Acer P3250 Refresh Manuel utilisateur

SERVICE MANUAL

SI : TSE: Check: Approved:

Date Revise Version Description

2008.4.10 V1.0 Initial Issue

2008.5.28 V2.0 Add Marketing Spec in Chapter 1

2008.7.22 V3.0 Add P3150 Refresh/P3250 Refresh

2008.10.10 V4.0

Add Waveform Download in Ch5

modify Ch4, Ch6 and AppendixB

P3150/P3250/P3150 Refresh/P3250 Refresh

P3150/P3250/P3150 Refresh/P3250 Refresh Condential

Comparison List

Part P3150 P3150 refresh P3250 P3250 refresh

MAIN BOARD 70.89Y23GR01 70.89Y33GR01 70.89Y29GR01 70.89Y34GR01

LAMP COVER 51.89Y02G002 51.89Y02G003 51.89Y02G002 51.89Y02G003

DMD 48.87K01G001 48.87M01G001

TOP COVER 70.89Y25GR01 70.89Y30GR01

P3150/P3250/P3150 Refresh/P3250 Refresh Condential II

Preface

This manual is applied to P3150/P3250/P3150 refresh/P3250 refresh projection system.

The manual gives you a brief description of basic technical information to help in service

and maintain the product.

Your customers will appreciate the quick response time when you immediately identify

problems that occur with our products. We expect your customers will appreciate the

service that you offer them.

This manual is for technicians and people who have an electronic background. Please

send the product back to the distributor for repairing and do not attempt to do anything that

is complex or is not mentioned in the troubleshooting.

Notice:

The information found in this manual is subject to change without prior notice. Any

subsequent changes made to the data herein will be incorporated in future edition.

P3150/P3250/P3150 refresh/P3250 refresh Service Manual

Manual Version 4.0

P3150/P3250/P3150 Refresh/P3250 Refresh Condential

III

Table of Content

Chapter 1 Introduction

Highlight 1-1

Compatible Mode 1-3

Product Overview 1-8

Chapter 2 Disassembly Process

Equipment Needed & Product Overview 2-1

Disassemble Lamp Cover Module 2-2

Disassemble Lamp Module 2-3

Disassemble Top Cover Module 2-4

Disassemble Key Pad Board Module 2-5

Disassemble Zoom Ring Module 2-5

Disassemble Main Board Module 2-6

Disassemble Color Wheel Module 2-8

Disassemble Front Cover Module 2-9

Disassemble Ballast Module 2-10

Disassemble DC-DC Module 2-11

Disassemble Thermal Switch Module 2-12

Disassemble Lamp Blower and System Fan Module 2-13

Disassemble Lamp to Ballast Cable 2-14

Disassemble Engine Module 2-15

Disassemble DMD Board and DMD Ship 2-15

Disassemble Speaker Module 2-16

Disassemble Interrupt Switch Module 2-16

Disassemble IR Sensor Module 2-17

Rod Adjustment 2-18

P3150/P3250/P3150 Refresh/P3250 Refresh Condential

Re-write Lamp Usage Hour 2-19

Assemble IR Sensor Module 2-20

Assemble Interrupt Switch Module 2-20

Assemble Speaker Module 2-21

Assemble DMD Board and DMD Chip Module 2-22

Assemble Engine Module 2-22

Assemble Lamp to Ballast Module 2-23

Assemble Lamp Blower and System Fan Module 2-24

Assemble Thermal Switch Module 2-25

Assemble DC-DC Module 2-26

Assemble Ballastl Module 2-27

Assemble Front Cover Module 2-28

Assemble Color Wheel Module 2-29

Assemble Main Board Module 2-30

Assemble Zoom Ring Module 2-31

Assemble Key Pad Board Module 2-32

Assemble Top Cover Module 2-33

Assemble Lamp Module 2-34

Assemble Lamp Cover Module 2-35

Chapter 3 Troubleshooting

LED Lighting Message 3-1

Main Procedure 3-3

Beep Sound 3-4

Chapter 4 Function Test & Alignment Procedure

Test Equipment Needed 4-1

Service Mode 4-1

OSD Reset 4-1

P3150/P3250/P3150 Refresh/P3250 Refresh Condential

Test Condition 4-2

Test Inspection Procedure 4-4

PC Mode 4-4

Video Performance 4-7

Optical Performance Measure 4-10

Other 4-12

Chapter 5 Firmware Upgrade

Section 1: System Firmware Updategrade 5-1

Equipment Needed 5-1

DLP Composer Lite Setup Procedure 5-2

USB Driver Upgrade Procedure 5-4

Firmware Upgrade Procedure 5-5

Section 2: MCU Firmware Updategrade 5-9

ISP Environment set up 5-9

Install ISP Procedure 5-13

MCU Set up procedure 5-15

MCU Firmware Upgrate 5-16

Waveform Download 5-20

P3150/P3250/P3150 Refresh/P3250 Refresh Condential

Chapter 6 EDID Upgrade

EDID Introduction 6-1

Equipment Needed 6-2

Setup Procedure 6-3

EDID Key-In Procedure 6-3

Setup Procedure (HDMI) 6-7

Default Language Reset 6-9

Appendix A P3150/P3250 Exploaded Overview I

Appendix B Serial Number System Denition I

PCBA Code Denition II

P3150/P3250/P3150 Refresh/P3250 Refresh Condential 1-1

Chapter 1

Introduction

1-1 Highlight

No Item Description

1Dimensions (WxDxH) - 209 x 74.2 x 172.2 mm

2Weight - 1.24 kg

3Tilt Angle - 7 degree with elevator mechanism

4 Keystone correction - +/ -40 degree (80 degree)

5DMD Chip

- TI DMD 0.55” 12° 2xLVDS Type-X SVGA Digital Mirror

Device (for P3150/P3150 refresh)

