AGFA ANAPURNA MV Manuel utilisateur
1
ABTechnical Manual
Technical Manual
(
(:ANAPURNA MV
:ANAPURNA MV)
)
AMV-1606-080531 V1.0
2
Content
Content
1. How to Install ------------------------------
3
2. Exterior Appearance & Specification------------ 15
3. How to Use & List of Notice in Use -------------
27
4. Error in Output & Quality of Printing ------------
94
5. Servo Motor Driver ------------------------ 98
6. Electric Diagram / PCB Description ------------
122
3
MODEL : ANAPURNA MV
MODEL : ANAPURNA MV
1.How to Install
1.How to Install
4
How to Install I
How to Install I-
-1
1
The below is important information that should be checked during installation.
1. The recommended work space for printing is 5M*5M.
(Actual Machine size => 3.5M*1.52M*1.6M)
2. The room in which the printer shall be installed should be easy to clean, dust-free space,
Electromagnetic-free space.
Reasonable temperature in 68 ~ 85℉(20~29℃) should be kept. Humidity in 20%~80% as well.
※Requirement for installation
3. This equipment should be installed on horizontal surface in order to get the printing in the best quality.
4. The equipment should be run with single grounding.
5. In case the safety of working space is required, gas ventilation system will be asked, and the
exhaust duct and ventilation fan should be installed
20% to 80%
Non-condensing
68℉to 85℉
(20℃to 29℃)
Humidity
Temperature
5
How to Install I
How to Install I-
-2
2
※List of Notice in relocating the printer.
- As shown in below, the equipment should be lifted up at the marked position.
- When forks of lifter are inserted, be aware not to damage (scratch) the equipment !!
- After checking the left & right balance of equipment, the equipment should be lifted up slowly.
( Please attention that it is sensitive device for impact. )
- Please check a relocating route before carrying by Lifter.
1. Dismantle the front and the upper of WOODEN BOX.
(Remove the screw on the Front and Upper with a driver or electric tool.)
2. After dismantling the packing box, the equipment is relocated by Folk Lifter.
6
How to Install I
How to Install I-
-2
2
Folks of Folk Lifter
7
How to Install II
How to Install II
3. After relocating to desire place, should make a machine balance by using high & low controlling
bolts and level checker.
The position of level checker should be based on box beam, connecting bar and side panel (left, right).
4. ANAPURNA MV is a device that needs compressed air.
Air line connected to Air-compressor or installation place should be mounted on right side of
equipment.
-The diameter of Air Inlet Tube is Φ6.
-The pressure of Compressor is 4~8kgf/㎠, Capacity of above 2HP.
(640 kcal/hr,760W) Air production is over 6 LPM.
★The Compressor must be Oil-less product.
★It is recommended that the compressor should be run independently.
5. Besides the standard power grounding, the print in good quality can be obtained
by connecting grounding line to controller panel in the middle of Machine rear side.
8
How to Install III
How to Install III
6. After connecting with AC-Line and grounding, connect with machine power code
(220V ±10%, Grounding : Less than 5V)
: ANAPURNA MV consists of power part of main body and that of sub-body.
- 1 st circuit breaker (main S/W) : ON / OFF for power source of main body.
- 2 nd Circuit breaker ( main breaker S/W) : ON / OFF for Main Power.
- 3 rd START S/W : Operation of printer.
Warning
After printer installation, please supply the ink in accordance with How
To Install IV. In case of not following the procedure or skip, some
problems related to head block & printing error would happen.
In order for personnel protection in operation of printing, must understand
the printer by studying thoroughly working guide described in the MSDS.
*APPENDIX: MSDS attached.
9
How to Install IV
How to Install IV-
-1 (HEAD CLEANING & INK SYPPLY)
1 (HEAD CLEANING & INK SYPPLY)
STEP 1. After removing the cap of ink tube in refill connecting part, push
the solution which remains in ink tube into sub ink tank by using tubing pump
including filter.
.
Be careful that a solution should not be smeared on the
printer while carrying out solution or ink handing work.
If smeared on the printer, its surface will be discolored.
STEP 2. Connect ink supplying tube in refill system with tube connector
of printer.
Make sure that the ink tube and connector of printer are
tightly connected by the NUT in end of supplying tube.
Impact can cause of tubing-out problem.
Warning
Warning
10
How to Install IV
How to Install IV-
-2 (HEAD CLEANING & INK SUPPLY)
2 (HEAD CLEANING & INK SUPPLY)
.
STEP 3. Fill 500ml of ink in a main refill ink tank.
ÆBe sure to deflate the air from ink filter of refill part and fill with the ink
after being finished automated refill.
ÆIf ink is supplied in the condition that the air in Ink filter is not completely
removed, overflowing from secondary ink tank will take place due to
excess of air quantity.
Ink Outlet
Structure of Sub Ink Tank
Level Sensor
Air inlet
Ink Inlet
