Acer LX.RR902.004 Manuel utilisateur

Aspire Notebook Series

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire Notebook Series Quick Guide

Original Issue: 06/2011

Acer recommends...

Productivity Software

Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects

with Office 2010.

Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,

YouTube or Windows Live.

Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more

informed decisions.

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your

computer.

The Aspire Generic User Guide contains useful information applying to

all models in the Aspire product series. It covers basic topics such as

using the keyboard and audio, etc. Please understand that due to its

nature, the Generic User Guide will occasionally refer to functions or

features which are only contained in certain models of the series, but not

necessarily in the model you purchased. Such instances are marked in the

text with language such as "only for certain models".

The Quick Guide introduces you to the basic features and functions of

your new computer. For more on how your computer can help you to be

more productive, please refer to the Aspire Generic User Guide. This

guide contains detailed information on such subjects as system utilities,

data recovery, expansion options and troubleshooting. In addition it

contains warranty information and the general regulations and safety

notices for your notebook. It is available in Portable Document Format

(PDF) and comes preloaded on your notebook. Follow these steps to

access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on Aspire Generic User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on Aspire Generic User Guide

will run the Adobe Reader setup program first. Follow the instructions

on the screen to complete the installation. For instructions on how to

use Adobe Reader, access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us

show you around your new Acer notebook.

Top view

#Icon Item Description

1Integrated

webcam Web camera for video communication.

English

2Displayscreen

Also called Liquid-Crystal Display (LCD),

displays computer output (configuration

may vary by model).

3 Power button Turns the computer on and off.

4 Keyboard For entering data into your computer.

5Touchpad

Touch-sensitive pointing device which

functions like a computer mouse.

6 Microphone Internal microphone for sound recording.

Power indicator Indicates the computer's power status.

Battery indicator

Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

8Click buttons (left

and right)

The left and right buttons function like the

left and right mouse buttons.

9 Speaker Delivers audio output.

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of

the computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the

other key in the hotkey combination.

Hotkey Icon Function Description

<Fn> +

<F3>Communication Enables/disables the computer’s

communication devices.

<Fn> +

<F4>Sleep Puts the computer in Sleep mode.

<Fn> +

<F5>Display toggle

Switches display output between

the display screen, external

monitor (if connected) and both.

<Fn> +

<F6>Screen blank

Turns the display screen backlight

off to save power. Press any key to

return.

<Fn> +

<F7>

Touchpad

toggle

Turns the internal touchpad on and

off.

<Fn> +

<F8>Speaker toggle Turns the speakers on and off.

<Fn> +

<> Brightness up Increases the screen brightness.

<Fn> +

Brightness

down Decreases the screen brightness.

<Fn> +

<> Volume up Increases the sound volume.

<Fn> +

<> Volume down Decreases the sound volume.

<Fn> +

<Home>Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>Stop Stop playing the selected media

file.

<Fn> +

<Pg Dn>Previous Return to the previous media file.

<Fn> +

<End>Next Jump to the next media file.

English

Closed front view

Left view

#Icon Item Description

Microphone jack Accepts inputs from external

microphones.

Headphones/

speaker jack

Connects to audio devices

(e.g., speakers, headphones).

2 2-in-1 card reader

Accepts Secure Digital (SD),

MultiMediaCard (MMC).

Note: Push to remove/install the card.

Only one card can operate at any time.

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2External display

(VGA) port

Connects to a display device (e.g.,

external monitor, LCD projector).

3 Ethernet (RJ-45) port Connects to an Ethernet 10/100-based

network.

21345

English

Right view

4HDMIport Supports high-definition digital video

connections.

5USB2.0port

Connects to USB 2.0 devices (e.g., USB

mouse, USB camera).

#Icon Item Description

1 USB 2.0 ports Connect to USB 2.0 devices (e.g.,

USB mouse, USB camera).

2 Optical drive Internal optical drive; accepts CDs or

DVDs.

3Optical disk access

indicator

Lights up when the optical drive is

active.

4Optical drive eject

button Ejects the optical disk from the drive.

5Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the

emergency eject hole to eject the

optical drive tray when the computer

is off.

#Icon Item Description

314562

English

Base view

Kensington lock

slot

Connects to a Kensington-compatible

computer security lock.

Note: Wrap the computer security

lock cable around an immovable

object such as a table or handle of a

locked drawer. Insert the lock into the

notch and turn the key to secure the

lock. Some keyless models are also

available.

#Icon Item Description

1 Battery bay Houses the computer's battery pack.

2 Battery lock Locks the battery in position.

3 Battery release lock Releases the battery for removal.

#Icon Item Description

English

Environment

•Temperature:

•Operating: 5 °C to 35 °C

•Non-operating: -20 °C to 65 °C

•Humidity (non-condensing):

•Operating: 20% to 80%

•Non-operating: 20% to 80%
