ACC SmarTouch Digital series Manuel utilisateur
SMARTOUCH DIGITAL
Series
1000 & 2000
USER
&
PROGRAMMING
MANUAL
701 W. Foothill Blvd Azusa CA 91702
(626) 969 - 9655 Fax (626) 334 - 4809
SmarTouch Digital controls are microprocessor based
electronic spa control systems and as such are
susceptibletostaticdischarge andhigh levelsof humidity.
To prevent premature control failure do not hose down,
flood or allow water to enter the control box enclosure.
CAUTION
High voltage levels exist inside the control box, they can
cause injury and even electrocution.
Only certified electricians or trained servicemen
shouldhaveaccesstothecomponentsinsidethebox.
There are no user serviceable parts inside the box. All
programming is done at the spa side control panel without
the need to access the inside of the box. If for some
reason the control system needs to be serviced, please
contactAppliedComputerControlsforproperprocedures.
Model # _________________ Serial # __________________
Software Rev # _______ Purch Date _____ / _____ /_______
Device 120V 240V 1Sp 2Sp 12V Installed
Primary Pump
Circulating Pump
Second Pump
Third Pump
Air Blower
Spa Light
Fiber Optic Light
Fiber Optic Wheel
Spa Mister
Page 3
TABLE OF CONTENTS
INTRODUCTION 4
IN A HURRY 5
Setting Temperature 5
The SET Key 5
Time Of Day TOD 6
Setting TOD 6
THE CONTROL PANEL 7
DEVICE CONTROL GROUP 7
Primary Water Pump 7
Air Blower 8
Auxiliary Pump(s) 8
Spa Light 8
Summary of Device Functions 9
STATUS CONTROL GROUP 10
The TEMP key 10
The TIME key 11
The SET key 11
PROGRAMMING THE SC-1000 & SC-2000 12
Parameter Programming 12
Programming Example 13
PROGRAMMING SYSTEM OPTIONS 17
User Options 17
Protected Options 19
Diagnostic Values 20
ERROR MESSAGES 21
CoLD, OH, LHoH 21
SEoP,SESH,PSoC,PSoL,PSoH 22
ToE - Time out error 22
ELECTRICAL COONECTION INSTRUCTIONS 23
bRANCH CIRCUIT BREAKER REQUIREMENTS 24
Page 4
INTRODUCTION
Thank you for buying a spa equipped with a SmarTouch
Digital control systems. Many years of experience went into
the design of this family of controls. You can be assured your
spa control system is the most advanced, it is highly reliable
and will serve you for many years to come.
The control system has been designed with the you the user
in mind. It is very easy to operate and requires a minimal effort
on your part. You may use it just as it comes to you and
without any programming. Yet you have the option of getting
deeply involved in the inner workings of the control if you so
choose. You can custom tailor it to fit your needs.
Please take the time to read at least the first section (next
page) “IN A HURRY - READ THIS” portion of the manual
before starting to use your spa for the first time. You can
familiarize yourself with the rest of the manual at your leisure.
This manual will also serve as a reference if you choose to
modify the operation of your spa.
SAVE THIS MANUAL.
Make it available for other spa users.
You should also have a spa user’s manual which explains
how to care for your spa. Please read and follow all
instructions in your spa user’s manual. Maintaining the proper
levels of pH and the sanitizer will extend the life of your spa
equipment. Improper chemical levels in the spa are sure to
cause premature heater failure as well as failure of other
components in the system. Failures caused by chemical
imbalance are not covered by warranty.
IN A HURRY - READ THIS
For those who don’t like to read manuals or would like to read the
manual later, please read at least the following section.
SmarTouch Digital comes to you with a universal set
of default settings. If you choose to keep these
settings, then you only need to remember 2 things :
how to set the spa temperature and to press the SET
key whenever you are done using the spa.
Setting Temperature
♦Pressand hold the TEMP key for 2 seconds. Release all keys
The display will flash the current selected temperature.
♦Using the TEMP and TIME keys (UP and DOWN arrows)
scroll to the desired temperature.
♦Press the SET key to lock in the new selection
The SET Key
After using the spa, press the SET key to tell the microcontroller you
are done using the spa. It will then take over the spa’s management
including the different filtration cycles, heat maintenance, economy
modes and protection against freezing.
Upon entering this mode the FILTER light is turned on and a post use
filtration cycle is executed - that is when the spa needs filtration the
most. The default system setting includes a 3 hour economy mode,
the pump will come on at most once every 3 hours to sample water
temperature and heat if necessary. The controller remembers when
you have used the spa and in anticipation of your next usage will
perform a 3 hour Auto Filtration cycle before your next spa use.
SmarTouch Digital Series 1000 and 2000 is a family of intelligent, spa
control systems. These systems are rich with features and can be
extensively programmed to fit just about any need. The rest of this
manual will explain the function of each of the keys on the control
panel, how to change programmed settings and what each setting
does. It will also explain all the error messages that you may
encounter, and their significance and way to correct them.
Page 5
Time Of Day (TOD)
SmarTouch Digital maintains a 12 hour AM / PM internal real time
clock TOD (Time Of Day). The clock based on the line frequency.
There is no battery backup and whenever the power is turned off,
TOD is no longer correct. It defaults to 12:00 AM whenever the power
is turned on.
Setting TOD is only necessary if you are going to program the filtration
and silence cycles. If you use the factory default settings then you do
not need to set TOD.
If you set TOD then SmarTouch will display time every first 10
seconds of each minute. If TOD has not been set then it will not be
displayed.
Setting TOD
1. Press and hold the TIME key for 2 seconds. Current TOD will
be displayed with the hour portion flashing.
2. Release the TIME key.
3. Using the TEMP and TIME keys scroll up and down to the
desired hour. - Notice the AM / PM Led.
