ADTRAN NetVanta Series Manuel utilisateur

Technical Support 1-888-4ADTRAN (1-888-423-8726)

NetVanta Series

(with Serial Network Interface Module)

Quick Configuration Guide 64200866L1-42C March 2005

• V.35 or X.21 cable for connecting the system to the existing network.

• VT100 terminal or PC with VT100 emulation software.

• DB-9 (male) to DB-9 (female) straight-through cable for configuring the unit.

Frame Relay Diagram

PPP over Point-to-Point T1 Diagram

Equipment Required

Cable length for the serial interface should not exceed 25 feet.

This quick configuration guide provides step-by-step instructions for configuring

your application. The configuration scripts are available on the ADTRAN OS

Documentation CD.

Network Diagrams

Branch Office Corporate HQ

NetVanta

LAN IP: 10.10.10.1 /24

WAN IP: 192.168.72.2 /30

Network IP: 190.72.22.0

Network IP: 10.10.20.0

eth 0/1

LAN IP: 10.10.20.7 /24

PWR STAT TD

VPN

RD TD RD TD RD

WAN LAN

PWR STAT TD

VPN

RD TD RD

NetVanta3200

WAN LAN

DLCI 16

Annex D Signaling

192.168.72.1 /30

FR 1.x

SHIFT

QUICK

TSUIQ

ENTER

CANCEL

NEXT PREV ADD

DELETE

TSU

SHIFT

QUICK

TSUIQ

ENTER

CANCEL

NEXT PREV ADD

DELETE

TSU

V.35 or X.21 V.35 or X.21

Branch Office Corporate HQ

NetVanta

LAN IP: 10.10.10.1 /24

eth 0/1

LAN IP:

serial 1/1

10.10.20.7 /24

WAN IP: 192.168.72.2 /30

PWR STAT TD

VPN

RD TD RD TD RD

WAN LAN

PWR STAT TD

VPN

RD TD RD

NetVanta3200

WAN LAN

Point-to-Point T1

PPP Signaling

192.168.72.1 /30

PPP 1

SHIFT

QUICK

TSUIQ

ENTER

CANCEL

NEXT PREV ADD

DELETE SHIFT

QUICK

TSUIQ

ENTER

CANCEL

NEXT PREV ADD

DELETE

TSU TSU

V.35 or X.21V.35 or X.21

Network IP: 190.72.22.0

Network IP: 10.10.20.0

2 Technical Support 1-888-4ADTRAN (1-888-423-8726) 64200866L1-42C

The NetVanta may be initially accessed and managed either via a console session or through a

Telnet session. Refer to Initiate a Console Session below for console session instructions.

Initiating a Telnet session requires using a hub and two Ethernet cables (one for the PC and one

for the unit). The default Ethernet IP address is 10.10.10.1. Refer to step 9 to change Telnet

session settings.

1. Connect a VT100 terminal (or PC with VT100 emulation software) to the NetVanta

CONSOLE port using a DB-9 (male) to DB-9 (female) straight-through serial cable.

2. Configure the COM port with the following parameters:

Data Rate: 9600

Data Bits: 8

Parity Bits: None

Stop Bits: 1

Flow Control: None

3. Open a VT100 terminal session. (Please refer to the appropriate VT100 terminal software

documentation for detailed instructions.)

4. Press the <Enter> key.

5. Enter enable at the >prompt.

6. Enter the password when prompted. The default password is password.

7. You are now at the #prompt. At the # prompt, enter config terminal to enter the Global

Configuration mode.

1. At the (config)# prompt, enter interface eth 0/1 to access the configuration parameters for

the Ethernet port located on the rear panel of the unit.

2. Enter ip address 10.10.20.7 255.255.255.0 to assign an IP address to the Ethernet port

using a 24-bit subnet mask.

3. Enter no shutdown to activate the interface to pass data.

4. Enter exit to exit the Ethernet interface commands and return to the Global Configuration

mode.

Configure the Unit

Initiate a Console Session

Configure the Ethernet Port Parameters

If you are accessing the NetVanta via Telnet, once you change this IP address, you will

lose connection to the NetVanta. You must change the IP address of your PC before you

can proceed.

ADTRAN recommends that you set the Ethernet speed and duplex to match the switch or

hub it is plugged in to.

For example: (config-eth 0/1)#speed 10

(config-eth 0/1)#half-duplex

64200866L1-42C Technical Support 1-888-4ADTRAN (1-888-423-8726) 3

The following steps demonstrate configuring a serial network interface.

1. At the (config)# prompt, enter interface serial 1/1 to activate the interface configuration

mode for the serial network interface.

2. Enter serial-mode v35 to configure the serial interface for use with the V.35 adapter cable

(P/N 1200873L1).

