ABB L240 Series Mode d’emploi

Security Technology

KNX-Intrusion Alarm System L240

Installation, Commissioning, Operation

Contents

Contents Page

1Intrusion Alarm System L240 7

1.1 General description 7

1.2 Degree of expansion 7

1.3 System components 8

1.4 System overview 9

2Installation Instructions 10

2.1 General explanations 10

2.2 Wiring 10

2.3 Required components to an entry (door) 11

3Intrusion Alarm Panel L240 12

3.1 General 12

3.2 Installation 13

3.3 Connections and technical data 14

3.4 Description of the inputs and outputs 16

4Commissioning 18

4.1 Basic expansion 18

4.2 Direct connection of the inputs and outputs 18

4.3 External connection of the inputs and outputs 19

4.4 Expansion of the panel with bus nodes 20

5Keypad L240/PT 22

5.1 General description 22

5.2 Connection 23

6Operation with Keypad L240/PT 24

6.1 General information 24

6.2 Operation without PIN code (access level 0) 26

6.2.1 Button 1 “Int Set” 26

6.2.2 Button 2 “Cct Off” 26

6.2.3 Button 3 “Disp Cct Off” 27

6.2.4 Button 4 “Input PIN” 27

6.2.5 Button 5 “Disp Cct Fault” 27

6.3 Operation with PIN code (access level 1) 28

6.3.1 Menu 01 “Int Set” 29

6.3.2 Menu 02 “Cct Off” 29

6.3.3 Menu 03 “Disp Cct Off” 29

6.3.4 Menu 04 “Change PIN” 29

6.3.5 Menu 05 “Disp Cct Fault” 30

6.3.6 Menu 06 “Test” 30

6.3.7 Menu 07 “Alarm Counter” 30

6.3.8 Menu 08 “Log” 31

6.3.9 Menu 09 “Ext Set” 33

6.3.10 Menu 10 “Time/Date” 33

6.3.11 Menu 11 “Log Eng On” 34

6.3.12 Menu 12 “Tamp.Reset” 34

Contents

7Operation by the Engineer 35

7.1 Functions 35

7.1.1 Menu 1 “Time/Date” 36

7.1.2 Menu 2 “Tamp.Reset” 36

7.1.3 Menu 3 “Test” 36

7.1.4 Menu 04 “Change PIN” 38

7.1.5 Menu 5 “Printer” 39

7.1.6 Menu 6 “Printer” 40

7.1.7 Menu 7 “Remote” 41

7.1.8 Menu 8 “Edit” 43

7.1.9 Menu 9 “Cct Off” 43

8Configuration and programming 44

8.1 Overview 44

8.1.1 Menu 01 “System Size” 46

8.1.2 Menu 02 “Area Opts” 47

8.1.3 Menu 03 “Circuits” 50

8.1.4 Menu 04 “Relay” 58

8.1.5 Menu 05 “Alarm Times” 59

8.1.6 Menu 06 “Keypads” 60

8.1.7 Menu 07 “Concs” 60

8.1.8 Menu 08 “User Auth” 61

8.1.9 Menu 09 “Text” 61

8.1.10 Menu 10 “L240/B/BS” 62

8.1.11 Menu 11 “XS/S1.1 KNX” 62

8.1.12 Menu 13 “2-Conc Tamper” 63

8.1.13 Menu 15 “Defaults” 63

8.1.14 Menu 16 “XIB-Detectors” 64

9Management of the chip key/keypad

code 65

9.1 General 65

9.2 Operating menu 66

9.2.1 Menu 06 – Add 66

9.2.2 Menu 05 – Text 67

9.2.3 Menu 01 – Edit 67

9.2.4 Menu 02 – Show (Key/Code) 68

9.2.5 Menu 02 – Show (L240/BS) 68

9.2.6 Menu 04 – Delete 69

9.2.7 Menu 03 – Identify 70

9.2.8 Exiting management 70

10 2-Detector Circuit Module L240/MG 2 71

10.1 General notes 71

10.2 Circuit diagram 71

10.3 Description of the inputs and outputs 72

10.4 Addressing 72

10.5 Commissioning 73

10.6 Address table L240/MG 2 and L840/MG 4 75

10.7 Technical data 75

Contents

11 4-Detector circuit module L840/MG 4 76

11.1 General 76

11.2 Circuit diagram 76

11.3 Description of the inputs and outputs 76

11.4 DIP switch/jumper settings: 77

11.5 Addressing 77

11.6 Commissioning 77

12 SafeKey Evaluation Module L240/BS 79

12.1 General 79

12.2 Wiring 80

12.2.1 Magnetic reed contact 80

12.2.2 Lock bolt switching contact 80

12.2.3 Bolt lock 81

12.2.4 XIB security bus 81

12.2.5 Cover tamper contact 82

12.2.6 Wall reader 82

12.2.7 Transistor outputs 83

12.3 Description of the inputs and outputs 84

12.4 LEDs 85

12.4.1 Light emitting diode “LED1” (red) 85

12.4.2 Light emitting diode “LED2” (green) 85

12.4.3 Light emitting diode “LED3” (red) 85

12.5 DIP switch blocks 85

12.5.1 Function switch 1 86

12.5.2 Function switch 2 86

12.5.3 Address switch 87

12.6 Commissioning 88

12.7 Operation 91

12.7.1 SET circuit 92

12.7.2 Access and UNSET switching 92

12.7.3 Access 94

12.7.4 Personal attack 94

13 Bus Motion Detector 95

