Introduction

The Acer Projector Gateway (APG) is a smart, integrated system that enhances

presentations via your Acer projector. The APG provides versatile source

connectivity, the latest eDisplay Management tools for networking display,

supports for media contents playback via the built-in decoder and more.

Networking APG features

•With high-performance wireless projection via an acer USB WiFi adapter or

an RJ-45 port for wired connections (only for the models with RJ-45 port).

•The projector can act as an access point (AP) or work in Client mode when

doing networking display.

•Users can easily launch the Acer eDisplay Management to do Full screen, L/

R, 4-split screen projection and enable high quality video streaming.

•Powerful wireless display features ready for devices with different OS (MS

Windows, Mac OS, Android, iOS)

•Supports wireless network security (WPA-PSK, WPA2-PSK).

•Acer Projector Gateway Web Management enables a web-based control of

Acer projector for Windows NB/PC (only when the projector is in AP mode).

•Supports firmware upgrade via USB flash drive.

•Crestron compliant (only for the models with RJ-45 port).

Multi-media features

•Fancy and stylish user interface for better experience.

•You can enjoy media & documents playback via internal memory, USB flash

drive and SD card (for selected models).

•Supports high resolution JPEG and BMP picture formats, slideshow and

various slideshow effects for the best viewing experience.

•Supports MP3, PCM and WMA...audio formats, music spectrum and

random play function for your pleasing.

•Supports MPEG4, H.264, WMV, MKV and RMVB...video formats and

smooth video playback with 1080p@30Hz.

•Supports office documents playback (Word, Excel, PowerPoint, PDF).

•Easy control for all media functions by the remote control.

•DLNA compliant. You can enjoy connectivity with other DLNA devices if

under the same local area network environment.

•You can mirror or extend your screen via the source USB B or USB

Connection.

Downloaded From projector-manual.com Acer Manuals

English

Getting Started

Connecting multi-media device to the projector

To switch between different inputs,

press SOURCE on the projector or

remote control to open the Source

menu that allows you to select an

input signal source.

#Component Description

1 LAN port Connects to an Ethernet 10/100-based network.

2 Mini USB Projects NB/PC screen via mini USB (USB B or USB

Connection).

NOTE: USB Type A is for USB display (K1

series).

3 USB Type A Connects to USB flash drive for multimedia playback.

Or connects to a USB WiFi adapter (optional).

NOTE: To enable wireless function, the

USB Wireless Adaptor must be plugged

into the USB A1 port if the projector is

equipped with 2 USB Type A ports.

4SDcardslot(for

selected models)

Insert the SD card for multimedia playback.

123 4

USB B

Downloaded From projector-manual.com Acer Manuals

English

Changes may be made periodically to the information in this publication

without obligation to notify any person of such revisions or changes.

Such changes will be incorporated in new editions of this manual or

supplementary documents and publications.

This company makes no representations or warranties, either expressed or

implied, with respect to the contents hereof and specifically disclaims the

implied warranties of merchantability or fitness for a particular purpose.

Downloaded From projector-manual.com Acer Manuals

English

Control Panel and Remote Control

Control Panel

#Function Description

1 MENU Launches the projector Onscreen Display (OSD) menu.

2BACK

Stop

Cancels your selection, or goes back to previous page.

Stops the playing media files.

3 SOURCE Press to open the Source

menu that allows you to select

an input signal source.

4 Four directional

selection keys

Selects the media files in four directions.

5ENTER

Play/Pause

Confirms your selection of items.

Plays/Pauses the playing media files.

Downloaded From projector-manual.com Acer Manuals

English

Remote Control

#Function Description

1 ENTER Confirms your selection of items.

2 BACK Cancels your selection, or goes back to previous page.

3 MEDIA HOME Goes to MEDIA HOME page.

NOTE: This button is only available when

the input signal is MEDIA.

4Four

directional

select pad

Selects the media files in four directions.

