User Manual

USB-4751/4751L

48/24-channel Digital Input/

Output USB Module

USB-4751/4751L User Manual ii

The documentation and the software included with this product are copyrighted 2023

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgments

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed according to the cost of replacement mate-

rials, service time, and freight. Please consult your dealer for more details.

If you believe your product to be defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages displayed when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain a return merchandise authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the pack-

age prepaid to your dealer.

Part No. 2003475102 Edition 3

Printed in Taiwan January 2023

iii USB-4751/4751L User Manual

Declaration of Conformity

FCC Class A

This equipment has been tested and found to comply with the limits for a Class A dig-

ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference. In

this event, users are required to correct the interference at their own expense.

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

type of cable is available from Advantech. Please contact your local supplier for

ordering information.

Test conditions for passing also include the equipment being operated within an

industrial enclosure. In order to protect the product from damage caused by electro-

static discharge (ESD) and EMI leakage, we strongly recommend the use of CE-

compliant industrial enclosure products.

Technical Support and Assistance

1. Visit the Advantech website at www.advantech.com/support to obtain the latest

product information.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before calling:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

Document Feedback

To assist us with improving this manual, we welcome all comments and constructive

criticism. Please send all feedback in writing to [email protected].

USB-4751/4751L User Manual iv

Safety Precautions - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from

damage.

To avoid electrical shock, always disconnect the power from the PC chassis

before manual handling. Do not touch any components on the CPU card or

other cards while the PC is powered on.

Disconnect the power before making any configuration changes. A sudden rush

of power after connecting a jumper or installing a card may damage sensitive

electronic components.

v USB-4751/4751L User Manual

Contents

Chapter 1 Introduction..........................................1

1.1 Introduction ............................................................................................... 2

1.2 Hardware Features ................................................................................... 2

1.3 Software Overview.................................................................................... 2

Chapter 2 Installation............................................3

2.1 Unpacking ................................................................................................. 4

2.2 Driver Installation ...................................................................................... 4

Figure 2.1 XNavi Installer ............................................................ 4

2.2.1 Software Development Using DAQNavi SDK ............................... 5

2.3 Hardware Installation ................................................................................ 5

2.4 Hardware Uninstallation............................................................................ 6

Figure 2.2 Uninstalling USB-4751/4751L .................................... 6

Chapter 3 Signal Connections .............................7

3.1 Overview ................................................................................................... 8

3.2 I/O Connectors.......................................................................................... 8

3.2.1 Pin Assignments ........................................................................... 8

Figure 3.1 I/O Connector Pin Assignment ................................... 8

Figure 3.2 CN1/CN2 .................................................................... 8

3.2.2 Pin Assignments CN1 ................................................................... 9

Table 3.1: .................................................................................... 9

3.2.3 Pin Assignments CN2 ................................................................... 9

Table 3.2: .................................................................................... 9

3.2.4 I/O Connector Signal Description................................................ 10

Table 3.3: I/O Connector Signal Descriptions ........................... 10

3.2.5 LED Indicator Status Description ................................................ 10

Table 3.4: Table 3.2: LED Indicator Status Description............. 10

3.3 Digital I/O Connections ........................................................................... 11

3.3.1 Digital Input Signal Connection (TTL DI/O, Pull-Up)................... 11

Figure 3.3 Digital input signal connection .................................. 11

3.3.2 Digital Output Signal Connection (TTL DI/O).............................. 12

Figure 3.4 Digital output signal connection................................ 12

3.3.3 Counter Input Signal Connection (TTL, Pull-Up) ........................ 12

Figure 3.5 Counter input signal connection ............................... 12

3.3.4 Counter Output Signal Connection (TTL) ................................... 13

Figure 3.6 Counter output signal connection ............................. 13

3.4 Field Wiring Considerations .................................................................... 13

Appendix A Specifications ....................................15

A.1 Digital Input/Output ................................................................................. 16

A.2 Digital Input ............................................................................................. 16

A.3 Digital Output .......................................................................................... 16

A.4 General-Purpose Counter ....................................................................... 17

A.5 General Specifications ............................................................................ 17

USB-4751/4751L User Manual vi

Chapter 1

1Introduction

Sections include:

Introduction

Features

Specifications

USB-4751/4751L User Manual 2

1.1 Introduction

Thank you for buying the Advantech’s USB-4751/4751L data acquisition module.

The Advantech USB-4751/4751L is a powerful data acquisition (DAS) module for the

USB port. It features a unique circuit design and complete functions for data acquisi-

tion and control.

1.2 Hardware Features

USB-4751/4751L features excellent measurement & control functions:

48/24 digital input/output channels

50-pin box header

Interrupt handling

Programmable Counter/Timer

Supports both dry and wet contact

Compatible with USB 1.1/2.0

Bus-powered

1.3 Software Overview

Advantech offers device drivers, SDKs, third-party driver support and application

software to help fully exploit the functions of your DAQ devices. All these software

packages are available on Advantech website: http://www.advantech.com/.

The Advantech Navigator is a utility that allows you to set up, configure and test your

device, and later stores your settings in a proprietary database.

1. To set up the I/O device for your card, you could first run the Advantech Naviga-

tor program (by accessing Start/Programs/Advantech Automation/DAQNavi/

Advantech Navigator). The settings could also be saved to XML file, that can be

loaded in the applications using LoadProfile API.

