AEG TR3050TW Manuel utilisateur

USER

MANUAL

EN User Manual 2

Tumble Dryer

DE Benutzerinformation 26

Wäschetrockner

TR3050TW

CONTENTS

1. SAFETY INFORMATION.............................................................................................3

2. SAFETY INSTRUCTIONS.............................................................................................5

3. PRODUCT DESCRIPTION...........................................................................................7

4. CONTROL PANEL....................................................................................................... 7

5. PROGRAMME TABLE................................................................................................. 9

6. OPTIONS....................................................................................................................10

7. SETTINGS...................................................................................................................12

8. BEFORE FIRST USE................................................................................................... 13

9. DAILY USE..................................................................................................................13

10. HINTS AND TIPS..................................................................................................... 15

11. CARE AND CLEANING.......................................................................................... 15

12. TROUBLESHOOTING.............................................................................................18

13. TECHNICAL DATA..................................................................................................19

14. QUICK GUIDE.........................................................................................................21

15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION

1369/2017........................................................................................................................23

16. GUARANTEE .......................................................................................................... 24

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com/webselfservice

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.aeg.com

1. SAFETY INFORMATION

Before beginning the installation and use of this

appliance, carefully read the supplied instructions. The

manufacturer is not responsible for any injuries or

damages that are the result of incorrect installation or

usage. Always keep the instructions in a safe and

accessible location for future reference.

- Read the supplied instructions.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent

disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be

kept away from the appliance unless continuously

supervised.

•Children of less than 3 years of age should be kept

away from the appliance unless continuously

supervised.

•Do not let children play with the appliance.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•If the appliance has a child safety device, it should be

activated.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

ENGLISH 3

1.2 General Safety

•Do not change the specification of this appliance.

•If the tumble dryer is put on top of a washing

machine, use the stacking kit. The stacking kit,

available from your authorized vendor, can be used

only with the appliance specified in the instructions

supplied with the accessory. Read it carefully before

installation (refer to the Installation leaflet).

•The appliance can be installed as freestanding or

below a kitchen counter with correct space (refer to

the Installation leaflet).

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite

side, that would prevent the appliance door from

being fully open.

•The ventilation opening in the base must not be

covered by a carpet, mat, or any floor covering.

•CAUTION: The appliance must not be supplied

through an external switching device, such as a timer,

or connected to a circuit that is regularly switched on

and off by a utility.

•Connect the mains plug to the mains socket only at

the end of the installation process. Make sure that the

mains plug is accessible after installation.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Do not exceed the maximum load of 8 kg (refer to the

"Programme chart" chapter).

•Do not use the appliance if items have been soiled

with industrial chemicals.

•Wipe away lint or packaging debris that has

accumulated around the appliance.

•Do not run the appliance without a filter. Clean the lint

filter before or after each use.

•Do not dry unwashed items in the tumble dryer.

www.aeg.com

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should

be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes

or pillows fitted with foam rubber pads should not be

dried in the tumble dryer.

•Fabric softeners, or similar products, should only be

used as specified by the product manufacturer’s

instructions.

•Remove all objects from items that could be a source

of fire ignition such as lighters or matches.

•WARNING: Never stop a tumble dryer before the end

of the drying cycle unless all items are quickly

removed and spread out so that the heat is

dissipated.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use the appliance

where the temperature can be lower

than 5°C or higher than 35°C.

• The floor area on which the appliance

is to be installed must be flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always keep the appliance vertical

when it is being moved.

• The rear surface of the appliance

must be put against a wall.

• When the appliance is in its

permanent position, check if it is

levelled correctly with the aid of a

spirit level. If it is not, adjust the feet

accordingly.

2.2 Electrical connection

WARNING!

Risk of fire and electric

shock.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• The appliance must be earthed.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

ENGLISH 5

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the

E.E.C. Directives.

2.3 Use

WARNING!

Risk of injury, electric shock,

fire, burns or damage to the

appliance.

• This appliance is for household use

only.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• If laundry has been washed with a

stain remover, carry out an additional

rinse cycle before starting a drying

cycle.

