A&D UC-350BLE Manuel utilisateur

E-1

Instruction Manual

Safety Information E-2

Overview E-4

Initial Start-Up E-6

Start Measuring E-9

Manage Your Health E-11

Troubleshooting E-12

Specications E-14

Maintenance E-15

Warranty E-15

UC-350BLE

DELUXE CONNECTED

WEIGHT SCALE

Thank you very much for selecting the A&D Medical Deluxe Connected Weight

Scale UC-350BLE. Please do read the user manual carefully and thoroughly so

as to ensure the safe usage of this product, and keep the manual well for further

reference in case you have problems.

E-2

Safety Information

Symbol Meaning

The warning signs and symbols are essential to ensure your correct and safe use of

this product and protect you and others from injury. Please kindly nd the meanings

of the warning signs and symbols, which you may encounter in the label and user

manual, as follows:

Symbol Description

Manufacturer

Direct Current

Serial Number

Complies with EU Requirements

Environment Protection – Waste electrical products should not be

disposed of with household waste. Please recycle where facilities

exist. Check with your local authority or retailer for recycling advice

E-3

Your Scale and Its Environment

To ensure your safety as well as the service life of your scale, please avoid

using the scale under the following circumstances:

• Slippery oor such as tile oor

• Jumping onto the platform immediately after bath or with wet hands

• Near a cell phone or microwave oven

Avoid storage in the following locations:

• Where there is water

• Where the device may be exposed to extreme temperatures, humidity, moisture,

direct sunlight, dust, or salt air

• Where there is risk of shock or drop

• Where you store chemicals or full of corrosive gases

• Where in reach of the infants or children

Efcient Use of Your Scale

To ensure the accuracy of measurement, please follow below instructions

when you start measurement.

• Place the scale on a at, hard surface. Soft surface such as carpet will affect the

performance of the scale.

• Avoid measurement immediately after strenuous exercise, sauna or bath,

drinking, and dinning.

• Always start measurement in the same time slot and on the same scale located

on the same at, hard surface.

E-4

Overview

Device Components

Includes:

• Glass Body Scale GBS-1270-B

• 4 x AAA Batteries (1.5V each)

• User Manual

LCD Display

LCD display

DOWN Button

SET Button

UP Button

UNIT and activation

Button Sensor

Battery Compartment

Pound

Kilogram

Successful Bluetooth Connection

Data transmitting/pending to transmit

to wireless wellness system

Low Battery

E-5

Initial Start-Up

Insert the Batteries

• Open the battery door in the back of the scale.

• Insert the batteries (4 x 1.5V AAA) into the battery

compartment according to the polarity indications

marked inside the compartment.

* The digits “ ” will be shown on the LCD.

• Close the battery door and wait until the digits “ ”

are shown on the LCD.

CAUTION

• When the symbol appears, the device will power off. Then you shall

replace with a new set of batteries. Please replace all four batteries at the

same time. Do NOT mix the old batteries with the new one.

• Worn batteries are hazardous waste. Do NOT dispose of them together with

the household garbage. Please refer to the local ordinances and recycling

instructions regarding disposal of the worn batteries and scrapped device.

• If you do not intend to use this unit for a prolonged period of time, it is

advisable to remove the batteries before storing.

E-6

Pair-Up

With the advanced Bluetooth 4.0 technology applied, the mobile or portable

equipments, which are equipped with Bluetooth function in line with BLE Technical

Specications established by global organization Bluetooth SIG, are capable to

receive your personal health data.

• Turn on Bluetooth and the App. Make sure both are ON when pair-up is

proceeding.

• Press and hold “UNIT” button in the back of the scale to start pair-up.

Symbol and symbol will

be shown on the LCD alternatively,

indicating pair-up is proceeding.

If SUCCEED, symbol will be

shown on the LCD.

If FAIL, symbol “E1” will be shown

on the LCD.

E-7

Select Measurement Unit

With batteries correctly installed, press “UNIT” button in the back of the scale to

select measurement unit. The default measurement unit is “lb”. You may press

“UNIT” button to choose among kilogram and pound.

CAUTION

• Please put the scale on at hard ground when nishing the unit selection.

Wait for a few seconds, then you may start measuring according to the

measuring procedure below. If there is not any operation in weighing mode,

the scale will turn off in a few seconds.

Initialising Your Scale

1. Press the platform centre and remove your foot.

2. “0.0” will be displayed.

3. The scale will switch off and is now ready for use. This initialisation process must

be repeated if the scale is moved. At all other times step straight on the scale.

E-8

Start Measuring

Weight Only Operation

Your TRANSTEK Body Scale will operate as a conventional weight – reading

scale. No special programming steps are required.

Once the scale is initialized, as previously described, you may simply step on the

scale to measure your current weight. For only weight reading.

1. Position the scale on a at, hard surface. Carpeted or uneven oors may affect

accuracy.

2. Step onto the scale platform and remain still while the scale computes your

weight.

3. Step off and the scale will display your weight value.

4. The scale will automatically turn off after a few seconds.

Note: The weight value won’t be saved in the scale, and won’t be transmitted to the APP.

Setting the User ID and Start Measuring

Assigning User ID

• With batteries correctly installed, press “SET” button to enter setting. Or when

the LCD displays 0.0, press and hold “SET” button for about 3s to enter setting

mode.

• As pictured below,“P1” blinks. The operator may press the function button or

 to select User ID among P1 to P8.

• Press “SET” button to conrm User ID.

E-9

• After setting the personal information, step on the platform when the scale

displays “0.0”.

• Stand still and keep full contact with the scale until the unit stop ashing, then

the weight is locked.

• When your scale is successfully paired with your smartphone and the Bluetooth

is ON, it will process data transmission automatically. (Please refer to Data

Transmission for more details.)

E-10

Manage Your Health

Data Transmission

• Once the Body Scale GBS-1270-B is successfully

paired-up with your smartphone, please open the

“TransHealth” App and turn on your Bluetooth. Keep

smartphone and scale in transmission distance.

Step on the scale and take a measurement. Once

the measurement is nished the data is automatically

transferred to the app.

• The symbol will disappear after

successful data transmission,

and you may check your personal

health data stored in your

smartphone.

• If the data transmission fails,

the symbol will remain. The

pending measurement data will

be temporarily kept in the scale

and transmitted to your smartphone

when next measurement is

complete.

Note: Whether the data transmission is successful, the device will shut down automatically 3 seconds later.

Data transmitting

Data ready to transmit to

the App:

• If SUCCEED, the symbol

disappears;

• If FAIL, the symbol remains.
