ACV HeatMaster 25 Manuel utilisateur
EN
HeatMaster ®
660Y1400 - A
SyStem Control
25 - 35 - 45 - 70 - 85 - 120 TC
71 - 101 - 201
EN
en
2
Table of ConTenTs
660Y1400 - A
GENERAL RECOMMENDATIONS............................... 3
USER'S GUIDE.............................................................. 4
How to use this manual....................................................................................4
APPLIANCE DESCRIPTION......................................... 5
MCBA Interface........................................................................................................5
CONNECTION DIAGRAMS AND ACCESSORIES ....... 6
High-temperature heating circuit controlled by a room
thermostat ..................................................................................................................6
Installation of two heating circuits controlled by room unit
and ZMC-2 module............................................................................................ 10
Cascade installation.......................................................................................... 13
MCBA PARAMETERS FOR THE SPECIALIST............ 14
Stand-by Mode ( ).............................................................................. 14
Parameter Mode ( )........................................................................... 16
info Mode ( )........................................................................................... 17
Code Mode ( )....................................................................................... 20
Setting the parameters ................................................................................ 21
Communication Mode (with code) : ................................................... 29
Fan Mode (with code) :................................................................................... 29
Error Mode (with code) :................................................................................29
BLOCKAGE AND ERROR CODES.............................. 30
List of error codes + solutions [in error mode]........................... 30
NOTE
This manual contains important information with respect to the installation and set-up of the boiler.
This manual must be provided to the installer, who will keep it in a safe place.
We accept no liability should any damage result from the failure to comply with theinstructions contained in this technical manual.
Essential recommendations for safety
• It is prohibited to carry out any modifications to the appliance without the manufacturer’s prior and written agreement.
• The appliance must be set up by a qualified installer, in accordance with applicable standards and regulations.
• The installation must comply with the instructions contained in the boiler's installation manual and with the standards and regulations
applicable to installations.
• Failure to comply with the instructions in this manual could result in personal injury or a risk of environmental pollution.
• The manufacturer declines all liability for any damage caused as a result of incorrect installation or in the event of the use of appliances or
accessories that are not specified by the manufacturer.
Essential recommendations for the correct operation of the appliance
• To guarantee the correct operation of the installation, it is essential to carry out the adjustments in accordance with the instructions in this manual.
• In order to ensure that the appliance operates correctly, it is essential to inspect and service the boiler every year.
• Faulty parts may only be replaced by genuine factory parts.
If you smell gas:
- Immediately isolate the gas supply.
- Open windows and doors to ventilate the area.
- Do not use any electrical appliances and do not operate any switches.
- Immediately notify your gas supplier and/or your installer..
en
3
EN
660Y1400 - A
GENERAL RECOMMENDATIONS
EN
en
4660Y1400 - A
USER'S GUIDE
HOW TO USE THIS MANUAL
This manual is for the exclusive use of ACV-approved installers.
After a short description of the control module (MCBA) and of the keys used to make the adjustments, the manual includes a section with the installation
diagrams and a list of the accessories required for each specic installation. The electrical connection diagrams are also included as well as the specic settings
of the MCBA to be made using an access code provided by ACV.
The next sections contain the codes available in each mode of the MCBA, as well as the error codes displayed on the MCBA, which will allow the installer to
troubleshoot the possible faults.
For any other installation conguration than those in this manual, please contact your ACV representative.
bar
2
1
O
3
4
12
3
4 5 6 7 8
en
5
EN
660Y1400 - A
APPLIANCE DESCRIPTION
Description
MCBA - Allows to set-up the boiler operation and more specically, to dene the
required temperature of the Domestic Hot Water (DHW) and the Central Heating
(CH) and to activate/deactivate the DHW and heating modes using the display
and the following keys:
1. Display: Indicates the modes and appliance settings through the use
of various codes.
2. "Reset"key: Allows to reset the appliance.
3. Connector: Allows to connect a laptop equipped with the appropriate
software to the MCBA.
4. "Mode" key: Allows to toggle the modes and dene various parameters.
5. "Step" key: Allows to scroll through the various functions of a mode.
6. "Store"key: Allows to save the dened settings.
7. "+" key: Allows to increase the displayed value.
8. "-" key: Allows to decrease the displayed value.
MCBA INTERFACE
The MCBA is an electronic control module and a regulator for gas boilers, developed by Honeywell and tted with a microprocessor.
It includes several basic functions: temperature control, ame monitoring, heating pump control, fan control, 3-way valve control, electrical ignition and boiler
control.
Its control panel also displays, through codes, the boiler operational condition, the mode in which it is operating and the possible faults in the system. Finally,
it allows to set the system up according to the type of installation.
Using a special maintenance code to be entered in the MCBA interface, the qualied installers can access parameters and therefore adjust the boiler settings
to specic requirements. The parameters are normally factory-preset for all normal applications.
For more information on how to use the MCBA and on the specic settings, refer to the section "MCBA Parameters for the Specialist", page 14 of this manual.
General remarks
If a fault occurs, the MCBA disables the appliance and displays an error code: the display flashes and the first character is "E"followed by the fault
number.
- Reset the appliance by pressing the "RESET"key of the MCBA interface.
- If the error code displays again, refer to the section "Blockage and Error Codes", page 30 of this manual
1
2
MCBA
Cold water
Hot water
EN
en
6660Y1400 - A
CONNECTION DIAGRAMS AND ACCESSORIES
HIGHTEMPERATURE HEATING CIRCUIT CONTROLLED BY A ROOM THERMOSTAT
en
7
ENConneCtion Diagrams anD aCCessories
660Y1400 - A
Required optional material
Applicable to Description Code
All HM TC models Room thermostat ACV 22 10800018
HM 25 / 35 / 45 TC High temperature kit DN 25 : comprised of a heating pump, two isolating valves, a check valve,
two thermometers. 10800294
HM 70 / 85/ 120 TC High temperature kit DN 32 : comprised of a heating pump, two isolating valves, a check valve,
two thermometers. 10800296
1
2
2
Remove this link to
connect the room
thermostat.
1 2 3 4 5 6 7 8 9 10 11 12 13
1 2 3 4 5 6
EN
en
8
ConneCtion Diagrams anD aCCessories
660Y1400 - A
Block diagram for wiring in accordance with applicable standards.
en
9
ENConneCtion Diagrams anD aCCessories
660Y1400 - A
Setting the MCBA
Initial Adjusted DESCRIPTION
3. 0 1 3. 0 1 00 : Heating mode “OFF”
01 : Heating mode “ON”
4. 85 4. 85 Preset temperature for the heating circuit water (adjustable between 30 and 85°C.
p. 4 5
. 00
p. 4 5
. 00 00 : Using an outdoor sensor and a room thermostat
Cold water
Hot water
EN
en
10
ConneCtion Diagrams anD aCCessories
660Y1400 - A
INSTALLATION OF TWO HEATING CIRCUITS CONTROLLED BY ROOM UNIT AND ZMC2 MODULE
MCBA
M
M
3
3
1
5
7
7
4
2
2
6