• Dry only fabrics that are suitable to

dry in the appliance. Follow the

cleaning instruction on the item label.

• Do not drink or prepare food with the

condensed water/distilled water. It

can cause health problems to people

and pets.

• Do not sit or stand on the open door

of the appliance.

• Do not dry dripping wet clothes in the

appliance.

2.4 Internal lighting

WARNING!

Risk of injury.

• Visible LED radiation, do not look

directly into the beam.

• The LED lamp is dedicated to drum

lighting. This lamp cannot be reused

for other lighting purposes.

• To replace the internal lighting,

contact the Authorised Service

Centre.

2.5 Care and cleaning

WARNING!

Risk of injury or damage to

the appliance.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use any abrasive products,

abrasive cleaning pads, solvents or

metal objects.

• To prevent damage to the cooling

system be careful when you clean the

appliance.

2.6 Compressor

WARNING!

Risk of damage to the

appliance.

• The compressor and its system in the

tumble dryer is filled with a special

agent which is free from fluoro-chloro-

hydrocarbons. This system must stay

tight. The damage of the system can

cause a leakage.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

www.aeg.com

3. PRODUCT DESCRIPTION

1 2

1Water container

2Control panel

3Internal light

4Appliance door

5Filter

6Rating plate

7Airflow slots

8Heat Exchanger lid

9Heat Exchanger cover

10 Adjustable feet

For ease of loading laundry

or ease of installation the

door is reversible. (see

separate leaflet).

4. CONTROL PANEL

1011 9 8

432

1Programme knob and RESET

switch

2Knitterschutz (Extra Anticrease)

touch button

3Trockengrad (Dryness Level)

touch button

4Display

5Zeit (Time Dry) touch button

6Start/Pause touch button

7Zeitvorwahl (Delay Start) touch

button

8Signal (End Alert) touch button

9Reverse Plus touch button

10 Extra Leise (Extra Silent) touch

button

11 On/Off button

ENGLISH 7

Press the touch buttons with

your finger in the area with

the symbol or name of the

option. Do not wear gloves

when you operate the

control panel. Make sure

that the control panel is

always clean and dry.

4.1 Display

Symbol on the display Symbol description

laundry dryness option: iron dry, cupboard dry,

extra dry

time drying option on

delay start option on

indicator:

check Heat Exchanger

indicator:

clean filter

indicator:

drain the water container

child lock on

wrong selection or knob is in the "Reset" posi-

tion

indicator:

drying phase

indicator:

cooling phase

indicator:

anti-crease phase

programme duration

, , , extension of default anti-crease phase: +30min,

+60min, +90min, +2h)

- time drying selection (10min-2h)

www.aeg.com8

Symbol on the display Symbol description

- delay start selection (1h-20h)

5. PROGRAMME TABLE

Programme Load 1) Properties / Fabric type2)

3) Baumwolle (Cot-

ton) Eco 8 kg

Cycle to be used to dry cotton with

"cotton cupboard" dryness level,

with maximum energy saving. /

Baumwolle (Cotton) 8 kg

Cycle defined to dry all types of

cotton ready to store (cupboard

dry). /

Mischgewebe (Synthetics) 3,5 kg Synthetic and mixed fabrics. /

Feinwäsche (Delicates) 4 kg Delicate fabrics such as viscose,

rayon, acrylic, and their blends. /

Daunen (Duvet) 3 kg

Single or double duvets and pil-

lows (with feather, down or syn-

thetic fillings). /

Auffrischen (Refresh) 1kg Refreshing textiles that were in storage.

Seide (Silk) 1 kg Gentle drying of hand-washable

silks. /

Wolle (Wool) 1 kg

Woollen fabrics. Gentle drying for hand-washa-

ble woollens. Remove items immediately when

the programme is completed.

The wool drying cycle of this machine has been

approved by The Woolmark Company for the

drying of wool garments labelled as "hand

wash" provided that the garments are dried ac-

cording to the instructions issued by the manu-

facturer of this machine. Follow the garment

care label for other laundry instructions. M1641

The Woolmark symbol is a Certification mark in

many countries.

