AC7046 USB-C 4K Multiport Docking Station
MST and Power Delivery
2 | ENGLISH
AC7046 USB-C 4K Multiport Docking Station
MST and Power Delivery
Table of contents
1.0 Introduction .............................................................................................................. 2
1.1 Packing contents ................................................................................................. 2
2.0 Connections ............................................................................................................. 3
2.1 Front .................................................................................................................... 3
2.2 Rear ..................................................................................................................... 4
3.0 Connect the AC7046................................................................................................ 5
4.0 Monitor setup ........................................................................................................... 5
4.1 Single Monitor ...................................................................................................... 6
4.2 Dual Monitor (SST/MST) ..................................................................................... 6
4.3 Triple Monitor (SST/MST) .................................................................................... 6
4.4 SST (Single Stream Transport) ........................................................................... 6
4.5 MST (Multi Stream Transport) ............................................................................. 6
5.0 Power Delivery ......................................................................................................... 7
6.0 Frequently Asked Questions and other related information ..................................... 9
7.0 Service and support ................................................................................................. 9
8.0 Warning and points of attention ............................................................................... 9
9.0 Warranty conditions ............................................................................................... 11
1.0 Introduction
Congratulations with the purchase of this high-quality ACT product! This product
has undergone extensive testing by ACT’s technical experts. Should you
experience any problems with this product, you are covered by ACT
warranty. Please keep this manual and the receipt in a safe place.
Register your product now on www.act-connectivity.com and receive product updates!
1.1 Packing contents
The following parts need to be present in the packing:
AC7046
Power adapter
USB-C to C cable
Quick Installation Guide
3 | ENGLISH
2.0 Connections
2.1 Front
1x USB-C female notebook connection (connect this port to the USB-C connector
of your notebook
1x USB-C 3.2 Gen1 female (5Gbps)
1x USB-A 3.2 Gen1 female (5Gbps)
1x 3.5mm jack headset female (headphone + mic)
1x SD/micro SD card reader
4 | ENGLISH
2.2 Rear
1x DC power supply
1x USB-C female PD Pass-through port (connect your USB-C charger to charge
your notebook)
1x HDMI 2.0 female port (connect your HDMI monitor) to this HDMI port
2x DisplayPort female port(connect your DP monitor(s)) to these DP ports
2x USB-A 3.2gen1 female
1x Gigabit LAN RJ45 female port
5 | ENGLISH
3.0 Connect the AC7046
a. Connect the plug of the power supply to the DC connector of the docking station
and then connect the other end of the power supply into the wall outlet.
b. Connect the supplied USB-C cable to the USB-C host connector on the docking
station and the other end to the USB-C connector of your computer.
c. Connect the docking station to your HDMI and DP display(s)
d. Connect the docking station to:• USB peripherals • Audio devices • Gigabit
Ethernet
4.0 Monitor setup
Your USB-C device needs to support DP-Alternate mode or Thunderbolt™3 on its
USB-C port in order to display your video output to 1 or more displays. Check the
technical specifications of your USB-C device if it supports DP-Alternate mode or
Thunderbolt™3. If the device does not support DP-Alternate mode or Thunderbolt™3,
the AC7046 will not be able to display video onto your Display(s).
Please Note!!! For the AC7046 to be able to display the max resolution of 4K on all
three monitors your PC/Notebook needs to support additionally DP1.4 and DSC
6 | ENGLISH
please check the technical specs of your PC/Notebook if DSC and DP1.4 is
supported.
4.1 Single Monitor
For the single monitor setup, the AC7046 Docking station supports a max. resolution
of 4K @ 60Hz via HDMI or DisplayPort (DP).
4.2 Dual Monitor (SST/MST)
For the dual monitor setup, the AC7046 Docking station supports a max. resolution of
4K @ 60Hz on HDMI or DisplayPort (DP).
4.3 Triple Monitor (SST/MST)
For the triple monitor setup, the AC7046 Docking station supports a max. resolution of
2x 4K @ 30Hz on HDMI or DisplayPort (DP) and the 3rd monitor on 1080P @ 60Hz if
DSC is not supported by your laptop. If your laptop does support DSC you will be able
to use a max. resolution of 4K @ 60Hz on all three displays.
