AGA AEXT 720 (72) Manuel utilisateur
AEXT720(72)
Instruction Manual
GB
11
GB
CONTENTS
Dear Customer,
If you follow the recommendations con-
tained in this Instruction Manual, your
appliance will give you constant high
performance and will remain efcient
for many years to come.
RECOMMENDATIONSAND SUGGESTIONS 12
CHARACTERISTICS 13
INSTALLATION 14
USE 16
MAINTENANCE 17
12
GB
RECOMMENDATIONSAND SUGGESTIONS
INSTALLATION
• The manufacturer will not be held liable for any damages resulting from
incorrect or improper installation.
• The minimum safety distance between the cooker top and the extractor
hood is 650 mm (some models can be installed at a lower height, please
refer to the paragraphs on working dimensions and installation).
• Check that the mains voltage corresponds to that indicated on the rating
plate xed to the inside of the hood.
• For Class I appliances, check that the domestic power supply guarantees
adequate earthing. Connect the extractor to the exhaust ue through a
pipe of minimum diameter 120 mm. The route of the ue must be as short
as possible.
• Do not connect the extractor hood to exhaust ducts carrying combustion
fumes (boilers, replaces, etc.).
• If the extractor is used in conjunction with non-electrical appliances (e.g.
gas burning appliances), a sufcient degree of aeration must be guaranteed
in the room in order to prevent the backow of exhaust gas. The kitchen
must have an opening communicating directly with the open air in order
to guarantee the entry of clean air. When the cooker hood is used in
conjunction with appliances supplied with energy other than electric, the
negative pressure in the room must not exceed 0,04 mbar to prevent fumes
being drawn back into the room by the cooker hood.
• In the event of damage to the power cable, it must be replaced by the
manufacturer or by the technical service department, in order to prevent
any risks.
• If the instructions for installation for the gas hob specify a greater distance
specied above, this has to be taken into account. Regulations concerning
the discharge of air have to be fullled.
USE
• The extractor hood has been designed exclusively for domestic use to
eliminate kitchen smells.
• Never use the hood for purposes other than for which it has been designed.
• Never leave high naked ames under the hood when it is in operation.
• Adjust the ame intensity to direct it onto the bottom of the pan only,
making sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored during use: overheated
oil can burst into ames.
• Do not ambè under the range hood; risk of re
• This appliance is not intended for use by persons (including children) with
reduced physical, sen-sory or mental capabilities, or lack of experience
and knowledge, unless they have been given su-pervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• “ CAUTION: Accessible parts may become hot when used with cooking
appliances.”.
MAINTENANCE
• Switch off or unplug the appliance from the mains supply before carrying
out any maintenance work.
• Clean and/or replace the Filters after the specied time period.
• Clean the hood using a damp cloth and a neutral liquid detergent.
13
GB
CHARACTERISTICS
Dimensions
Components
Ref. Q.ty Product Components
11 Hood Body, complete with: Controls, Light,
Blower, Filters
91 Reducer Flange ø 150-120 mm
Ref. Q.ty Installation Components
12c 2 Screws 2,9 x 6,5
Q.ty Documentation
1 Instruction Manual
1 Electric Diagram
14
GB
INSTALLATION
Drilling the Support surface and Fitting the Hood
The Hood can be tted directly to the underside of the Wall units (min. 650 mm above the cooker
top) with snap-on side supports, which are set up for a support panel thickness of between 15 mm
and 30 mm.
• Cut a tted opening in the bottom surface of the
wall unit, as shown.
• Remove the metal grease lters (see par. on
Maintenance).
• Disconnect the lter support by turning the
internal handles provided.
• Insert the hood until the side supports snap into
place.
• Lock in position by tightening the screws Vf
from underneath the hood.
Hood Type 54 72
L2 515 695
15
GB
• Replace the lter support
• Screw the lter support using the 2 screws 12c (2,9 x 6 ,5) pro-
vided.
• Replace the grease lters make sure that the handle is visible on
the outside.
Connections
DUCTED VERSIONAIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the chimney using either a exible or rigid
pipe ø 150 or 120 mm, the choice of which is left to the installer.
• To install a ø 120 mm air exhaust connection,
insert the reducer ange 9 on the hood body
outlet.
• Fix the pipe in position using sufcient pipe
clamps (not supplied).
• Remove any activated charcoal lters.
