SCPI Command Summary

The following conventions are used for SCPI command syntax for remote

interface programming:

•Square brackets ( [ ] ) indicate optional keywords or parameters.

•Braces ( { } ) enclose parameter choices within a command string.

•Triangle brackets ( < > ) enclose parameters for which you must

substitute a value.

•A vertical bar ( |) separates multiple parameter choices.

Rules for Using a Channel List

Many of the SCPI commands for the 34970A include a scan_list or ch_list

parameter which allow you to specify one or more channels. The channel

number has the form (@scc), where sis the slot number (100, 200, or 300) and

cc is the channel number. You can specify a single channel, multiple channels,

or a range of channels as shown below.

•The following command configures a scan list to include only channel 10

on the module in slot 300.

ROUT:SCAN (@310)

•The following command configures a scan list to include multiple

channels on the module in slot 200. The scan list now contains only

channels 10, 12, and 15 (the scan list is redefined each time you send a

new ROUTe:SCAN command).

ROUT:SCAN (@210,212,215)

•The following command configures a scan list to include a range of

channels. When you specify a range of channels, the range may contain

invalid channels (they are ignored), but the first and last channel in the

range must be valid. The scan list now contains channels 5 through 10

(slot 100) and channel 15 (slot 200).

ROUT:SCAN (@105:110,215)

Note to Writer: Scale PDF file to 85% (printer setting for LJet 4)

Final Cut Size: 5.5 x 8.5 inches

$JLOHQW$'DWD$FTXLVLWLRQ6ZLWFK QLW

Scan Measurement Commands

(see page 226 in the User’s Guide)

MEASure

:TEMPerature? {TCouple|RTD|FRTD|THERmistor|DEF}

,{<type>|DEF}[,1[,{<resolution>|MIN|MAX|DEF}]] ,(@<scan_list>)

:VOLTage:DC? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:VOLTage:AC? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:RESistance? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:FRESistance? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:CURRent:DC? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:CURRent:AC? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:FREQuency? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:PERiod? [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

:DIGital:BYTE? (@<scan_list>)

:TOTalize? {READ|RRESet} ,(@<scan_list>)

Monitor Commands

(see page 237 in the User’s Guide)

ROUTe

:MONitor (@<channel>)

:MONitor?

ROUTe

:MONitor:STATe {OFF|ON}

:MONitor:STATe?

ROUTe:MONitor:DATA?

Scan Statistics Commands

(see page 233 in the User’s Guide)

CALCulate

:AVERage:MINimum? [(@<ch_list>)]

:AVERage:MINimum:TIME? [(@<ch_list>)]

:AVERage:MAXimum? [(@<ch_list>)]

:AVERage:MAXimum:TIME? [(@<ch_list>)]

:AVERage:AVERage? [(@<ch_list>)]

:AVERage:PTPeak? [(@<ch_list>)]

:AVERage:COUNt? [(@<ch_list>)]

:AVERage:CLEar [(@<ch_list>)]

DATA:LAST? [<num_rdgs>,][(@<channel>)]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Scan Configuration Commands

(see page 226 in the User’s Guide)

ROUTe

:SCAN (@<scan_list>)

:SCAN?

:SCAN:SIZE?

TRIGger

:SOURce {BUS|IMMediate|EXTernal|ALARm1|ALARm2|ALARm3|ALARm4|TIMer}

:SOURce?

TRIGger

:TIMer {<seconds>|MIN|MAX}

:TIMer?

TRIGger

:COUNt {<count>|MIN|MAX|INFinity}

:COUNt?

ROUTe

:CHANnel:DELay <seconds>[,(@<ch_ list>)]

:CHANnel:DELay? [(@<ch_list>)]

:CHANnel:DELay:AUTO {OFF|ON}[,(@<ch_list>)]

:CHANnel:DELay:AUTO? [(@<ch_list>)]

FORMat

:READing:ALARm {OFF|ON}

:READing:ALARm?

:READing:CHANnel {OFF|ON}

:READing:CHANnel?

:READing:TIME {OFF|ON}

:READing:TIME?

:READing:UNIT {OFF|ON}

:READing:UNIT?

FORMat

:READing:TIME:TYPE {ABSolute|RELative}

:READing:TIME:TYPE?

ABORt

INITiate

READ?

Scan Memory Commands

(see page 235 in the User’s Guide)

DATA:POINts?

DATA:REMove? <num_rdgs>

SYSTem:TIME:SCAN?

FETCh?

R? [<max_count>]

This command redefines the scan list when executed.

This command applies to all channels in the instrument (Global setting).

Default parameters are shown in bold.