13.1 General notes 95

13.2 Circuit diagram 95

13.3 Description of the LEDs 96

13.4 Commissioning and addressing 96

13.5 Teaching in the first detector 97

13.5.1 Teaching-in further detectors 98

13.6 Parameter settings 99

13.7 Walk test 100

13.8 Delete 100

13.9 Faults 101

13.10 VdS operation 101

Contents

14 Interface Module L208/V.24 102

14.1 General 102

14.2 Circuit diagram 102

14.3 Login 103

14.4 Serial connection 103

14.5 Setting the interface parameters 103

15 LAN Interface L240/IP 104

15.1 General 104

15.2 Circuit diagram 105

15.3 Commissioning 105

15.4 Setting the IP address of the PC 105

15.5 Setting the network parameters on the L240 106

Appendix

Overview User / Programming Menu L240 A

Programming Example B

System Protocol C

General Description

1 Intrusion Alarm System L240

1.1 General

description The Intrusion Alarm Panel L240 is a compact emergency signalling centre,

which uses the same base device, and depending on the connected bus

nodes complies with the guidelines of the VdS for class A, B or C, as well as

the standards DIN/VDE 0100, 0800 and 0833. The unit is also CE compliant.

The panel is a black-box device without installed keypads and displays;

operation is generally undertaken using seven separate keypads.

1.2 Degree of expansion In its basic configuration, the panel features 10 inputs, which are suitable

both for the connection of sensors (detector groups) as well as for a setting

device.

In order to expand the panel with bus devices, an LCD Keypad L240/PT that

can also be used for programming the panel is absolutely necessary.

As an option, the panel can be expanded by up to 4 setting areas.The

switching devices are then connected to bus modules: Up to 8 Evaluation

Modules L240/BS can be used for the SafeKey components, whereby both

the key management as well as the access memory can be handled via the

panel.

On the detector circuit side, the panel can be expanded via bus modules: Up

to 40 motion detectors, up to 24 Detector Circuit Modules L840/MG4 or

L240/MG2 (can be combined) (1).

The enclosure offers space for the installation of 2 batteries 12 V/7 Ah and

the telephone dialling devices TSQ8, TS9S/L2 (2) or TS9/ISDN-L2 (2).

The panel is delivered with basic programming features that can be used to

immediately commission the device.

Should individual functions be reprogrammed or further components

connected and enabled, this can be undertaken via a keypad that has to be

permanently connected or just connected for the duration of programming.

Alternatively, the programming of the panel can also be undertaken with the

PC and the programming software WIN-PC.

(1) Regarding the number of Detector Circuit Modules L240/MG2 or L840/MG4 and bus

modules, it is important to observe that the total number of detector circuits does not exceed

80 (incl. the 10 circuits for the panel).

(2) For Germany only

General Description

1.3 System components Product description Short

designation

Panel

Intrusion Alarm Panel L240

System components:

LCD keypad L240/PT

Evaluation module SafeKey, PCB L240/BS

Detector circuit module, 2 circuits, for 60 mm flush

mounted switch box L240/MG2

Detector circuit module, universal, 4 detector circuits,

PCB L840/MG4

Serial interface module (incl. programming software) L208/V.24

LAN interface L240/IP

Batteries:

Battery, 12 V, 7.2 Ah (max. 2 per panel) SAK7

Installation accessories:

Flush mounting enclosure for modules L240/BS,

L840/MG4 SAD/GUP

Wall box for SAD/GUP SAD/ED

Surface mounting enclosure for modules L240/BS,

L840/MG4 SAD/GAP

General Description

1.4 System overview

L240/PT Keypad

Operation, programming and display

of all functions in a range. In total 7

keypads (addresses 1-7) are

permissible. At least one keypad is

required per area..

