WIRELESS
PREMIUM WEIGHT SCALE
UC-352BLE
Instruction Manual
Contents
Preface E-2
General Information E-2
Safety Information E-3
Wireless Communication Function E-5
Parts Identication E-7
Installing (or replacing) the batteries E-8
Connecting to a mobile device (Pairing) E-9
Setting the Units E-10
Taking a Measurement E-11
Other Functions E-12
Troubleshooting E-14
Maintaining the Scale E-15
Specications E-16
Warranty E-18
E-2
Preface
Congratulations on purchasing a state-of-the-art A&D medical connected scale,
one of the most advanced health scales available today. Designed for ease of use
and accuracy, this device will facilitate your daily weight management regimen. We
recommend that you read through this manual carefully before using the device for
the rst time.
General Information
This scale is intended to be used on a at, hard surface. If using on a soft surface,
such as carpet, it may cause inaccurate measurements.
E-3
Safety Information
The following items contain information to prevent the risk of harm or injury to
yourself or other people. Please read these items carefully and be sure to use this
product correctly.
Danger This symbol indicates an immediate danger which could result in
death or serious injury.
Warning This symbol indicates the possibility of death or serious injury.
Caution This symbol indicates the possibility of physical injury or damage
to property.
Precautions For Use
Warning
• Do not rely on self-diagnosis when attempting weight loss or therpeutic
exercise. Follow the instructions of a physician or specialist.
• Do not step on the edges of the scale or jump on the scale. It may result in
a fall, causing injury.The impact may also cause damage to the scale.
• Do not use the scale on an uneven surface. It may damage the scale. Also,
the scale cannot measure accurately.
• Do not use the scale on a slippery surface or step on the scale with wet
feet. It may result in slipping and injury. Also, the scale cannot measure
accurately.
Caution
• Do not place the scale where it is exposed to excess water or humidity such
as a bathroom, where it is exposed to direct sunlight, where it is exposed
directly to the air outlet of an air conditioning unit, or near re. It may cause
the scale to malfunction.
• This scale should only be used for weighing body weight.
• This scale is precision measuring device. Do not drop the scale, or expose
it to vibration or powerful shocks.
E-4
Safety Information
Caution
• Do not disassemble, repair or modify the scale. It may cause malfunction or
injury.
• Person with disabilityies should be assisted by a caregiver when using this
scale. Failure to do so may result in a fall, causing injury.
• When installing the batteries, be sure that the + (positive) and - (negative)
terminals are correct. Installing incorrectly may cause overheating, battery
uid leaks or rupturing of the batteries, resulting in damage to the scale or
injury.
• This scale is designed for personal use.
• Store this scale out of the reach of small children.
• Do not store this scale vertically. If for any reason this scale is stored
vertically, be sure not to let the scale fall.
• Do not place any items on this scale during storage.
• If use of this scale is shared with a person who has an infectious disease
such as a skin disease on the feet, etc., clean the scale before use. (For
details on cleaning the scale, see “Maintaining the Scale (P.14)”.)
• To accurately measure your weight, use the scale on a at, hard oor. Do
not use on a carpet or other soft surface.
E-5
Wireless Communication Function
This scale uses Bluetooth®wireless connectivity to communicate with a receiver
device. At the end of measurement, the measurement data is sent from this scale
to the receiver device.
Bluetooth®is communication technology that enables devices to communicate
wirelessly. The Bluetooth®word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by A&D is under license. Other
trademarks and trade names are those of their respective owners.
This device complies with Part 15 of FCC rules and contains the FCC ID
VPYLBVZ. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operations.
This device complies with Industry Canada licence-exempt RSS standard(s) and
contains IC 772C-LBVZ. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the
device.
Receiver Device
Use with a device such as mobile device (tablet or smartphone) with an
application to enable Bluetooth®communication. Download and install the app
from Apple or Google.
Precautions For Wireless Functions
Warning
• Do not use in places where wireless communication is prohibited, such
as on airplanes or in hospitals. This scale may have an adverse eect on
electronic devices or medical electrical equipment.
E-6
Caution
• If the communication function of this scale is used near a wireless device
that communicates in the 2.4 GHz range, the processing speed of both
devices may decrease. Do not use near a microwave oven where a
magnetic eld, static electricity or radio wave interference may occur.
(The signal may not reach due to environmental reasons.)
Note: A&D cannot accept any reponsibility for any losses incurred such as operating malfunctions or loss of
data that may occur through the use of this scale. This scale is not guaranteed to connect to all Bluetooth®
compatible devices.
Wireless Communication Function
E-7
Components
• Digital Weight Scale
• 4 AAA Batteries
• Instruction Manual
• Quick Start Guide
Scale
Display
Display Symbols
Symbol Name Description
Ready/Stable symbol This symbol is displayed when the
measurement display is stable
Batteries are depleted. Replace all four batteries
Low battery indicator If this symbol is displayed, replace
all four batteries with new ones
Bluetooth®Communication Symbol
Battery compartment
Feet
SMART
Display Set switch
Battery indicator
Stable Symbol
Bluetooth
C
ommunication
S
ymbol
Unit
E-8
Installing (or replacing) the batteries
1. Remove the battery cover on the back of the device.
2. Insert the 4 AAA batteries with the postive (+) and
negative (-) terminals properly aligned with the
corresponding symbols in the battery compartment.
3. Close the battery cover.
Caution
• Install each battery with the positive (+) and negative (-) terminals properly
aligned with the corresponding symbols in the battery compartment.
• Improper installation of the batteries may cause battery leakage.
• Replace all four batteries with new ones, when the symbol is
displayed. Do not mix new and used batteries. It may cause damage to the
scale or shorten the battery life.
• Be sure to use AAA size alkaline batteries. Do not use any other type of
battery.
• Never use rechargeable batteries with this scale.
• The battery life is dependant upon the environmental temperature, battery
type and usage.
• The batteries provided with the device are for testing the scale performance
and may have a limited life.
• Remove the batteries from the battery compartment, when the scale is not
to be used for a long time. Storing the scale with the batteries installed may
result in battery uid leaking from the batteries, causing damage to the
scale. The supplied batteries are for checking operation of the scale and
may have a short lifespan.
E-9
Connecting to a mobile device (Pairing)
This scale needs to be registered with a receiver in order to use Bluetooth®
communication with the receiver. The process of registering this scale with a
receiver is known as pairing. When pairing is completed, measurement data from
this scale is automatically sent to the paired device each time a measurement is
made when the receiver is in the state in which it can receive transmissions.
Consult the receiver instruction manual and set it to enable pairing. If the receiver
has a “pairing wizard”, use the wizard to complete pairing. Place the receiver and
this scale as close as possible to carry out pairing.
1. Install four AAA size alkaline batteries into this scale.
• For details, see “Installing (or replacing) the batteries” on page E-8.
2. Conrm that the scale is turned o, and press and hold
the set switch.
• When the set switch is continuously pressed, “Pr” is
displayed.
3. Release the set switch when “Pr” is displayed.
• “ ” ashes.
• This scale is discoverable by the receiver.
• Pairing can be skipped press the set switch when
“Pr” is displayed.
4. Start pairing on the receiver.
• Follow the pairing instructions for the receiver to
search for, select and pair with this scale.
5. Conrm that “End” is displayed.
Once paired, changing batteries should not require
re-pairing.
Beep
Beep beep