Scanning With an External Instrument

(see page 239 in the User’s Guide)

ROUTe

:SCAN (@<scan_list>)

:SCAN?

:SCAN:SIZE?

TRIGger

:SOURce {BUS|IMMediate|EXTernal|TIMer}

:SOURce?

TRIGger

:TIMer {<seconds>|MIN|MAX}

:TIMer?

TRIGger

:COUNt {<count>|MIN|MAX|INFinity}

:COUNt?

ROUTe

:CHANnel:DELay <seconds>[,(@<ch_ list>)]

:CHANnel:DELay? [(@<ch_list>)]

ROUTe

:CHANnel:ADVance:SOURce {EXTernal|BUS|IMMediate}

:CHANnel:ADVance:SOURce?

ROUTe

:CHANnel:FWIRe {OFF|ON}[,(@<ch_list>)]

:CHANnel:FWIRe? [(@<ch_list>)]

INSTrument

:DMM {OFF|ON}

:DMM?

:DMM:INSTalled?

This command redefines the scan list when executed.

This command applies to all channels in the instrument (Global setting).

Default parameters are shown in bold.

Temperature Configuration Commands

(see page 219 in the User’s Guide)

CONFigure

:TEMPerature {TCouple|RTD|FRTD|THERmistor|DEF}

,{<type>|DEF}[,1[,{<resolution>|MIN|MAX|DEF}]] ,(@<scan_list>)

CONFigure? [(@<ch_list>)]

UNIT

:TEMPerature {C|F|K}[,(@<ch_list>)]

:TEMPerature? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:TYPE {TCouple|RTD|FRTD|THERmistor|DEF}[,(@<ch_list>)]

:TYPE? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:TCouple:TYPE {B|E|J|K|N|R|S|T}[,(@<ch_list>)]

:TCouple:TYPE? [(@<ch_list>)]

:TCouple:CHECk {OFF|ON}[,(@<ch_list>)]

:TCouple:CHECk? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:TCouple:RJUNction:TYPE {INTernal|EXTernal|FIXed}[,(@<ch_list>)]

:TCouple:RJUNction:TYPE? [(@<ch_list>)]

:TCouple:RJUNction {<temperature>|MIN|MAX}[,(@<ch_list>)]

:TCouple:RJUNction? [(@<ch_list>)]

[SENSe:]TEMPerature:RJUNction? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:RTD:TYPE {85|91}[,(@<ch_list>)]

:RTD:TYPE? [(@<ch_list>)]

:RTD:RESistance[:REFerence] <reference>[,(@<ch_list>)]

:RTD:RESistance[:REFerence]? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:FRTD:TYPE {85|91}[,(@<ch_list>)]

:FRTD:TYPE? [(@<ch_list>)]

:FRTD:RESistance[:REFerence] <reference>[,(@<ch_list>)]

:FRTD:RESistance[:REFerence]? [(@<ch_list>)]

[SENSe:]TEMPerature:TRANsducer

:THERmistor:TYPE {2252|5000|10000}[,(@<ch_list>)]

:THERmistor:TYPE? [(@<ch_list>)]

[SENSe:]

TEMPerature:NPLC {0.02|0.2|1|2|10|20|100|200|MIN|MAX}[,(@<ch_list>)]

TEMPerature:NPLC? [{(@<ch_list>)|MIN|MAX}]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Voltage Configuration Commands

(see page 223 in the User’s Guide)

CONFigure

:VOLTage:DC [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

VOLTage:DC:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

VOLTage:DC:RANGe? [{(@<ch_list>)|MIN|MAX}]

VOLTage:DC:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

VOLTage:DC:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

VOLTage:DC:RESolution {<resolution>|MIN|MAX}[,(@<ch_list>)]

VOLTage:DC:RESolution? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

VOLTage:DC:APERture {<time>|MIN|MAX}[,(@<ch_list>)]

VOLTage:DC:APERture? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

VOLTage:DC:NPLC {0.02|0.2|1|2|10|20|100|200|MIN|MAX}[,(@<ch_list>)]

VOLTage:DC:NPLC? [{(@<ch_list>)|MIN|MAX}]

INPut

:IMPedance:AUTO {OFF|ON}[,(@<ch_list>)]

:IMPedance:AUTO? [(@<ch_list>)]

[SENSe:]

ZERO:AUTO {OFF|ONCE|ON}[,(@<ch_list>)]

ZERO:AUTO? [(@<ch_list>)]

CONFigure

:VOLTage:AC [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

VOLTage:AC:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

VOLTage:AC:RANGe? [{(@<ch_list>)|MIN|MAX}]