ENGLISH 9

Programme Load 1) Properties / Fabric type2)

Outdoor 2 kg

Outdoor clothing, technical, sports

fabrics, waterproof and breathable

jackets, shell jackets with a remov-

able fleece or inner insulation.

Suitable for drying in tumble dryer.

Denim 4 kg

Leisure clothing such as jeans,

sweat-shirts of different material

thicknesses (e.g. at the neck, cuffs

and seams).

Bettwäsche (Bedlinen) XL 4,5 kg Up to three bed linen sets, one of

which can be double size. /

Mix (Mixed) XL 6 kg

Mix of garments made of cotton,

cotton-synthetic blend and syn-

thetic fabric. /

1) The maximum weight refers to dry items.

2) For fabric mark meaning see chapter

HINTS AND TIPS: Preparing the laundry.

3) The Baumwolle (Cotton) Schranktrocken (Cupboard Dry) ECO programme is the “Standard cot-

ton programme” according to Commission Regulation EU No. 392/2012. It is suitable for drying normal

wet cotton laundry and it is the most efficient programme in terms of energy consumption for drying wet

cotton laundry.

6. OPTIONS

6.1 Knitterschutz (Extra

Anticrease)

Extends the anti-crease phase by 30,60,

90 or 2 hours at the end of the drying

cycle. This function reduces creases. The

laundry can be removed during the anti-

crease phase.

6.2 Trockengrad (Dryness

Level)

This function helps to increase dryness of

the laundry. There are 3 options:

•Extratrocken (Extra Dry)

•Schranktrocken (Cupboard Dry)

•Bügeltrocken (Iron Dry)

6.3 Zeit (Time Dry)

You can set the programme duration,

from a minimum of 10 minutes to a

maximum of 2 hours. The required

duration is related to the quantity of

laundry in the appliance.

We recommend that you set

a short duration for small

quantities of laundry or for

only one item.

6.4 Zeit (Time Dry) on Wolle

(Wool) programme

Option suitable for Wolle (Wool)

programme to adjust final dryness level.

6.5 Signal (End Alert)

The buzzer sounds at the:

• cycle end

• start and end of the anti-crease phase

• cycle interruption

The buzzer function is by default always

on. You can use this function to activate

or deactivate the sound.

www.aeg.com

Table des matières

Langues :

Autres manuels AEG Séchoir

AEG

AEG LAVATHERM 57760 electronic Manuel utilisateur

AEG

AEG LAVATHERM 6DBG720N Manuel utilisateur

AEG

AEG LAVATHERM 76385AH3 Manuel utilisateur

AEG

AEG TR3060TW Manuel utilisateur

AEG

AEG LAVATHERM T8DHC862B Manuel utilisateur

AEG

AEG LAVATHERM 56740 Manuel utilisateur

AEG

AEG T7DBE38S Manuel utilisateur

AEG

AEG Lavatherm 450 R Manuel utilisateur

AEG

AEG T8DED844E Manuel utilisateur

AEG

AEG TR959M6OBC Manuel utilisateur

AEG

AEG LAVATHERM 743 U Manuel utilisateur

AEG

AEG LAVATHERM 86585IH Manuel utilisateur

AEG

AEG LAVATHERM 320 U Manuel utilisateur

AEG

AEG SV 2514 Manuel utilisateur

AEG

AEG LAVATHERM 37720 electronic Manuel utilisateur

AEG

AEG TB6080TW Manuel utilisateur

AEG

AEG TR939M4OBC Manuel utilisateur

AEG

AEG LAVATHERM 33600 Manuel utilisateur

AEG

AEG LAVATHERM 6DEL821G Manuel utilisateur

AEG

AEG LAVATHERM 65170AV Manuel utilisateur

AEG

AEG TR8G83GW Manuel utilisateur

AEG

AEG LAVATHERM 59840 Manuel utilisateur

AEG

AEG LAVATHERM 57520 electronic Manuel utilisateur

AEG

AEG TR7080TW Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire
