ACTiSYS ACT-IR2002UL Manuel utilisateur

921 Corporate Way, Fremont, CA94539, USA

Tel: +1-510-490-8024, Fax: +1-510-623-7268

Web: http://www.actisys.com, E-mail: [email protected]

ACT-IR2002UL/ACT-IR4002US

IrReadyTM FIR USB Adapter

User’s Manual

ACT-IR2002UL

ACT-IR4002US

April 7, 2014

Version. 1.0.6

Warning! Please Install Driver BEFORE you

plug in the Dongle to USB port, for MAC & all

Windows OS unless your PC is Windows 7 or

8 which is plug and play already.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 2 of 30 Apr. 7, 2014

V.1.0.6

FEDERAL COMMUNICATIONS COMMISSION

DECLARATION OF CONFORMITY

FOR THE FOLLOWING EQUIPMENT:

PRODUCT NAME: _IrReady™ USB ADAPTER

MODEL NO.: ACT-IR2002UL/ACT-IR4002US

IS HEREWITH CONFIRMED AND FOUND TO COMPLY WITH THE REQUIREMENTS OF CFR 47

PART 15 REGULATION.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE

FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND,

THIS DEVICE MUST ACCEPTANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE

THAT MAY CAUSE UNDESIRED OPERATION.

NOTE: Must be used with shielded cable only.

FOR YOU RECORDS

For your assistance in reporting this product in case of loss or theft, please record below the model

number and serial, which are located on the bottom of the case. Please retain this information.

Model Number Serial Number

Date of Purchase Place of Purchase

All indicated copyrights and trademarks in the following pages are the properties of their respective

owners.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 3 of 30 Apr. 7, 2014

V.1.0.6

TABLE OF CONTENTS

REVISION HISTORY........................................................................................................................................................... 4

1INTRODUCTION....................................................................................................................................................... 6

2PACKAGING CHECK LIST .................................................................................................................................... 6

3SYSTEM REQUIREMENTS..................................................................................................................................... 6

4BIOS SETUP ............................................................................................................................................................... 6

5DRIVER INSTALLATION FOR WINDOWS XP/2000/ME/98SE........................................................................ 7

6DRIVER INSTALLATION FOR WINDOWS 8/7/VISTA (32 & 64 BIT)............................................................. 8

7DRIVER INSTALLATION FOR MAC OS INTEL BASED PC.......................................................................... 10

8CHECK DRIVER INSTALLATION IN WINDOWS 8/7/VISTA/XP/2000/ME................................................. 13

9CHECK DRIVER INSTALLATION IN MAC OS................................................................................................ 14

10 DRIVER UN-INSTALLATION FOR WINDOWS XP ......................................................................................... 14

11 DRIVER UN-INSTALLATION FOR WINDOWS 8/7/VISTA (32 & 64 BIT).................................................... 16

12 DRIVER UN-INSTALLATION IN MAC OS ........................................................................................................ 17

13 MANUALLY UPDATE THE DRIVER IN WINDOWS XP/ VISTA /7 / 8 ......................................................... 18

14 IRCOMM2K DRIVER AND THE VIRTUAL COM PORT................................................................................ 22

15 TROUBLE SHOOTING........................................................................................................................................... 25

16 SPECIFICATION..................................................................................................................................................... 26

17 PRECAUTIONS........................................................................................................................................................ 28

18 WARRANTY INFORMATION .............................................................................................................................. 29

19 CONTACT INFORMATION .................................................................................................................................. 30

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 4 of 30 Apr. 7, 2014

V.1.0.6

REVISION HISTORY

Revision History

Revision Date Comment

1.0.0 6/26/2009 Initial released

1.0.1 6/25/2010 Windows 7 update and Added chapter for guide to update the driver

manually in Windows XP / Vista / Windows 7

1.0.2 7/02/2010 Combined ACT-IR2002UL and ACT-IR4002US User’s Manual

1.0.3 7/30/2010 Updated Driver and installation procedure for Windows O.S

1.0.3.1 8/4/2010 Added chapter of IrCOMM2K driver & Virtual COM port

1.0.4 5/12/2011 Updated to single click & silent installer driver for Win XP/Vista/Win7

32 & 64 bit OSes

1.0.5 3/5/2014 Updated Windows Support which includes Win 8

1.0.5.1 3/21/2014 Added IR4002US in the 1st paragraph of chapter 8 Check Driver

1.0.6 4/7/2014 Updated screen shot in Installation step, & Add or Remove

Programs. Updated FCC declaration chapter.

ACTiSYS reserves the right to make changes without further notice to any products herein to improve reliability,

function or design. ACTiSYS does not assume any liability arising out of the application or use of any product or

circuit described herein.

All trademarks, logos, organizations or company names and product model names are the properties of the

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 5 of 30 Apr. 7, 2014

V.1.0.6

respective owners.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 6 of 30 Apr. 7, 2014

V.1.0.6

1 INTRODUCTION

ACT-IR2002UL & ACT-IR4002US are advanced Infrared USB adapters to replace the serial port

peripheral through USB port.

ACT-IR4002US is the thumb size version of ACT-IR2002UL. The latter has build in USB cable while the

former, like a flash disk, has only build in USB connector so that it becomes more compact to be carried.

They are also the next generation of ACT-IR2000UL/ ACT-IR4000US respectively. You will find no any

functional difference between them except the new generation has new driver and more flexible to use.

Features :

Supports all Windows from Win98 up to Win8 (32 & 64 bit), Win CE 4.2 & 5.0 (USB host), Mac 10.x

(both Intel & Power PC based) and Linux.

WHQL certified.

Fully compliant to USB specification 1.1 and IrDA®specification 1.4

Full-speed (12 Mbps) USB device operation

Supports FIR (4Mbps), MIR (1.152 Mbps) and all SIR speeds (9.6, 19.2, 38.4, 57.6 and 115.2 kbps).

Bus-powered device. Obtain power from USB port. No external power supply required.

Low power consumption in standby mode (Standby current 20 mA).

Not occupy PC's COM or Parallel port and has no complicated hardware port and resource setting

and conflict, such as IO address / IRQ / DMAnumbers.

2 PACKAGING CHECK LIST

The package includes:

A) ACT-IR2002UL B) ACT-IR4002US

1. ACT-IR2002UL USB Dongle with built in USB

cable.

2. Installation CD for Driver and User’s manual.

1. ACT-IR4002US USB Dongle

2. USB Cable

3. Installation CD for Driver and User’s manual.

3 SYSTEM REQUIREMENTS

1. Windows 98SE/ME/2000/XP/Vista/Windows 7/8, Win CE 4.2 & 5.0 (USB host), Mac 10.x (both Intel

& Power PC based) and Linux

2. One unoccupied USB port.

4 BIOS SETUP

Before you use this device, you MUST enable your computer USB port in BIOS Settings.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 7 of 30 Apr. 7, 2014

V.1.0.6

5 DRIVER INSTALLATION FOR WINDOWS XP/2000/ME/98SE

1. Insert the driver CD, It

will automatically

initialize the driver

installation wizard as

shown. Or manually

browse CD to double

click “setup.exe” for this

installation.

2.The Installer will install

ACT-IR2002UL /

ACT-IR4002US driver

without any user action.

The installer will exit

without any prompts after

successful installation

3.Now plug the

ACT-IR2002UL. /

ACT-IR4002US dongle It

will pop up a Bubble

Window : “Found New

Hardware” as shown in the

figure. Then this bubble

window will show

“USB-Infrared Adapter”

after completing this

procedure.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 8 of 30 Apr. 7, 2014

V.1.0.6

6 DRIVER INSTALLATION FOR WINDOWS 8/7/VISTA (32 & 64 BIT)

Note: Windows 8/7/Vista actually has its Native drivers for you. You can just Plug and Play and

Windows will auto find it.So you can skip this chapter. Yet, you can still follow below procedure just in

case you fail to find the proper native driver.

1. Insert the driver CD, It

will automatically

initialize the driver

installation wizard as

shown

2. The Installer will install

the driver. After this step

completes, you will see

“Completed” window.

3. Please click Finish to

close it.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 9 of 30 Apr. 7, 2014

V.1.0.6

4. Now plug the dongle

ACT-IR2002UL./

ACT-IR4002US It will

pop up a Bubble

Window : “Installing

device driver software”,

which will display as

“USB-Infrared Adapter”

after installed

successfully as right

figure.

The Infrared Wireless Expert

ACT-IR2002UL/ACT-IR4002US

User’s Manual

ACTiSYS Confidential Information Page 10 of 30 Apr. 7, 2014

V.1.0.6

7 DRIVER INSTALLATION FOR MAC OS INTEL BASED PC

IMPORTANT: Please install driver BEFORE you plug in ACT-IR2002UL / ACT-IR4002US

to USB port.

1. Insert the CD, Double

click the package file

MCS7780DriverDisk.

pkg for installing the

driver or go to

Applications and

double click the

installer and browse

for the

MCS7780DriverDisk.p

2. An installer wizard will

popup. Click Continue to

start the installation.
