INSTRUCTION

MANUAL

TP-446

PROFESSIONAL FM TRANSCEIVER

* Please carefully read before use

iii

In order to make you fully understand the equipment, please

read this user manual before using.

Thank you for purchasing our hand held FM transceiv-

er. This model is novel designed with stable perfor-

mance and we want to develop this model to be a por-

table equipment, also easy to operate with a variety

of sophisticated functions, so we are using the most

advanced technology. We deeply condent that its

quality and functionality would make you feel satised!

viv

PRECAUTION

The transceiver is a product with good design and advanced tech-

nology. The following suggestions will help you perform the obliga-

tions of warranty cause, understand and realize the security of us-

ing transceivers.

1. Put transceiver and all its parts and accessories in place out of

children’s reach.

2. Do not try to disassemble transceiver as non-professional’s treat-

ment to the transceiver may cause damage.

3. Please use our company’s assorted battery pack and charger,

avoid damage to transceiver.

4. Please use our company’s assorted antenna, to prevent shorten

communication distance.

5. Do not expose transceiver to sunlight for a long time or in the

overheated areas.

6. Do not put transceiver in dusted or wet areas.

7. Do not clean transceiver with strong chemicals, cleaning agents

or strong lotion.

8. Do not transmit unless the antenna has been installed.

9. If you discover the transceiver giving o odor or smoke, please

immediately turn o the power of transceiver, remove battery

pack from transceiver and contact with dealers.

ANNOUNCEMENT

» All the proposals above are equally applicable to your transceiver

and its accessories. If they can not work properly, please contact

with dealers promptly.

» If you use accessories which are not produced or sold by our

company, We will not guarantee the safety and operability of the

transceiver.

CONTENTS

UNPACKING AND CHECKING EQUIPMENT.............. 1

Assorted Accessories .....................................................1

PREPARATION ............................................................. 2

Charging the Battery Pack ..............................................2

Installing/Removing the Battery Pack..............................4

Installing the Antenna .....................................................5

Installing the Belt Clip .....................................................5

Installing the Optional Speaker/Microphone ...................5

GETTING ACQUAINTED.............................................. 6

OPERATION.................................................................. 7

AUXILIARY FUNCTIONS.............................................. 8

Time-out Timer................................................................8

Battery Power Save.........................................................8

Low Power Warning ........................................................8

Monitor............................................................................9

Quiet Talk (QT) and Digital Quiet Talk (DQT) ...................9

SPECIFICATIONS....................................................... 10

TROUBLESHOOTING GUIDE.................................... 11

FREQUENCY CHART................................................. 12

UNPACKING AND CHECKING EQUIPMENT

Please take the transceiver from the package carefully. We suggest

that you should check the following accessories before throwing

away the package. If any items is lost or damaged when transporta-

tion, please submit a claim to the delivery man immediately.

Assorted Accessories

Item Qty.

Antenna 1

Charger 1

Battery 1

Belt Clip 1

Screw Set 1

User Manual 1

Adaptor 1

PREPARATION

Charging the Battery Pack

The battery pack is not charged at the factory; Please charge it be-

fore using.

After purchasing or long time storage (more than two months), the

battery can not reach its normal capacity when charge at the rst

time. After charging 2-3 times then the capacity reach the normal

one.

Do not recharge the battery pack if it is already fully charged.

Otherwise, the battery life will be shorten or damaged.

After recharging the battery pack, disconnect it from the char-

ger. Charging the battery pack more than 5 days may reduce

the battery pack life due to overcharging.

CAUTION

NOTE:

The ambient temperature should be between 42 and 104°F (5 to

40°C) while charging is in progress. Charging outside this range

may not fully charge the battery.

Always switch OFF the transceiver equipped with a battery pack

before charging. Using the transceiver while charging will inter-

fere with correct charging.

Even after completely correct charge, the using time still not in-

creases, then the battery life is over, please replace the battery.

Plug the Charger power cable

into an AC outlet.

Insert the battery pack or

transceiver with a battery pack

into the charger.

Make sure the battery pack

contact with the charging ter-

minals correctly.

The charger LED lights on

and charging begins.

