APVBM11
Rear View Camera Input
www.aerpro.com
www.connects2.com
www.aerpro.com
2
ABOUT THIS PRODUCT...
APVBM11
Camera Add-On Interface for BMW X5 (E70) and X6 (E71) with Professional CCC
navigation systems and factory PDC. Add on Camera interface designed to allow
the addition of an aftermarket reverse camera to the OEM screen. Designed for
vehicles with factory PDC only - interface codes navigation for rear view camera,
compatible with both PAL and NTSC cameras.
Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installa-tion. The
place of installation must be free of moisture and away from heat sources. Please ensure you use
the correct tools to avoid damage to the vehicle or product.
Aerpro can not be held responsible for the installation of this product.
Technical Support
Aerpro want to provide a fast and suitable resolution should you encounter any technical issues.
With this in mind, when contacting Aerpro, try to provide as much Information as possible.
This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: intranet.tdj.com.au/
support
www.connects2.com
3
FITTING GUIDE
NB: Before installation, switch off ignition, disconnect the vehicle battery and
remove the vehicle’s head unit.
12-pin Connector Conguration
Cable Colour Assignment
Pin 1 - Pink +12V ACC (Output) max.1.5A
Pin 2 - Blue CAN-LOW (Input)
Pin 6 - Red +12V Permanent (Input)
Pin 8 - Yellow CAN-HIGH (Input)
Pin 9 - Green Reverse gear (Output) max. 1.5A
Pin 12 - Black Ground
Coding of Rear-View Camera
Whilst in the vehicle’s main menu, press the menu button for 5 seconds to code
the unit
Reversing the Coding of the Rear-View Camera
To reverse the coding, repeat the above step
Picture Settings
For the best display of the rear-view camera video, the PDC function (optical)
must be set to OFF and camera function set to ON in the submenu.
Mode of Operation
After engaging reverse gear, the rear-view camera will be displayed on the
monitor automatically, remaining there until the vehicle reaches a speed of 20
km/h. The rear view camera can also be switched on or off manually by
pressing the PDC button.
www.aerpro.com
www.aerpro.com
4
NOTES
