Acer Aspire M1620 Manuel utilisateur

Aspire M1620

VeritonM262

Service Guide

Service guide files and updates are

available on the AIPG/CSD web;for

more information please refer to

http://csd.acer.com.tw

PRINTED IN TAIWAN

Revision History

Please refer to the table below for the updates made on Aspire M1620 VeritonM262

service guide.

Date Chapter Updates

III

publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or

by any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of Acer Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Acer Incorporated makes no representations or warranties, either expressed

or implied, with respect to the contents hereof and specifically disclaims any

warranties of merchantability or fitness for any particular purpose. Any Acer

Incorporated software described in this manual is sold or licensed "as is".

Should the programs prove defective following their purchase, the buyer (and

not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of

all necessary servicing, repair, and any incidental or consequential damages

resulting from any defect in the software.

Acer is a registered trademark of Acer Corporation.

Intel is a registered trademark of Intel Corporation.

Pentium 4 and Celeron are trademarks of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks

of their respective holders.

Conventions

The following conventions are used in this manual:

SCREEN

MESSAGES

Denotes actual messages that appear on screen.

NOTE Gives bits and pieces of additional information

related to the current topic.

WARNING Alerts you to any damage that might result from

doing or not doing specific actions.

CAUTION Gives precautionary measures to avoid possible

hardware or software problems.

IMPORTANT Remind

ou to do s

ecific actions relevant to the

accomplishment of procedures.

Preface

Before using this information and the product it supports, please read the

following general information.

1. This Service Guide provides you with all technical information relating to

the BASIC CONFIGURATION decided for Acer's "global" product offering.

To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the

functionality of a machine (e.g. add-on card, modem, or extra memory

capability). These LOCALIZED FEATURES will NOT be covered in this

generic service guide. In such cases, please contact your regional offices or

the responsible personnel/channel to provide you with further technical

details.

2. Please note WHEN ORDERING FRU PARTS, that you should check the

most up-to-date information available on your regional web or channel. If,

for whatever reason, a part number change is made, it will not be noted in

the printed Service Guide. For ACER-AUTHORIZED SERVICE

PROVIDERS, your Acer office may have a DIFFERENT part number code

to those given in the FRU list of this printed Service Guide. You MUST use

the list provided by your regional Acer office to order FRU parts for repair

and service of customer machines.

Chapter 1 System Specifications 1

Features…………………………………………………………………………... 1

Main board Placement……………………………………………………….10

Block Diagram…………………………………………………………………..11

AspireM1620 Front Panel……………...………….............…………….12

Aspire M1620 Rear Panel……………….………………..............….…..13

VeritonM262 Front Panel………………….................………….….….14

VeritonM262 Rear Panel………………........………...........……………15

Hardware Specifications and Configurations………………….…….16

Power Management Function (ACPI support function)………….22

Chapter 2 System Utilities 23

Entering Setup………………………………………………………………..24

Product Information………………………………………………………..26

Standard CMOS Features…………………………………………………27

Advanced BIOS Features………………………………………………….30

Integrated Peripherals……………………………………………………..34

Power Management…………………………………………………………41

PnP/PCI Configuration…………………………………………………….44

PC Health Status…………………………………………………………......46

Frequency/Voltage Control……………..………………………….…....47

Load Default Settings………………………………………………..……. 49

Set Supervisor/User Password……………………………….…………50

Save & Exit Setup………………………………………………….…………52

Exit Without Saving………………………………………………….……..53

Chapter 3 Machine Disassembly and Replacement 54

General Information………………………………………………………. 55

Disassembly Procedure……………………………………………………56

AspireM1620 Disassembly Procedure…..............……..…………57

VeritonM262 Disassembly procedure………...................………63

Chapter 4 Troubleshooting 73

Chapter 5 Jumper and Connector Information 74

Jumper Setting……………………………………………………………….74

Chapter 6 FRU (Field Replaceable Unit) List 83

Exploded Diagram………………………………………………………….84

Parts……………………………………………………………………………..86

System Specifications

Features

Operating System

 Microsoft Windows Vista (Home Basic, Home Premium,

Business)

Processor

 Socket Type: Intel®Socket T LGA 775 pin

 Processor Type:

 Support 105W CPU, Intel®Core 2 Quad, Core 2 Extreme,

Core 2 Duo, Pentium®D, Pentium®4, Celeron D processors ,

Socket T (LGA775)Intel®Kens field

Chipset

 North Bridge: 945G/GC

 South Bridge: ICH7

PCB

 Form Factor: ATX

 Dimension/Layer: 9.6"x 8.8"

Memory

 Memory Type: DDRII 400/533/667

 Support single channel 64 bit mode with maximum memory size

up to 4GB

 DIMM Slot: 2

 Memory Max: 128Mb/256Mb/512Mb/1Gb devices technologies

 Capacity: Up to 128MB per DIMM with maximum memory size

up to 4 GB

Graphics

 Intel 945G/GC on die graphic solution

 DVMT 4.0 technology support

 Enhanced 3D and Clear Video technology support

 Dual View function support (by Intel ADD2/MEC card)

 1 D-sub VGA port on rear

PCI

 PCI Express Slot Type: x16

 PCI Express x16 Slot Quantity: 1

 Support ADD2/MEC card

 PCI Express Slot Type: x1

 PCI Express x1 Slot Quantity: 1

 PCI Slot

 PCI Slot Quantity: 2

FDD

 Slot Quantity: 1

 Design Criteria:

 Should support 1.44MB/3 mode 3.5” Devices

SATA

 Slot Type: SATA slot

 Slot Quantity: 4

 Storage Type support:

 HDD/CD-ROM/CD-RW/DVD-ROM/DVD-RW/DVD+RW/

DVD Dual/DVD

SuperMultiPlus/Blu-Ray ODD

Audio

 Audio Type: HD audio codec

 Audio Channel: 7.1 channel

 Audio Controller /Codec: ALC883, colay with ALC888

 Support S/PDIF: S/PDIF-out header (1*4)