RECIRCULATION VERSION AIR OUTLET
• Drill a hole ø 120 or 150 mm in the shelf above the hood
and connect the hood canopy outlet to the top part of
the wall unit by means of a rigid or exible pipe of the
same diameter, the choice of which is at the discretion
of the installer.
• To install a ø 120 mm air exhaust connection, insert the
reducer ange 9 on the hood body outlet.
• Fix the pipe in position using sufcient pipe clamps (not
supplied).
• Ensure that the activated charcoal lters have been
inserted.
ELECTRICAL CONNECTION
• Connect the hood to the mains through a two-pole switch having a contact gap of at least 3
mm.
16
GB
USE
Control Panel
The hood can be switched on pushing directly onto the requested speed without rstly having to
select 0/1 button.
Button Led Function
L- Turns the lights on/off at maximum strength.
T1 Fixed Turns the motor on/off at speed one.
T2 Fixed Turns the Motor on at speed two.
Press and hold the button for approximately 3 seconds, with all the loads turned
off (Motor and Lights), to turn the Activated Charcoal Filter alarm on.
The relevant LED ashes twice to conrm.To turn the alarm off, press the
button again and hold for at least 3 seconds. The relevant LED ashes once.
T3 Fixed Turns the Motor on at speed three.
Press and hold the button for approximately 3 seconds, with all the loads turned
off (Motor and Lights), to perform a reset of Filter saturation alarm. The LED
S1 ashes three times.
T4 Fixed Turns the Motor on at INTENSIVE Speed.This speed is timed to run for 10
minutes. At the end of this time, the system returns automatically to the speed
that was set before.
If it is activated with the motor turned off, the hood will switch to OFF at the
end of the time.
Press and hold for 3 seconds to enable the remote control, indicated by the
LED ashing twice.
Press and hold for 3 seconds to disable the remote control, indicated by the
LED ashing just once.
S1 Fixed Signals the Metal Grease Filter saturation alarm, indicating that it is necessary
to wash the lters. The alarm is triggered after the Hood has been in operation
for 100 working hours. (Reset see the parag. Maintenance)
Flashing When this is activated, it signals the Activated Charcoal Filter saturation alarm,
indicating that the lter must be changed; the Metal Grease Filters must also be
washed. The Activated Charcoal Filter saturation alarm comes into operation
after the Hood has been working for 200 hours. (Activation and Reset see the
parag. Maintenance)
17
GB
REMOTE CONTROL (OPTIONAL)
The appliance can be controlled using a remote
control powered by a 1.5 V carbon-zinc alkaline
batteries of the standard LR03-AAA type.
• Do not place the remote control near to heat
sources.
• Used batteries must be disposed of in the proper
manner.
MAINTENANCE
Grease lters
CLEANING METAL GREASE FILTERS
Alarm signal reset
• Switch of the lights and extractor motor.
• Press T3 and hold for at least 3 seconds, until
LED ashes three times in conrmation.
Cleaning the lters
• The lters are washable and must be cleaned
when led S1 ashes or at least every 2 months
of operation, or more frequently for particularly
heavy usage.
• Remove the lters one at a time, supporting
them with one hand and turning the safety
knobs (pull and turn).
• Wash the lters, taking care not to bend them.
Allow them to dry before retting.
• Replace them and x them using the safety
knobs provided (pull and turn).
18
GB
Activated charcoal lter (Recirculation version)
REPLACING THEACTIVATED CHARCOAL FILTER
• The lter is not washable and cannot be regene-
rated. It must be replaced when led S1 ashes
or at least every 4 months. The alarm signal
will only light up when the extractor motor is
switched on.
Alarm signal reset
• Switch off the lights and extractor motor.
• Press T3 and hold for at least 3 seconds, until
LED ashes three times in conrmation.
Replacing the Filter
• Remove the grease lters.
• Remove the saturated activated charcoal lters
as shown (A).
• Fit new lters (B).
• Replace the grease lters.
Alarm signal activation
• In Recirculation Version Hoods, the Filter Saturation Alarm must be activated on installation or
at a later date.
• Turn the Lights and the Suction Motor off.
• Press button T2 and hold it for 5 seconds until the LED ashes twice in conrmation:
Lighting
LIGHT REPLACEMENT
35 W halogen light.
• Remove the 2 screws xing the light cover.
• Remove the lamp by gripping the protruding
part and turning to the left.
• Replace with a new lamp with the same cha-
racteristics, making sure that you insert the two
pins properly into their housings.
• Replace the cover and x it in position using
the two screws removed as above