3. Enter no shutdown to activate the interface to pass data.

The following steps outline configuring a Frame Relay virtual interface (labeled 1) using a single

DLCI back to the corporate router (defined as DLCI 16).

1. At the (config)# prompt, enter interface fr 1 to create a Frame Relay virtual interface

labeled 1.

2. If the default setting of ansi was changed, enter frame-relay lmi-type ansi to configure

Frame Relay virtual interface 1 to use ANSI (Annex D) signaling.

3. Enter no shutdown to activate the virtual interface to pass data.

4. Enter exit to return to the Global Configuration mode.

5. The unit has a factory default PPP 1 interface. Enter the command no ppp 1 to remove this

interface.

1. At the (config)# prompt, enter interface fr 1.16 to create a PVC assigned to Frame Relay

virtual interface 1. This activates the configuration parameters for the PVC. Your prompt

should now display (config-fr 1.16)#.

2. Enter frame-relay interface-dlci 16 to assign DLCI 16 to this PVC.

3. Enter ip address 192.168.72.1 255.255.255.252 to assign an IP address of 192.168.72.1 for

this PVC using a 30-bit subnet mask.

4. Enter no shutdown to activate the virtual interface to pass data.

5. Enter exit to return to the Global Configuration mode.

6. If you are configuring the NetVanta for use in a Frame Relay application and have completed

this step, skip to Create the Cross-Connect on page 4.

The NetVanta Network Interface Modules (NIMs) use a slot/port notation for interface

identification. All non-modular interfaces built into the base unit (e.g., the Ethernet port) are

identified using 0as the slot number.

Configure the Serial Interface

Skip to Configure the Virtual PPP Interface on page 4 for PPP configuration.

Configure the Frame Relay Virtual Interface

Create the PVC and Assign an IP Address

The default encapsulation is RFC 1490 or IETF. Make certain the remote unit uses the

same encapsulation for Frame Relay.

4 Technical Support 1-888-4ADTRAN (1-888-423-8726) 64200866L1-42C

The following steps show how to configure a PPP virtual interface (labeled 1) to the corporate

router. Skip to Create the Cross-Connect below if you are using Frame Relay.

1. At the (config)# prompt, enter interface ppp 1 to create a PPP virtual interface labeled 1.

2. Enter ip address 192.168.72.1 255.255.255.252 to assign an IP address to the PPP

endpoint using a 30-bit mask.

3. Enter no shutdown to activate the virtual interface to pass data.

4. Enter exit to return to the Global Configuration mode.

1. For Frame Relay applications, at the (config)# prompt, enter cross-connect 1 serial 1/1

frame-relay 1 to connect the serial NIM to the virtual Frame Relay interface (fr 1.16).

2. For PPP applications, enter cross-connect 1 serial 1/1 ppp 1 to connect the serial NIM to

the virtual PPP interface labeled 1 (ppp 1).

Routes may be assigned either statically or dynamically. Continue with this section to create a

static route. Refer to the next section for information on configuring RIP and OSPF dynamic route

assignments.

Depending on your network setup, configure static routing on your unit in one of the following

ways.

Scenario 1: Configuration for Corporate HQ router in the diagram on page 1 (Static Route

to the Far Side/Internet Access at Local Site)

1. At the (config)# prompt, enter ip route 10.10.20.0 255.255.255.0 ppp 1 (or frame-relay

1.16) to set up the static route.

2. Enter ip route 0.0.0.0 0.0.0.0 10.10.10.x (i.e., address of internet router) to set up the default

route.

Configure the Virtual PPP Interface

Create the Cross-Connect

Configure the Static Routes

These examples are based on the network diagrams on page 1.

64200866L1-42C Technical Support 1-888-4ADTRAN (1-888-423-8726) 5

Scenario 2: Configuration for Branch Office router in the diagram on page 1 (No Internet

Access at Local Site)

1. At the (config)# prompt, enter ip route 0.0.0.0 0.0.0.0 ppp 1 (or frame-relay 1.16) to set up

the default route.

2. The internet router at the far side will need a route statement to send traffic back to this

network through the NetVanta router. The information (based on the diagram shown at the

beginning of this document) is as follows:

• Destination address: 10.10.20.0 (remote LAN)

• Subnet mask: 255.255.255.0

• Gateway: 10.10.10.1 (NetVanta router’s Ethernet)

3. Enter bind 3 t1 3/2 1 ppp 2 to connect DS0 1 through 24 of the T1 network connection

(t1 3/2) to the multilink ppp interface labeled 2.

4. Repeat the process to configure any additional T1 interfaces needed for your application.

Scenario 1: Dynamic Routing via OSPF

1. At the (config)# prompt, enter router ospf to activate the OSPF configuration mode. Your

prompt should now display (config-ospf)#.

