is forbidden to make the tractor downhill with

the gear shift at neutral position or by treading the clutch pedal; and it is forbidden to

perform gear shift when uphill or downhill, so as to prevent turnover risk;

10. The tractor shall not make a sharp turn when high-speed driving, and the sharp turn

shall not be made by adopting unilateral braking, so as to prevent turnover risk;

11. Pay attention to traffic signs when driving the tractor on road, and the traffic rules

shall be well complied with, so as to prevent turnover risk;

12. When transfer, the traffic rules shall be well complied with; and the distance

between two vehicles shall be 60m at least, so as to prevent accident and risk (crash);

13. The road bed near trench, hole and dike is vulnerable and the weight of the tractor

may damage it, so please detour, or accident and risk may be caused;

14. The tractor shall not be used under overload conditions, so as to prevent overload

of machine members (which may cause machine damage and even personal injury);

15. There shall be proper lighting equipment when night work of tractor, so as to

prevent the working effect of the tractor from being affected and prevent accident and risk;

16. When the tractor is performing reaping or backyard operation, spark annihilator

shall be installed on the exhaust pipe, so as to prevent fire risk;

17. When operation in rainy and snowy days, the running speed must be reduced, so

as to prevent the turnover risk caused by sloppy road and ground;

18. When power take off operation, it must be ensured that the connection and

protection are reliable, so as to prevent movable parts from loosening (which may cause

personal injury);

19. When connection and traction of implements, it must be ensured that all the hinge

pins are reliably and firmly connected, so as to prevent the crash risk caused by falling

hinge pins. When loosening and articulation of implements, it shall be ensured that the

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Agrison Tracteur

Agrison

Agrison 80HP CDF Manuel utilisateur

Manuels Tracteur populaires d'autres marques

Ariens

Ariens 936051 Manuel utilisateur

MacDon

MacDon M150 Manuel utilisateur

Belarus

Belarus 3522.5 Manuel utilisateur

CARRARO

CARRARO Vigneto Manuel utilisateur

Cub Cadet

Cub Cadet 3208 Manuel utilisateur

GREMO

GREMO 1250F Manuel d'instructions

HATTAT

HATTAT A90 Manuel utilisateur

Kubota

Kubota WSM STV32 Manuel d'instructions

Kubota

Kubota M108DC Manuel utilisateur

Case

Case 385 Diesel Guide d'installation

AL-KO

AL-KO Heritage RS 14/82 Manuel utilisateur

Webb

Webb WE1742SD Manuel utilisateur

MacDon

MacDon 9250 Manuel utilisateur

Toro

Toro 03200 Reelmaster 3100-D Manuel utilisateur

MASSEY FERGUSON

MASSEY FERGUSON 5400 Series Manuel utilisateur

Kubota

Kubota T1880 Manuel utilisateur

Case

Case JX 90 Manuel utilisateur

Iseki

Iseki TXG23 Manuel utilisateur
