Adaptec USBConnect2000 Manuel utilisateur

USER’SGUIDE

USBCONNECT 2000

Adaptec, Inc.

691 South Milpitas Boulevard

Milpitas, CA 95035

are trademarks of Adaptec, Inc. which may be regis-

tered in some jurisdictions.

Printed in Singapore

STOCK NO.: 512323-00, Rev. A MO 7/99

▼ ▼ ▼ ▼ USBConnect 2000

User’s Guide

iii

▼ ▼ ▼ ▼ Contents

Introduction

Overview 1

Contents of Kit 2

System Requirements 2

Installing the USBConnect 2000 Adapter

Hardware Installation 3

Software Installation 4

Completing the Installation

Installing the Windows 98 Driver 5

Installing Macintosh 6

Understanding SCSI

SCSI IDs 7

Terminating the SCSI Bus 8

Obtaining SCSI Cables 8

Troubleshoting

Contacting Adaptec

Electronic Support 13

Technical and Product Support 14

Sales and Ordering Information 14

Introduction

Congratulations on your purchase of Adaptec’s USBConnectTM 2000

adapter. The USBConnect 2000 adapter allows SCSI devices to plug

into the Universal Serial Bus (USB) port of your PC or MAC

computer.

The built-in SCSI controller in the USBConnect 2000 adapter allows

you to connect up to seven SCSI devices to your desktop or portable

PC or MAC. These devices include the Iomega Jaz drive, CD-ROM

drives, hard disk drives, Magneto-optical (MO) drives and most

scanners.

Overview

The USBConnect 2000 adapter is designed as an integrated adapter

and 50-pin high-density (SCSI 2) connector and is available as a

■USB-to-SCSI with a 50 pin Micro-D SCSI-2 type connector

Note: The USBConnect 2000 adapter is designed as a self-

powered device and as such receives it’s power from the ter-

mination power line of the attached SCSI devices. As a

result, all SCSI devices must supply termination power.

Some devices such as the Iomega Zip drive and some

scanners do not provide termination power and therefore

can only be used if they are attached to the SCSI chain with

another SCSI device that provides termination power.

USBConnect 2000 User’s Guide

Contents of Kit

■USBConnect 2000 adapter

■CD-ROM for Windows®98 and Macintosh OS v8.5

■USBConnect 2000 adapter User’s Guide

■Registration Card

System Requirements

■Macintosh, PC or Portable PC with a USB compliant port

■Windows 98 on PC or Portable PCs or Macintosh v8.5 on iMac,

G3s or PowerBook

■SCSI device such as CD-ROM scanner, hard disk drive, Jaz

drive, MO or other SCSI device with termination power

Installing the USBConnect 2000 adapter

Installing the USBConnect

2000 adapter

The following information describes the hardware and software

installation for the USBConnect 2000 adapter.

Hardware Installation

Follow these steps to install the USBConnect 2000 adapter:

1Remove the USBConnect 2000 adapter from its packaging.

2Connect the USBConnect 2000 adapter into the SCSI device

you want to connect.

3Connect the USB connector (small end) into your systems USB

port. (See diagram below.)

4If attaching the USBConnect 2000 adapter through a USB hub,

we recommend using A/C powered hubs.

Note: The USBConnect 2000 adapter receives its +5V

power from the terminator power line of the attached SCSI

device. See Terminating the SCSI Bus, on page 8.

USB Port

USB Connect

USBConnect 2000 User’s Guide

Note: Do not turn on the power until the SCSI device is

attached to the USBConnect 2000 adapter. Once the attach-

ment is made, you can make the connection with the power

either on or off.

Note: The USBConnect 2000 adapter is hot-pluggable, that

is you can connect and disconnect it from a live system.

This completes the physical installation of your USBConnect 2000

adapter. Next you need to install the installation CD.

Software Installation

Follow these steps for the software installation of the USBConnect

2000 adapter:

1Insert the USBConnect 2000 adapter CD into the CD-ROM.

2Click Run, then type c:setup (or use the appropriate CD-ROM

letter) in the Run dialog box.

3Click OK.

4Follow the instructions on the screen to complete the setup

process.
