Accusplit Healthengine AH120M9 Manuel utilisateur

2 3

6 7

Operating Instructions

ACCUSPLIT

AH120M9 PEDOMETER

DISPLAYS

CURRENT DAY

Display

days

7644

MEMORY

display area (flashes when in memory mode)

MEMORY

Display

8922

16:30

The pedometer has two display modes: CURRENT DAY and

MEMORY.

1. CURRENT DAY display: Memory display area in

lower right of screen is blank and clock is present

in lower left corner.

2. MEMORY display: Memory display area in lower

right of screen shows which day’s results you are

viewing.To enter MEMORY display, press the gray

“M” button.

Return to CURRENT DAY display by repeatedly pressing

the gray “M” button until the memory display area is

blank, and clock returns.

Make sure you are in CURRENT DAY display when setting up

your pedometer and checking today’s steps.

SETTING UP YOUR PEDOMETER

ACCUSPLIT products use a common setting procedure,

S1-S2-S3-S4.

Press S1 for 2 seconds: Enter the SET mode

Press S2: Change the ﬁeld to be set

Press S3: Change the ﬁeld value

Press S4 for 2 seconds: Exit the SET mode

SETTING THE CLOCK

The clock must be set in order for the memory’s automatic

rollover function to work correctly.

1. Press and hold the gray S1 button for 2 seconds. The

HOUR display will start to blink, showing that you’ve

entered SET mode.

8922

16:30

2. Press the gray S3 button to increase the HOUR display.

Hold the button down to change hours quickly.

PM hours are displayed in military time (1:00 PM is

13:00, 2:00 PM is 14:00, etc.).

3. Press the yellow S2 button to switch from the HOUR

display to the MINUTE display.The MINUTE display

will start to blink.

4. Press the gray S3 button to increase the MINUTE

display. Hold the button down to change minutes

quickly.

5. Press and hold the yellow S4 button for 2 seconds to

exit SET mode and return to STEP mode.The display

will stop ﬂashing.

990-003B

ACCUSPLIT, Inc.

2290A Ringwood Ave., San Jose, CA 95131

800-965-2008 • 925-226-0888 • FAX 925-463-0147

www.ACCUSPLIT.com/support • support@ACCUSPLIT.com

Eat Right! Walk More! Live Well!

The ACCUSPLIT Lifestyle

How to Open your pedometer.

See diagrams at right.

ACCUSPLIThealthengine

125379

15:15 785

MODE

MEMORY

RESET

10 11

8 9

12 13

14 15

Leash is already attached

to the pedometer.

Clasp the waistband of

your clothing with

the attached

alligator clip. Or, loop a

badge holder, then

put into pocket

(Badge holder

not included)

Or, loop a belt

or belt loop

SAFETY LEASH

This pedometer comes with a free safety leash, to help

prevent accidental loss.The leash comes pre-attached to the

pedometer.

To use the leash, simply clasp the waistband of your clothing

with the attached alligator clip. You can also use a safety pin

to fasten the leash to your clothing, loop the leash through

your belt or belt loop, or use a badge holder.

See sketch on next page for details.

VIEWING YOUR RESULTS

Viewing Today’s Results

Once you put on your pedometer and close the lid, it will

automatically begin to record your steps.

• STEP mode displays all the step count activity since

last automatic daily reset (at 3:50 AM)

• TIME OF DAY appears in lower left hand corner of

the display.

5:18

8722

Clock

STEP count

VIEWING PREVIOUS DAYS’ RESULTS

Your pedometer has 9 total memories.There are 7 days

of step memories, plus today’s step count, plus a TOTAL

memory of all steps taken during the past 7 days.

WEARING YOUR PEDOMETER

While gently holding the metal belt clip open, slide the pe-

dometer onto your belt or the top edge of your pants or skirt.

It should ﬁt snugly and level, above one knee.

Note: the pedometer should be as vertical as possible.

Walkers with larger stomachs may ﬁnd it helpful to wear the

pedometer farther back on the body, toward one hip.

The cover must be closed for the pedometer to work.

yes

days

7total

87329

MEMORY

display area

(flashes when in memory mode)

(no clock in

memory mode)

To recall the daily memories from the previous 7-day period:

1. Press the gray “M” button to search for the speciﬁc

day’s records you would like to recall. For example, if

you would like to review the records of 2 days ago,

press the “M” button until the DAYS display shows

“2 days.”

2. “1 days” is the record for yesterday, “2 days” is for

2 days ago, etc. “7 days total” shows you the total

activity for the past 7 days.

3. Records older than 7 days are automatically

discarded.

REPLACING THE BATTERY

1. When the ﬁgures on the display start to blink, it is

time to replace the battery.

2. The unit uses oneType CR2032 3-volt lithium battery.

3. Insert a coin into the slot at the bottom of the body

case.Twist the coin to remove the front case.

4. Locate the BATTERY HOLDING PLATE at the bottom

left corner of the inside case. Remove the plate by

loosening the two small screws with a small Phillips

head screwdriver.

5. Take out the old battery and replace it with a new

battery. Place the battery’s positive (+) terminal

FACE UP while you install it into the pedometer.

CLEARING THE MEMORIES

Auto Reset: At 3:50 AM every day, the previous day’s STEP

record is automatically saved and STEP display resets to 0.

You do not need to press the RESET button every day.

Manual Reset: To reset today’s STEP data to 0, press and

hold the yellow RESET button for 2 seconds. Note: Resetting

today’s steps before automatic nightly rollover prevents them

from being tallied in memory.

System Reset: To reset all memories to 0 (including the clock),

press the recessed SYSTEM RESET button in the lower left

corner of the front of the display. (Use a pen or the end of

a paper clip.) Note: In case of irregular display due to static

electricity, pressing the SYSTEM RESET button, and then

resetting the CLOCK, will return the unit to normal.

Terminal

Screws

NO-PROOF-OF-PURCHASE LIMITED WARRANTY

Free service for ﬁrst year of ownership;

$12 fee for service thereafter. See label inside unit for date.

See www.accusplit.com/support for details

and back case together, then pressing the bottom of

the case together. If the two halves don’t go together

easily, check if the front case is upside down!

7. Reset the CLOCK to restore all functions to your

pedometer.

CAUTION: Please DO NOT TOUCH inner pedometer parts,

other than battery. Touching the sensor mechanism may

affect the accuracy of the pedometer.

6. Reinstall the BATTERY HOLDING PLATE

by tightening the two

screws. Put the case

back together by

matching the

top edges of

the front case

16 17

18 19
