Advantech FWA-3180 Series Manuel utilisateur
Advantech
Internet Security Platform
FWA-3180
Rackmount Internet Security
Platform with 8 Front LAN
Ports/ PCI Expansion Slot/
LCD Display
FWA-3180 User Manual --- Page II
Copyright Notice
This document is copyrighted, 2004. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described in
this manual at any time without notice. No part of this manual may be reproduced,
copied, translated or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original manufacturer
assumes no responsibility for its use, nor for any infringements upon the rights of
third parties which may result from its use.
CE Notification
The FWA-3180, developed by Advantech Co., Ltd., has passed the CE test for
environment specifications when shielded cables are used for external wiring. We
recommend the use of shielded cables.
1stEdition
PrintedinTaiwan June2004
FWA-3180 User Manual --- Page III
Product warranty
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two year from the date of
purchase.
This warranty does not apply to any products which have been repaired or altered
by persons other than repair personnel authorized by Advantech, or which have
been subject to misuse, abuse, accident or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is
defective, it will be repaired or replaced at no charge during the warranty period. For
out-of-warranty repairs, you will be billed according to the cost of replacement
materials, service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. For example, CPU
speed, Advantech products used, other hardware and software used, etc. Note
anything abnormal and list any on-screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return more
quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt) in
a shippable container. A product returned without proof of the purchase date is not
eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to
your dealer.
FWA-3180 User Manual --- Page IV
Packing List
Before installation, ensure that the following materials have been received:
• One FWA-3180 Internet Security Platform
• One box of accessories
• One CD-ROM for user manual (PDF file)
If any of these items are missing or damaged, contact your distributor or sales
representative immediately.
Technical Support and Sales Assistance
If you have any technical questions about the FWA-3180 or any other Advantech
products, please visit our support website at:
• http://www.advantech.com.tw/support
For more information about Advantech's products and sales information, please
visit:
• http://www.advantech.com.
FWA-3180 User Manual --- Page V
Contents
1. General Information....................................... 1
1.1 Introduction......................................................................... 2
1.2 Features................................................................................. 2
1.3 Specifications................................................................... 2
1.4 Dimensions....................................................................4
1.5 Model List....................................................................5
2. System Setup............................................... 6
2.1 Removing the cover............................................................................. 7
2.2 Installing Central Processing Unit (CPU)...................................... 8
2.3 Installing Memory Module............................................................9
2.4 Installing Hard Drive........................................................................10
2.5 Installing Compact Flash...................................................11
2.6 Setting LAN Bypass function.........................................................12
Appendix A...................................................15
A.1 NAME-3180 Mother Board...............................................16
FWA-3180 User Manual --- Page VI
Figures
Figure 1-1: FWA-3180 dimensions................................................................... 4
Figure 1-2: Outlook of FWA-3180......................................................................... 4
Figure 2-1: Front view of FWA-3180.......................................................... 7
Figure 2-2: Removing the cover............................................................. 7
Figure 2-3: Top view of FWA-3180.......................................................... 8
Figure 2-4: Installing Central Processing Unit steps..................................... 9
Figure 2-5: Installing Memory Module steps.................................................. 10
Figure 2-6: Installing Hard Disk Drive steps............................................. 11
Figure 2-7: Installing Compact Flash steps.................................... 12
Figure 2-8: The illustration of LAN Bypass function.................... 12
Figure 2-9: LAN Bypass function jumps....................................... 13
FWA-3180 User Manual --- Page 1
1
General Information
FWA-3180 User Manual --- Page 2
1.1 Introduction
Conceived as a powerful rackmount Internet Security platform, the FWA-3180 was
specifically designed for Internet secure connectivity. Designed with the Intel®
Pentium® 4 processor, it provides high performance and meets the requirements of
Internet security appliances. The system supports Compact Flash for OS and
Internet security applications. This avoids service disruption caused by hard disk
mechanical / magnetic failures. In addition, the FWA-3180 can support system
memory up to 2 GB DDR memory. Both Compact Flash and memory can be
accessed and replaced for software upgrades through an easily removable cover.
Designed with the Plug-and-Serve concept in mind, the FWA-3180 offers eight
10/100/1000 Mbps auto-sensing LAN ports in the front panel. There are two LED
Indicators which monitor power and HDD activities. For easy access, the front panel
has a 9-pin, RS-232 serial port for local system management, maintenance and
diagnostics. The FWA-3180 provides optional 3.5” IDE HDD and one PCI slot. It is
FCC and CE compliant. Please see the FWA-3180 user manual for more details.
1.2 Features
• 1U rackmount Internet security platform
• Socket 478 Intel® Pentium® 4
• One 32-bit/33 MHz PCI expansion slots
• Eight 10/100 Fast Ethernet or 10/100/1000 Gigabit Ethernet ports
• Console port for local setting
• Hard drive mounting bracket for 3.5” drive
• LCD display module
• LAN Bypass function
1.3 Specifications
• Processor System:
CPU: Intel Pentium 4 , 3.06G Hz
Max. Speed: 533/400 MHz FSB
L2 Cache: 512/256KB
Chipset: Intel 845GV, ICH4
BIOS: Award 2 Mb Flash
• Memory: Support DDR 266/200, Max. Capacity 2 GB, Socket 184-pin DIMM x 2
• Ethernet: 10/100 Fast Ethernet or 10/100/1000 Gigabit Ethernet, RJ-45 x 8
FWA-3180 User Manual --- Page 3
• Drive Bay: 3.5”HDD x1
• Management: Console RS-232 x1
• Cooling: Fan (15 CFM) x2, Blower x1
• Miscellaneous: Power Switch, 2 LED indicators for Power/HDD, CompactFlash
Socket x1, LCD Display Module x1
• Adapter Power Requirement:
Input: ATX PS, AC 90 ~ 264 V @ 47 ~ 63 Hz, full range
Output: 250W
• Operating Environment:
Operating: Temperature 0 ~ 40 °C (32 ~ 104 °F), Humidity 5 ~ 85 %
Non-Operating: Temperature -20 ~ 75 °C (-4 ~ 167 °F), Humidity 5 ~ 95 %
• Dimensions (W x H x D):
1U: 426 x 44.4 x 380 mm (16.7” x 1.7” x 14.9”)
• Weight: 4.5 Kg (9.9 lb)
FWA-3180 User Manual --- Page 4
1.4 Dimensions
Figure 1-1: FWA-3180 dimensions.
Figure 1-2: Outlook of FWA-3180