4.4 SST (Single Stream Transport)
With SST (Single Stream Transport) the connected screens will only show a clone
(copy) of your main screen on the connected screens.
4.5 MST (Multi Stream Transport)
MST is part of the DisplayPort 1.2 standard, with which monitors and computers can
support "daisy-chaining". You usually recognize daisy-chaining when the monitor has
both a DisplayPort input and output. You can connect the first monitor to the computer
and the second monitor to the first monitor. If both the monitor and the computer
support MST daisy-chaining, the two screens work as separate screens. Exactly as if
they were connected directly to the computer.
7 | ENGLISH
If your notebook supports DP alt mode (DisplayPort alternate mode) it also supports
MST. In this case the AC7046 will work as a USB-C to MST adapter. You will be able
to use the multiple video outputs. The connected screens will be recognized as
separate screens on your laptop / PC and can be used as an extended desktop.
Windows 10 has a short key to switch between the different display modes:
Use: “Windows key + P” an overview of display modes is displayed on your screen.
Please Note!!! MacOS does not support MST Daisy chaining. MacOS only supports
Daisy chaining with the Thunderbolt™3 standard. So the AC7046 will not provide the
desired result for macOS devices. In this case the connected screens only show a
clone (copy) of your main screen on the connected screens also called SST (Single
Stream Transport).
5.0 Power Delivery
The AC7046 supports Power Delivery (PD) on the USB-C port. This protocol enables
your notebook to be charged safely over one single USB-C cable. One footnote: all
devices within the power chain must support Power Delivery. Including the USB-C
cables. The devices and cables have built-in chips that communicate with each other
to decide the best PD profile to ensure a safe power delivery.
For example, if you connect a 45.0W USB-C charger to the AC7046 (supports PD
profiles up to 100.0W) and your notebook supports a USB-C PD profile of max.
65.0W. The max. power that will be provided to your notebook is 45.0W.
If for some reason in the example above, the USB-C cable is exchanged by a USB-C
cable which does not support PD (no built-in chip), your notebook will not be charged.
Besides this all, USB-C with PD enables charging in two directions. For example, you
can charge your smartphone with your tablet, but also your tablet with your
smartphone.
8 | ENGLISH
Which Power Delivery profiles are available? 5.0V, 9.0V, 12.0V, 15.0V and 20.0V.
What max. Power Delivery profiles are supported by the AC7046:
5.0V 3.0A 15.0W
9.0V 3.0A 27.0W
12.0V 3.0A 36.0W
15.0V 3.0A 45.0W
20.0V 5.0A 100.0W
9 | ENGLISH
6.0 Frequently Asked Questions and other
related information
The latest Frequently asked questions for your product can be found on the support
page of your product. ACT will update these pages frequently to assure you have the
most recent information. Visit www.act-connectivity.com for more information about
your product.
7.0 Service and support
This user manual has been carefully written by ACT’s technical experts. If you have
problems installing or using the product, please check the support link at the website
www.act-connectivity.com.
8.0 Warning and points of attention
Due to laws, directives and regulations set out by the European parliament, some
(wireless) devices could be subject to limitations concerning its use in certain
European member states. In certain European member states the use of such devices
could be prohibited. Contact your (local) government for more information about this
limitations.
Always follow up the instructions in the manual*, especially where it concerns devices
which need to be assembled.
Warning: In most cases this concerns an electronic device. Wrong/improper use may
lead to (severe) injuries!
When you connect the device to the mains, make sure it will not be damaged or
subject to (high) pressure.
A power socket is needed which should be close and easy accessible from the device.
Repairing of the device should be done by qualified ACT staff. Never try to repair the
device yourself. The warranty immediately voids when products have undergone self-
repair and/or by misuse. For extended warranty conditions, please visit our website at
www.act-connectivity.com
Dispose of the device appropriately. Please follow your countries regulation for the
disposal of electronic goods.
Please check below safety points carefully:
- Do not apply external force on the cables
- Do not unplug the device by pulling the power cable
- Do not place the device near heating elements