VOLTage:AC:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

VOLTage:AC:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

VOLTage:AC:BANDwidth {3|20|200|MIN|MAX}[,(@<ch_list>)]

VOLTage:AC:BANDwidth? [{(@<ch_list>)|MIN|MAX}]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Resistance Configuration Commands

(see page 224 in the User’s Guide)

CONFigure

:RESistance [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

RESistance:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

RESistance:RANGe? [{(@<ch_list>|MIN|MAX}]

RESistance:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

RESistance:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

RESistance:RESolution {<resolution>|MIN|MAX}[,(@<ch_list>)]

RESistance:RESolution? [{(@<ch_list>)|MIN|MAX}]

RESistance:APERture {<time>|MIN|MAX}[,(@<ch_list>)]

RESistance:APERture? [{(@<ch_list>)|MIN|MAX}]

RESistance:NPLC {0.02|0.2|1|2|10|20|100|200|MIN|MAX}[,(@<ch_list>)]

RESistance:NPLC? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

RESistance:OCOMpensated {OFF|ON}[,(@<ch_list>)]

RESistance:OCOMpensated? [(@<ch_ list>)]

CONFigure

:FRESistance [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

FRESistance:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

FRESistance:RANGe? [{(@<ch_list>)|MIN|MAX}]

FRESistance:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

FRESistance:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

FRESistance:RESolution {<resolution>|MIN|MAX}[,(@<ch_list>)]

FRESistance:RESolution? [{(@<ch_list>)|MIN|MAX}]

FRESistance:APERture {<time>|MIN|MAX}[,(@<ch_list>)]

FRESistance:APERture? [{(@<ch_list>)|MIN|MAX}]

FRESistance:NPLC {0.02|0.2|1|2|10|20|100|200|MIN|MAX}[,(@<ch_list>)]

FRESistance:NPLC? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

FRESistance:OCOMpensated {OFF|ON}[,(@<ch_list>)]

FRESistance:OCOMpensated? [(@<ch_ list>)]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Current Configuration Commands

(see page 224 in the User’s Guide)

Valid only on channels 21 and 22 on the 34901A multiplexer module.

CONFigure

:CURRent:DC [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

CURRent:DC:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

CURRent:DC:RANGe? [{(@<ch_list>)|MIN|MAX}]

CURRent:DC:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

CURRent:DC:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

CURRent:DC:RESolution {<resolution>|MIN|MAX}[,(@<ch_list>)]

CURRent:DC:RESolution? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

CURRent:DC:APERture {<time>|MIN|MAX}[,(@<ch_list>)]

CURRent:DC:APERture? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

CURRent:DC:NPLC {0.02|0.2|1|2|10|20|100|200|MIN|MAX}[,(@<ch_list>)]

CURRent:DC:NPLC? [{(@<ch_list>)|MIN|MAX}]

CONFigure

:CURRent:AC [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

CURRent:AC:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

CURRent:AC:RANGe? [{(@<ch_list>)|MIN|MAX}]

CURRent:AC:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

CURRent:AC:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

CURRent:AC:BANDwidth {3|20|200|MIN|MAX}[,(@<ch_list>)]

CURRent:AC:BANDwidth? [{(@<ch_list>)|MIN|MAX}]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Frequency and Period Configuration Commands

(see page 214 in the User’s Guide)

CONFigure

:FREQuency [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

FREQuency:VOLTage:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

FREQuency:VOLTage:RANGe? [{(@<ch_ list>)|MIN|MAX}]

FREQuency:VOLTage:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

FREQuency:VOLTage:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

FREQuency:APERture {0.01|0.1|1|MIN|MAX}[,(@<ch_list>)]

FREQuency:APERture? [{(@<ch_list>)|MIN|MAX}]

[SENSe:]

FREQuency:RANGe:LOWer {3|20|200|MIN|MAX}[,(@<ch_list>)]

FREQuency:RANGe:LOWer? [{(@<ch_list>)|MIN|MAX}]

CONFigure

:PERiod [{<range>|AUTO|MIN|MAX|DEF}

[,<resolution>|MIN|MAX|DEF}],] (@<scan_list>)

CONFigure? [(@<ch_list>)]

[SENSe:]

PERiod:VOLTage:RANGe {<range>|MIN|MAX}[,(@<ch_list>)]

PERiod:VOLTage:RANGe? [{(@<ch_ list>)|MIN|MAX}]

PERiod:VOLTage:RANGe:AUTO {OFF|ON}[,(@<ch_list>)]

PERiod:VOLTage:RANGe:AUTO? [(@<ch_list>)]

[SENSe:]

PERiod:APERture {0.01|0.1|1|MIN|MAX}[,(@<ch_list>)]

PERiod:APERture? [{(@<ch_list>)|MIN|MAX}]

This command redefines the scan list when executed.

