NeoV™ Optical Glass - e most

trusted hard glass protection available.

Only on AG Neovo displays

An industrial grade 42” LED display

with NeoVTM Optical Glass, Anti-

Burn-inTM technology, and advanced

SDI inputs, tailored specically

for professional 24/7 operation in

mission-critical surveillance and

broadcast environments.

Featured with SDI inputs to receive mega-pixel images directly

from HD-SDI devices, the HX-42 ensures ultra clear image

reproduction without signal interruption or video latency. Coupled

with advanced Anti-Burn-inTM and AIP technology, the HX-42

guarantees exible and real-time viewing options. Along with

NeoVTM Optical Glass and a durable metal housing, the HX-42

conforms to industrial standards in security and broadcast

applications.

> LED-backlit technology with 1920 x 1080 Full HD resolution

> SDI connection supports 3Gb/s, 1.5Gb/s HD, SD SDI video inputs

> NeoV™ Optical Glass

> Anti-Burn-in™ technology

> AG Neovo Advanced Image Platform (AIP) technology: PIP/PBP function; 3D

Comb Filter / Deinterlace / Noise Reduction

> IPS panel ensures consistent and accurate colour from all viewing angles

> Flexible display orientation: portrait/ landscape

> Versatile connectivity: VGA, DVI, HDMI, DisplayPort, 3G SDI, BNC, S-Video,

Component, Audio

> Built-in speakers

> Built-in Scheduler allows dierent scheduled activations

> EcoSmart Sensor for low power consumption

> HeatControl Sensor prevents the display from overheating

> Rigorous screening of the components for mission-critical 24/7 operations

> RS-232 and RJ45 for display control from a remote location

> Tiling function for easy video wall setup (supports up to 5 x 5)

> Durable metal housing

HX-42

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: HX4200 Version 1.0, 20131115

Panel Panel Type

Panel Size

Max. Resolution

Refresh Rate

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time (GTG)

LED-Backlit TFT LCD (IPS Panel)

42.0”

1920 x 1080

60 Hz

0.4833 mm

400 cd/m2 (Typical)

1000 : 1 (Typical)

178°/178°

16.7 M

6ms (GTG)

Frequency (H/V) H.Freq

V.Freq

30 kHz - 75 kHz

50 Hz - 75Hz

Input VGA

DVI

S-Video

Component (YPbPr)

HDMI

SDI

CVBS

DisplayPort

15-Pin D-Sub

24-Pin DVI-D

4-Pin mini DIN

RCA

HDMI x 2

BNC

DisplayPort

Output VGA

DVI

SDI

CVBS

15-Pin D-Sub

24-Pin DVI-D

BNC

External Control RS-232 in/out

RJ45

9-Pin D-Sub

RJ45

Audio Audio In

Audio Out

Internal Speaker

External Speaker Out

1 x stereo audio in for PC

(audio jack, 3.5 Ø)

1 x stereo audio in (RCA)

1 x stereo audio out (RCA)

12W x 2

SDI 3G-SDI (SMPTE 424M)

HD-SDI (SMPTE 292M)

SD-SDI (SMPTE 259M)

1080p @50/60fps

720p @25/30/50/60fps

1080p @24/25/30/50/60fps

1080i @50/60fps

480i @60fps/576i @50fps

Power Power Supply

Power Requirements

Consumption

Internal

100 ~ 240 V, 50 - 60 Hz

< 150W (On)

< 0.5W (Stand-by)

< 0.5W (Off)

Sync Format Video System NTSC/PAL

Operating

Conditions

Temperature

Humidity

0°C ~ 40°C (32°F~104°F)

10% ~ 80% (No condensation)

Storage

Conditions

Temperature

Humidity

-20°C ~ 60°C (-4°F ~ 140°F)

10% ~ 90% (No condensation)

Mounting VESA FPMPMI Yes (400 x 200mm)

Dimensions w/o Base (W x H x D)

w/o Base Packaging

(W x H x D)

980 x 574 x 121mm

(38.6” x 22.6” x 4.8”)

1122 x 723 x 284mm

(44.2” x 28.5” x 11.2”)

Weight w/o Base

Packaging weight

25.7 kg (56.5 lbs)

29.3 kg (64.5 lbs)

Regulation

Approval

Certications &

Compliance

Accessories Supplied

Optional

CD ROM (user manual), 15-Pin

D-Sub cable, power cord, remote

control, batteries

Stand base (STD-03)

HX-42

NeoV™ Optical Glass protects against scratches,

impacts and other physical damage

SDI inputs bring forth mega-pixel images without

interruption or delay

Anti-Burn-in™ technology prevents image sticking

Specications HX-42

Multiple video inputs (VGA, DVI, HDMI, BNC, S-Video,

DisplayPort and Component) allow for eortless system

integration
