protection to safeguard. (See fig 1.)
3. NEVER USE OXYGEN, COMBUSTIBLE OR ANY OTHER BOTTLE GAS as a power source
or would cause explosion and serious personal injury. (See fig 2.)
4. DO NOT CONNECT TOOL TO COMPRESSED AIR which pressure exceeds 120psi.
5. DO NOT PLACE OVER-LONG AIR HOSE in working area in case of the operator’s
unexpected tripping .Make sure all connections are tight
6. CARRING TOOL ONLY BY THE HANDLE do not keep the trigger pull on safety yoke
mechanism to avoid unintentional firing of fastener.
7. KEEP THE TOOL POINTED AWAY FROM YOURSELF and others at all time and keep hands,
any body parts away rear area to Safety guard against possible injury.
8. DISCONNECT TOOL FROM AIR SUPPLY BEFORE LOADING fasteners to prevent a
fastener from being fired during connection. (See fig3.)
9. DO NOT KEEP THE TIRGGER OR SAFETY DEPRESSED during loading fasteners or the
unintentional firing of a fastener would cause personal injury.
10. DO NOT KEEP THE TIRGGER OR SAFETY DEPRESSED during loading fasteners or the
unintentional firing of a fastener would cause personal injury.
11. DISCONNECT TOOL FROM AIR SUPPLY HOSE and close the compressor before performing maintenance, alter the
accessories or during non-operation.
12. DO NOT DRIVE FASTENER ON SCAFFOLDINGS,LADDERS and on such similarly construction, not working on
airtight case, and vehicles.
13. DO NOT DRIVE FASTENER ON TOP OF NAILED FASTENER, or the fastener can ricochet causing personal injury.
14. NEVER USE A TOOL that is leaking air, had missing or damaged parts or requires repair and make sure all the screws
and securely tightened.
15. ONLY USE PARTS AND ACCESSORIES recommend by manufacturer.
※ADDITIONAL SAFETY INSTRUCTIONS FOR PNEUMATIC POWER TOOLS
Air under pressure can cause severe injury.
Always shut off air supply, drain hose of air pressure and disconnect tool from air supply whenever not in use, before
changing accessories or where making repairs.
Never direct air at yourself or anyone else.
Whipping hoses can cause severe injury. Always check for damaged or loose hoses and fittings.
Cold air should be directed away from the hands.
Whenever universal twist couplings(claw couplings) are used, lock pins shall be installed and whip check safety
cables shall be used to safeguard against possible hose-to-tool and hose-to-hose connection failure.
Do not exceed the maximum air pressure stated on the tool.
Never carry an air tool by the hose.
Only fasteners listed in the specifications may be used in the fastener driving tool. The fastener driving tool and the
fasteners specified in the specifications are to be considered as one unit safety system.
Quick action couplings shall be used for connection to the compressed air system and the non-sealable nipple must
be fitted at the tool in such a way that no compressed air remains in the tool after disconnection.
Oxygen or combustible gases shall not be used as an energy source for compressed air operated fastener driving
tools.
Fastener driving tools shall only be connected to an air supply where the maximum allowable pressure of the tool
cannot be exceeded by more than 10%; in the case of higher pressure ,a pressure reducing valve which includes a
downstream safety valve shall be built into the compressed air supply.
Only the main energy and the lubricants listed in the operating instructions may be used for the maintenance of
fastener driving tools. Only spare parts specified by the manufacturer or his authorised representative shall be used.
Repairs shall be carried out only by the manufacturer's authorized agents or by other experts, having due regard to
the information given in the operating instructions.