Default parameters are shown in bold.

Mx+B Scaling Commands

(see page 244 in the User’s Guide)

CALCulate

:SCALe:GAIN <gain>[,(@<ch_list>)]

:SCALe:GAIN? [(@<ch_list>)]

:SCALe:OFFSet <offset>[,(@<ch_list>)]

:SCALe:OFFSet? [(@<ch_list>)]

:SCALe:UNIT <quoted_string>[,(@<ch_ list>)]

:SCALe:UNIT? [(@<ch_list>)]

CALCulate:SCALe:OFFSet:NULL [(@<ch_list>)]

CALCulate

:SCALe:STATe {OFF|ON}[,(@<ch_list>)]

:SCALe:STATe? [(@<ch_list>)]

Alarm Limit Commands

(see page 247 in the User’s Guide)

OUTPut

:ALARm[1|2|3|4]:SOURce (@<ch_list>)

:ALARm[1|2|3|4]:SOURce?

CALCulate

:LIMit:UPPer <hi_limit>[,(@<ch_ list>)]

:LIMit:UPPer? [(@<ch_list>)]

:LIMit:UPPer:STATe {OFF|ON}[,(@<ch_list>)]

:LIMit:UPPer:STATe? [(@<ch_list>)]

CALCulate

:LIMit:LOWer <lo_limit>[,(@<ch_ list>)]

:LIMit:LOWer? [(@<ch_list>)]

:LIMit:LOWer:STATe {OFF|ON}[,(@<ch_list>)]

:LIMit:LOWer:STATe? [(@<ch_list>)]

SYSTem:ALARm?

OUTPut

:ALARm:MODE {LATCh|TRACk}

:ALARm:MODE?

:ALARm:SLOPe {NEGative|POSitive}

:ALARm:SLOPe?

OUTPut

:ALARm{1|2|3|4}:CLEar

:ALARm:CLEar:ALL

STATus

:ALARm:CONDition?

:ALARm:ENABle <enable_value>

:ALARm:ENABle?

:ALARm[:EVENt]?

Ch 01

DIO (LSB)

Ch 02

DIO (MSB)

Ch 03

Totalizer

Ch 04

DAC

Ch 05

DAC

CALCulate

:COMPare:TYPE {EQUal|NEQual}[,(@<ch_list>)]

:COMPare:TYPE? [(@<ch_list>)]

:COMPare:DATA <data>[,(@<ch_list>)]

:COMPare:DATA? [(@<ch_list>)]

:COMPare:MASK <mask>[,(@<ch_list>)]

:COMPare:MASK? [(@<ch_list>)]

:COMPare:STATe {OFF|ON}[,(@<ch_list>)]

:COMPare:STATe? [(@<ch_list>)]

This command applies to all channels in the instrument (Global setting).

Default parameters are shown in bold.

Autres manuels pour 34970A

Table des matières

Autres manuels Agilent Technologies Changer

Agilent Technologies

Agilent Technologies U2121A-101 RF Manuel utilisateur

Agilent Technologies

Agilent Technologies 86060C Series Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent 34980A Manuel utilisateur

Agilent Technologies

Agilent Technologies 11713A Manuel de service

Agilent Technologies

Agilent Technologies 86062C Manuel utilisateur

Agilent Technologies

Agilent Technologies 86060A Manuel utilisateur

Agilent Technologies

Agilent Technologies 8710 Series Manuel de service

Agilent Technologies

Agilent Technologies Agilent 3499A Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent 34980A Manuel utilisateur

Agilent Technologies

Agilent Technologies 34945A Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent E5250A Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent 34980A Manuel utilisateur

Agilent Technologies

Agilent Technologies E1364A Manuel utilisateur

Agilent Technologies

Agilent Technologies 34950A Manuel utilisateur

Agilent Technologies

Agilent Technologies 86060C Series Instructions d'utilisation et de sécurité

Agilent Technologies

Agilent Technologies Agilent E5252A Manuel utilisateur

Agilent Technologies

Agilent Technologies 81591B Manuel utilisateur

Agilent Technologies

Agilent Technologies Switch/Measure Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent E6474A Manuel utilisateur

Agilent Technologies

Agilent Technologies Agilent 34980A Manuel utilisateur

Agilent Technologies

Agilent Technologies E1463A Manuel du propriétaire

Agilent Technologies

Agilent Technologies 3488A Guide de démarrage rapide

Agilent Technologies

Agilent Technologies B2200A Manuel utilisateur

Agilent Technologies

Agilent Technologies L4445A Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