- TI DMD 0.55” 12° 2xLVDS Type-X XGA Digital Mirror Device

(for P3250/P3250 refresh)

6Number of active dots - 800(H) x 600(V) (for P3150/P3150 refresh)

- 1024(H) x 768(V) (for P3250/3250 refresh)

7 Power Supply

- Universal AC 100 -240 V ~ 50-60 Hz with PFC input

- Variance FAN speed control (Depends on temperature

variant)

8 Terminal

- HDMI Female Terminal X 1

- VGA input ( D-SUB X 1)

- Video input (RCA jack Type X 1, Mini DIN 4-pin S-video X 1)

- Audio input (Phone jack Type X 1)

- USB (Type-B X 1)

9Lamp - 165 Watt for OSRAM E17.6 Lamp @ normal operation

10 Projection lens - F# 2.41 ~2.55, f = 21.79~23.99 mm, 1.10X Mechanical Zoom

Lens

11 Projection Image Size - Adjustable from 22.9” to 302.8” (Diagonal)

12 Throw Distance - 1.0m – 12m

13 Throw Ratio - 1.95 – 2.15:1 @ 60”

P3150/P3250/P3150 Refresh/P3250 Refresh Condential 1-2

No Item Description

14 Input signal spec

- Hsync Frequency 31.5 k ~ 100 kHz

- Vsync Frequency 50 ~ 85 Hz

- Video Signal RGB (PC)

● Analog RGB 0.7Vp-p, 75 ohm, Separate TTL H,V Sync

● Analog RGB 1Vp-p, 75 ohm, Sync. On Green signal

● Analog RGB 0.7Vp-p, 75 ohm, Composite TTL Sync.

- Video

● Composite video 1Vp-p,75 ohm

● S-video Luminance 0.714Vp-p, 75 ohm

● Chrominance 0.286Vp-p, 75 ohm

● Component Video 1Vp-p, 75 ohm

15 Video Compatibility

- Standards :

● NTSC (3.58/4.43)

● PAL (B/D/G/H/I/M/N)

● SECAM (B/D/G/K/K1/L)

● HDTV - 480p, 576p, 720p, 1080i (for P3150/3150 refresh)

● HDTV - 480p, 576p, 720p, 1080p (for P3250/P3250 re

fresh)

16 Brightness

P3150/P3250/P3150 refresh/P3250 refresh Engineering Spec:

- 1800 ANSI Lumens (Typical; Full power mode)

- 1600 ANSI Lumens (Minimum; Full power mode)

P3150/P3250/P3150 refresh/P3250 refresh Markteting Spec:

- 2000 ANSI Lumens

17 Contrast

P3150/P3250/P3150 refresh/P3250 refresh Engineering Spec:

- 1400 : 1 Full White and Black (Minimum; Full power mode)

- 1800 : 1 Full White and Black (Typical; Full power mode)

P3150/P3250/P3150 refresh/P3250 refresh Markteting Spec:

- 2000 :1 Full White and Black

18 Uniformity

P3150/P3250/P3150 refresh/P3250 refresh Engineering Spec:

- 65% Japan standard (Minimum; Full power mode)

- 80% Japan standard (Typical; Full power mode)

P3150/P3250/P3150 refresh/P3250 refresh Markteting Spec:

- 85% Japan standard

19 Color Wheel

- 6 segments (R90Y28G90C28W42B80)

- 7200rpm @ 2x

9000rpm @ 3x, PAL 50Hz

20 Operation temperature - 5°C -- 35°C

21 Storage temperature - -20°C -- 60°C

22 Maximum Humidity - Operating: 5°C -- 35°C, 80%RH (Max.), non-condensing

- Storage: -20°C -- 60°C, 80%RH (Max.), non-condensing

23 Lamp life - 3000 hours min, 50% survival rate (Full power Mode)

- 4000 hours min, 50% survival rate (Echo power Mode)

24 System controller - TI DDP2230

P3150/P3250/P3150 Refresh/P3250 Refresh Condential 1-3

1-2 Compatible Mode

A. Analog

Compatibility Resolution V-Sync [Hz] H-Sync [KHz]

VGA

640x480 60 31.50

640x480 72 37.90

640x480 75 37.50

720x400 70 31.50

SVGA

800x600 56 35.20

800x600 60 37.90

800x600 72 48.10

800x600 75 46.90

832x624 75 49.73

XGA

1024x768 60 48.40

1024x768 70 56.50

1024x768 75 60.00

SXGA 1152x864 70 63.80

1280X1024 60 63.98

QuadVGA 1280x960 60 59.70

1280x960 75 75.23

SXGA+ 1400x1050 60 65.32

WXGA

1280x800 60 49.702

1360x768 60 47.72

1440x900 60 55.935

1680x1050 60 65.290

UXGA 1600x1200 60 75.00

Power Mac G4

640x480 66.6(67) 34.93

800x600 60 37.90

1024x768 60 48.40

1152x870 75 68.68

1280x1024 60 63.98

PowerBook G4

640x480 60 31.35

640x480 66.6(67) 34.93

800x600 60 37.90

1024x768 60 48.40

1152x870 75 68.98

1280x1024 60 63.98

i Mac DV (G3) 1024X768 75 60.00