After charging the assorted battery pack for 4~8 hours, take

the battery or the transceiver with battery from the charger.

The charge completes when charging light turns green.

Unplug the AC adaptor from the AC outlet.

Installing/Removing the Battery Pack

The average using time of the supplied battery pack is 8 hours. Av-

erage times is calculated by using 5% transmit time, 5% receive

time, and 90% standby time.

Do not make the battery terminals short circuit or dispose the

battery into re.

Do not try to remove the shell from the battery pack.

CAUTION

Battery Latch

Pull the latch

downward to

remove the

battery pack.

Installing the Antenna

Hold the antenna base and screw the anten-

na clockwise into the antenna connector at

the top of the transceiver, until tighten.

NOTE: Don’t hang keys, speaker or micro-

phone on the antenna. Otherwise the

antenna will be damaged or perfor-

mance of the radio will be degraded.

Installing the Belt Clip

If necessary, can use two 3 x 8mm screws in

the package to x the belt clip.

NOTE:

If not install the belt clip, its installation lo-

cation will get hot in the hot environment

or in the continuous communication.

You must remove the belt clip before re-

moving the battery pack.

Installing the Optional Speaker/

Microphone

Outward apart the moisture-proof rubber of

the headphone mouth, Insert the speaker/

microphone plugs into the speaker/micro-

phone jacks.

NOTE: The transceiver is not fully waterproof

while using the speaker/microphone.

GETTING ACQUAINTED

Antenna Channel selector

Rotate to select

channels 1~199.

Power switch/

Volume control

Turn clockwise

to switch ON the

transceiver. To

switch OFF the

transceiver, turn

counterclockwise

until a click sounds.

Rotate to adjust the

volume level.

PTT (Push-To-

Talk) Switch

Press, then

speak into the

microphone to

call. Release to

receive.

Monitor key

Press and hold to

turn the squelch

OFF.You will

hear background

noise. Release to

turn the squelch

ON.

Speaker/

Microphone

jacks

Battery pack

LED indicator

Lights red while

transmitting.

Lights green while

receiving a signal.

Purple light ashing

when transmit with

low battery power.

Speaker

Microphone

Channel

OPERATION

Switch ON the transceiver by turning

the Power switch/Volume control

clockwise.

A beep sounds.

Adjust the volume by rotating the Vol-

ume control.

Rotates the Channel switch to select

channel.

When you receive an appropriate signal,

you will hear audio from the speaker.

To make a call, press and hold the

PTT switch, then speak into the mi-

crophone using your normal speaker

voice.

Keep the microphone approximately

1.5 inches (3 to 4cm) from your lips.

Release the PTT switch to receive signal.

NOTE: If the battery voltage gets low, transmit will stop, status light will

ashing red.

AUXILIARY FUNCTIONS

Time-out Timer

The purpose of the Time-out Timer is to prevent any person from

using a channel for an extended period of time.

If you continuous transmitting 60 seconds, transceiver will stop

transmitting and beep sound comes out.

To stop the beep sound, release PTT button. Press the PTT button

again then can transmit regain.

Battery Power Save

Power saving function is to reduce the power consumption when

not receive signal or not operation (no press buttons or switch on/

o the power. )

If the channel is not busy or not operation more than 10 minutes,

the battery power saving function ON. When receive signal or dur-

ing operation, the battery power saving function automatically OFF.

Low Power Warning

Low Battery Warning alerts you when the battery needs to be re-

charged.

If the battery low to the preset value when you are transmitting, the

red lights will ash. If the beep sound comes out, transmit will stop.

Please replace the battery or charge.

109

Monitor

If no signal occurs, the transceiver squelch circuit will automatically

make the speaker silence, so you will not hear background noise.

To manually turn o the squelch circuit, hold the Monitor button.

This operation is helpful for you to adjust the volume level or receive

a weak signal.

The LED indicator lights green while the Monitor button is

pressed.

Quiet Talk (QT) and Digital Quiet Talk (DQT)

Some channels may have preset QT/DQT tones. A QT/DQT tone is

a subaudible tone which allows you to ignore (not hear) calls from

other parties who are using the same channel.

