ACEFAST D10 Manuel utilisateur
D10
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch • Manuel d'utilisation
2
English
3 –10
Čeština
11 –18
Slovenčina
19 –26
Magyar
27 –34
Deutsch
35 –42
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
Product picture
Dashboard base
Back clip
Dry & wet tissue
Silicone pad
Knob
Air vent mount
USB-C charging cable
The bottom support of the stand can be
adjusted to the proper position according
to the size of the mobile phone
5
Operating Instructions
Operation steps of the center console holder:
1. Use a wipe pack
to clean the surface
of the center
console of
the car.
2. Stick the silicone
pad on the surface
of the center
console of the car
3. Raise the lever of
the center console
base, stick the base
on the silicone pad,
lower the lever of
the center
console base.
4. Unscrew the
fixing nut behind
the back clip, put
the universal
ball in and then
tighten the nut.
Operation steps of the air vent holder:
1. Unscrew the fixing nut
behind the back clip, put
the universal ball in and
then tighten the nut.
2. Fix the holder at the air
vent. Turn the knob
counter clockwise to open
the hook clamp, and turn
the knob clockwise to lock
thehook clamp.
Air vent
6
Back clamp operation steps:
1. Use the USB-C charging
cable to connect the car
charger to the USB-C port
at the bottom of the back
clip.
2. Press the "Press" button
on the back of the holder,
the back clip arm
automatically opens.
3. Put in the phone in and
lock the clamp arm.
Specifications
Model
HD-C60
Colour
Black
Material
Plastic, silicone, metal alloy
Place of mount
Dashboard, in-car air vent
Input (USB-C )charging port
5V 2A; 9V 1.67A
Output
5W/7.5W/10W/15W(Max)
Size
Back clip size: 110x69x57mm / 4.33x2.72x2.24in
Clamp inner width (max./min.): 53-96mm / 2.09-3.78in
Dashboard base size: 167x72.5x40mm /
6.57x2.85x1.57in
Air vent clip size: 93x45x34mm / 3.66x1.77x1.34in
Weight
About 220g / 7.76oz
7
Precautions:
Do not disassemble or modify this product by yourself.
Do not place this product in a humid environment.
Please do not charge near a heat source.
Do not allow water or other liquids to flow into the product, otherwise it will cause
damage to the product.
Do not install this product in the area where the airbag is located.
Do not drop.
Do not scratch the surface of this product with sharp objects to avoid surface damage.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
RF Exposure Warning Statements:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled
environment. This equipment shall be installed and operated with minimum distance
20cm between the radiator & body.
8
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
9
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: PODLE “SEO PREFIX” V LISTOVACÍ TABULCE
Model / Type: Acefast-D10
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/53/EU
Directive No. 2011/65/EU as amended 2015/863/EU
Prague, 8.3. 2022
10
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