2. You can then view the device(s) already installed on your system (if any) on the

Installed Device tree view. If the software and hardware installation are com-

pleted, you will see the device in the Installed Devices list.

Note! You can install up to sixteen USB-4751/4751L’s to a system because of

the maximum number limit of the device BoardID.

Note! The power output of an USB port is 500 mA, while the USB-4751/4751L

requires 500mA (Max.). This means that if an USB hub is used, it will

need an external power supply to support more than one USB-4751/

4751L device.

Note! For detailed specifications of USB-4751/4751L, please refer to Appendix

A, Specifications.

Chapter 2

2Installation

Sections include:

Unpacking

Driver Installation

Hardware Installation

Hardware Uninstallation

USB-4751/4751L User Manual 4

2.1 Unpacking

After receiving your USB-4751/4751L package, please inspect its contents first. The

package should contain the following items:

USB-4751/4751L Module

Shielded USB 2.0 Cable (1.72 m)

User Manual

The USB-4751/4751L Module harbors certain electronic components vulnerable to

electrostatic discharge (ESD). ESD could easily damage the integrated circuits and

certain components if preventive measures are not carefully paid attention to. Before

removing the module from the anti-static plastic bag, you should take following pre-

cautions to ward off possible ESD damage:

Touch the metal part of your computer chassis with your hand to discharge static

electricity accumulated on your body. One can also use a grounding strap.

Make contact between the anti-static bag and ground before opening.

After taking out the module, you should first:

Inspect the module for any possible signs of external damage (loose or damaged

components, etc.). If the module is visibly damaged, please notify our service depart-

ment or our local sales representative immediately. Avoid using a damaged module

with your system.

Avoid physical contact with materials that could hold static electricity such as

plastic, vinyl and Styrofoam.

2.2 Driver Installation

The driver package could be found on Advantech Support Portal (https://www.advan-

tech.com/support). Search for USB-4751/4751L on the support portal, then the corre-

sponded driver/SDK package could be found. You’ll get the XNavi installer after the

download session finishes.

Execute the installer, then it will guide you through the session. You can choose the

device and software components you’d like to install in the system (Figure 2.1). After

the selection, click on “start” to begin the installation.

Figure 2.1 XNavi Installer

Autres manuels pour USB-4751

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Advantech Système d'E/S

Advantech

Advantech USB-5801 Manuel utilisateur

Advantech

Advantech PCL-813 Manuel utilisateur

Advantech

Advantech PCM-27J3AU Manuel d'installation et d'exploitation

Advantech

Advantech PCI-1730 Manuel utilisateur

Advantech

Advantech WISE-4210 Series Manuel utilisateur

Advantech

Advantech 48/24-Channel Digital Input/Output USB Module... Manuel utilisateur

Advantech

Advantech WISE-4060 Manuel d'installation et d'exploitation

Advantech

Advantech ADAM-6100EI Series Manuel utilisateur

Advantech

Advantech WISE-4610 Series Manuel utilisateur

Advantech

Advantech USB-4751 Manuel utilisateur

Advantech

Advantech AMAX-5000 Series Manuel utilisateur

Advantech

Advantech ECU-P1702 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-3730 Manuel utilisateur

Advantech

Advantech WISE-4210 Series Manuel d'installation et d'exploitation

Advantech

Advantech PCIE-1756H Manuel utilisateur

Advantech

Advantech WISE-4000 Series Manuel utilisateur

Advantech

Advantech PCIE-1730 Series Manuel utilisateur

Advantech

Advantech PCI-1750 Manuel utilisateur

Advantech

Advantech AMAX-5000 Series Manuel utilisateur

Advantech

Advantech ADAM-6100PN Series Manuel utilisateur

Advantech

Advantech WISE-5000 Series Manuel utilisateur

Advantech

Advantech PCI-1758UDO Manuel d'installation et d'exploitation

Advantech

Advantech AIIS-1750 Manuel d'installation et d'exploitation

Advantech

Advantech ADAM-3013 Manuel utilisateur

Manuels Système d'E/S populaires d'autres marques

WAGO

WAGO 750-344 Manuel utilisateur

Teknim

Teknim TWM-1887 Mode d’emploi

Intelligent Appliance

Intelligent Appliance IA-2662-E Manuel utilisateur

BERGHOF

BERGHOF ECC DIO 16/16 Mode d’emploi

Festo

Festo CP-E08-M12-CL Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manuel utilisateur

Hitachi

Hitachi HX-RIO3 Series Manuel utilisateur

NUUO

NUUO SCB-A08 Manuel utilisateur

M-system

M-system R3Y-RS8 Manuel utilisateur

jablotron

jablotron JB-110N Manuel utilisateur

Omron

Omron SYSMAC C200H Manuel utilisateur

DOLD

DOLD SAFEMASTER M Manuel utilisateur

ABB

ABB OPT-MF-001 Manuel utilisateur

Omron

Omron SYSMAC C2000H Manuel utilisateur

Helmholz

Helmholz TB20 Manuel utilisateur

ICP DAS USA

ICP DAS USA tM-AD2 Manuel utilisateur

Automationdirect.com

Automationdirect.com DL305 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur
