ADC ADG-758 Manuel utilisateur

ADC Part No. 113107

For replacement parts, contact the distributor from which the dryer

was purchased or

American Dryer Corporation

88 Currant Road

Fall River MA 02720-4781

Telephone: (508) 678-9000 / Fax: (508) 678-9447

e-mail: [email protected]

081799JEV/abe

WARNING: For your safety the

information in this manual must be

followed to minimize the risk of fire or

explosion or to prevent property damage,

personal injury or death.

Do not store or use gasoline or other flammable

vapor and liquids in the vicinity of this or any

other appliance.

WHAT DO YOU DO IF YOU SMELL GAS

*Do not try to light any appliance.

*Do not touch any electrical switch; do not use

any phone in your building.

*Clear the room, building or area of all

occupants.

*Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.

*If you cannot reach your gas supplier, call the

fire department.

Installation and service must be performed by a

qualified installer, service agency or the gas

supplier.

AVERTISSEMENT: Assurez-vous de bien

suivre les instructions données dans cette

notice pour réduire au minimum le risque

d’incendie ou d’explosion ou pour éviter tout

dommage matériel, toute blessure ou la mort.

Ne pas entreposer ni utiliser d’essence ni

d’autres vapeurs ou liquides inflammables dans

le voisinage de cet appareil ou de tout autre

appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR

DE GAZ:

*Ne pas tenter d’allumer d’appareil.

*Ne touchez à aucun interrupteur. Ne pas

vous servir des téléphones se trouvant dans

le bâtiment où vous vous trouvez..

*Évacuez la pièce, le bâtiment ou la zone.

*Appelez immédiatement votre fournisseur de

gaz depuis un voisin. Suivez les instructions

du fournisseur.

*Si vous ne pouvez rejoindre le fournisseur

de gaz, appelez le service des incendies.

L’installation et l’entretien doivent être assurés

par un installateur ou un service d’entretien

qualifié ou par le fournisseur de gaz.

ADG-758

Installation Manual

(Gas DSI)

Retain This Manual In A Safe Place For Future Reference

Replacement parts can be obtained from your distributor or the ADC factory. When ordering replacement parts from the

factory, you can FAX your order toADC at (508) 678-9447 or telephone your orders directly to the ADCPartsDepartmentat

(508) 678-9000. Please specify the dryermodelnumber andserialnumberin addition to thedescription andpartnumber,so

that your order is processed accurately and promptly.

DATE OF PURCHASE MODEL NO.

DISTRIBUTORS NAME

Serial Number(s)

“IMPORTANT NOTE TO PURCHASER”

Information must be obtained from your local gas supplier on the instructions

to be followed if the user smells gas. These instructions must be posted in a

prominent location near the dryer.

American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is

properly maintained, it will provide many years of safe, efficient, and trouble-free operation.

ONLY qualified technicians should service this equipment.

OBSERVEALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual

included with the dryer.

The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors or liquids

in the vicinity of this or any other

appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides

inflammables dans le voisinage de cet

appareil ou de yout autre appareil.

We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make

changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or

discontinue models.

Important

For your convenience, log the following information:

ADG-758

IMPORTANT

YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS

SUPPLYBEFOREANYCOVERSorGUARDSAREREMOVEDFROMTHEMACHINE

TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING

OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration)

STANDARDS.

CHILDREN SHOULD NOTBE ALLOWED TO PLAY ON OR NEAR THE DRYER(S).

WARNING

CHILDREN SHOULD BESUPERVISED IF NEAR DRYER(S) IN OPERATION.

DRYER(S) SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.

CAUTION

FOR YOUR SAFETY

DO NOT DRY MOP HEADS IN THE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices

ever be disabled.

“Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.”

«Attention: Lordesopérationsd’entretien

des commandes étiqueter tous fils avant

de les déconnecter. Toute erreur de

câblage peut étre une source de danger et

de panne.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY or FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVEALLSAFETY PRECAUTIONS displayed on the equipment and/or

specified in the installation/operator's manual included with the dryer.

Dryer(s) must not be installed or stored in an area where it will be exposed to water and/or

weather.

The wiring diagram for the dryer is located in the front electrical control box area.

DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN

PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED.

WARNING

Table of Contents

SECTION I

IMPORTANT INFORMATION..........................................................................3

A. Receiving and Handling ............................................................................................................... 3

B. Safety Precautions ....................................................................................................................... 4

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION..................................6

A. Specifications .............................................................................................................................. 6

B. Component Identification............................................................................................................. 8

SECTION III

INSTALLATION PROCEDURES ....................................................................10

A. Location Requirements.............................................................................................................. 10

B. Unpacking/Setting Up ................................................................................................................11

C. Dryer Enclosure Requirements .................................................................................................. 12

D. Fresh Air Supply....................................................................................................................... 13

E. Exhaust Requirements............................................................................................................... 14

F. Electrical Information ................................................................................................................ 18

G. Gas Information......................................................................................................................... 24

H. Preparation For Operation/Start-up ........................................................................................... 28

I. Preoperational Tests .................................................................................................................. 29

J. Preoperational Instructions ........................................................................................................ 31

K. Shut Down Instructions ............................................................................................................. 32

SECTION IV

SERVICE/PARTS INFORMATION .................................................................33

A. Service ..................................................................................................................................... 33

B. Parts ......................................................................................................................................... 33

SECTION V

WARRANTY INFORMATION .........................................................................34

A. Returning Warranty Card(s) ...................................................................................................... 34

B. Parts ......................................................................................................................................... 34

C. Returning Warranty Card(s) ...................................................................................................... 34

SECTION VI

ROUTINE MAINTENANCE ............................................................................36

A. Cleaning ................................................................................................................................... 36

B. Adjustments .............................................................................................................................. 37

SECTION VII

PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT

COMPONENTS ................................................................................................38

SECTION VIII

REVERSING TIMER SPIN/DWELL ADJUSTMENTS..................................40

SECTION IX

TECHNICAL INFORMATION ........................................................................41

Data Label ..................................................................................................................................... 42

SECTION X

TROUBLESHOOTING.....................................................................................43

Microprocessor (Computer) Models ............................................................................................... 45

Dual Timer Models ......................................................................................................................... 52

SECTION I

IMPORTANT INFORMATION

A. RECEIVING and HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or

optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden

skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect

further before delivering carrier leaves.

Dryers damaged in shipment:

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker's receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers which were not damaged in

a damaged shipment should be accepted, but the number received and the number refused must be

noted on the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier's freight terminal immediately and file a claim. The freight company considers this concealed

damage. This type of freight claim is very difficult to get paid and becomes extremely difficult when more

than a day or two passes after the freight was delivered. It is your responsibility to file freight claims.

Dryer/parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

ADC assumes no responsibility for freight claims or damages.

6. If you need assistance in handling the situation, please contact the ADC Traffic Manager at (508)

678-9000.

IMPORTANT:The dryer must be transported and handled in an upright position at all times.

B. SAFETY PRECAUTIONS

WARNING:For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING: The dryer must never be operated with any of the back guards, outer tops, or

service panels removed. PERSONAL INJURY or FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS...

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALLoccupants.

e. Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryer(s) must be exhausted to the outdoors.

6. Although ADC produces a very versatile machine, there are some articles that, due to fabric composition or

cleaning method, should not be dried in it.

WARNING:Dry only water-washed fabrics. DO NOT dry articles spotted or washed in dry

cleaning solvents, a combustible detergent, or "all purpose" cleaner.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,

or wax. EXPLOSION COULD RESULT.

WARNING:DO NOT dry mop heads. Contamination by wax or flammable solvent will create a

afire hazard.

WARNING:DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage

plastics or rubber and also may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust duct

work, and area around the back of the dryer. The frequency of inspection and cleaning can best be determined

from experience at each location.

WARNING:The collection of lint in the burner area and exhaust duct work can create a potential

fire hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

NATIONAL ELECTRICAL CODE ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the

CANADIAN ELECTRICAL CODES PARTS 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE:Failure to do so will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or heat safety

circuit, ever be disabled.

WARNING: PERSONAL INJURY or FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING:Articles left in the dryer after the drying and cooling cycles have been complete can create

a fire hazard.

12. READ and FOLLOWALL CAUTIONandDIRECTIONLABELS ATTACHEDTOTHE DRYER.

WARNING: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and

THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED

FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,

ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per

OSHA (Occupational Safety and Health Administration) STANDARDS.

NOTE:ADCreserves the right to make changes in specifications at any time, without notice or

obligation.

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION

A. SPECIFICATIONS

Gas

BASKET (TUMBLER)DIAMETER 37" 94 cm

BASKET (TUMBLER)DEPTH 36" 91.5 cm

BASKET (TUMBLER)MOTOR 3/4 HP* .560 kw

DOOR OPENING (DIAMETER)21-1/2" 54.61 cm

BASKET (TUMBLER)VOLUME 22.4 cu. ft. .634 cu.m.

DRYERS PER 20'/40' CONTAINER 10/20

DRYERS PER 6 m/12 m CONTAINER 10/20

DRYERS PER 45'/48' TRUCK 24/26

DRYERS PER 14 m/15 m TRUCK 24/24

VOLTAGE AVAILABLE 120-460v / 1ø-3ø/ 3, 4w / 50/50 Hz

APPROX. WEIGHT (UNCRATED)721 lbs. 327.1 kg

APPROX. WEIGHT (CRATED)771 lbs. 349.7 kg

HEAT INPUT 175,000 btu/hr 44,100 kcal/hr

AIRFLOW 750 cfm 21.24 cm

INLET PIPE SIZE** 3/4" 1.91 cm

Shaded areas are stated in metric equivalents

* For Non-Reversing Models.

** A minimum of 3/4" (1.91 cm) must be supplied to the gas inlet for each dryer.

Autres manuels pour ADG-758

Table des matières

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
