A E R O P R O

s.r.o.,Production of UL Planes

Dlhá 126, 949 07 Nitra, Slovak Republic

Tel./Fax: +421 37 6526355

FLIGHT MANUAL

AEROPRO

EUROFOX

AEROPRO EURO

FOX

FLIGHT MANUAL

- date- 2

Aircraft Name - Type:

EuroFOX 912 in version:

AEROPRO

EuroFOX Pro

EuroFOX Basic

EuroFOX modell 99

EuroFOX Space Bugrad

Serial Number:

Registration Mark: ………………………..

Date of Issue: ………………………..

Stamp, Signature

This ultralight has not been registered by state administration and

is to be operated at operator’s own responsibility.

This ultralight can be operated in compliance with information and

limitations contained herein.

AEROPRO EURO

FOX

FLIGHT MANUAL

- date- 3

DATA OF THE AEROPLANES

Type

Produktion

Serial

Number:

Destination and

year of

production

Fuselage

Engine

PROPELLERs

AEROPRO EURO

FOX

FLIGHT MANUAL

- date- 4

RECORD OF REVISIONS

Any revisions or amendments to the present manual shall be issued in

the form of bulletins with attached new pages. It is in the interests of

every user to enter such revision into the table of revisions and to

replace the existing page by the new one. The revised or corrected text

shall be indicated by a vertical line on left page margin and the page

shall bear revision number and date of its issue.

Rev.

No. Chapters

Affected Pages

Affected Date of

Issue Bulletin

Number

Bulletin

Approved On New Page

Inserted On,

Signature

AEROPRO EURO

FOX

FLIGHT MANUAL

- date- 5

0.1 LIST OF EFFECTIVE PAGES

Chap.

Page Date Chp.

Page Date Chap.

Page Date

0 1 2-9 4-11

2 4-12

3 3 3-1

4 3-2

5 3-3 5 5-1

6 3-4 5-2

1 1-1 3-5 5-3

1-2 3-6 5-4

1-3 3-7

1-4 6 6-1

1-5 4 4-1 6-2

4-2 6-3

2 2-1 4-3

2-2 4-4 7 7-1

2-3 4-5 7-2

2-4 4-6

2-5 4-7

2-6 4-8

2-7 4-9

2-8 4-10

AEROPRO EURO

FOX

FLIGHT MANUAL

- date- 6

0.2 TABLE OF CONTENTS

Chapter

General ..................................................................................................................1

Operating Limitations...............................................................................................2

Emergency Procedures ...........................................................................................3

Normal Procedures..................................................................................................4

Performance ............................................................................................................5

Weight and C.G. Position ........................................................................................6

Supplements............................................................................................................7

AEROPRO EURO

FOX

FLIGHT MANUAL

- date - 1-1

CHAPTER 1

1. GENERAL

TABLE OF CONTENTS

1.1

Introduction

1.2

Certification Basis

1.3

Warning, Caution and Note

1.4

Brief Description

1.4.1

Aircraft Type

1.4.2

Power Unit

1.4.3

Propeller

1.4.4

Aircraft Dimensions

1.4.5

Deflections of Control Surfaces

1.4.6

Landing Gear

1.4.7

Other equipment

1.5

Three-View Drawing

AEROPRO EURO

FOX

FLIGHT MANUAL

- date - 1-2

1.1 Introduction

This manual is designed to acquaint personnel with information towards

increasing safe and efficient aircraft operation.

This manual contains instructions necessary for pilots. Further it

contains additional data supplied by the aircraft manufacturer.

1.2 Certification Basis

This type of ultralight has been approved by Technical Board of LAA of

the Czech Republic in compliance with UL-2 regulation and it has been

issued Type Certificate No. ULL 03/96. Slovak Republic civile Aviation

Authotity has inssued Typ Certificate N: V – 82/2004 and DAeC has

issued Typ Certificate No: 61139.

1.3 Warning, Caution and Note

The following definitions apply to warnings, cautions and notes in the

flight manual:

WARNING Means that the non-observation of the corresponding

procedure leads to an immediate or important degradation

of the flight safety.

CAUTION Means that the non-observation of the corresponding procedure

leads to a minor or to a more or less long term degradation of

the flight safety.

NOTE Draws the attention of any special item not directly related to

safety but which is important or unusual.

AEROPRO EURO

FOX

FLIGHT MANUAL

- date - 1-3

1.4 Brief Description

1.4.1 Aircraft Type

EuroFOX is an ultralight designed as a high-wing monoplane supported

by struts. A two-spar wing is provided with flaperon. Fuselage is a lattice-

work of steel tubes. Tail unit is formed of a lattice-work tube frame.

Landing device is a type of trigear undercarriage with a controllable nose

wheel

1.4.2 Power Unit

The EUROFOX ultralight is powered by ROTAX 912 UL engine. It is a

four-cylinder, four-stroke, opposed-cylinder, centre-camshaft engine with

over-head valves. Engine cooling is of a combined type, cylinder heads

are water-cooled, while cylinders are air-cooled. Dry sump lubrication.

The ignition system is of a dual, distributorless and capacitor flywheel

magneto type. The engine is equipped with an electric starter, AC

generator and a mechanical fuel delivery pump. The propeller is

powered from an integrated reduction gear with mechanical damping.

WARNING This engine has not been certified as an aircraft one and its

failure may occur at any time! The aircraft pilot is fully

responsible for consequences of such failure.

1.4.3 Propellers

The propeller made by Woodcomp/FITI/DUC company is a three-

bladed, right-handed, tractor, composite.

1.4.4 Aircraft Dimensions

Wing span..................................................................................9,125 m

Length........................................................................................5,605 m

Height ........................................................................................2,25 m

Wing area with flap..................................................................11,4 m

Chord length without flap...........................................................1,12 m

with flap...........................................................1,3 m

Wing loading ..........................................................................39,47 kgm

-2

Aspect-ratio................................................................................7,3

Propeller clearance (in flight position).......................................0,22 m

AEROPRO EURO

FOX

FLIGHT MANUAL

- date - 1-4

1.4.5 Deflections of Control Surfaces

Elevator...................................................................up ............35°± 2°

...........................................................................down ............27°± 2°

Trim tab...................................................................up ............15°± 3°

...........................................................................down ............50°± 3°

Rudder...................................................................................±27°± 3°

Ailerons...................................................................up ............18°± 2°

...........................................................................down ........8.5°± 1°

Wing flaps...........................................................................0 ÷20°± 2°

1.4.6 Landing Gear

Track....................................................................................1.96 m

Wheel base..........................................................................1.3 m

Main landing gear wheel tire................................................ 14x4

Tire pressure.........................................................................200 kPa

Nose wheel tire........................................................................12x4

Tire pressure.........................................................................200 kPa

1.4.7 Other equipment

This aircraft is equipped with a hang glider release which can be used for

pulling of the advertisement flag.