L240/MG2

2 circuits with termination resistor.

Suitable for glass break and magnetic

contacts (SPGS/W, MRS/W, SWM4).

Installation in 60 mm FM socket.

Max. 24 devices (addresses 1-24).

MRS/W

Magnetic reed

contact

SPG S/W

Glass break

sensor

SWM4

Water sensor

SGL

Gas sensor

ORM1003

Optiical smoke

detector

E1000BREL

12NL

Socket for

smoke detector

ND/W

Panic button

L240/IR-XB

Motion Detector

Module

SSF/GB

External siren

SSS

Internal siren

Intrusion Alarm Panel L240

Power supply for 2 * 7.2 Ah,

10 preprogrammed circuits,

2 bus terminations,

8 transistor outputs,

3 relays (alarm, set, walk test)

lerting and comm signals,

4 areas

Note: In total 80 circuits may not be exceeded.

Example: intrusion alarm panel 10 ccts, 10*L240/MG2

(20 ccts), 5*L240/IR-XB (5 ccts): total 35.

ESPE

Bolt lock

WRK/W

Bolt switching

contact

MRS/W

Magentic reed

contact

WEL/A

SafeKey wall

reader

WELT

SafeKey wall

reader

For connection of one PC with software

WIN-PC. Max. 1 module optional

L208/V.24 or L240/IP can be connected

L208/V.24

Serial interface

L240/IP

LAN interface

L240/BS

SafeKey evaluation module,

for connection of 1 complete

door with SafeKey setting

cirtcuit. User and key

administration via central

keypad. Max. 8 pieces

(address 1-8).

(optional)

XIB BUS

10 circuits

V.24 / LAN

Installation Instructions

2 Installation Instructions

2.1 General explanations

The installation locations of the panel and keypads must comply with the

guidelines of the VdS or the VDE 0833. They should be:

• within the security area and monitoring area of a detector,

• on the interior wall of the building,

• not visible to third-parties.

As there are no keypads or displays on the panel, they can be installed in

concealed locations (e.g. in the cellar or in a wall cabinet).

The keypad(s) should be easily accessible for the operator.

2.2 Wiring The following cable types must be used for wiring the system:

Low-voltage 230 V AC: NYM 3 x 1.5 mm²

Extra-low voltage: I-Y(St)Y n x 2 x 0.8 mm

Components for connection Required twin-cores

XIB bus device:

Keypads L240/PT

Interface Module L208/V.24

Evaluation Module L240/BS

Detector Circuit Modules /MG2,

L840/MG4

BUS Motion Detector

Magnetic contacts,

Passive glass break sensors:

Combination Signalling Devices

SSF/GB:

The sheath wire of the shield (cable of the detector group,

XIB bus line, ...) must be consistently looped through and attached to the

earthing stud in the panel on the left beside the cable entry.

The shield may not be earthed at any other point on the cable network

(earth loops).

The sequence in which the bus slaves are connected is irrelevant; no spur

lines may be used. Max. length of the bus cable: 800 m.

For connection optimisation, the use of a main distribution board (e.g. MV40

or MV80) is recommended.

All electrical work may only be performed when the system is not live.

The installation and commissioning may only be carried out by

electrical specialists.

Autres manuels pour L240 Series

Table des matières

Autres manuels ABB Système de sécurité

ABB

ABB N9611.02 Manuel d'exploitation et d'entretien

ABB

ABB 83327-500 Manuel utilisateur

ABB

ABB M22411-W Manuel utilisateur

ABB

ABB Welcome IP H8131.P. Series Manuel utilisateur

ABB

ABB Welcome M2303 Manuel utilisateur

ABB

ABB Welcome M2303 Manuel utilisateur

ABB

ABB 83220 AP-5 series Manuel utilisateur

ABB

ABB SACO 16D1 Manuel utilisateur

ABB

ABB M2231 SERIES Manuel utilisateur

ABB

ABB Arc Guard System TVOC-2 Manuel du produit

ABB

ABB SAS-W1.1E Guide de l'utilisateur

ABB

ABB L240 Series Manuel utilisateur

ABB

ABB M2131xPx-A series Manuel utilisateur

ABB

ABB FIM 1300 Series Manuel utilisateur

ABB

ABB GE GEH4576 Manuel utilisateur

ABB

ABB Welcome M22344-W Manuel utilisateur

ABB

ABB Welcome M21311P1-A Guide de configuration

ABB

ABB ZMT Zirconia Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
