Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 1 / 8

1 For your safety

Carefully read and comply with this

quick start guide.

Carefully read and comply with the

safety information provided with the

DLT-V72.

Keep all documents for future

reference.

DANGER

Observe the intended use.

Observe the intended use of the DLT-V72, e.g. no use in EX zone (potentially

explosive), no use in life-supporting systems or security-critical facilities.

For details, see User Manual DLT-V72 available in the Download

Center at www.advantech-dlog.com.

WARNING

Hazardous voltage, electric shock from contact with live parts.

This quick start guide is intended for skilled personnel.

Only authorized skilled personnel may put the DLT-V72 into operation.

For DLT-V72 industrial PCs with an uninterrupted power supply (UPS),

knowledge is required of lithium-ion batteries and the precautions that have to be

taken with them.

Do not put the DLT-V72 into operation if it is visibly damaged.

Do not open or modify the DLT-V72.

Operators of the DLT-V72 must be trained in the handling of the device.

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 2 / 8

2 Technical data DLT-V72

Dimensions and weight

DLT-V7210

Dimensions

Width x height x depth in mm: 297 x 238.5 x 67

Weight

3.7 kg (with screen defroster, without accessories)

DLT-V7212

Dimensions

Width x height x depth in mm: 335 x 267 x 69

Weight

4.65 kg (with PCT, without accessories)

Environmental conditions DLT-V72 without integrated UPS

Operating temperature

-30 to +50 °C

Storage temperature

-30 to +65 °C

Vibration/shock Class 5M3 according to EN 60721-3-5

US Highway Truck according to MIL-STD 810F

IP protection class

IP66

Environmental conditions DLT-V72 with integrated UPS

See chapter 8.

3 Operation DLT-V72

This key has two fuctions.

Function 1: Activate/deactivate touchscreen

Touch LED on (orange): Touchscreen inactive

Touch LED off: Touchscreen active

Function 2, in combination with the <SHIFT> key:

Activate/deactivate screen defroster (optional)

Note: The temp LED indicates whether the screen defroster is active

or inactive, not the touch LED above this key.

- Device on/off

- Display brighter

- Display darker

- Backlighting on/off

- Touchscreen or

Screen deforster

on/off

- S1 to S8

- SHIFT

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 3 / 8

4 Software configuration

4.1 DLoG Config for DLT-V72 with Microsoft Windows

The DLoG Config software is used to configure DLT-V72 devices with a Microsoft

Windows operating system. Aspects such as the following are configured:

−Automatic shutdown

−Wi-Fi status display

−Front-key assignment

−Network settings

−Battery pack charge settings (only on devices with optional UPS)

−Screen defroster heating function (only on devices with optional screen

defroster)

−Operation with gloves possible (only on devices with optional PCT touchscreen)

Start DLoG Config by choosing Start -> Programs -> DLoG: DLoG Config

or by clicking the Config icon on the taskbar.

DLoG Config default password: "gold".

DLoG Config is automatically started in admin mode. Only in admin mode is it possible

to save settings.

4.2 DLT-V72 with ADLoG Linux

You will find the configuration description for the ADLoG Standard Linux image at

www.advantech-dlog.com (Download menu, login required).

5 Wi-Fi settings

CAUTION

Radio wave emission due to incorrect Wi-Fi configuration.

Risks to health are possible due to incorrect radio wave emission if the

transmission power and the frequency are set incorrectly during the Wi-Fi

configuration.

Observe the applicable regulations for your deployment location/country with

regard to frequencies and the maximum permissible transmitting power.

Responsibility for this lies with the company operating the DLT-V72. The

regulatory authorities in the relevant country can provide information on this.

A default profile with basic settings for Wi-Fi operation is defined at the factory.

To create a custom profile, please use the Wi-Fi configuration program that is

preinstalled on your DLT-V72.

Depending on the Wi-Fi driver used, the following configuration programs are

available:

Laird Connection Manager (LCM)

Password: SUMMIT

(Upper case mandatory)

Windows Zero Configuration (WZC) No password required

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 4 / 8

6 Observe before installing

WARNING

Risk of injury and damage due to improper installation.

Observe the following important safety notice sections in the DLT-V72 User

Manual before installing the device:

−Installation of the DLT-V72 on vehicles

−Vehicle potential ratios

−

Electrically isolated installation

Recommend sequence for the mechanical installation

Requirement: The vehicle / installation location must be prepared (e.g. connection to

the ignition, correct voltage, etc.)

