AEG 33320 DK-M Manuel utilisateur
33320 DK-M
Einbau-Kochmulde
Electric Built-In Hob
Table de cuisson eléctrique
Electrischekookplaat
Gebrauchsanweisung
Operating Instructions
Mode d’emploi
Gebruiksaanwijzing
22
ImportantSafetyInformation
YouMUSTreadthesewarningscarefullybeforeinstallingorusing
thehob.
Keepthisinstructionbookforfuturereferenceandensureitis
passedontoanynewowner.
Thefollowingsymbolswillbefoundinthetexttoguideyouthroughoutthe
Instructions:
SafetyInstructions
Stepbystepinstructionsforanoperation
HintsandTips
EnviromentalInformation
ENGLISH
23
Contents
ChildSafety ....................................................................................... 22
Disposal ............................................................................................ 22
DuringUse ........................................................................................ 23
Descriptionoftheappliance .......................................................... 24
UsingtheHob ............................................................................. 24
OperationPilotLamp ................................................................... 24
Cookware .................................................................................. 26
CleaningandMaintenance ................................................................. 27
SomethingNotWorking? .................................................................... 28
Installation ........................................................................................... 29
Warningsabouttheelectricalconnection......................................... 29
ElectricalConnection................................................................... 30
Replacementofconnectioncable .................................................. 30
Warningsaboutbuildinginthehob ................................................. 31
Buildingindimensions ................................................................. 32
Cutoutsize ................................................................................ 32
SecuringtheHobintotheCutout ................................................... 33
TechnicalData ................................................................................... 34
Servicing ........................................................................................... 35
24
●This hob is designed to be operated by adults. Do not allow
children to play near or with the hob.
●The hob gets hot when it is in use.
●Children should be kept away until it has cooled.
●Children can also injure themselves by pulling pans or pots off
the hob.
Child Safety
Packaging
●Afterinstallation, please disposeof the packagingwith due regard
to safety and the environment.
The symbol on the product or on its packaging indicates that
this product may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health,
whichcould otherwise becaused byinappropriatewaste handling
of this product. For more detailed information about recycling of
this product, please contact your local city office, your household
waste disposal service or the shop where you purchased the
product.
Disposal of an old appliance
When disposing of an old appliance, make it unusable, by cutting
off the cable.
Disposal
25
Warnings
●Itis importanttonotethatthe platemay smokea littleandprodu-
ce a slightly unpleasant odour when used for the first time. This
is quite normal and will disappear after a few minutes.
●Take care when frying food in hot oil or fat, as the overheated
splashes could easily ignite.
●Neverleavetheplatesonwithoutapan onthemorwithanempty
pan on them.
●Never use the hob as a space heater.
●Never attempt to repair the hob! Repais carried out by
unexperienced persons can cause damage or injuries. This hob
should only be repaired or serviced by an authorised Service
Engineerandonlygenuineapprovedsparepartsshouldbeused.
●Thishob hasbeen registeredas a“Class Y”applianceaccording
to Fire Risk Protection Regulations. It can be built-in in furniture
units placed near higher walls or units, provided that one of the
sides is adjacent to an unit with the same height.
During Use
26
Using the
Hob
Description of the appliance
Using the hob
The knobs have 3 main heat settings, from "1" (minimum) to "3"
(maximum), but they can also be set in every intermediate
position, to adjust to personal needs.
To switch on a cooking zone, turn the relevant control knob
anticlockwise to the desired heat setting.
Place a saucepans on the cooking zone before switching it on.
Never leave the plates on without a pan on them or with an
empty pan on them.Avoid leaving an hot saucepan on a cold
plate, or leaving a hot saucepan to cool down on a switched off
plate. This could cause condensation and damage the plate.
Operating Pilot Lamp
This lamp comes on each time a cooking zone is switched on.
FrontHotplate
RearHotplate
Control Knob Operating Pilot
Lamp
Rear
Hotplate
FrontHotplate
Control Knob
27
For best cooking zone regulation, refer to the following table.
Setting Level best for
0 OFF
• Simmering vegetables
Fish in its own juice
1 LOW
Simmering potatoes or soups
• Boiling large quantities
of food, stews and soups
2 MEDIUM slow frying, making a roux
• Fast frying of meat or fish
3 HIGH
Rapidheatingup offator water
1
2
3
0
1
2
3
0
Operating Pilot Lamp
Control Knobs
Using the
Hob
28
Boiling
To parboil, select setting 3 and turn back to 1 for boiling; use
higher or lower setting as required.
Frying
Heat the fat up on setting 3, then insert food to be fried and turn
back to 2; use higher or lower setting as required.
Cookware
Utensils with an even bottom should be used in any case, best if
made of heatproof ceramic.
Uneven pots and pans do not allow heat to be spread evenly
throughout food, causing cooking times to be delayed and the
hob to be damaged.
Use utensils of a size matching the hotplates, or slightly larger,
and place them exactly on the hotplates.
Avoid using wet saucepans, or leaving wet saucepan covers on
the cold hotplates, because condensation can damage the
plate.
Cookware to be used on the hotplates should have strong, trued
bottom with triple layer, in order to ensure the best heat
absorption cooking results. Covered pans allow you to save
time and energy.
Glass pots, cast iron steak pans, such as copper or aluminium
pans are not recommended, because they often leave
reasidues which can damage the the hotplates.
Never use plastic cookware in any case!
Using the
Hob
Wrong Wrong Right
29
CleaningandMaintenance
Before any maintenance or cleaning can be carried out, you
must DISCONNECT the hob from the electricity supply and
allow it to cool down.
Wipe over the hob top using a soft cloth well wrung out in warm
water to which a little washing up liquid has been added.Avoid
the use of household detergent and bleaches, impregnated
pads unsuitable for non-stick saucepans, steel wool pads or
bath/sink stain removers.
The Hob Top
Regularly wipe over the hob top using a soft cloth well wrung out
in warm water to which a little wasing up liquid has been added.
Avoid the use of the following:
- household detergent and bleaches;
- impregnated pads unsuitable for non-stick saucepans;
- steel wool pads;
- bath/sink stain removers.
Should the hob top become heavily soiled, it is recommended
that a cleaning product such as Hob Brite or Bar Keepers Friend
is used.
The control knobs may be removed by carefully pulling them
upward for easier cleaning.
The Hotplates
Spills onto the actual plate should be removed using warm
water and a soft brush, nylon or plastic scourer. To keep the
plates looking as new, hotplate conditioner can be purchased
from most hardware stores, e.g. "4 Hob" by HomeCare
Products (follow the manufacturer's instruction for use).
Alternatively, wipe the plates with a drop of olive oil on a kitchen
towel to avoid rust. It is important to note that the plate will
smoke a little and produce a slightly unpleasant odour when
next used.
30
Something Not Working?
The operation pilot lamp does not come on.
Check you have followed all points of operating procedure
Check the mains fuses of the installation are not burnt out.
If after all these checks, your hob still does not operate correctly,
contact your local Service Centre.
Please note that it will be necessary to provide proof of
purchase for any in-guarantee service calls.
In-guarantee customers should ensure that the above
checks have been made as the engineer will make a
charge if the fault is not a mechanical or electrical
breakdown.
