FM6300G-AN

Gas cooking surface

Installation and Operating Instructions

Dear Customer,

Please read these user instructions carefully and keep them to refer to

later.

Please pass the user instructions on to any future owner of the appli-

ance.

The following symbols are used in the text:

1Safety instructions

Warning! Notes that concern your personal safety.

Important! Notes that show how to avoid damage to the appliance.

3Useful tips and hints

2Environmental information

Contents

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description of the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Burner powers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Ring switch settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Ring burner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operating the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Switching the appliance on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Tips on cooking and frying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Installing more than one Frontline hob . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Operating Instructions

1Safety instructions

3Please comply with these instructions. If you do not, any damage re-

sulting is not covered by the warranty.

Correct use

•This appliance should be used only for normal domestic cooking and

frying of food.

•The appliance must not be used as a work surface or as a storage sur-

face.

•Additions or modifications to the appliance are not permitted.

Gas/electrical safety

•This appliance must only be connected by a qualified electrician. Be-

fore installation and using for the first time, the operating and instal-

lation instructions are to be followed.

•The appliance must only be installed in accordance with the regula-

tions in force and only in a well ventilated, sufficiently large room. If

in doubt, speak to your installer.

•In the event of faults with the appliance or damage to the burner or

the glass ceramic (cracks, scratches, splits), switch off the appliance,

shut off gas supply. Do not use the appliance if damaged!

•If away from home for a long time: shut off mains gas supply.

•Repairs to the appliance must only be carried out by a qualified

service engineers. Considerable danger may result from improper re-

pairs. If repairs become necessary, please contact our Customer Care

Department or your dealer.

Child safety

•Small children must be kept away from the appliance.

•Only let older children work on the appliance under supervision.

Safety during use

1Warning in the event of a smell of gas

•Do not activate any electrical switches.

•Do not light matches or lighters, do not smoke.

•Open windows and doors, ventilate very well.

•Shut off gas supply to the appliance and mains gas supply.

•Contact your gas company’s emergency service or the servicedepart-

ment.

•Do not do anything to the appliance.

1In addition follow the safety instructions of your local gas supplier.

•Be careful if connecting electrical appliances to sockets near to this

appliance. Electrical leads must not be allowed to come near hot

rings.

1Warning: Risk of burns!

•During operation the rings become hot.

•Overheated fats and oils can ignite quickly. If you are cooking foods

in fat or oil (e. g., chips), you should watch the cooking process.

•Do not place or store flammable liquids, highly inflammable materials

or fusible objects (e.g. plastic film, plastic, aluminium) on or near the

appliance.

Safety when cleaning

•For cleaning, the appliance must be switched off and cooled down.

•For safety reasons, the cleaning of the appliance with steam jet or

high-pressure cleaning equipment is not permitted.

How to avoid damage to the appliance

•The glass ceramic can be damaged by objects falling onto it.

•Objects that melt and things that boil over can burn onto the glass

ceramic and should be removed straightaway.

Before using for the first time

•Remove pan stand, burner cover and burner crown.

•Remove any stickers that are on the glass ceramic.

•Put a few drops of glass ceramic cleaner on the glass ceramic and rub

with a cloth or kitchen paper.

•Wipe glass ceramic dry.

•Clean pan holder, burner crown and burner cover with warm water

and washing up liquid. Dry off.

•Replace burner crown, burner cover and pan stand.

Description of the Appliance

Cooking surface layout

Burner powers

Ring switch settings

Burner / Type of gas Natural gas Town gas Liquid gas

High capacity burner 3,0 kW 2,8 kW 2,8 kW

Normal burner 1,9 kW 2,0 kW 1,9 kW

Low capacity burner 1,0 kW 1,0 kW 1,0 kW

Total power 7,8 kW 7,8 kW 7,6 kW

Symbol Description

•Off position

maximum power

minimum power

Normal burner

Frontline strip

Ring switch

Low capacity burner

High capacity

burner

Ring burner

3The appliance is equipped with fully protected ring burners. If the

flames go out, for whatever reason, the gas supply is automatically

closed off.

Burner crown

Pan bracket

Burner cover

Burner body Thermosensor

Spark plug

Large flame jet

Operating the appliance

1Important

Each time before switching on make

sure that the burner crown and

burner cover are lying straight on

the burner body.

If burner crown and burner cover

are lying crookedly, the gas flame

does not burn evenly and it can

cause damage to the burner cover.

1Important

The apertures for the gas flames on the burner crown must not be

blocked by foods that have boiled over or by cleaning products.

Switching the appliance on and off

1. Turn the ring switch to the left to

maximum power .

2. Press the ring switch in firmly, until

the gas has ignited. After a success-

ful ignition hold the ring switch de-

pressed for about 5 seconds. If the

flames should go out, repeat the ig-

nition process.

3. Set the desired power. The power

can be set progressively from maxi-

mum power to minimum power .

4. To end the cooking process, turn

back to the Off position.

3In the event of a power cut or also when the spark plug is wet (because

of food boiling over or cleaning) the rings can also be ignited using a

gas lighter or a match.

1Warning!

Only take cookware from the ring when at minimum power or in the

Off Position •.

Tips on cooking and frying

Cookware

Use cookware with a flat bottom. The cookware must stand firmly on

the pan brackets.

Energy saving

2If possible, always place lids on the

pans.

The flames should not burn out be-

yound the bottom of the cookware.

We recommend the following sizes:

Ring Minimum diameter of the cookware

Low capacity

burner

120 mm

Normal burner 140 mm

High capacity

burner

160 mm