We recommend the following sequence for the mechanical and electrical installation:

−Determine a suitable mounting position for the DLT-V72.

−Secure device mounting at the vehicle / installation location.

−Connect external accessories to the DLT-V72.

−Install an easily accessible disconnecting device, such as a switch

close to the device.

−Connect all cables.

−Close the DLT-V72 with cable cover.

−Mount the DLT-V72 on the device mounting bracket

7 Cable connection, strain relief rail, cable cover

7.1 Inserting the rubber seal in the cable compartment

Place the rubber seal in the frame of the cable compartment (see figure).

Press the plugs of the rubber seal into the holes of the frame.

7.2 Plugging in and screwing on the power supply cable

Plug the power supply cable into the power supply

plug-in location.

Screw both mounting screws hand-tight.

Fold open the round cable passage in the rubber

seal.

Insert the power supply cable.

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 5 / 8

7.3 Securing the ground using ring tongue to the ground bolt

Secure the ring tongue of the power supply cable to the ground bolt:

ATTENTION

For correct grounding, it is important to have

the correct order of the components on the

ground bolt (from inside to outside):

1. Toothed washer (internal)

2. Ring tongue of the power supply cable

(flat side faces the DLT-V72 connector

panel)

3. Tightening the nut hand-tight.

7.4 Securing the power supply cable to the strain relief rail

Place one cable clip on the power supply cable.

Secure the cable clip to the strain relief rail using 2 mounting screws (ISO 4762-

M4x10-A2 cylinder-head screws).

Tighten the mounting screws alternatingly.

ATTENTION Tighten the mounting screws sufficiently but on no account pinch or

crush the cable. If you do, the cables may break or the cable insulation may get

damaged.

7.5 Connecting the USB, Ethernet and COM cables

Only use accessories that have been tested and approved by Advantech-DLoG for

the respective DLT-V72.

Proceed as described in section above (Securing the power supply cable).

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 6 / 8

7.6 Closing off unused cable openings

Close off all unused cable openings of the rubber seal using the accompanying

blind plugs so that they are sealed.

7.7 Attaching the cable cover

Place the cable cover in the DLT-V72 housing slot.

Screw the cylinder-head screws loosely into the holes of the cable cover.

Then fully tighten the screws alternatingly with 3 Nm torque.

8 Integrated UPS and battery pack (optional)

The DLT-V72 is optionally available with an integrated uninterrupted power supply

(UPS). The battery pack (lithium-ion technology) of the UPS is located in the battery

pocket up top on the device.

WARNING

Personal injury due to short-circuit, fire, chemical burns, toxic substances.

DLT-V72 devices with integrated UPS contain lithium-ion battery packs. These

can ignite if handled or stored improperly (risk of fire), cause chemical burns or

release toxic substances.

Use care when handling lithium-ion battery packs.

Do not damage lithium-ion battery packs; do not drill through and do not

crush or drop.

Do not allow water or other liquids to come into contact with the device

(exercise particular caution with corrosive liquids).

Do not allow it to come into contact with fire.

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 7 / 8

Environmental conditions / performance specifications battery packs

Battery pack type I, 2500 mAh battery capacity, order no. DL-BTRG79461600

Bridging time

Typically 20 minutes. (when battery pack is fully charged)

Operating temperature

-20 to +40 °C

Charging time

4 h (fully recharge a completely discharged battery pack)

Charging temperature

-10 to +30 °C (ambient temperature)

Storage temperature

-20 to +60 °C

Maximum output power

40 W

Battery voltage

7,2 V

Battery pack type II, 2000 mAh battery capacity, order no. DL-BTRG79461700

Bridging time

Typically 20 minutes. (when battery pack is fully charged)

Operating temperature

-30 to +50 °C

Charging time

4 h (fully recharge a completely discharged battery pack)

Charging temperature

-10 to +50 °C (ambient temperature)

Storage temperature

-30 to +60 °C

Maximum output power

40 W

Battery voltage

7,2 V

8.1 Charging the battery pack

Connect the properly installed DLT-V72 to the main supply voltage.

(Note: DLoG Config settings may affect the charging behavior of the DLT-V72).

ATTENTION:

The cable cover and the battery pocket of the DLT-V72 must be screwed together

properly. The device must be fully closed.

WARNING

Electric shock when charging the battery pack.

Do not connect damaged battery packs to the DLT-V72; do not charge.

Battery packs become warm while charging; this is normal. However, if they

become excessively hot, immediately disconnect the DLT-V72 from the

power source.

