Addonics Technologies

ExDrive

User Guide

Revision 2.7

Table of Contents

I. Introduction

FCC Warning Statement 3

Welcome 4

Hardware Requirement 4

Operating System Requirement 4

Introduction 5

Package Contents 6

II. Installation & Operation

Hardware Installation 7

Driver Installation 10

ExData Pro Installation 12

III. Troubleshooting 13

FCC Warning Statement

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency

energy. If not installed and used in accordance with the

instruction, it may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which

can be determined by turning the equipment on and off, the user is

encouraged to try to correct the interference by one or more of the

following measures:

* Reorient or relocate the receiving antenna.

* Increase the separation between the equipment and the receiver.

* Connect the equipment to a power outlet on a different circuit

from that to which the receiver is connected.

* Consult the dealer or a professional radio/TV technician.

Caution: changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment. To meet FCC requirements, shielded

cables are required to connect the device to a personal computer

and/or other Class B certified device.

Welcome

Congratulations on your purchase of the Addonics

Technologies’ ExDrive. We hope you will enjoy our product for

its great features and value. This users guide is designed to help

you install the ExDrive and accompanying ExData software

drivers. It should also explain all the various features built into the

unit.

Your comments are valuable to us for further improvement

to our existing and future products and services. In order for us to

keep you informed of any updates on the ExDrive, or on any new

products or services from Addonics Technologies, please go online

to www.addonics.com to register your warranty at your earliest

convenience.

Hardware Requirement

100% IBM compatible PCMCIA socket, or Universal Serial Bus

(USB). PC/AT or compatible, Pentium 100MHz or higher with

16MB memory or more.

Operating System Requirements

Any of the Following:

MS-DOS 6.22 or later

Microsoft Windows for Workgroups

Microsoft Windows 95/98 (USB version does not support

Windows 95)

Microsoft Windows NT (USB does not support Windows NT)

Introduction

Introduction To The Portable Hard Drive

The Addonics Technologies ExDrive is a small, lightweight and

portable 2.5” Hard Disk Drive which comes in capacities starting

at 2GB. The unit is external and uses the PCMCIA socket or USB

port, so there is no need to open up your computer since there are

no cards to install, and no special tools are required for installation.

Just attach the unit to the PCMCIA or USB port of you computer

with the supplied cable, plug in the power cord, install the supplied

software (ExData Pro is optional) and you are done.

Package Contents

(1) Addonics Technologies 2.5” ExDrive

(1) PCMCIA (No Driver needed) or UBS Cable (One driver

floppy)

(1) ExData Pro Software (Optional)

(1) AC Power Cable

(1) Owner’s Manual & Registration Card

PCMCIA Package

USB Package

Installation

Hardware Installation

1. Make sure the power is off on both your computer and the

ExDrive.

2. *For empty ExDrive case users only:

•PCMCIA and USB installation are the same.

a). Press down the middle of the case and pull it apart.

Note: Try not to use sharp objects to open it; it might damage

the inner IC broad.

a). Remove the case and disassemble the unit into 3 parts.

Note: Take the inner IC broad out

b). Connect the 2.5” IDE hard disk to the connector on the IC

broad.

Note: Make sure pins match the connecter

c). Secure the HD on the IC board with 4 screws after

connecting.

Note: Do not screws the screws too tight

d). Get ready to put everything back together.

Note: Do not connect power at this time

4. Connect the Portable Hard Drive to your computer’s

PCMCIA or USB port with the supplied PCMCIA or USB

cable.

5. Turn on your computer and Portable Hard Drive’s power.

Get ready to plug in the device. Make sure the green light

goes on after you plug the power cable in and turn on the

switch.

Driver Installation

*** Important information for PCMCIA users ***

•You do not need to install driver if you are running

Windows 95 or Windows 98. The Windows will install

its default driver for our PCMCIA card, which is called

the “Standard IDE/ESDI Hard Disk Controller”. After

the Windows installs it, you can find it in “Device

Manager” and under “Hard Disk Controllers”.

*** Important information for USB users ***

•Before you go on. We just want to let you know that

our USB devices do not support Windows 95 and

Windows NT.

For USB users:

1. Make sure your ExDrive is powered on and the USB cable

is attached, then plug the USB cable into your computer.

2. The Windows 98 will find the new hardware when you

plug in the device at the first time, and it will ask you to

insert the driver diskette. Just put the floppy diskette into

the floppy disk drive.