When you receive a signal that has a tone dierent from the one set

up in you transceiver, you will not hear the signal. Likewise, signals

that you transmit will only be heard by parties whose QT/DQT tone

matches the tone set up in your transceiver.

NOTE: Although using channels set up with QT/DQT tones relieves

you from listening to unwanted calls, it does not mean your

calls will be private.

SPECIFICATIONS

Unity Section

Frequency range 446MHz

Rated voltage DC 7.4V (Li-ion battery)

Memory channel 16 channels

Antenna disposition inductively loaded antenna

Antenna impedance 50Ω

Working manner

same frequency single opera-

tion or dierent frequency sin-

gle operation

Dimension 125×65×35mm

Launching Parts

Modulation mode frequency modulation

Maximum frequency deviation ≤ ±5kHz

Remanent radiation < -60dB

Modulation mode (W/N) 16KØF3E,11KØF3E

Emission current ≤ 1000mA

Receiving Parts

Sensitivity < 0.16 µV(12dB SINAD)

Squelch sensitivity < 0.2 µV

Intermodulation Rejection 50dB

Audio frequency power ≥ 300mW

Receiving current ≤ 100mA

Squelch Standby 20mA

1211

TROUBLESHOOTING GUIDE

Problem Solution

No power

Battery may run out of power, please

update the battery or recharge the

battery.

The battery pack may not be in-

stalled correctly. Remove the battery

pack and install it again.

Battery power o

shortly after charging

The battery pack life is over. Replace

the battery pack with a new one.

Can not talk to or hear

other members in

your group

Make sure you are using the same

frequency and Quiet Talk tone as the

other members in your group.

Other group members may be too

far away. Make sure you are within

the working range of the transceiv-

ers.

Other voices (besides

group members) are

present on the chan-

nel

Change the Quiet Talk tone. Be sure

to change the tone on all transceiv-

ers in your group.

FREQUENCY CHART

Model Name: ________________________________________

Serial Number: _______________________________________

Channel Transmit

Frequency

Receive

Frequency QT/DQT

Please cut along with this line

Model Number:

Serial Number:

Purchasing Date:

Dealer: Telephone:

User’s Name: Telephone:

Address: Post Code:

REMARKS:

1. This guarantee card to be kept by the user, no replen-

ishment if lost.

2. This guarantee card to be lled & chopped by the deal-

er, or it is invalid.

3. Don’t alter the guarantee card, please conrm the se-

rial number on the guarantee card is same as that on

the machine.

4. One-year guarantee, BUT charger, battery, ear-phone,

antenna and can cable are not under guarantee.

5. The user can get repairing service from the following

ways:

a. Go to the shop where you buy the machine.

b. Our local repairing agent.

c. Send to us or visit our company.

GUARANTEE CARD

Table des matières

Autres manuels Adesso Émetteur-récepteur

Adesso

Adesso TP-3200 Manuel utilisateur

Manuels Émetteur-récepteur populaires d'autres marques

Yaesu

Yaesu FT-7B Manuel utilisateur

Kenwood

Kenwood ProTalk TK-3201 Manuel utilisateur

Texas Instruments

Texas Instruments TLK10232 Manuel utilisateur

Mizuho

Mizuho MX-2 Guide produit

Kenwood

Kenwood TK-3180 Manuel d'utilisation et d'entretien

Blitz

Blitz MJ-398U Manuel utilisateur

Utilicom

Utilicom LongRanger 2050 Manuel utilisateur

Standart

Standart HX290UKA Manuel utilisateur

Altronix

Altronix Pace1PTM Manuel utilisateur

Kirisun

Kirisun PT2208 Manuel utilisateur

ELECRAFT

ELECRAFT KX2 Manuel utilisateur

Zodiac

Zodiac K3 Manuel utilisateur

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuel utilisateur

Kenwood

Kenwood TK-2217 Manuel utilisateur

Siemens

Siemens PSO 4000 Manuel utilisateur

Kenwood

Kenwood TS-590SG Manuel utilisateur

Midland

Midland G8E-BT Manuel

ComNav

ComNav Mariner X2 Manuel utilisateur