2. Specify the networks:

Corporate HQ Router

(config-ospf)#network 10.10.10.0 0.0.0.255 area 0

(config-ospf)#network 192.168.72.0 0.0.0.3 area 0

Branch Office Router

(config-ospf)#network 10.10.20.0 0.0.0.255 area 0

(config-ospf)#network 192.168.72.0 0.0.0.3 area 0

3. Enter exit to return to the Global Configuration mode.

Scenario 2: Dynamic Routing via RIP

1. At the (config)# prompt, enter router rip to activate the RIP configuration mode. Your prompt

should now display (config-rip)#.

2. Enter version 2 to globally define RIP version 2 on all interfaces.

3. Specify the networks:

Corporate HQ Router

(config-rip)#network 10.10.10.0 255.255.255.0

(config-rip)#network 192.168.72.0 255.255.255.252

Branch Office Router

(config-rip)#network 10.10.20.0 255.255.255.0

(config-rip)#network 192.168.72.0 255.255.255.252

4. Enter exit to return to the Global Configuration mode.

1. Verify that the prompt of your unit displays (config)#.

2. Enter enable password word to set the Enable Security mode password.

3. Enter enable password md5 word to encrypt the enable password using MD5 encryption.

Configure Dynamic Routes

Set the Enable Security Mode Password

6 Technical Support 1-888-4ADTRAN (1-888-423-8726) 64200866L1-42C

The following steps show how to access the Telnet configuration parameters and change the

password. The default password for initializing a Telnet session is password (all lowercase). For

security purposes, change the password to something unique. For this example, replace the

underlined word with a password of your choosing. The NetVanta supports five Telnet sessions

(0 through 4).

1. Verify that the prompt of your unit displays (config)#.

2. Enter line telnet 0 4 to change the configuration parameters for the Telnet session.

3. Enter password word to change the login password for the Telnet session.

4. Enter exit to return to the Global Configuration mode.

1. Verify that the prompt of your unit displays (config)#.

2. Enter exit to leave configuration mode.

3. Enter copy running-config startup-config to save the current configuration to memory. This

command may be abbreviated as copy run start.

4. Enter exit to close the configuration session.

The NetVanta is now configured and operational. Complete the installation by connecting the

appropriate cables to the serial and Ethernet networks. Please refer to your NetVanta Hardware

Installation Guide for more details on pinouts and cabling.

The Enable Security mode passwords are case sensitive.

Configure Telnet Access

An enable security mode password and Ethernet port parameters must be defined before

configured Telnet sessions are activated. Refer to Configure the Ethernet Port

Parameters on page 2 and Set the Enable Security Mode Password on page 5 for

information.

Save the Configuration

Complete the Installation

Table des matières

Autres manuels ADTRAN Matériel réseau

ADTRAN

ADTRAN 500 Series Manuel utilisateur

ADTRAN

ADTRAN 401 1 GE Micro ONT Manuel utilisateur

ADTRAN

ADTRAN NetVanta 8044M Manuel utilisateur

ADTRAN

ADTRAN Total Access 604 Guide de l'utilisateur

ADTRAN

ADTRAN HTU-C Manuel utilisateur

ADTRAN

ADTRAN OSU 300 Manuel utilisateur

ADTRAN

ADTRAN Total Access 362R Manuel du produit

ADTRAN

ADTRAN NT1 ACE Manuel utilisateur

ADTRAN

ADTRAN TRACER 4106 Plan Guide de l'utilisateur

ADTRAN

ADTRAN Total Access 1500 Total Reach DDS-DP Manuel utilisateur

ADTRAN

ADTRAN NetVanta T1/FT1 + DSX-1 Manuel utilisateur

ADTRAN

ADTRAN D4 FT1 DP Manuel utilisateur

ADTRAN

ADTRAN jobAid Manuel utilisateur

ADTRAN

ADTRAN ENHANCED PSD 239 H2R Manuel utilisateur

ADTRAN

ADTRAN T1 Nx64 HTU-R Mode d’emploi

ADTRAN

ADTRAN NetVanta E1/FE1 + G.703 Network Interface... Manuel utilisateur

ADTRAN

ADTRAN DSU 5600 Manuel utilisateur

ADTRAN

ADTRAN AOC QSFP28 100G AOC QSFP28 100G 3M Manuel utilisateur

ADTRAN

ADTRAN SHDSL T1 Mode d’emploi

ADTRAN

ADTRAN Total Access 1248 Manuel utilisateur

ADTRAN

ADTRAN 3.125 Gigabit Ethernet Manuel utilisateur

ADTRAN

ADTRAN ESU LT Manuel utilisateur

ADTRAN

ADTRAN DUAL Nx56/64 1200142L1# Manuel utilisateur

ADTRAN

ADTRAN 6540 Mode d’emploi

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
