SCSI Card 2930CU

Installation Guide

This Installation Guide describes how to install the Adaptec SCSI Card

2930CU. It also describes how to install and connect your internal and

external SCSI devices.

For instructions on how to install the SCSI card driver, refer to the SCSI

Card 2930CU User’s Guide on the SCSI Card 2930 CD.

Kit Contents

Your SCSI Card 2930 package includes:

■SCSI Card 2930CU adapter

■Standard 50-pin internal SCSI cable

■SCSI Card 2930 CD, containing drivers, online documentation, and

other useful tools and information

■Adaptec SCSI Card 2930CU Installation Guide

If you plan to connect more than two internal SCSI devices, or one or

more external SCSI devices, to your computer, you will need additional

cables not included in this package. Refer to the SCSI Card 2930CU User’s

Guide on the SCSI Card 2930 CD for information on obtaining cables.

Installing the SCSI Card 2930CU

To install the SCSI Card 2930CU

1Ground yourself by touching the chassis.

2Turn off the computer and disconnect the power cord.

3Open the computer cabinet, following the manufacturer’s

instructions.

4Find an unused PCI expansion slot (typically white or ivory) in the

computer. Unscrew the expansion slot cover screw and remove the

slot cover to provide an opening, as shown. Save the slot cover screw

for use in Step 7.

PCI expansion slots

Expansion slot

cover

5Remove the SCSI Card 2930CU from its antistatic packaging.

Note: Always handle the SCSI card by its edges or metal bracket.

Do not

touch the gold connector or any components on the card.

6Place the SCSI Card 2930CU in the slot and press it down firmly until

the connector fingers are fully seated.

7Secure the card bracket with the screw you removed in Step 4.

Do not close the computer cabinet or reconnect the power cord yet.

Continue with the next section, Installing Internal SCSI Devices.

Card bracket

Installing Internal SCSI Devices

If you are connecting only external devices, skip to Connecting External

SCSI Devices on page 8.

To install internal SCSI devices

1Ensure that each internal SCSI device has a unique SCSI ID number

between 0 and 6. Refer to the SCSI device’s documentation for

instructions on setting the SCSI ID.

Note: Avoid touching the device connector pins.

2Mount each SCSI device in an available drive bay inside your

computer. Refer to the documentation for your computer and SCSI

devices for installation instructions.

Note: If space is limited inside your computer, you may have

difficulty connecting SCSI and power supply cables to your

SCSI devices once they’re installed. Consider completing these

connections (starting with Step 3) before installing the devices.

3Connect one end of the 50-pin internal SCSI cable to the SCSI

connector on the card, as shown in the next figure. Ensure that the

connector fits snugly.

Make sure Pin 1 on the cable aligns with Pin 1 on the internal SCSI

device connector. Pin 1 is usually designated by a “1” or small

triangle.

4Connect the other end of the cable to the internal SCSI device.

5If you are installing one internal SCSI device only, you must

terminate this device, then skip to Step 8 on page 7.

Refer to your SCSI device’s documentation for termination

instructions.

Blue or red stripe

denotes Pin 1

Pin 1 marking

Internal SCSI

connector

Key

Standard 50-pin

internal SCSI cable

(included in kit)

6Connect any other internal SCSI devices, as shown.

7Terminate the device that is connected to the end of the cable. Refer

to the SCSI device’s documentation for instructions.

8Connect a power cable from your computer’s power supply to the

power input connector on the SCSI device, as shown. Repeat this

step for each SCSI device.

Terminated internal

SCSI device

Unterminated internal

SCSI device

Internal SCSI cable

Power input connector

Power cable

Power supply

9Close the computer cabinet. Do not reconnect the power cord yet.

If you are also connecting external SCSI devices, skip to the next

section, Connecting External SCSI Devices.

If you are not connecting external SCSI devices, complete the

installation by continuing with Step 10.

10 Reconnect the power cord, then turn on the computer.

11 Install the software driver for your operating system. See Installing

Drivers on page 11 for more information.

Refer to the SCSI Card 2930CU User’s Guide on the SCSI Card 2930 CD for

useful information on SCSI, SCSI devices, and using SCSISelect.

Connecting External SCSI Devices

The SCSI Card 2930CU has one 50-pin high-density external connector.

You will need a high-quality 50-pin high-density external SCSI cable for

each external SCSI device you are connecting. External SCSI cables are

not included in the SCSI Card 2930CU kit. Refer to the SCSI Card 2930CU

User’s Guide on the SCSI Card 2930 CD for more information on cables.

To connect external SCSI devices

Ensure that each external SCSI device has a unique SCSI ID from 0 to 6.

For most external SCSI devices, the SCSI ID is set with a switch on the

back of the device, as shown. Refer to the SCSI device’s documentation

for instructions on setting the SCSI ID.

Note: Each device connected to your SCSI Card 2930CU (both

internal and external) must have a unique SCSI ID from 0 to 6. You

cannot use the same SCSI ID twice.

SCSI ID

Connect one end of an external SCSI cable to the SCSI Card 2930CU

external SCSI connector. Secure the cable by tightening the thumb

screws on the cable connector.

Note: Avoid touching the device connector pins.

3Connect the other end of the cable to a SCSI connector on the back of

the SCSI device.

4If you are installing only one external SCSI device, terminate the

device.

Refer to your SCSI device’s

documentation for termination

instructions.

5Connect other external SCSI devices by cabling each device to the

previous one, as shown. Only terminate the SCSI device at the end of

the chain.

Terminated

Unterminated devices

device