4. When the correct hour and AM / PM are displayed press the
SET key to lock in the new hour.
5. The display will now flash the minutes portion of current TOD.
6. Using TIME and TEMP scroll to the desired minutes.
7. When the correct minutes are displayed press the SET key to
lock in the time of day (hours and minutes)
Note : TOD is the only parameter in SmarTouch Digital that is not
preserved on power down. On power up it will default to 12:00 AM, all
other parameters are restored to the their last setting.
Every time the controller is powered up, the microprocessor
automatically measures and determines whether the line frequency is
50 or 60 cycles in order to maintain the correct TOD.
Page 6
THE CONTROL PANEL
The control panel is normally installed on the lip of the spa for easy
and convenient access. Within the panel housing is a 4 digit LED
display used to communicate to the user spa temperature, TOD,
elapsed user time, programming, status - diagnostic and error codes
and messages. There are 2 different size panels. They are
interchangeable. the 2000 Series panel can have up to 7 keys, the
1000 Series panel will have at most 6 keys. These are membrane type
switches which when depressed generate a signal that the
microprocessor will interpret and act upon. The switches are labeled
and have specific functions. They are divided into 2 groups:
Device Control Group Pump(s), Air Blower & Spa Light.
Status Control Group: Up & Down Keys & the Set Key.
Note: if any of the keys is pressed and held closed for longer
than 20 seconds, that key will be disabled and becomes non
functional. After releasing the key, it will be reactivated after
20 seconds. This is to prevent a collapsed or defective key
from locking up the system.
DEVICE CONTROL KEYS
There are up to 4 device key, JETS, AIR, AUX & LITE. Your spa will
have at least one water pump. Optionally your spa may have an air
blower, a second and/or third pump and a spa light. It may also have a
mister or a fiber optic light setup. If your spa does not have a specific
device please disregard the function of that device.
Primary Water Pump
Each spa should have at least one primary water pump which is usually
a dual speed pump. The low speed is used to filter the spa. Also while
the spa is being heated or there is an error condition, the low speed
circulates the water and you will not be able to turn it off.
Page 7
The JETS key (switch) on the control panel is a 3 position switch :
Low Pump, High Pump, Off. Each time the key is pressed, the next
function is executed. If your primary pump is a single speed pump
then only the high pump will be activated. 2 LED indicators, LO & HI
inform you which speed is on.
Note : if your spa is equipped with a circulating pump it will
be used for filtration and heating instead of the low speed
pump.
Air Blower.
If your spa is equipped with an air blower (bubbler), it is activated by
the AIR key. This is an ON/OFF key. An LED will indicate when the air
blower is on.
Auxiliary Pump(s).
Your spa may be equipped with 1 or 2 more pumps. If you have a
second pump, it could be a single speed or a dual speed.
If you have a third pump then both the second and third pumps must be
single speed. The function of the AUX key changes with the number
and type of auxiliary pumps used. Please consult with the table on the
following page for the proper sequence of activation.
Spa Light
The LITE key can also be a multifunction key. In its simplest
configuration, the LITE key is a simple on / off switch. It turns the spa
light and the accessory, if one is attached, on / off together at the same
time. Alternatively the LITE key may be programmed as a 3 function
key. Pressing it once will turn the spa light on. Pressing it a second time
will turn on the attached accessory, while the light is still on. Press it a
third time and both spa light and accessory will go off.
The table on the following page summarizes all the possible device key
combinations. Please note that your spa may not necessarily have all
these devices attached.
Page 8
SUMMARY OF FUNCTIONS FOR EACH DEVICE
Key Device 1 2 3 4
Single speed pump ON OFF
JETS Dual speed pump LOW HIGH OFF
Dual speed with Circ pump LOW HIGH OFF
Circ pump is independent
AIR Single speed air blower ON OFF
One single Speed pump ON OFF
AUX One dual speed pump LOW HIGH OFF
Two Single speed pumps P1 P1&2 P2 ALL OFF
Spa light ON OFF
LITE Spa Light & Accessory Both Both
ON OFF
Spa Light & Accessory Lite Both Both
3 Function ON ON OFF
Table 1 - Device keys summary of functions
The four device keys, JETS, AIR, AUX and LITE are exclusive, when
one is pressed, no other key may be pressed simultaneously. You
must release the pressed key before you may press another key. Also
these keys do not repeat.
If you press and hold a key for more than 20 seconds that key will be
considered defective (collapsed) and will be deactivated and ignored
by the system. When released the key will stay inactive for 20
seconds before it is recognized and activated.
STATUS CONTROL KEYS
The keys in this group are used to communicate to the controller
system settings and option selection(s). There are 3 keys in this group
and 3 functions that are combinations of these keys:
Key Press Function
TEMP (up arrow) Prog Temp, + or Next
TIME (down arrow) Prog TOD, - or Previous
SET key. Select or Accept , Enter
SET & TEMP Invert display
SET & TIME Parameter programming
TEMP & TIME System programming
Table 2 - Status Control Keys Summary
The TEMP key , which is also the UP ARROW key, is a repeat key if
held down. Think of this key as “+ or next”. Use it to :
♦Press and hold for 2 seconds then release it to start desired
temperature selection.
♦During temperature setting press TEMP to increase selected
temperature.
♦When doing system programming press TEMP to scroll to the
next message.
♦After message selection, the system displays the associated
value, press TEMP to increase that value.
Note: When the display is inverted, you will be able to read
the display from inside the spa ; the keys will retain their
functions and will not be inverted. The UP ARROW will still
function as the UP ARROW even though when you look at it
from within the spa it appears to be the DOWN ARROW.
The same also applies to the rest of the keys.
Page 10
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels ACC Système de contrôle