Do not continue to use the DLT-V72 if you notice an unusual level of heat or

an unusual smell during charging.

Provide for sufficient ventilation of the DLT-V72 during charging.

8.2 Replacing the battery pack

WARNING

Personal injury due to short-circuit, fire, chemical burns, toxic substances.

No third-party battery packs permitted.

Use only original battery packs from Advantech-DLoG.

The battery packs must be authorized/approved for the DLT-V72.

Do not use battery packs from any other Advantech-DLoG devices; they are not

compatible.

If battery packs from other manufacturers are inserted in the DLT-V72, the

warranty provided by DLoG GmbH for this device will be rendered void.

Quick Start Guide: DLT-V72 Industrial PC

Advantech-DLoG

Quick Start Guide: DLT-V72, V1.00, PN 20DLDOCX88521E00

Page 8 / 8

Procedure for replacing the battery pack

IMPORTANT: Switch off the DLT-V72 and disconnect the device from

the power supply.

Loosen the two screws of the battery cover using an Allen wrench.

Remove the battery cover.

Remove the battery pack.

Insert the new battery pack into the battery pocket.

Make sure that the removal tab of the battery pack is inside the sealing surface.

Then reattach the battery cover (tightening torque 2 Nm).

9 End-of-life device disposal / Recycling

DLT-V72 devices that are defective or ready for disposal are

considered to be special waste and can be recycled. They must not

disposed of with general/domestic waste

The lithium-ion batteries in DLT-V72 devices with an integrated UPS

are also special waste and recyclable. In the same way, they must not

be disposed of with general/domestic waste.

Proper disposal in accordance with local regulations is required.

Please contact the responsible authorities in your country/region to find

out about the applicable regulations, if necessary.

10 Technical customer support

E-Mail: helpdesk@advantech-dlog.com Web: www.advantech-dlog.com

Phone: (+49) 89 / 41 11 91 999

DLoG GmbH

Industriestraße 15

D-82110 Germering

Quick Start Guide DLT-V72

PN: 20DLDOCX88521E00

V1.00

02/02/2016

Warranty conditions

For DLT-V72 industrial PCs, batteries and accessories the Advantech-DLoG TOB

regulations are valid (section Liability for defects -> limitation period for claims).

Find details at www.advantech-dlog.com.

Regulatory information, conformity

Please find regulatory information and a copy of the declaration of

conformity in the DLT-V72 User Manual at www.advantech-dlog.com.

We reserve the right to make changes to this document at any time – and without prior

notice. DLoG GmbH is not liable for technical or printing errors or shortcomings in this

document. DLoG GmbH accepts no liability for damage caused directly or indirectly by

the delivery, performance or use of this document.

Autres manuels pour DLoG DLT-V72 Series

Table des matières

Autres manuels Advantech Ordinateur de bureau

Advantech

Advantech MICA-071 Manuel d'instructions

Advantech

Advantech MIC-1810 Manuel utilisateur

Advantech

Advantech DLT-M8110 Manuel utilisateur

Advantech

Advantech POC-W242 Manuel d'instructions

Advantech

Advantech SOM-7532 Manuel utilisateur

Advantech

Advantech UBC-220 Manuel utilisateur

Advantech

Advantech ARK-DS262 Manuel utilisateur

Advantech

Advantech ARK-1124 Manuel utilisateur

Advantech

Advantech PPC-L156T Manuel utilisateur

Advantech

Advantech PPC-415 TGL Manuel utilisateur

Advantech

Advantech ECU-4784 Series Manuel utilisateur

Advantech

Advantech DS-410 Manuel utilisateur

Advantech

Advantech UNO-1170E Manuel utilisateur

Advantech

Advantech ITA-5231 Series Manuel d'installation et d'exploitation

Advantech

Advantech DS-562SQ-S6A1E Manuel utilisateur

Advantech

Advantech ark-3405 Manuel utilisateur

Advantech

Advantech EPC-T1228 Series Manuel utilisateur

Advantech

Advantech PPC-3100 Manuel utilisateur

Advantech

Advantech ITA-2231 Series Manuel d'installation et d'exploitation

Advantech

Advantech ARK-3534 Manuel utilisateur

Advantech

Advantech PCA-6013 Manuel d'installation et d'exploitation

Advantech

Advantech MIC-770 Manuel d'installation et d'exploitation

Advantech

Advantech UTC-315 POS Series Manuel utilisateur

Advantech

Advantech UNO-1110-R11AE Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
