Subsystems for the
UAS intergration into
the airspace
Omni-directional
GroundStation
withBLE/Wi-Fi
Technology
Data sheet & User manual
1|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
Omni-directional Ground
Station with BLE/Wi-Fi
Technology
Introduction
OGS station is an ADS-B and BLE/Wi-Fi RemoteID Omni-directional receiver station with multi-constellation GNSS
sensor to provide best accuracy. LTE connectivity which simple setup of the MQTT broker allows usage in all LTE/4G
rich environments without the need for any additional cabling to send data. It has been designed to allow quick and
easy assemble enclosed in IP67 case for high weather condition resistance. Device comes with all necessary cables
and antennas for straight forward installation.
Data can be used with your server (user gets full data access). There is no obligation to send data to foreign servers,
user always retains data.
Air traffic data is also available via API and can be integrated with third-party software and applications, for example
using the MQTT protocol.
It is a perfect solution for permanent installation in open areas for constant airspace monitoring and conducting
VLOS/BVLOS operation where safety is critical.
Applications
• Airports and critical infrastructure
• Nationwide traffic management systems (manned and unmanned)
• Perfect solution for local airfields
• U-Space and UTM systems
• Network based Remote Identification (central monitoring)
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
2|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
Contents
1 Technical parameters ............................................... 3
2 Electrical specification ............................................... 4
2.1 Power supply .................................................. 4
3 Mechanical specification ............................................. 5
3.1 Mechanical parameters ............................................ 5
4 Quick start ...................................................... 6
4.1 Scope of delivery ................................................ 6
4.2 Installation process ............................................... 6
4.2.1 Mounting ................................................ 6
4.2.2 Power supply connection ....................................... 10
4.3 Inserting a SIM/chip card ........................................... 11
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
3|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
1Technical parameters
Parameter Description Typ. Unit
First Band ADS-B 1090 MHz
Second Band BLE/Wi-Fi 2400 MHz
Sensitivity (ADS-B) -90 dBm
Sensitivity (BLE) -105 dBm
Sensitivity (Wi-Fi ) -90 dBm
Integrated GNSS Multi-GNSS for precise time stamp
LTE Cat. 1 Data transport layer (global bands)
Table 1: General technical parameters.
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
4|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
2Electrical specification
2.1 Power supply
Parameter Value
Power connector Standard USB connector (programming and power supply)
Power consumption 1.5 W
Power supply 100 - 240 VAC
Table 2: Power supply of OGS-BLE
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
5|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
3Mechanical specification
3.1 Mechanical parameters
Parameter Value
Dimensions 170 x 170 x 100 mm
Weight 0.5 kg (Module without cables and antennas)
2.5 kg (With cables, arm and antennas)
Table 3: Mechanical parameters of OGS-BLE
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
6|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
4Quick start
4.1 Scope of delivery
1. Omni-directional Ground Station
2. ADS-B antenna
3. BLE antenna
4. Power Supply Cables
5. Small assembly parts
6. Antenna’s installation arm
7. Distance bracket
Figure 1: OGS-BLE equipment kit
4.2 Installation process
4.2.1 Mounting
1. Take the OGS out of the box and place facing down - as shown on the picture.
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
7|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
2. Place the arm on the OGS case (without installed antennas).
NOTE: Please observe correct direction. Front of the arm and front of the case have to face the same
direction.
Rotate OGS as shown on the picture below.
3. Mount black distance bracket with the protective earth conductor on the case.
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
8|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
NOTE: It is important that the cable is connected to the appropriate hole, which is marked on the case
with following electrical marking.
For installation, use the screws included in the kit.
4. After installing the arm, attach the antennas. Loosen the screws on both sides of the arm and tighten them
after inserting antennas. It is recommended to install antennas one by one to avoid damaging them.
Date: 2022-12-20 Document ref: 23ob-v1.0.15
This document is subject to change without notice. For technical questions, contact: [email protected]
9|Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet
5. After the mechanical part of installation, connect the antennas to the device and the device to the power supply
as shown below. Do not use both power sources at the same time.
6. Correct mounting shown below.