5 VOL +/- Increases/decreases the volume.

Downloaded From projector-manual.com Acer Manuals

English

6Rewind •Goes to the previous file.

•Rewinds the playing media files with a long press

for 1 second.

Play/Pause Plays/Pauses the playing media files.

Stop Stops the playing media files.

Fast-forward •Goes to the next file.

•Fast-forwards the playing media files with a long

press for 1 second.

Previous Goes to the previous file.

Next Goes to the next file.

Rewind Rewinds the playing media files.

Fast-forward Fast-forwards the playing media files.

7 SOURCE Press to open the Source

menu that allows you to

select an input signal source.

8 MENU Launches the projector Onscreen Display (OSD) menu.

9 MEDIA SETUP Opens MEDIA SETUP page.

10 PAGE ^/v

PgUp/PgDn

For computer mode only. Use the button to select the

next or previous page. This function is only available

when connected to a computer via a USB cable.

11 INFO Displays information of the selected file.

12 A/a Launches the projector OSD subtitle menu during video

playback.

#Function Description

Downloaded From projector-manual.com Acer Manuals

English

Media Mode

This mode allows you to browse media files stored in different devices, such as

RAM (internal memory), USB flash drive, USB hard drive and SD card (for

selected models) when connected to the projector. No matter where you are,

you can always press MEDIA HOME to go back to MEDIA HOME page.

Adjust projector source to MEDIA.

NOTE: Document mode is an optional function.

NOTE: Supported capacity for USB flash drive: up to USB 3.0 64GB,

for USB hard drive: up to 1TB.

NOTE: Supported capacity for SD/SDHC/MicroSD: up to 64GB Class

2-10.

NOTE: Some external USB hard drives may not be supported due

to lack of USB power.

NOTE: Disks with partitions are not supported.

Main features

Content

sources

Main Home page

Downloaded From projector-manual.com Acer Manuals

English

Music

When viewing music files

You can press the four directional selection keys to select the album and press

ENTER to access. To use the sidebar, press repeatedly until it displays and you

can browse files by albums/artists/genres/songs.

When playing music

You can press / to adjust the volume. To select the backward/forward

speed, press the Rewind/Fast-forward key repeatedly. For details on the Music

setting, see "Music Setting".

Title image/

source

Thumbnail

sorting

Goes back to previous page

Sidebar

Total

events/

files

Goes to the Music Setting in the

Media Setup page

Goes back to previous page

Goes to the Music Setting in the

Media Setup page

Song

information

Music playback

status

Control bar

Downloaded From projector-manual.com Acer Manuals

English

NOTE: Only MP3 files with ID3 tags can be sorted in the sidebar.


When viewing photos

You can press the four directional selection keys to select the file and press

ENTER to access. To use the sidebar, press repeatedly until it displays and you

can browse files by events/photos.

When playing photos

Title

image/

source

Thumbnail

sorting

Goes back to previous page

Sidebar

Total

events/

files

Goes to the Photo Setting in

the Media Setup page

Goes back to previous page

Selected


Control bar

Goes to the Photo Setting in

the Media Setup page

Downloaded From projector-manual.com Acer Manuals

English

You can press to start a slideshow in full screen. Music playback is allowed

during a slideshow. You can press / to adjust the volume. For details on

the Photo Setting, see "Photo Setting".

Video

When viewing video files

You can press the four directional selection keys to select the file and press

ENTER to access. To use the sidebar, press repeatedly until it displays and you

can browse files by collections/videos.

When playing videos

You can press / to adjust the volume. To select the backward/forward

speed, press the Rewind/Fast-forward key repeatedly. To display the subtitle,

Title image/

source

Thumbnail

sorting

Goes back to previous page

Sidebar

Total

events/

files

Goes to the Video Setting in

the Media Setup page

Goes back to previous page

Video

playback

status

Control bar

Goes to the Video Setting in

the Media Setup page

Downloaded From projector-manual.com Acer Manuals
